SPECIFICATIONS
Model 2705
Arbor hole 15.88 mm (5/8")
Blade diameter 255 mm (10")
Riving knife-related specs. Blade body thickness 1.8 mm (1/16")
Riving knife thickness 2.3 mm (3/32")
Blade diameter Max.255 mm (10") - Min.250 mm (9-7/8")
Kerf width 2.6 mm (3/32")
Max. cutting capacities 90° 91 mm (3-9/16")
45° 63 mm (2-1/2")
Maximum dado capacity 21 mm (13/16")
No load speed (RPM) 4,800/min.
Table size (L x W) 567 mm x (753 mm - 1,066 mm)
22-1/4" x (29-5/8" - 42")
Dimensions (L x W x H) with table not extended 678 mm x 766 mm x 344 mm
(26-3/4" x 30-1/4" x 13-1/2")
Net weight 29 kg (64 lbs)
• Due to our continuing programme of research and development, the specications herein are subject to change
without notice.
• Specications may differ from country to country.
For Your Own Safety Read
Instruction Manual
Before Operating Tool
Save it for future reference
GENERAL SAFETY
PRECAUTIONS
(For All Tools)
1. KNOW YOUR POWER TOOL. Read the owner's
manual carefully. Learn the tool's applications
and limitations, as well as the specic poten-
tial hazards peculiar to it.
2.
KEEP GUARDS IN PLACE and in working order.
3. REMOVE ADJUSTING KEYS AND WRENCHES.
Form habit of checking to see that keys and
adjusting wrenches are removed from tool
before turning it on.
4. KEEP WORK AREA CLEAN. Cluttered areas
and benches invite accidents.
5. DO NOT USE IN DANGEROUS ENVIRONMENT.
Do not use power tools in damp or wet loca-
tions, or expose them to rain. Keep work area
well lighted. Do not use tool in presence of
ammable liquids or gases.
6. KEEP CHILDREN AWAY. All visitors should be
kept safe distance from work area.
7. MAKE WORKSHOP KID PROOF with padlocks,
master switches, or by removing starter keys.
8. DO NOT FORCE TOOL. It will do the job better
and safer at the rate for which it was designed.
9. USE RIGHT TOOL. Do not force tool or attach-
ment to do a job for which it was not designed.
10. WEAR PROPER APPAREL. Do not wear loose
clothing, gloves, neckties, rings, bracelets, or
other jewelry which may get caught in moving
parts. Nonslip footwear is recommended. Wear
protective hair covering to contain long hair.
11. ALWAYS USE SAFETY GLASSES. Also use
face or dust mask if cutting operation is dusty.
Everyday eyeglasses only have impact resis-
tant lenses, they are NOT safety glasses.
12. SECURE WORK. Use clamps or a vise to hold
work when practical. It's safer than using your
hand and it frees both hands to operate tool.
13. DO NOT OVERREACH. Keep proper footing
and balance at all times.
14. MAINTAIN TOOLS WITH CARE. Keep tools
sharp and clean for best and safest perfor-
mance. Follow instructions for lubricating and
changing accessories.
15. DISCONNECT TOOLS before servicing; when
changing accessories such as blades, bits,
cutters, and the like.
16. REDUCE THE RISK OF UNINTENTIONAL
STARTING. Make sure switch is in off position
before plugging in.
17. USE RECOMMENDED ACCESSORIES. Consult
the owner's manual for recommended acces-
sories. The use of improper accessories may
cause risk of injury to persons.
18. NEVER STAND ON TOOL. Serious injury could
occur if the tool is tipped or if the cutting tool
is unintentionally contacted.

3ENGLISH
19.
CHECK DAMAGED PARTS. Before further use of
the tool, a guard or other part that is damaged
should be carefully checked to determine that it
will operate properly and perform its intended
function - check for alignment of moving parts,
binding of moving parts, breakage of parts,
mounting, and any other conditions that may
affect its operation. A guard or other part that is
damaged should be properly repaired or replaced.
20. DIRECTION OF FEED. Feed work into a blade or cutter
against the direction of rotation of the blade or cutter only.
21. NEVER LEAVE TOOL RUNNING UNATTENDED.
TURN POWER OFF. Do not leave tool until it
comes to a complete stop.
22. REPLACEMENT PARTS. When servicing, use
only identical replacement parts.
23.
POLARIZED PLUGS. To reduce the risk of electric
shock, this appliance has a polarized plug (one
blade is wider than the other). This plug will t in a
polarized outlet only one way. If the plug does not
t fully in the outlet, reverse the plug. If it still does
not t, contact a qualied electrician to install the
proper outlet. Do not change the plug in any way.
VOLTAGE WARNING: Before connecting the tool
to a power source (receptacle, outlet, etc.) be sure
the voltage supplied is the same as that specied
on the nameplate of the tool. A power source with
voltage greater than that specied for the tool can
result in SERIOUS INJURY to the user- as well as
damage to the appliance. If in doubt, DO NOT PLUG
IN THE APPLIANCE. Using a power source with
voltage less than the nameplate rating is harmful to
the motor.
USE PROPER EXTENSION CORD. Make sure your
extension cord is in good condition. When using an
extension cord, be sure to use one heavy enough to
carry the current your product will draw. An under-
sized cord will cause a drop in line voltage resulting
in loss of power and overheating. Table 1 shows the
correct size to use depending on cord length and
nameplate ampere rating. If in doubt, use the next
heavier gage. The smaller the gage number, the
heavier the cord.
Table 1: Minimum gage for cord
Ampere Rating Volts Total length of cord in feet
More Than Not More Than
120V 25 ft. 50 ft. 100 ft. 150 ft.
AWG
06
6
10
12
10
12
16
18
18
16
14
16 16 14
1416
16
12
14
12
12
Not Recommended
ADDITIONAL SAFETY RULES
DO NOT let comfort or familiarity with product
(gained from repeated use) replace strict adherence
to table saw safety rules. If you use this tool unsafely
or incorrectly, you can suffer serious personal injury.
1. Wear eye protection.
2. Do not use the tool in presence of ammable
liquids or gases.
3. NEVER use the tool with an abrasive cut-off
wheel installed.
4. Check the blade carefully for cracks or damage
before operation. Replace cracked or damaged
blade immediately.
5. Clean the spindle, anges (especially the
installing surface) and hex nut before install-
ing the blade. Poor installation may cause
vibration/wobbling or slippage of the blade.
6. Use saw-blade guard and riving knife/spreader
and antikickback pawls for every operation
for which it can be used, including all through
sawing operations. Always assemble and
install the blade guard following the step by
step instructions outlined in this manual.
Through sawing operations are those in which
the blade cuts completely through the top of
the workpiece as in ripping or cross cutting.
NEVER use the tool with a faulty blade guard
or secure the blade guard with a rope, string,
etc. Any irregular operation of the blade guard
should be corrected immediately.
7.
Immediately raise the riving knife/spreader to the
Spreader position and reattach the guard assem-
bly and side guards, after completing an opera-
tion which requires removal of the guarding.
8. Do not cut metal objects such as nails and
screws. Inspect for and remove all nails,
screws and other foreign material from the
workpiece before operation.
9. Remove wrenches, cut-off pieces, etc. from the
table before the switch is turned on.
10. NEVER wear gloves during operation.
11. Keep hands out of the line of the saw blade.
12. NEVER stand or permit anyone else to stand in
line with the path of the saw blade.
13. Make sure the blade is not contacting the
riving knife/spreader or workpiece before the
switch is turned on.
14.
Before cutting an actual workpiece, let the tool run
for a while. Watch for vibration or wobbling that could
indicate poor installation or a poorly balanced blade.
15. NEVER make any adjustments while tool is
running. Disconnect tool before making any
adjustments.

4ENGLISH
16. Use a push stick when required. Push sticks
MUST be used for ripping narrow workpieces
to keep your hands and ngers well away from
the blade.
17. Pay particular attention to instructions for
reducing risk of KICKBACK. KICKBACK is
a sudden reaction to a pinched, bound or
misaligned saw blade. KICKBACK causes
the ejection of the workpiece from the tool
back towards the operator. KICKBACKS CAN
LEAD TO SERIOUS PERSONAL INJURY. Avoid
KICKBACKS by keeping the blade sharp, by
keeping the rip fence parallel to the blade, by
keeping the riving knife/spreader, antikickback
pawls and blade guard in place for every oper-
ation for which it can be used and operating
properly, by not releasing the workpiece until
you have pushed it all the way past the blade,
and by not ripping a workpiece that is twisted
or warped or does not have a straight edge to
guide along the fence.
18. Do not perform any operation freehand.
Freehand means using your hands to support
or guide the workpiece, in lieu of a rip fence or
miter gauge.
19. NEVER reach around or over saw blade.
NEVER reach for a workpiece until the saw
blade has completely stopped.
20. Avoid abrupt, fast feeding. Feed as slowly as
possible when cutting hard workpieces. Do not
bend or twist workpiece while feeding. If you
stall or jam the blade in the workpiece, turn
the tool off immediately. Unplug the tool. Then
clear the jam.
21. NEVER remove cut-off pieces near the blade
or touch the blade guard while the blade is
running.
22. Knock out any loose knots from workpiece
BEFORE beginning to cut.
23. Do not abuse cord. Never yank cord to discon-
nect it from the receptacle. Keep cord away
from heat, oil, water and sharp edges.
24. Some material contains chemicals which may
be toxic. Take caution to prevent dust inhala-
tion and skin contact. Follow material supplier
safety data.
25. The side guards can be lifted during workpiece
setup and for ease of cleaning. Always make
sure that the side guards are down and resting
at against sawtable before plugging in the
tool.
SAVE THESE INSTRUCTIONS.
WARNING:
WARNING: MISUSE or failure to follow
the safety rules stated in this instruction
manual may cause serious personal injury.
INSTALLATION
Positioning table saw
620 mm
1
525 mm
(24-9/16")
(20-5/8")
► 1. Hole diameter 8 mm (5/16")
1
25 mm
2
(1")
► 1. 6 mm (1/4") Std. washer 2. No.10 wood screw 40
mm (1-1/2") min. length
12
► 1. 6 mm (1/4") Std. washer 2. 6 mm (1/4") Mounting
bolt & Nut tighten securely
Locate the table saw in a well lit and level area where you can
maintain good footing and balance. It should be installed in an
area that leaves enough room to easily handle the size of your
workpieces. The table saw should be secured with four screws
or bolts to the work bench or table saw stand using the holes
provided in the bottom of the table saw. When securing the
table saw on the work bench, make sure that there is an open-
ing in the top of the work bench the same size as the opening in
the bottom of the table saw so the sawdust can drop through.

5ENGLISH
If during operation there is any tendency for the table
saw to tip over, slide or move, the work bench or table
saw stand should be secured to the oor.
FUNCTIONAL
DESCRIPTION
CAUTION:
• Always be sure that the tool is switched off and
unplugged before adjusting or checking function
on the tool.
Adjusting the depth of cut
1
► 1. Handle
The depth of cut may be adjusted by turning the handle.
Turn the handle clockwise to raise the blade or counter-
clockwise to lower it.
NOTE:
• Use a shallow depth setting when cutting thin
materials in order to obtain a cleaner cut.
Adjusting the bevel angle
12
3
► 1. Lock lever 2. Arrow pointer 3. Handwheel
Loosen the lock lever counterclockwise and turn the
handwheel until the desired angle (0° - 45°) is obtained.
The bevel angle is indicated by the arrow pointer.
After obtaining the desired angle, tighten the lock lever
clockwise to secure the adjustment.
CAUTION:
• After adjusting the bevel angle, be sure to
tighten the lock lever securely.
Adjusting positive stops
12
► 1. 90°Adjusting screw 2. 45°Adjusting screw
(A)
(B)
90
90 45
45
The tool is equipped with positive stops at 90° and 45°
to the table surface. To check and adjust the positive
stops, proceed as follows:
Move the handwheel as far as possible by turning it.
Place a triangular rule on the table and check to see if the
blade is at 90° or 45° to the table surface. If the blade is at
an angle shown in Fig. A, turn the adjusting screws clock-
wise; if it is at an angle shown in Fig. B, turn the adjusting
screws counterclockwise to adjust the positive stops.
After adjusting the positive stops, set the blade at 90° to
the table surface. Then adjust the arrow pointer so that
its right edge is aligned to the 0° graduation.
1
► 1. Arrow pointer

6ENGLISH
Switch action
ON OFF
1
► 1. Switch
CAUTION:
• Before plugging in the tool, always be sure that
the tool is switched off.
To start the tool, raise the switch lever. To stop it, lower
the switch lever.
The hinged switch lever plate can be locked by passing
padlock through the hasp on the left hand side.
1
► 1. Padlock
Sub table (R)
1
► 1. Lever
1
► 1. Sub table (R)
This tool is provided with the sub table (R) on the right
side of the main table. To use the sub table (R), raise
both levers on the front right side, pull out the table (R)
fully and then lower the levers to secure it.
When using the sub table (R ), locate the scale plate
on the sub table after loosening the screw on it with
a screwdriver so that it becomes successive with the
scale plate on the main table.
1
2
► 1. Scale plate 2. Screw
Sub table (back) and sub table (L)
(BOTH optional accessories)
1
2
► 1. Sub table (back) 2. Screw
To use the sub table (back), loosen the screws on the
left and right hand sides under the table and pull it out
backwards to the desired length. At the desired length,
tighten the screw securely.

7ENGLISH
NOTE:
• When using the sub table (back ) during use of
the rip fence, pull out the sub table (back) more
than 50 mm so that it does not hit against the
top end of the rip fence.
1
1
2
► 1. Screw 2. Sub table (L)
Sub table (back) can be installed at the back of the table
to assure wider space. Sub table (L) can be installed on
the left side of the table.
ASSEMBLY
Overview of Table Saw Blade
Guarding System
1
2
4
5
3
► 1. Table saw blade guard assembly 2. Antikickback
pawls 3. Riving knife/spreader 4. Riving knife/
spreader release lever location 5. Table saw blade
side guards
WARNING:
• Always be sure that the tool is switched off and
unplugged before carrying out any work on the
tool.
The saw blade and blade guard are not installed on the
tool when it is shipped from the factory.
Installing or removing saw blade
WARNING:
• Always be sure that the tool is switched off and
unplugged before installing or removing the
blade.
• Use only the Makita socket wrench provided to
install or remove the blade. Failure to do so may
result in overtightening or insufcient tightening
of the hex bolt. This could cause an injury.
1
2
3
► 1. Wrench 2. Hex nut 3. Offset wrench
Remove the table insert on the table. Hold the outer
ange with the offset wrench and loosen the hex nut
counterclockwise with the wrench. Then remove the
outer ange.
Assemble the inner ange, blade, outer ange and hex
nut onto the arbor, making sure that the teeth of the
blade are pointing down at the front of the table. Always
install the hex nut with its recessed side facing the outer
ange.
12
3
4
► 1. Inner ange 2. Outer ange 3. Saw blade 4. Hex
nut
CAUTION:
• Keep the ange surface clean of dirt or other
adhering matter; it could cause blade slippage.
Be sure that the blade is installed so that
the teeth are aligned in the cutting (turning)
direction.
To secure the blade in place, hold the outer ange with
the offset wrench, then tighten the hex nut clockwise
with the wrench. BE SURE TO TIGHTEN THE HEX
NUT SECURELY.

8ENGLISH
1
2
► 1. Wrench 2. Offset wrench
CAUTION:
• Be sure to hold the hex nut carefully with the
wrench. If your grip should slip, the wrench may
come off the hex nut, and your hand could strike
the sharp blade edges.
Riving Knife/Spreader Positioning
1. Locate the riving knife/spreader release lever
located at the back of the table saw as shown in
gure 1.
1
Fig.1
► 1. Riving Knife/Spreader Release Lever
2. Pull the riving knife/spreader release lever until it
stops as shown in gure 2. This action will release
the riving knife/spreader for positioning.
1
Fig.2
► 1. Pull the Riving Knife/Spreader release Lever
3. With the release lever pulled move the riving
knife/spreader up or down by hand to the desired
position. Once the riving knife/spreader begins to
move release the lever and continue to move the
riving knife/spreader to the next setting and it will
automatically lock into position. The riving knife/
spreader is able to lock into 3 positions as shown
in gures 3-5 below.
Three Operating Positions of the
Riving Knife/Spreader Unit
Spreader Position
WARNING:
• This position is used for through-cutting
operations and the guard assembly with the
side guards should always be used for this
type of operation. Conducting a through-cut
without proper guarding may result in serous
personal injury.
The riving knife/spreader unit can be made ready for
the attachment of the guard assembly and side guards
by positioning it at the maximum adjustable height as
shown in Fig 3. In this position the unit is raised above
the blade so that the guard assembly can be installed
and made operational. Make sure that the release lever
located at the back of the table saw has returned to
the position as shown in gure 1. Before mounting the
guard be sure to check that the riving knife/spreader
unit is in a locked position by pulling up and pushing
down on the unit to ensure there is no movement.
Spreader Position
1
Fig.3
► 1. Riving Knife/Spreader in Spreader Position

9ENGLISH
Riving Knife Position
WARNING:
• Never Operate The Saw With The Guard
Mounted To The Riving Knife/ Spreader
When The Riving Knife/ Spreader Unit Is In
The Riving Knife Position. The guard may
interfere with the feeding of the work piece and
could result in kickback and serious injury.
The riving knife/spreader unit can be positioned and
locked at a height setting that is just below the top of the
saw blade as shown in gure 4. The unit would be used
in this position for non-through cutting operations with the
guard removed such as rabbets and groove cutting. Make
sure that the release lever located at the back of the table
saw has returned to the position as shown in gure 1.
Before operating the tool be sure to check that the riving
knife/spreader unit is in a locked position by pulling up and
pushing down on the unit to ensure there is no movement
Riving Knife Position
1Fig.4
► 1. Riving Knife/Spreader in Riving Knife Position
Dado Position
The riving knife/spreader unit can be positioned and
locked at a setting that is just below the table behind the
blade as shown in gure 5. This position would only be
used while attempting to perform dado cuts with a dado
type blade. For ease of operation by pulling the riving
knife/spreader release lever the unit will automatically
pop up above the table to provide an easy grasping
area on the unit so that it can be pulled up from below
the table and moved into the next desired position.
Dado Position
1Fig.5
► 1. Riving knife/Spreader in Dado Position
Riving Knife/Spreader Alignment
WARNING:
•
Always make sure the blade is properly aligned with the
riving knife / spreader. If the blade and the riving knife /
spreader are not aligned this could cause interference with
the feeding and/or the pinching of the work piece resulting in
a kickback situation and possible serious personal injury.
• NEVER make any adjustments while the tool
is running. Always disconnect the tool before
making any adjustments, accidental start up of
the tool could result in serious personal injury.
The riving knife / spreader installation is factory-adjusted so that
the blade and the riving knife / spreader are properly aligned.
However, if the blade and the riving knife / spreader come out
of alignment this can be corrected by rst unplugging the tool to
prevent unintentional operation. Then the hex bolts as shown in
item 5 should be loosened using the specially provided wrench.
With the hex bolts loosened adjust the riving knife/spreader
so that it is aligned directly behind the blade while maintaining
equal clearance on either side of the riving knife / spreader in
relation to the blade as shown in item 1. Once the riving knife
spreader is located properly lock the mounting means into place
by tightening the hex bolts as shown in item 5.
1
2
34
5
► 1. These two clearances should be equal 2. Blade
3. Riving knife/spreader 4. Pressure plate 5. Hex bolts
Blade Guard Assembly Installation
or Removal
1. Release the locking lever pin of the blade guard by
lifting the locking lever tab as shown in gure 1.
1
2
3
Fig.1
► 1. Locking Lever in the released position 2. Locking
Lever tab 3. Locking Lever Pin

10 ENGLISH
2. For ease of guard assembly installation adjust
the table saw for maximum depth of cut. With the
locking lever released as shown in Figure 1, posi-
tion the locking lever pin center groove into the
notch provided on the riving knife/spreader unit as
shown in gure 2.
1
2
3
Fig.2
► 1. The notch provided on the Riving Knife/Spreader
for the locking lever pin center groove 2. Locking
lever pin sleeves 3. Locking lever pin center groove
3. Once the locking lever pin is placed into the riving
knife/spreader notch it is to be locked into position
by pushing the tab of the pin's locking lever into
the locked position as shown in Figure 3. Once the
pin's locking lever is in the locked position check
to ensure that the guard assembly is properly
attached to the riving knife/spreader assembly by
pulling up on the guard assembly and making sure
it does not move its position.
WARNING:
• Always ensure proper attachment of the
guard assembly to the Riving Knife/Spreader
before turning the saw on. Improper attach-
ment of the guard assembly could result in the
saw blade making contact with the guard, caus-
ing serious injury.
1
2
Fig.3
► 1. Locking Lever in the locked position 2. Locking
Lever tab
To remove the blade guard for non through cutting
operations reverse the above steps 1 - 3.
Installation of Side Guards to Blade
Guard Assembly
WARNING:
• The guard assembly and side guards should
only be used with the riving knife/spreader in
the spreader position to prevent guard inter-
ference with the work pieces. The use of the
guard assembly with the riving knife/spreader in
the riving knife position may cause interference
with the work piece resulting in a kickback situa-
tion and possible serious personal injury.
1. Release the locking lever pin of the side guard by
lifting the locking lever tab as shown in gure 1.
1
3
2
Fig.1
► 1. Side Guard Locking Lever in the released posi-
tion 2. Side Guard Locking Lever Tab 3. Side Guard
Locking Lever Pin
2. With the locking lever pin released position the pin
into the notch provided on the blade guard assem-
bly as shown in gure 2.
1
2
Fig.2
► 1. The Notch provided in the Blade Guard Assembly
2. Place locking lever pin into the blade guard
assembly

11 ENGLISH
3. Once the locking lever pin is placed into the notch
provided on the blade guard assembly it is to be
locked into position by pushing the tab of the pin's
locking lever into the locked position as shown in
Figure 3.
1
Fig.3
► 1. The locking lever in the locked position
To remove the blade guard for non through cutting
operations reverse the above steps 1-3.
Antikickback Pawl Operation
WARNING:
• Use the Antikickback pawls whenever pos-
sible during the through cutting operations.
This will help prevent the material from being
pushed forward into the operator during a
kickback situation which may result in serious
personal injury.
1
2
Fig.1
► 1. The blade guard assembly item 1 is provided with
two on board antikickback pawls item 2. The pawls
are located on either side of the blade and can be
stored or put into operation independently for ease
of operation
1
2Fig.2
► 1. Item 1 illustrates the antikickback pawl on the
right side of the blade being lifted and placed into
the pawl holder located at the back of the blade
guard assembly. 2. In addition item2 illustrates
the antikickback pawl on the left side of the blade
remaining in the operational position.
1
Fig.3
► 1. Item 1 demonstarates both antikickback pawls
being lifted and placed into the pawl holders located
at the back of the blade guard assembly for storage
1
2
3
Fig.4
► 1. Item 1 indicates the location of the antikickback
pawl holders located at the back of the blade guard
assembly 2. Item 2 points to the arrow direction
which should be followed when taking the pawls
out of the storage position and placing them into
operation 3. Item 3 indicates the direction of which
the pawls should be lifted when storing and placing
them into the antikickback pawl holders

12 ENGLISH
Storage of Blade Guards and
Accessories
1
► 1. Miter gauge
1
2
► 1. Rip fence 2. Push stick
1
► 1. Table saw blade guard assembly and side guard
storage
The miter gauge, blade and wrenches can be stored
on the left side of the base and the rip fence can be
stored at the right side of the base. The Blade Guard
Assembly and Side Guards can be stored inde-
pendently in the pocket provided on the right side of the
table base.
Installing and adjusting rip fence
WARNING:
• Always be sure the tool is switched off and
unplugged before attempting to perform the
installation and adjustment of the rip fence.
1
2
3
► 1. Guide rail 2. Knob 3. Hook
1) Fit the hook on the tip of the rip fence into the far
guide rail on the table or sub table (R) and install and
push the rip fence forward so that the fence holder
engages with the nearmost guide rail.
To slide the rip fence on the guide rail sideways, pivot
the knob on the fence holder to the half way of its travel.
To secure the rip fence, pivot fully the knob on the fence
holder.
2) To slide the rip fence on the guide rail sideways,
return the knob on the fence holder fully without pulling
the lever on the knob.
3) To remove it, pull the lever on the knob and pivot the
knob fully forward while pulling the lever.
To check to be sure that the rip fence is parallel with the
blade, secure the rip fence 2 - 3 mm (5/64" - 1/8" ) from
the blade. Raise the blade up to maximum elevation.
Mark one of the blade teeth with a crayon. Measure
the distance (A) and (B) between the rip fence and
blade. Take both measurements using the tooth marked
with the crayon. These two measurements should be
identical. If the rip fence is not parallel with the blade,
proceed as follows:
A
B
1
► 1. Scale

13 ENGLISH
1
► 1. Hex bolts
1. Position the rip fence in the sliding position.
2. Loosen the two hex bolts on the rip fence with the
hex wrench provided.
3.
Adjust the rip fence until it becomes parallel with the blade.
4. Pivot down the knob on the rip fence toward the operator.
5. Tighten the two hex bolts on the rip fence.
WARNING:
•
Be sure to adjust the rip fence so that it is parallel with
the blade, or a dangerous kickback condition may occur.
When the rip fence cannot be secured solidly, adjust it
according to the following procedure.
(1) Set the rip fence on the table and then
pivot the knob half way through its rotation.
Tighten the screw (A) until the rip fence is
immobilized. Then loosen a 1/4 to 1/2 turn.
1
2
3
4
► 1. Rip fence 2. Released position 3. Moving position
4. LOCK position
12
3
4
► 1. Rip fence 2. Moving position 3. Screw (B)
4. Screw (A)
(2) Tighten the screw (B) fully and then loosen
about 2 full revolutions.
(3) Lock the rip fence by fully pivoting the knob
on the fence holder (lock position).
(4) Make sure that the rip fence can be installed
and removed in the original position
(released position).
(5) Make sure that the rip fence can be slid
smoothly with no wobble when the knob is
rotated half way through its rotation.
CAUTION:
• Be careful not to tighten screws with more than
the tightening amount specied in the above
instructions. Failure to do so may damage the
fastened parts.
Bring the rip fence up ush against the side of the
blade. Make sure that the guideline on the fence holder
points to the 0 graduation. If the guideline does not
point to the 0 graduation, loosen the screw on the scale
plate and adjust the scale plate.
1
2
► 1. Guideline 2. Screws

14 ENGLISH
OPERATION
CAUTION:
• Always use "work helpers" such as push sticks
and push blocks when there is a danger that
your hands or ngers will come close to the
blade.
• Always hold the workpiece rmly with the table
and the rip fence or miter gauge. Do not bend or
twist it while feeding. If the workpiece is bent or
twisted, dangerous kickbacks may occur.
• NEVER withdraw the workpiece while the blade
is running. If you must withdraw the workpiece
before completing a cut, rst switch the tool off
while holding the workpiece rmly. Wait until
the blade has come to a complete stop before
withdrawing the workpiece. Failure to do so may
cause dangerous kickbacks.
• NEVER remove cut-off material while the blade
is running.
• NEVER place your hands or ngers in the path
of the saw blade. Be especially careful with
bevel cuts.
• Always secure the rip fence rmly, or dangerous
kickbacks may occur.
• Always use "work helpers" such as push sticks
and push blocks when cutting small or narrow
workpieces, or when the dado head is hidden
from view while cutting.
Work helpers
Push sticks, push blocks or auxiliary fence are types of
"work helpers". Use them to make safe, sure cuts with-
out the need for the operator to contact the blade with
any part of the body.
NOTE:
• For your convenience a push stick has been
provided with the tool.
Push stick
38mm
6.35mm
6.35mm
6.35mm
1400mm 2
19mm
(3/4")
(1-1/2")
(1/4")
(1/4")
(1/4")
(15-3/4")
► 1. Workpiece end 2. 45° notch
Make the push stick using a piece of 1" x 2" as shown
in the gure.
Push block
120mm
(4-3/4")
300mm(12")
130mm(5")
50mm(2")
6mm
(1/4")
300mm(12")
130mm
(5")
100mm
(4")
50mm
(2")
9.5mm
(3/8")
50mm
(2") 8mm(5/16")
1
2
34
► 1. Face/edge parallel 2. Handle 3. Wood screw
4. Glue together
Use a 19 mm (3/4") piece of plywood.
Handle should be in center of plywood piece. Fasten
with glue and wood screws as shown. Small piece 9.5
mm x 8 mm x 50 mm (3/8" x 5/16" x 2") of wood must
always be glued to plywood to keep the blade from
dulling if the operator cuts into push block by mistake.
(Never use nails in push block.)
Auxiliary fence
9.5mm
(3/8")
19mm
(3/4")
120mm
(4-3/4")
40mm
(1-1/2")
140mm
(5-1/2")
460mm
(18")
1
► 1. Face/edge parallel
Make auxiliary fence from 9.5 mm (3/8") and 19 mm
(3/4") plywood pieces.

15 ENGLISH
Wood facing (rip fence)
1
► 1. No. 10 wood screws (long enough to penetrate
halfway into facing)
A wood facing should be used for operations when the
blade comes close to the rip fence. Wood facing for the
rip fence should be the same size as the rip fence. Make
sure the bottom of facing is ush with the table surface.
Ripping
CAUTION:
•
When ripping, remove the miter gauge from the table.
• When cutting long or large workpieces, always pro-
vide adequate support behind the table. DO NOT
allow a long board to move or shift on the table. This
will cause the blade to bind and increase the pos-
sibility of kickback and personal injury. The support
should be at the same height as the table.
Before operating the table saw, check to be sure that the anti-
kickback pawls operate properly. Turn the tool off and unplug
it. Feed the workpiece under the blade guard and along both
sides of the blade to simulate cutting. Try to withdraw the work-
piece on each side by pulling it toward you. The antikickback
pawls should grab the workpiece and prevent it from moving
back toward the operator. Always keep the antikickback pawls
sharp so they will operate properly. Keep them sharp by using a
round-shaped le to maintain the original shape of the pawls.
1. Adjust the depth of cut a bit higher than the thick-
ness of the workpiece.
2. Position the rip fence to the desired width of rip and
lock in place by pivoting the grip. Before ripping, make
sure the rear end of the rip fence is secured rmly. If
it is not secured enough, follow the procedures in the
section titled "Installing and adjusting rip fence".
3. Turn the tool on and gently feed the workpiece into
the blade along with the rip fence.
(1) When the width of rip is 150 mm (6") and
wider, carefully use your right hand to feed
the workpiece. Use your left hand to hold the
workpiece in position against the rip fence.
(2) When the width of rip is 65 mm - 150 mm (2-1/2" -
6") wide, use the push stick to feed the workpiece.
1
► 1. Push stick
(3)
When the width of rip is narrower than 65 mm
(2-1/2"), the push stick cannot be used because
the push stick will strike the blade guard. Use the
auxiliary fence and push block. Attach the auxil-
iary fence to the rip fence with two "C" clamps.
1
► 1. Auxiliary fence

16 ENGLISH
Feed the workpiece by hand until the end is
about 25 mm (1") from the front edge of the
table. Continue to feed using the push block
on the top of the auxiliary fence until the cut
is complete.
1
► 1. Push block
Cross cutting
CAUTION:
• When making a crosscut, remove the rip fence
from the table.
• When cutting long or large workpieces, always
provide adequate support to the sides of the
table. The support should be at the same height
as the table.
• Always keep hands away from path of blade.
Miter gauge
12
34
► 1. Cross cutting 2. Mitering 3. Bevel cutting
4. Compound mitering (angles)
Use the miter gauge for the 4 types of cutting shown in
the gure.
CAUTION:
• Secure the knob on the miter gauge carefully.
• Avoid movement of the workpiece and gauge by
rmly securing the workpiece and gauge, espe-
cially when cutting at an angle.
• NEVER hold or grasp the intended "cut-off"
portion of the workpiece.
Miter gauge positive stop
1
3
2
► 1. Knob 2. Small plate 3. Screw for positive stop
Miter gauge is provided with positive stops at 90°,
45°right and left miter angles for quick setting of miter
angles.
To set the miter angle, loosen the knob on the miter
gauge.
Raise the small plate on the miter gauge for free setting.
Turn the miter gauge to the desired miter angle. Return
the small plate on the miter gauge to the original posi-
tion and tighten the knob clockwise securely.
Use of miter gauge
12
3
► 1. Groove 2. Knob 3. Miter gauge
Slide the miter gauge into the thick grooves in the table.
Loosen the knob on the gauge and align to desired
angle (0° to 60°). Bring stock ush up against fence and
feed gently forward into the blade.

17 ENGLISH
Auxiliary wood facing (miter gauge)
To prevent a long board from wobbling, t the miter
gauge with an auxiliary fence board. Fasten with bolts/
nuts after drilling holes, but fasteners must not protrude
from the face board.
Non-through cut
Turn off the tool and unplug it before any adjustment.
Remove the blade guard assembly from the riving knife/
spreader.
Adjust the riving knife/spreader to the RIVING KNIFE
POSITION as described earlier in the manual. Before
making a through cut adjust the riving knife/spreader
to the spreader position and install the blade guard
assembly and the side guards before operation.
WARNING:
• Conducting a through cut without proper
guarding may result in serious personal
injury.
Carrying tool
Carry the tool by holding the tool part shown in the
gure.
MAINTENANCE
WARNING:
• Always be sure that the tool is switched off
and unplugged before attempting to perform
inspection or maintenance.
NOTICE: Never use gasoline, benzine, thinner,
alcohol or the like. Discoloration, deformation or
cracks may result.
Cleaning
Clean out sawdust and chips from time to time. Carefully
clean the blade guard and moving parts inside the table saw.
Lubrication
To keep the table saw in tip-top running condition, and
to assure maximum service life, oil or grease the mov-
ing parts and rotating parts from time to time.
Lubrication places:
• Threaded shaft to elevate the blade
• Hinge to rotate the frame
• Elevation guide shafts on motor
• Gear to elevate the blade
• Guide rails for the rip fence
• Shaft of the sub table (R) locking levers
• Sliding part of the sub table (R)
Replacing carbon brushes
1
► 1. Limit mark
Remove and check the carbon brushes regularly.
Replace when they wear down to the limit mark. Keep
the carbon brushes clean and free to slip in the holders.
Both carbon brushes should be replaced at the same
time. Use only identical carbon brushes.
Use a screwdriver to remove the brush holder caps. To replace
the carbon brushes, remove the blade guard and blade and
then loosen the lock lever, tilt the saw head and secure it at
45° bevel angle. Carefully lay the tool on itself backward. Then
loosen the brush holder cap. Remove the worn carbon brushes,
insert the new ones and secure the brush holder caps.
After replacing brushes, plug in the tool and break in
brushes by running tool with no load for about 10 minutes.
Then check the tool while running and electric brake opera-
tion when releasing the switch trigger. If electric brake is not
working well, ask your local Makita service center to repair.

18 ENGLISH
12
► 1. Brush holder cap 2. Screwdriver
To maintain product SAFETY and RELIABILITY,
repairs, any other maintenance or adjustment should
be performed by Makita Authorized or Factory Service
Centers, always using Makita replacement parts.
OPTIONAL
ACCESSORIES
WARNING:
• These accessories or attachments are recom-
mended for use with your Makita tool specied
in this manual. The use of any other accessories
or attachments might present a risk of injury to
persons. Only use accessory or attachment for
its stated purpose.
If you need any assistance for more details regard-
ing these accessories, ask your local Makita Service
Center.
Table insert (Part No. 317934-3)
It is required to use this Table Insert for dado head sets.
Use of the standard table insert will interfere with the
dado head set operation.
To install the dadao head set, proceed as follows.
1. Remove the blade guard assembly.
2. Remove the standard table insert.
3. Place riving knife/spreader into the dado position.
4. Install the dado head set according to manufactur-
er's instructions.
5. Place the table insert for dado cutting into the
table.
When dadoing, use featherboards. The diagram shown
illustrates dimensions for making a typical featherboard.
It should be made from a straight piece of wood that is
free of knots or cracks.
200 mm
600 mm
19 mm
115 mm
130 mm
1
(24")
(8")
(3/4") (4-1/2")
(5")
► 1. Kerf should be about 6 mm (1/4") apart
Featherboards are used to keep the workpiece in con-
tact with the rip fence and table as shown, and to stop
kickbacks.
1
2
3
4
► 1. C clamps 2. Facing board 3. Push stick
4. Featherboard
To install featherboards, proceed as follows:
6. Turn the tool off and unplug it.
7. Add 8" high at facing board to the rip fence, the
full length of the rip fence.
8. Mount featherboards to the rip fence and table as
shown, so that the leading edges of the feather-
boards will support the workpiece until the cut is
completed, and the workpiece has been pushed
completely past the cutter with a push stick.
9. Make sure featherboards are securely attached.

19 ENGLISH
WARNING:
• Do not use dado headsets wider than 21mm
(13/16") or dados greater than 6" in outmost
diameter.
• After dadoing, ALWAYS properly adjust the riv-
ing knife/spreader and replace the blade guard
assembly and side guards for through cuts.
• NEVER attempt bevel cuts when dadoing.
• NEVER dado if there is vibration (utter) or a
strange noise.
• Feed work slowly, especially when cutting
deep or wide grooves or dados. If a deep cut
is needed, make several passes through the
workpiece rather than one deep, wide cut. Fast
or abrupt feeds can be dangerous.
• Use a push stick. When the dado head is hid-
den from view while cutting, your hands should
never be on top of the stock.
• A very dangerous throwback can result if the
wood becomes stuck and you try to remove it by
pulling toward you. Always stop the tool and wait
for dado head to come to a complete stop. Then
simply withdraw the wood.
• Use extra caution when the guard assembly is
removed for any non-through sawing operation
such as dadoing, rabbeting or re-sawing. Adjust
the riving knife/spreader and replace the guard
assembly and side guards.
How to perform rabbeting
1
2
3
► 1. Rabbet 2. Second cut 3. First cut
1.
Remove blade guard assembly and properly adjust
the riving knife/spreader to the riving knife poisiton.
2. Attach auxiliary fence to rip fence for cuts that run
the length of the stock. Facing should be as high
as the workpiece is wide. Adjust fence and blade
to desired dimensions.
3. First cut: Hold board at on table as in ordinary
ripping.
4. Second cut: Set workpiece on its edge. (Use
featherboards, push stick, push block and so on,
using precautions, safety rules and guidelines for
ripping or related work.)
5. For end-type rabbeting, if the workpiece is less
than 10-1/2" wide, rest the wood at on the table
against the miter gauge (with wood facing). The
rip fence should not be used.
6. When moving from a rabbet cut operation to
a through cut operation adjust the riving knife/
spreader to the spreader position and install the
guard assembly and side guards.
Table stand set (accessory)
Refer to the instruction manual for table saw stand
that is provided with the table saw stand as an optional
accessory.
• Steel & Carbide-tipped saw blades
Table/Miter saw
blades For general purpose cuts for table and miter saws.
Combination General purpose blade for fast and smooth rip,
crosscuts and miters.
Fine cross cuts For sand-free cuts cleanly against the grain.
• Sub table ( L)
• Sub table ( back)
• Rip fence
• Miter gauge
• Offset wrench 13-22
• Wrench 19
• Hex wrench 5
• Auxiliary plate
• Stand set
• Sliding guide
NOTE: Some items in the list may be included in the
tool package as standard accessories. They may
differ from country to country.
MAKITA LIMITED WARRANTY
Please refer to the annexed warranty sheet for the
most current warranty terms applicable to this product.
If annexed warranty sheet is not available, refer to the
warranty details set forth at below website for your
respective country.
United States of America: www.makitatools.com
Canada: www.makita.ca
Other countries: www.makita.com

20 FRANÇAIS
FRANÇAIS (Mode d’emploi original)
SPÉCIFICATIONS
Modèle 2705
Alésage central 15.88 mm (5/8")
Diamètre de la lame 255 mm (10")
Caractéristiques liées au
couteau diviseur
Épaisseur de la lame 1.8 mm (1/16")
Épaisseur du couteau diviseur 2.3 mm (3/32")
Diamètre de la lame Max. 255 mm (10 ") - Min. 250 mm (9-7/8 ")
Dimension du trait de scie 2.6 mm (3/32")
Capacités de coupe max. 90° 91 mm (3-9/16")
45° 63 mm (2-1/2")
Capacités d'embrèvement maximales 21 mm (13/16")
Vitesse à vide (T/MIN) 4,800/min
Dimensions de la table (L x P) 567 mm x (753 mm - 1,066 mm)
22-1/4" x (29-5/8" - 42")
Dimensions (L x P x H) avec table non déployée 678 mm x 766 mm x 344 mm
(26-3/4" x 30-1/4" x 13-1/2")
Poids net 29 kg (64 lbs)
• Étant donné l'évolution constante de notre programme de recherche et de développement, les spécications conte-
nues dans ce manuel sont sujettes à modication sans préavis.
• Les spécications peuvent varier suivant les pays.
Pour votre propre sécurité, veuillez
lire le manuel d'instructions
Avant d'utiliser l'outil
Conservez-le pour référence
ultérieure
PRÉCAUTIONS GÉNÉRALES
(POUR TOUS LES OUTILS)
1. VOUS DEVEZ CONNAÎTRE VOTRE OUTIL
ÉLECTRIQUE. Lisez attentivement le manuel
d'instructions. Familiarisez-vous avec les
applications et limites de l'outil, ainsi qu'avec
les risques potentiels qui lui sont spéciques.
2. MAINTENEZ LES PROTECTEURS EN PLACE et
en bon état de fonctionnement.
3. RETIREZ LES CLÉS DE RÉGLAGE ET DE
SERRAGE. Prenez l'habitude de vous assu-
rer que les clés de réglage et de serrage ont
été retirées de l'outil avant de le mettre sous
tension.
4. MAINTENEZ LA ZONE DE TRAVAIL PROPRE.
Les zones de travail et les établis encombrés
ouvrent grande la porte aux accidents.
5. ÉVITEZ L'UTILISATION DANS UN
ENVIRONNEMENT DANGEREUX. N'utilisez
pas les outils électriques dans les endroits
humides ou mouillés, et ne les exposez pas
à la pluie. Maintenez un éclairage adéquat
dans la zone de travail. Ne vous servez pas
de votre outil en présence de liquides ou gaz
inammables.
6. MAINTENEZ LES ENFANTS À L'ÉCART. Toute
autre personne que l'utilisateur de l'outil doit
se tenir à une distance sûre de l'aire de travail.
7.
FAITES EN SORTE QUE L'ATELIER SOIT SANS
DANGER POUR LES ENFANTS, en y posant des
cadenas, un interrupteur principal, ou en retirant
des équipements leurs clés de démarrage.
8. NE FORCEZ PAS L'OUTIL. Il effectuera un tra-
vail de meilleure qualité et plus sécuritaire s'il
est utilisé au régime pour lequel il a été conçu.
9. UTILISEZ LE BON OUTIL. Ne forcez pas un
outil ou accessoire à effectuer un travail pour
lequel il n'a pas été conçu.
10.
PORTEZ DES VÊTEMENTS ADÉQUATS. Ne
portez ni vêtements ni gants amples, ni cravate,
anneaux/bagues, bracelets ou autres bijoux
susceptibles d'être happés par les pièces
mobiles de l'outil. Le port de chaussures anti-
dérapantes est recommandé. Portez un let de
protection pour envelopper les cheveux longs.
11. PORTEZ TOUJOURS DES LUNETTES DE
SÉCURITÉ. Si le travail de coupe dégage de la
poussière, portez également un écran facial ou un
masque antipoussières. Les lunettes ordinaires ne
sont munies que de lentilles résistances aux chocs
; elles ne constituent PAS des lunettes de sécurité.
12. FIXEZ BIEN LA PIÈCE. Lorsque cela est pos-
sible, xez la pièce à travailler à l'aide de dis-
positifs de serrage ou d'un étau. Cela est plus
sécuritaire que l'utilisation de la main et libère
les deux mains pour le maniement de l'outil.
13. MAINTENEZ UNE BONNE POSITION.
Assurez-vous d'une bonne prise au sol et
d'une bonne position d'équilibre en tout
temps.
