INSTRUCTION MANUAL
Cordless Cleaner
CL114FD
ENGLISH: Original instructions
Read before use.

2ENGLISH
WARNING
This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental capa-
bilities or lack of experience and knowledge if they have been given
supervision or instruction concerning use of the appliance in a safe
way and understand the hazards involved. Children shall not play
with the appliance. Cleaning and user maintenance shall not be
made by children without supervision.
SPECIFICATIONS
Model: CL114FD
Capacity with a dust bag 500 ml
with a paper lter 330 ml
Continuous use
(with battery BL1020V)
3 (Max speed mode) Approx. 10 min
2 (High speed mode) Approx. 18 min
1 (Normal speed mode) Approx. 55 min
Overall length Cleaner body 458 mm
With extension wand and nozzle 983 mm
Net weight 1.1 kg
Rated voltage D.C. 10.8 V - 12 V max
• Due to our continuing program of research and development, the specications herein are subject to change
without notice.
• Specications may di󰀨er from country to country.
• The weight does not include accessories.
Applicable battery cartridge and charger
Battery cartridge Battery charger Charging time (hours)
BL1020V DC1002 2.0
• Charging time varies by temperature (10°C (50°F) – 40°C (104°F)) that battery cartridge is charged at and con-
ditions of the battery cartridge, such as a battery cartridge which is new or has not been used for a long period
of time.
WARNING: Only use the battery cartridges and chargers listed above. Use of any other battery cartridges
and chargers may cause injury and/or re.
Symbols
The followings show the symbols which may be used
for the equipment. Be sure that you understand their
meaning before use.
Read instruction manual.
Detachable supply unit
Ni-MH
Li-ion
Only for EU countries
Do not dispose of electric equipment or
battery pack together with household
waste material! In observance of the
European Directives, on Waste Electric
and Electronic Equipment and Batteries
and Accumulators and Waste Batteries and
Accumulators and their implementation
in accordance with national laws, electric
equipment and batteries and battery
pack(s) that have reached the end of
their life must be collected separately and
returned to an environmentally compatible
recycling facility.

3ENGLISH
Intended use
The appliance is intended for collecting dry dust.
SAFETY WARNINGS
Cordless cleaner safety warnings
WARNING: IMPORTANT! READ CAREFULLY
all safety warnings and all instructions BEFORE
USE . Failure to follow the warnings and instructions
may result in electric shock, re and/or serious injury.
1. Do not expose to rain. Store indoors.
2. Do not allow to be used as a toy. Close
attention is necessary when used by or near
children.
3. Use only as described in this manual. Use only
manufacturer's recommended attachments.
4. Do not use with damaged battery. If appliance
is not working as it should, has been dropped,
damaged, left outdoors, or dropped into water,
return it to a service center.
5. Do not handle appliance with wet hands.
6. Do not put any object into openings. Do not
use with any opening blocked; keep free of
dust, lint, hair, and anything that may reduce
air ow.
7. Keep hair, loose clothing, ngers, and all parts
of body away from openings and moving parts.
8. Turn o󰀨 all controls before removing the
battery.
9. Use extra care when cleaning on stairs.
10. Do not use to pick up ammable or combusti-
ble liquids, such as gasoline, or use in areas
where they may be present.
11. Use only the charger supplied by the manufac-
turer to recharge.
12. Do not pick up anything that is burning or
smoking, such as cigarettes, matches, or hot
ashes.
13. Do not use without dust bag and/or lters in
place.
14. Do not charge the battery outdoors.
15. Recharge only with the charger specied by
the manufacturer. A charger that is suitable for
one type of battery pack may create a risk of re
when used with another battery pack.
16. Use power tools only with specically desig-
nated battery packs. Use of any other battery
packs may create a risk of injury and re.
17. When (the) battery pack is not in use, keep
it away from other metal objects, like paper
clips, coins, keys, nails, screws or other small
metal objects, that can make a connection
from one terminal to another.
18. Under abusive conditions, liquid may be
ejected from the battery; avoid contact. If con-
tact accidentally occurs, ush with water.
19. Do not use a battery pack or tool that is dam-
aged or modied. Damaged or modied batteries
may exhibit unpredictable behaviour resulting in
re, explosion or risk of injury.
20. Do not expose a battery pack or tool to re or
excessive temperature. Exposure to re or tem-
perature above 130 °C may cause explosion.
21. Follow all charging instructions and do not
charge the battery pack or tool outside the
temperature range specied in the instruc-
tions. Charging improperly or at temperatures
outside the specied range may damage the
battery and increase the risk of re.
SAVE THESE INSTRUCTIONS.
ADDITIONAL SAFETY RULES
This appliance is intended for household use.
1. Read this instruction manual and the charger
instruction manual carefully before use.
2. Do not pick up the following materials:
— Hot materials such as lit cigarettes or
spark/metal dust generated by grinding/
cutting metal
— Flammable materials such as gasoline,
thinner, benzine, kerosene or paint
— Explosive materials like nitroglycerin
— Ignitable materials such as Aluminum,
zinc, magnesium, titanium, phosphorus
or celluloid
— Wet dirt, water, oil or the like
— Hard pieces with sharp edges, such as
wood chips, metals, stones, glasses,
nails, pins or razors
— Powder to clot such as cement or toner
— Conductive dust such as metal or carbon
— Fine particle like concrete dust
Such action may cause re, injury and/or prop-
erty damage.
3. Stop operation immediately if you notice any-
thing abnormal.
4. If you drop or strike the cleaner, check it care-
fully for cracks or damage before operation.
5. Do not bring close to stoves or other heat
sources.
6. Do not block the intake hole or vent holes.
SAVE THESE INSTRUCTIONS.
IMPORTANT SAFETY
INSTRUCTIONS
FOR BUILT-IN BATTERY
1. Before using built-in battery, read all instruc-
tions and cautionary markings on (1) battery
charger, (2) battery, and (3) product using
battery.
2. Do not disassemble built-in battery.
3. If operating time has become excessively
shorter, stop operating immediately. It may
result in a risk of overheating, possible burns
and even an explosion.

4ENGLISH
4. If electrolyte gets into your eyes, rinse them
out with clear water and seek medical atten-
tion right away. It may result in loss of your
eyesight.
5. Do not short the built-in battery:
(1) Do not touch the terminals with any con-
ductive material.
(2) Avoid storing built-in battery in a con-
tainer with other metal objects such as
nails, coins, etc.
(3) Do not expose built-in battery to water or
rain.
A battery short can cause a large current
ow, overheating, possible burns and
even a breakdown.
6. Do not store and use the tool and built-in bat-
tery in locations where the temperature may
reach or exceed 50 °C (122 °F).
7. Do not incinerate the built-in battery even if
it is severely damaged or is completely worn
out. The built-in battery can explode in a re.
8. Be careful not to drop or strike battery.
9. Do not use a damaged built-in battery.
10. The contained lithium-ion batteries are subject
to the Dangerous Goods Legislation require-
ments. When disposing the battery, remove it
from the tool and dispose of it in a safe place.
Follow your local regulations relating to dis-
posal of battery.
11. Use the batteries only with the products speci-
ed by Makita.
SAVE THESE INSTRUCTIONS.
Tips for maintaining maximum
battery life
1. Charge the built-in battery before completely
discharged.
Always stop tool operation and charge the
built-in battery when you notice less tool
power.
2. Never recharge a fully charged built-in battery.
Overcharging shortens the battery service life.
3. Charge the built-in battery with room tempera-
ture at 10°C - 40°C (50°F - 104°F). Let a hot
built-in battery cool down before charging it.
4. Charge the built-in battery once in every six
months if you do not use the tool for a long
period of time.
FUNCTIONAL
DESCRIPTION
CAUTION: Always be sure that the appliance
is switched o󰀨 before adjusting or checking func-
tion on the appliance.
Charging the built-in battery
CAUTION: Only use genuine Makita batteries.
Use of non-genuine Makita batteries, or batteries that
have been altered, may result in the battery bursting
causing res, personal injury and damage. It will also
void the Makita warranty for the Makita product and
charger.
CAUTION: Always disconnect the charging
plug from the cleaner after charging.
CAUTION: Do not leave the charger in the
mains after disconnecting the appliance. Small
children may put the live plug in their mouth and
cause injury.
Charge the cleaner when using it for the rst time or
uncharged for a long time. Connect the charging plug to
the charging connector, then plug in the charger to the
power receptacle.
1
► 1. Charging connector
The battery power lamp lights up and the charging
starts. The light goes out after the charging is complete.
For more details, refer to the instruction manual of
battery charger.
1
► 1. Battery power lamp

5ENGLISH
NOTICE: The battery power lamp blinks and the
battery cannot be charged if the battery or cleaner
is exposed to extreme temperatures.
NOTE: The cleaner cannot be controlled while being
charged. To start the cleaner, unplug the charger from
the power source, disconnect the charging plug from
the cleaner, and then push the ON/speed change
button.
NOTE: Under the following conditions, the battery is
about to reach its end of life (or damaged/malfunc-
tioned). Unplug the charger from the power supply,
then replace the battery.
• The battery power lamp goes out shortly after
you begin to charge the cleaner.
• The cleaner works only for a period shorter than
half of the normal operating time after the bat-
tery has been fully charged.
NOTE: The battery can be recharged up to approx-
imately 500 times. The rechargeable times vary
depending on the conditions under which the battery
has been charged and discharged.
Switch action
CAUTION: Always switch o󰀨 the cleaner after
each use to prevent damage to the cleaner and to
extend the service life of the batteries.
To start the cleaner, simply push the ON/speed change
button. To switch o󰀨, push the OFF button.
You can change the cleaner speed in three steps by
pushing the ON/speed change button.
The rst push on this button is for high speed mode, the
second push for max speed mode and the third push for
normal speed mode. Each push on this button repeats
the high/max/normal speed cycle alternatively.
1
2
► 1. ON/speed change button 2. OFF button
Battery power lamp
When the remaining battery capacity gets low, the
battery power lamp blinks.
When the remaining battery capacity gets much lower,
the cleaner stops and the battery power lamp lights up
about 10 seconds. At this time, charge the battery.
Also when the battery gets overloaded or overheated,
the cleaner stops and the battery power lamp lights up
about 10 seconds. The cleaner does not actuate during
the lamp on.
1
► 1. Battery power lamp
NOTE: The time at which the battery power lamp start
blinking or lighting up depends on the temperature at
work place and the battery conditions.
Lighting up the lamp
CAUTION: Do not look in the light or see the
source of light directly.
To turn on the lamp, push the ON/speed change button.
Push the OFF button to turn o󰀨 the lamp. During the
cleaner actuating, the lamp turns on.
1
2
3
► 1. ON/speed change button 2. OFF button 3. Lamp

6ENGLISH
ASSEMBLY
CAUTION: Always be sure that the appliance
is switched o󰀨 before carrying out any work on
the appliance.
Dust bag and paper lter
Install either dust bag or paper lter before using
cleaner.
Use the dust stopper when installing either dust bag or
paper lter.
Dust bag are usable many times repeatedly by cleaning
it out.
Paper lter is a throw-away type. Throw away the entire
paper lter without emptying when it has become full.
NOTICE: To prevent dust from getting into the
motor:
• Make sure that the dust bag or paper lter is
installed before use.
• Insert the dust stopper together with the
dust bag or paper lter all the way into the
slots when installing them.
• Do not use a broken or ripped bag.
Otherwise the motor may be broken.
NOTICE: Do not fold the cardboard at its open-
ing when installing the paper lter.
NOTICE: Never throw away the dust stopper
because it needs to be used repeatedly whenever
either the dust bag or the paper lter is used.
NOTICE: The paper lter for the cleaner is an
important component for maintaining the cleaner
performance. Using other than the genuine paper
lter may cause smokes or ignition.
NOTE: When the dust bag or the paper lter is not
installed in the cleaner, the front cover does not close
completely.
Installing dust bag
Use the dust stopper when installing dust bag. Be
careful not to take the upper side for the lower side by
mistake because they are di󰀨erent each other.
1
2
► 1. Upper side of dust stopper 2. Lower side of dust
stopper
1. Insert the protrusion of the dust bag into the lower
groove on the dust stopper as shown in the gure.
1
23
► 1. Dust stopper 2. Lower groove 3. Dust bag
2. There is no distinction between the upper and
lower sides of the dust bag. You may insert its protru-
sion of either side into the lower groove of the dust
stopper.
1
► 1. Lower groove

7ENGLISH
3.
Overlap the frame of dust stopper with that of the dust bag.
4. Place the dust stopper and the dust bag together into the
cleaner cavity in the same direction of arrow on the dust stop-
per. Insert them all the way into the slots in the cleaner cavity.
5. Spread the cloth part of the dust bag inside the cleaner.
6. Close the front cover completely.
1
► 1. Front cover
Installing the paper lter
Use the dust stopper also when installing paper lter.
Be careful not to take the upper side for the lower side
by mistake because they are di󰀨erent each other.
1
2
► 1. Upper side of dust stopper 2. Lower side of dust
stopper
1. Unfold the entrance of the paper lter before
setting it on the dust stopper.
2. Insert the protrusion of the paper lter into the
lower groove on the dust stopper as shown in the gure.
1
23
► 1. Dust stopper 2. Lower groove 3. Paper lter

8ENGLISH
3. There is no distinction between the upper and
lower sides of the paper lter. You may insert its pro-
trusion of any side into the lower groove of the dust
stopper.
1
► 1. Lower groove
4. Overlap the frame of dust stopper with that of the
paper lter.
5. Place the dust stopper and the paper lter
together into the cleaner cavity in the same direction of
arrow on the dust stopper. Insert them all the way into
the slots in the cleaner cavity.
6. Spread the container part of the paper lter inside
the cleaner.
7. Close the front cover completely.
1
► 1. Front cover
OPERATION
CAUTION: Do not move your face close to
the air vent when operating the cleaner. If foreign
objects are blown into eyes, it may result in personal
injury.
Installing or removing the cleaner
attachment
CAUTION: After installing an attachment,
check if it is securely installed. If the attachment
is installed imperfectly, it may come o󰀨 and cause
personal injury.
CAUTION: Be careful not to hit your hand on
the wall etc. when removing the attachment.

9ENGLISH
When using attachment with lock function
To install an attachment, insert it to the suction inlet of the
cleaner until it clicks. Make sure that the attachment is locked.
1
2
3
4
► 1. Suction inlet 2. Attachment with lock function
3. Hook 4. Release button
NOTE:
When installing the attachment with lock func-
tion, be sure to align the release button with the hook
on the attachment. If they are not aligned, the attachment
will not be locked and may come o󰀨 from the cleaner.
To remove the attachment, pull it while pushing the release button.
1
2
► 1. Release button 2. Attachment with lock function
When using attachment without lock function
CAUTION: To install an attachment without
lock function, twist and insert it in direction of the
arrow to secure the connection during use. To
remove the attachment, twist and extract it also in
direction of the arrow.
Cleaning (Suction)
Nozzle
Attach the nozzle to clean o󰀨 tables, desks, furniture,
etc. The nozzle slips on easily.
1
► 1. Nozzle
Nozzle + Extension wand (Straight pipe)
The extension wand ts in between the nozzle and the
cleaner itself. This arrangement is convenient for clean-
ing a oor in a standing position.
1
2
3
► 1. Cleaner body 2. Extension wand 3. Nozzle
Corner nozzle
Fit on the corner nozzle for cleaning corners and crev-
ices of a car seat or furniture.
1
2
► 1. Corner nozzle 2. Cleaner body

10 ENGLISH
Corner nozzle + Extension wand
(Straight pipe)
In tight quarters where the cleaner itself cannot
squeeze in, or in high places hard to reach, use this
arrangement.
1
2
3
► 1. Corner nozzle 2. Extension wand 3. Cleaner body
Cleaning without nozzle
You can pick up powder and dust without nozzle.
For picking up dust on a oor in a standing position, it is
convenient to attach the extension wand to the cleaner.
1
► 1. Extension wand
Disposing of dust
CAUTION: Empty the cleaner before it
becomes too full, or the suction force weakens.
CAUTION: When closing the front cover, be
careful not to pinch your ngers.
NOTICE: Never throw away the dust stopper
because it should be used whenever either the
dust bag or the paper lter is used.
NOTICE: When the dust bag/paper lter is not
inside of the cleaner, the front cover does not
close completely. Do not force to close the front
cover. It may result in deforming or breakage of
the cleaner.
NOTICE: When disposing of dust, also clean the
room for the dust bag/paper lter. The remaining
dust and dirt in the room may cause the sponge lter
to be clogged or the motor to be damaged.
1. Push the button to open the front cover. Opening
it until a click is heard allows a positive stop at that
position.
1
2
► 1. Front cover 2. Button
2. Pull out both the orange-colored dust stopper and
dust bag/paper lter together at the same time.
1
► 1. Dust stopper

11 ENGLISH
3. Perform the procedures below depending on the
dust container type:
When using the dust bag
Remove the dust stopper and empty the dust bag.
1
2
► 1. Dust stopper 2. Dust bag
When using the paper lter
Remove the dust stopper and dispose of the paper lter.
1
2
► 1. Dust stopper 2. Paper lter
4. Place the dust bag/new paper lter and dust stop-
per together into the cleaner and close the front cover.
NOTE: The cleaner is constructed in such a way that
the front cover comes o󰀨 when trying to force the
front cover open at the angle of more than 90°. If the
front cover comes o󰀨, insert it into the front cover joint
in place.
1
2
► 1. Front cover 2. Front cover joint
MAINTENANCE
CAUTION: Always be sure that the appliance
is switched o󰀨 before attempting to perform
inspection or maintenance.
To maintain product SAFETY and RELIABILITY,
repairs, any other maintenance or adjustment should
be performed by Makita Authorized or Factory Service
Centers, always using Makita replacement parts.
NOTICE: Never use gasoline, benzine, thinner,
alcohol or the like. Discoloration, deformation or
cracks may result.
After use
When storing or charging the cleaner, lock the nozzle
head, and hang it from a hook available in the market.
CAUTION: Putting the cleaner against the
wall without any other support may cause the
cleaner to fall down and be damaged.

12 ENGLISH
Cleaning
Cleaner body
From time to time wipe o󰀨 the outside (cleaner body) of
the cleaner using a cloth dampened in soapy water.
Clean out also the suction opening, dust bag/paper lter
mounting area and the dust stopper.
Dust stopper
Wipe dust o󰀨 from the dust stopper.
Remove dust and dirt on the sponge part by lightly tapping it.
1
► 1. Sponge part
Dust bag
Wash the dust bag in soapy water when it is clogged
with dust and the cleaner power becomes weak. Dry it
out thoroughly before use. An insu󰀩ciently dried bag
may cause poor suction and shorten the service life of
the motor.
NOTE: Paper lter is a throw-away type.
When the sponge lter is clogged with dust, remove it
from the cleaner and then wipe it o󰀨 or wash in water.
Removing and installing the sponge
lter
CAUTION: After cleaning sponge lter, be
sure to install it on the cleaner. If washed in water,
dry it up before installing. An insu󰀩ciently dried
sponge lter may shorten the service life of the motor.
To remove the sponge lter, remove the dust bag or
paper lter and then pinch and take the sponge lter
out.
1
► 1. Sponge lter
To install the lter, press in the whole edge of the
sponge lter against the recessed wall inside the dust
bag/paper lter mounting area.
1
► 1. Recessed wall

13 ENGLISH
The nozzle cleaning
(country specic)
When the nozzle brush gets dusty, clean up the dust
with adhesive tape.
1
► 1. Brush
Wall mount for cordless cleaner
Optional accessory
NOTE: The screw to mount the holder is not included.
Prepare a screw which ts with the material to screw
into.
Attach the wall mount for cordless cleaner to a hard
wooden wall, beam or column, where the wall mount
for cordless cleaner can be rmly secured. Always be
sure that the wall mount for cordless cleaner is securely
attached before hanging the cleaner.
1
2
► 1. Wall mount for cordless cleaner 2. Plug
CAUTION: Do not hang the cleaner to the wall
mount violently or hang other appliances than the
cleaner.
NOTE: When you don’t charge the cleaner, the plug
can be stored on the wall mount for cordless cleaner
as illustrated.
Troubleshooting
Before asking for repairs, check the following points.
Symptom Area to be investigated Fixing method
Weak suction power Is dust bag or paper lter full of dust ? Empty dust bag or paper lter.
Is dust bag clogged ? Dust down or wash the dust bag.
Is paper lter clogged ? Replace paper lter.
Is the battery cartridge exhausted ? Charge the battery cartridge.
Not working Is the battery cartridge exhausted ? Charge the battery cartridge.
Dust case cover does not close Is dust bag or paper lter set ? Set dust bag or paper lter.
NOTICE: Do not attempt to repair cleaner by yourself.

14 ENGLISH
Disposing cleaner
A Li-ion battery is built in this cleaner. Always remove it
before disposing of the cleaner.
Removing built-in battery
CAUTION: Do not touch the terminals with
any conductive material.
CAUTION: Avoid storing battery unit in a
container with other metal objects such as nails,
coins, etc.
CAUTION: Do not expose battery unit to
water or rain.
CAUTION: Do not disassemble or alter bat-
tery unit.
CAUTION: The cleaner must be disconnected
from the supply mains when removing the battery.
1. To remove the rear cover, push it in the direction of
the arrow.
1
► 1. Rear cover
2. Slide the built-in battery halfway. Disconnect the
lead wires from the battery by slightly moving back the
battery while pressing the connector in the direction of
arrow as shown in the gure.
1
2
► 1. Connector 2. Lead wires
3. Then slide the battery unit out completely.
1
► 1. Battery unit
4. Put the removed battery unit in a carton box so
that it is not circuit-shorted.
Installing replacement battery
To install the replacement battery, follow the removal
procedure in reverse.
CAUTION: Route the lead so that it is com-
pletely stored inside the cleaner before putting
the rear cover back in the original position. Failure
to do this may damage the lead.
After installing the battery (see "SPECIFICATIONS"),
charge the battery before use.

OPTIONAL
ACCESSORIES
CAUTION: These accessories or attachments
are recommended for use with your Makita appli-
ance specied in this manual. The use of any other
accessories or attachments might present a risk of
injury to persons. Only use accessory or attachment
for its stated purpose.
If you need any assistance for more details regard-
ing these accessories, ask your local Makita Service
Center.
• Extension wand (Straight pipe)
• Nozzle
• Nozzle for carpet
• Shelf brush
• Corner nozzle
• Round brush
• Flexible hose
• Paper lter
• Wall mount for cordless cleaner
• Replacement battery
• Free nozzle
• Seat nozzle
• Crevice nozzle
• Cyclone attachment
NOTE: Some items in the list may be included in the
appliance package as standard accessories. They
may di󰀨er from country to country.
15 ENGLISH

www.makita.com
Makita Europe N.V.
Makita Corporation
3-11-8, Sumiyoshi-cho,
Anjo, Aichi 446-8502 Japa
n
Jan-Baptist Vinkstraat 2,
3070 Kortenberg, Belgium
885813-224
EN
20200629
