Manitou MHT 790 104JD H ST4 S1 User manual

649010 EN/US/AU (16/07/2018)
MHT 790 104JD H ST4 S1
OPERATOR'S MANUAL
(ORIGINAL INSTRUCTIONS)

IMPORTANT
Carefully read and understand this instruction manual before using the lift truck.
It contains all information relating to operation, handling and lift truck equipment,
as well as important recommendations to be followed.
This document also contains precautions for use, as well as information on the servicing and routine maintenance required
to ensure the lift truck's continued safety of use and reliability.
WHENEVER YOU SEE THIS SYMBOL IT MEANS:
WARNING ! BE CAREFUL ! YOUR SAFETY OR THE SAFETY OF THE LIFT TRUCK IS AT RISK.
- This manual has been produced on the basis of the equipment list and the technical characteristics
given at the time of its design.
- The level of equipment of the lift truck depends on the options chosen and the country of sale.
- According to the lift truck options and the date of sale, certain items of equipment/functions described
herein may not be available.
- Descriptions and figures are non binding.
- MANITOU reserves the right to change its models and their equipment without being required to
update this manual.
- The MANITOU network, consisting exclusively of qualified professionals, is at your disposal to answer
all your questions.
- This manual is an integral part of the lift truck.
- It is to be kept in its storage space at all times for ease of reference.
- Hand this manual to the new owner if the lift truck is resold.
p
CALIFORNIA PROPOSITION 65 WARNINGS
WARNING
This product can expose you to lead which is known to the State of California to cause cancer and birth defects or other
reproductive harm.
For more information go to www.P65Warnings.ca.gov
WARNING
Breathing diesel engine exhaust exposes you to chemicals known to the State of California to cause cancer and birth defects
or other reproductive harm.
- Always start and operate the engine in a well-ventilated area.
- If in an enclosed area, vent the exhaust to the outside.
- Do not modify or tamper with the exhaust system.
- Do not idle the engine except as necessary.
For more information go to www.P65Warnings.ca.gov/diesel
649010 EN/US/AU (16/07/2018) MHT 790 104JD H ST4 S1

Manitou BF S.A Limited liability company with a Board of Directors.
Head office: 430, Rue de l’Aubinière - 44150 Ancenis - FRANCE
Share capital: 39,548,949 euros
857 802 508 RCS Nantes.
Tel: [phone]
www.manitou.com
This manual is for information purposes only. Any reproduction, copy, representation, recording, transfer, distribution, or other, in part
or in whole, in any format is prohibited. The plans, designs, views, commentaries and instructions, even the document organization
that are found in this document, are the intellectual property of MANITOU BF. Any violation of the aforementioned may lead to civil
and criminal prosecution. The logos as well as the visual identity of the company are the property of MANITOU BF and may not be
used without express and formal authorization. All rights are reserved.
25/10/2016
16/07/2018 Update Prop 65 0-2 @ 0-3
UPDATED
1st ISSUE
SILICA DUST HAZARD
Exposure to crystalline silica (found in sand, soil and rocks) has been associated with silicosis,
a debilitating and often fatal lung disease. Comply with all applicable rules and regulations for
the workplace. Wear approved respiratory protection or use water spray or other means if there
is no other way to control the dust.
A Silica rule "29 CFR 1929.1153" by the U.S. Occupational Safety and Health (OSHA) indicates a
signicant risk of chronic silicosis for workers exposed to inhaled crystalline silica over a working
lifetime. Refer to the rule for more information regarding exposure limits and hazard prevention.
649010 EN/US/AU (16/07/2018) MHT 790 104JD H ST4 S1

1 - OPERATING AND SAFETY INSTRUCTIONS
2 - DESCRIPTION
3 - MAINTENANCE
4 - OPTIONAL ATTACHMENTS FOR USE WITH THE RANGE
1 - OPERATING AND SAFETY INSTRUCTIONS
2 - DESCRIPTION
3 - MAINTENANCE
4 - ADAPTABLE ATTACHMENTS IN OPTION ON THE RANGE
5 - LOAD CHARTS FOR INTERCHANGEABLE EQUIPMENT
649010 EN/US/AU (16/07/2018) MHT 790 104JD H ST4 S1

649010 EN/US/AU (16/07/2018) MHT 790 104JD H ST4 S1

LEGEND OF SIGNS AND SYMBOLS
OVERVIEW:
pWarning ! be careful ! your safety or the safety of the lift truck is at risk.
See image 2-48
eFor more details: see paragraph“Switches”
ATTACHMENT LOAD TABLE
5
7
6
8
2
12
1010
9
10
10
13
17
15
16
3
4
7
1
11
14
FAC-SIMILE
Reference Indication (example) Example
1load table
2machine type Forks Positioner
3load centre L.C.600mm/24in
4alphanumeric code which identies the type of attachment in use (Optional) Pos. AK
5machine model MHT 790
6machine in working conguration: on front tyres, on tyres and turret rotated, on stabilisers
(Depending on the model machine)
7working conditions
8load table code 53008788
9indicative drawing of the machine
10 metric system [unit of length (m) and unit of weight (kg)] or imperial system [unit of length (ft) and unit of
weight (lb)]
11 maximum length extension of the telescopic boom 3.8 m
12 load capacity range of the machine
3000kg/6000lbs,
3600kg/7900lbs,
4400kg/9700lbs,
5300kg/11700lbs,
8000kg/17700lbs
13 capacity table according to standards in force in the destination country
EN1459-ANNEXE B -
AS1418.19 -
ASME B56.6
14 maximum lift height of the telescopic boom 6.8 m
15 angle of the boom 0°, 10°, 20°, 30°, 40°,
50°, 60°, 62°
16 length of the boom (Optional) A, B, C, D
17 load centre 600 mm - 24in
649010 EN/US/AU (16/07/2018) MHT 790 104JD H ST4 S1

ATTACHMENT PICK AND CARRY TABLE
Reference Indication (example) Example
1load chart Pick and Carry
2type of attachment Forks Positioner
3load center L.C.600mm/24in
4alphanumeric code which identies the type of attachment in use (Optional) Pos. AK
5machine model MHT 790
6working conditions
7load table code 53008789
8capacity table according to standards in force in the destination country AS 1418.19
9metric system [unit of length (m) and unit of weight (kg)] or imperial system [unit of length (ft) and unit of
weight (lb)]
10 maximum load capacity of the attachment in use 8000 kg
11 indicative drawing of the machine
5
FAC-SIMILE
6
8
2
7
9
3
4
1
6
11
10
9
649010 EN/US/AU (16/07/2018) MHT 790 104JD H ST4 S1

649010 EN/US/AU (16/07/2018) MHT 790 104JD H ST4 S1

1 - 1
1 - OPERATING
AND SAFETY
INSTRUCTIONS
)
649010 EN/US/AU (16/07/2018) MHT 790 104JD H ST4 S1

1 - 2
TABLE DES MATIÈRES
1 - OPERATING AND SAFETY INSTRUCTIONS
INSTRUCTIONS TO THE COMPANY MANAGER 4
THE SITE 4
THE OPERATOR 4
THE LIFT TRUCK 4
A - THE TRUCK'S SUITABILITY FOR THE JOB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
B - ADAPTATION OF THE LIFT TRUCK TO STANDARD ENVIRONMENTAL CONDITIONS . . . . . . . . . . . . . . . . . . . . 4
C - MODIFICATION OF THE LIFT TRUCK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
D - FRENCH ROAD TRAFFIC RULES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
E - LIFT TRUCK CAB PROTECTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
THE INSTRUCTIONS 5
THE MAINTENANCE 5
INSTRUCTIONS FOR THE OPERATOR 6
PREAMBLE 6
GENERAL INSTRUCTIONS 6
A - OPERATOR'S MANUAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
B - AUTHORISATION FOR USE IN FRANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
C - MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
D - MODIFICATION OF THE LIFT TRUCK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
E - LIFTING PEOPLE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
OPERATING INSTRUCTIONS UNLADEN AND LADEN 7
A - BEFORE STARTING THE LIFT TRUCK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
B - DRIVER'S OPERATING INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
C - ENVIRONMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
D - VISIBILITY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
E - STARTING THE LIFT TRUCK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
F - DRIVING THE LIFT TRUCK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
G - STOPPING THE LIFT TRUCK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
H - DRIVING THE LIFT TRUCK ON THE PUBLIC HIGHWAY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
D - TRANSVERSE ATTITUDE OF THE LIFT TRUCK. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
E - TAKING UP A LOAD ON THE GROUND. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
F - TAKING UP AND LAYING A HIGH LOAD ON TYRES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
G - TAKING UP AND LAYING A HIGH LOAD ON STABILIZERS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
H - TAKING UP AND LAYING DOWN A SUSPENDED LOAD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
I - TRAVELLING WITH A SUSPENDED LOAD. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
PLATFORM OPERATING INSTRUCTIONS 19
A - AUTHORISATION FOR USE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
B - LIFT TRUCK SUITABILITY FOR USE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
C - PRECAUTIONS WHEN USING THE PLATFORM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
D - USING THE PLATFORM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
E - ENVIRONMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
F - MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
INSTRUCTIONS FOR USING THE RADIO-CONTROL 21
CONFORMITY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
RADIO LINK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
FREQUENCIES. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
SAFETY FUNCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
WARNINGS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
GENERAL OPERATING INSTRUCTIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
