Mark-10 TT01 series User manual

Series TT01
CAP TORQUE TESTERS
Quick Start Guide
OTHER MARK-10 PRODUCTS
A full line of force and torque measurement products and related items,
including force gauges, torque gauges, force and torque test stands, sensors,
grips, software, and more.
Force and torque measurement engineered better
Mark-10 Corporation
11 Dixon Avenue
Copiague, NY 11726
888-MARK-TEN
Tel: [phone]
Fax: [phone]
Internet: www.mark-10.com
E-mail: [email protected]
32-1123
121119

Thank you!
Thank you for purchasing a Mark-10 Series TT01 Cap
Torque Tester. We are condent that you will get many
years of service from this product.
Please read through this Quick Start Guide and the com-
plete User’s Guide before using the tester.
Series TT01 Cap Torque Testers
IMPORTANT SAFETY CONSIDERATIONS
Force and torque measuring instruments are sensitive and must be treated
with care. Please review the safety information provided in the User’s Guide
prior to operating the gauge.
LIST OF INCLUDED ITEMS:
POWER
To power on the tester, press the button. Press and hold to power o󰀨. The
tester may be powered either by the internal rechargeable battery or an AC adapter/
charger. The battery will last approximately 7 hours with the backlight turned on,
and 24 hours with the backlight turned o󰀨 before recharging is necessary
LITERATURE & SOFTWARE DOWNLOADS
Download at: www.mark-10.com/downloads
1. User’s guides (PDF)
Provided for all Mark-10 instruments. Locate the user’s guide for this product
and read it thoroughly before use.
2. USB driver
For Mark-10 instruments and the model RSU100 RS-232 to USB converter.
Required for communication with a PC. Follow the installation instructions
provided in the user’s guide.
3. MESUR®family of software – see below.
INSTALLING MESUR®SOFTWARE
Mark-10 o󰀨ers three data collection applications:
MESUR®Lite
Free basic data acquisition application, for data tabulation and exporting to Excel.
Compatible with gauges only, not test stands.
MESUR®gauge / MESUR®gauge Plus
Data tabulation, graphing, analysis, and reporting, with user-congurable start and
stop triggers and other tools. Compatible with gauges and test stands for load
vs. time or load vs. travel. MESUR®gauge Plus adds test stand motion control
coordination. Both applications can be evaluated for 90 days.
PC requirements
Compatible with PCs running Microsoft Windows 7 or later. Minimum monitor
resolution is 1108 x 758. A USB or RS-232C serial port is required. If USB
communication is required, install the Mark-10 USB driver.
Quick Start Guide
Qty. Part No. Description
1MTT01-12 / MTT01-25 /
MTT01-50 / MTT01-100 Series TT01 digital cap torque tester
1AC1030 / AC1031 /
AC1032 / AC1035
AC adapter/charger w/US, EU, UK, or AUS
prong
1 CT004 Sample gripping posts, 4
1 08-1026 Rechargeable NiMH battery
(inside the instrument)
1 - Certicate of calibration
1 09-1165 USB cable
1 CT001 Flat jaws set, 2 (optional)
1 CT002 Carrying case (optional)
1 CT003 Adjustable jaws set, 2 (optional)
1 CT005 Set of 4 posts, 2.5” (optional)
1 CT006 Set of 4 posts, 4” (optional)
1 CT007 Kit of 4 posts of each length (optional)
