Manitou MRT Series User manual

Quick Reference guide for
Manitou ST3 Rotational Telehandler
21.50, 24.50 non add Blue
Contact
Paul Orange –07711 957985 (North)
Chris Moisey - 07711 957974 (South)

HANDOVER GUIDE

2
HANDOVER GUIDE
The MRT + PRIVILEGE telehandler can work with a comprehensive range of
attachments, combining lift, offset and rotation functions within the same
machine, and enabling the use of the machine in static mode with stabilisers.
The range meets fully all the challenges with working at great heights in
cramped sites.
Thisistrulya3-in-1machine:
Telescopic/Crane/Platform

3
MRT /MRT-X PRIVILEGE
MRT 1850 + MRT 2150 + MRT 2540 +
- MRT-X 2150 + MRT-X 2540 +
Machine weight with standard attachment (transport position):
Unladenweight 15350kg 16410kg 17165kg
Nominal laden weight 20 349 kg 21 409 kg 21 165 kg
Maximumloadoneachstabiliser 10600kg 11500kg 10600kg
Maximumloadpertyre 8900kg 9050kg 8600kg
Traction force 8 200 kg 8 200 kg 8 200 kg
Weight distribution per axle:
Frontaxle 7620kg 7810kg 8135kg
Rearaxle 7730kg 8600kg 9030kg
Dimensions:
Overall width 2.43 m 2.43 m 2.43 m
Overall length 6.06 m 6.78 m 7.82 m
Overallheight 3.05m 3.05m 3.05m
Ground clearance 0.37 m 0.37 m 0.37 m
MRT 1850+ 2150+ 2540+
MRT-X 2150+ 2540+
mm
A1200
A1 150
A2 1320
A3 50
B290
C577064907530
D 5050
E1155
F2750
G1155
H380
I2485
J 3110
K24852985
K1 -- 485
L1930
mm 2425
N4700
O5100
P150
Q4500
R3800
S4550
T4040
U564062306700
V950
Y12°
Z105°
DIMENSIONS AND WEIGHTS

4
1
2
METHODOLOGY
THEMAINSTAGESINTHEHANDOVERPROCESS
LEFT SIDE
REAR
Hydraulic oil tank and its access cover
Hydraulic oil lling access
Air conditioning radiator
located under the roof cap
Steering cylinder inside
and above the axle
Rear axle locking
cylinders
Fueltankanditsaccesscover
(differentfromthehydraulicoilaccesscover)
*according option

5
3
4
FRONT
Quick coupler (manual locking bolt
or hydraulic locking *)
Attachments (if required)
Safety sleeve (to lock the lifting
cylinder)
Tilting corrector
Telescopic stabilisers
Engine oil
level
Oil lter
Coolant level
Air lter under
the cover
Battery
Fuel pre-lter
and lter
Engine oil ller port
*according option
ENGINE COMPARTMENT – RIGHT SIDE

6
JOYSTICKS
METHODOLOGY
Control wheel for attachment
hydraulic line movements
Speed control validation
button (use F4 screen)
Warning! This switch cuts the attachment
line movements off
Attachment movement selector
Switch:
FORWARD GEAR
REVERSE GEAR
NEUTRAL
Check that the machine
is in neutral before
starting the engine
Press the dead man’s button to
validate the movement command
(one per joystick)

7
CABINE
7
6
2
5
4
3
2
2
1
1
CABIN
1
Dashboard
2
Joysticks
3
Load charts
4
Emergency box
5
Switch panel (overhead right)
6
Turret locking lever: must be on when
transporting the machine or in travel mode
7
Heating and air conditioning*
1
Platform emergency key: it allows another operator, in the event of impairment of the platform
occupant, to start the engine and operate functions from the cabin, TURN THE KEY AND PRESS
THE RED BUTTON (
1
) AT THE SAME TIME (the key is in the emergency box located on
the cabin’s right pillar, next to the seat; break the glass using the hammer provided).
2
LMI shunt key: to deactivate the safety, the operator must turn / press and hold the key.
FOCUS
*according option

F1
F2
1 2
1 2
8
345
3
4
5
DASHBOARD DISPLAY
Select the total load of the attachment
Resetting of the partial hour counter
Escape key
Confirm the attachment
FOCUS
Axle alignment and steering mode
indications
Turret alignment indication.
When the icon is displayed, the turret
can be locked using the lever located
totherightoftheseat.
When the turret is aligned, the turret
alignment icon is on:
Load level indication
 Red: maximum load allowed in the
current position
 Green: actual load lifted
Stabiliser mode indication (example
shown: fully extended and down)
Set the position of the load in space

F3
F5
9
F4
Working zone limits: the yellow icons
indicate that the zone limit has been
reached. The conguration is carried
out by setting the machine in the
required maximum position and
pressingF6toF10keys
Retrievalofspeedsfrommemory
aspercentageoftheboom
hydraulic speed
Display of attachment recognition
by machine
Conguration screen for maximum
speeds of the boom’s hydraulic
movements. Use F6 to F9 to select
the required line, and modify the value
bymovingthejoystickandvalidating
the percentage with the red button
in the right joystick. The parameters
will be displayed on F3 page.
F10 allows resetting movements
to 100%
Error diagnostics screen

Switch for radio-
control option:
ON WHEN
ACTIVATED
“
”
10
FOCUS
Stabiliser
movement control
indicators
Stabiliser
selectors
ele
The stabiliser movement
selector
DASHBOARD
Site speed (low gear) /
travel speed (high gear)
switch
Resetswitch:ifrequired,
it synchronises gear change
Manual-mode parking brake
switch (the machine is
equipped as standard with
automaticparkingbrake)
Switch to allow moving the machine
with the turret out of alignment:
to be used on at surfaces with care
Steering mode selector
switch:
 4 STEERING WHEELS
for short radius on
narrow places
 2 FRONT STERRING
WHEELS to ensure
safety on the road
 CRAB-STEERING for
sideways approaches

11
FOCUS
The stabiliser movement
selector
r
l
s
Themachinehastwospeeds:
 Site speed (low gear)
 Travel speed (high gear)
To select a gear:
 Select neutral
 Press fully on the brake
 Select the required gear using the switch
In normal conditions of use, the RESET indicator
light is on. If forward or reverse gear is not
selected, the blue indicator light turns off.
Iftheselectedgearisnotshift,presstheRESET
buttonwithforwardorreversegearengagedand
Accelerate GENTLY until the machine starts to
move, releasing then the RESET button
Emergency pump
electric switch (including
in the platform
provision)
Radio-control
switch
Electric accelerator
switch
Economy
consumption
mode
Automatic machine
levelling*
Frame levelling
control level
Boom suspension*
ent
or
*according option

12
Q
S
FOCUS
S1
S2
Q1
Q2
USING THE STABILISERS
FRAME LEVELLING
The lever, located to the right of the display monitor, controls the levelling corrector. To carry out
levellingoperations,pushthelevertothelefttotiltthemachinetotheleft,andpushthelevertothe
right to tilt the machine to the right.
Warning!Thefunctionisenabledonlyif:
 The telescopic boom is retracted
 The boom height is < 3 metres
 The turret is aligned with the chassis
FOCUS
Pads fully on the
ground
Stabiliser fully
deployed
Select one or several stabilisers
Using switchS,select S1or S2mode
(raise/lower or extend/retract stabilisers)
Using switch Q, drive the stabilisers as per
the required mode and movement:
- Q1 : lower / raise stabilisers
- Q 2 : extend /retract stabilisers

13
Frame Mounted Hook Crane
Tipping forks Extensible platform Hydraulic Winch
Read
the Instruction
Manual
“
”
1
Tilt the coupler
2
Extend the boom
4
Insert the locking
bolt into the coupler
If it is a hydraulic attachment:
connect the hoses and the return to the
tank if required (e.g. winch)
Attachments are now equipped with a
RFID chip that enables the machine to
recognize them. Once the attachment is
hitched, the machine will automatically
provide the right load chart, for better
operating comfort.
3
Engage the coupler

2
14
1 2 3
2
22
3
1
RADIO-CONTROL MODE
1Machine display screen
2Joysticks, selector button for different
functions
3Emergency stop button
To change to radio-control mode:
1. Start the machine
2. Stabilise the machine
3. Press the radio-control button
The engine stops
Check that the door is properly closed and the gear lever is in neutral
4. Switch the radio-control on (
1
)
5. Press the “start” green button (
2
). The horn indicates that the machine radio-control
communication is established
6. Start the engine using the radio-control button (
3
)

15
1
2
3
4
To change to platform mode:
1. Hang the platform to the machine coupler;
insert the locking bolt into the coupler
2. Stabilisethemachineanddonotswitchtheignition
off
3. Connect the platform’s electrical lead to the boom
head (
1
).Themachineenginestops
4. Connect the hydraulic hoses (if applicable)
5. Place the control box in its location in the platform.
Securewiththelockingsystemprovided(
3
)
6. Connect the platform’s electrical lead to the right
side of the control box (
4
)
7. Switch the control box on
8. Press the “start” green button. The horn indicates
that the machine radio-control communication is
established
9. Start the engine using the radio-control button
PLATFORM MODE
When the platform
exceeds
the load limit,
the only
movement
allowed
is the
boom retraction
DON’T forget!
In
platform
mode,
put the joystick
gear selector
in neutral
CAUTION!

www.manitou.com
HG004EN_A_0413_MRTPRIV
Check the
machine safety
system and
lights
April 2013
HANDOVER GUIDE
Daily maintenance
The machine must be maintained in good working order in accordance with the
relevant regulations. Refer to the Daily Maintenance chapter in the Instruction
Manual.
Check the engine oil level, the coolant level and the hydraulic oil level. All these operations must be
carried out on a at surface, with the engine stopped.
Check the
lubrication
of the telescopic
boom slides
Ensure the correct application of all the recommendations and instructions
concerning the machine that are described in the Instruction Manual.
This document does not substitute in any way the Instruction Manual.
DON’T forget!
