Makita MAKSTAR BJR240SH User manual

CORDLESS RECIPRO SAW MODEL BJR240SH
01-02 1Model BJR240SH
73
90
74
76
75
71
72
69 70
68
67
81
80
79
78
77
86 85
82
83
87
88
89
57
56
55
54
43
44
38
37
42
45
46
47
48
50
51
52
41
40
39
34
35
23
29
16
21
13
15
11 12
10
9
8
7
6
5
4
3
22
21
20
19
18
27
66
60
53
59
58
28
36
30
31
32
33
26
25
24
17
61
62
64
63
91
65
14
49

Item Part Qty. Item Part Qty.
No. No. Used Description No. No. Used Description
1256471-1 1SHOULDER PIN 5 54 961016-9 1STOP RING E-10
2233345-3 1COMPRESSION SPRING 6 55 211131-2 1BALL BEARING 6001DDW
3961078-7 1RETAINING RING S-18 56 253744-3 1FLAT WASHER 12
4162228-9 1DRIVING SLEEVE 57 961016-9 1STOP RING E-10
5268094-3 1PIN 3 58 285706-3 1BEARING RETAINER 58
6331639-1 1GUIDE SLEEVE 59 251372-8 2+ C.S.H. SCREW M5X12
7417791-0 1DRIVING SLEEVE GUIDE 60 240052-1 1FAN 46
8256158-5 1PIN 3 61 417792-8 1BAFFLE PLATE
9310129-7 1SLEEVE 62 519074-5 1ARMATURE ASS'Y 24V
10 345214-7 1PUSH PLATE (INCL. FIG. 60, 61, 63, & 64)
11 233025-1 1COMPRESSION SPRING 2 63 681652-2 1INSULATION WASHER
12 231662-5 1TORSION SPRING 17 64 210017-7 1BALL BEARING 607DDW
13 163433-1 1SHOE 65 266060-4 2TAPPING SCREW 4X65
14 266173-1 4TAPPING SCREW 5X30 66 638107-8 1YOKE UNIT
15 421809-1 1INSULATION COVER 67 183421-2 1HANDLE SET (INCL. FIG. 90)
16 911114-9 1PAN HEAD SCREW M4X10 68 266045-0 1TAPPING SCREW 4X20
17 931102-0 1HEX. NUT M4 69 266045-0 1TAPPING SCREW 4X20
18 272240-2 1LEVER 60 70 266050-7 4TAPPING SCREW 4X30
19 921442-4 1HEX. BOLT M8X25 71 643983-7 1TERMINAL
20 344733-0 1LOCK PLATE 72 650519-5 1SWITCH C3LA-2A-L2SM
21 344732-2 1INNER PLATE 73 232205-6 1LEAF SPRING
22 257558-2 1SLEEVE 9 74 344898-8 1SUPPORT PLATE
23 443070-0 1PLATE 12X16 75 689116-0 1HEAT SINK
24 214169-6 1PLANE BEARING 14 76 911006-2 1P. H. SCREW M3X8
25 341462-6 1PLATE 77 417790-2 1STOPPER
26 911225-0 2P. H. SCREW M5X16 78 417789-7 1LOCK OFF BUTTON
27 443117-0 1FELT 6X20 79 231469-9 1COMPRESSION SPRING 4
28 168361-5 1SLIDER 80 232198-7 1LEAF SPRING
29 345213-9 1SLIDE PLATE 81 417788-9 1SPEED CHANGE LEVER
30 911225-0 2P. H. SCREW M5X16 82 643990-0 1BRUSH HOLDER
31 341462-6 1PLATE 83 417783-9 1MOTOR HOUSING
32 214169-6 1PLANE BEARING 14 85 643949-7 1BRUSH HOLDER R
33 443070-0 1PLATE 12X16 86 191976-3 1CARBON BRUSH CB-432 SET
34 911228-4 2P. H. SCREW M5X18 87 643941-3 2BRUSH HOLDER CAP
35 911228-4 2P. H. SCREW M5X18 88 417787-1 2BUMPER
36 153371-5 1GEAR HOUSING COVER Cpl. 89 819063-3 2MAKITA LABEL
37 212001-8 1NEEDLE BEARING 708 90 183421-2 1HANDLE SET (INCL. FIG. 67)
38 265906-1 1H. S. H. BOLT M6X18 91 417921-3 1GASKET
39 153373-1 1CRANK SHAFT Cpl. D01 654037-5 2INSULATED TERMINAL RBV1.25-3.5
40 257251-8 1RING 21 D02 654208-4 2RECEPTACLE
41 313109-2 1COUNTER WEIGHT D03 652038-7 2P. H. SCREW M3X8
42 345215-5 1PLATE
43 251372-8 4+ C.S.H. SCREW M5X12 ACCESSORIES
44 345216-3 1GUIDE PLATE A02 193128-2 1BATTERY B2417 (1.7AH)
45 266210-1 1H. S. H. BOLT M10X18 A03 824659-7 1PLASTIC CARRYING CASE
46 153372-3 1GEAR COMPLETE (INCL. 2 EA. 417075-6 LATCH)
47 257053-2 1RING 15 A04 DC24SA 1CHARGER
48 285705-5 1BEARING RETAINER 58
49 265976-0 4H.S.H. BOLT M5X10
50 211206-7 1BALL BEARING 6202LLB
51 324251-4 1GEAR SHAFT
52 211101-1 1BALL BEARING 6001LLB
53 317539-9 1GEAR HOUSING
01-02 2Model BJR240SH
