Mase IS3501 Programming manual

MANUALE USO E MANUTENZIONE
USAGEANDMAINTANCEMANUAL
MANUEL D'INSTRUCTIONS ET D'ENTRETIEN
GEBRAUCHSANWEISUNGUNDWARTUNGSVORSCHRIFTEN
MANUAL USO Y MANTENIMENTO
INSTALLATIEHANDLEIDING
Rev.0-Cod.41454
IS 3501
IS 4501
IS 5501
GENERATORS

IS 3501 - 4501- 5501
- 2 -
mase
GENERATORS
MASE GENERATORS S.p.A.
Tel.[phone]
Fax [phone] (commercial dept.)
Fax [phone] (service dept.)
Fax [phone] -Tlx 550397
NR.000000
DICHIARAZIONECEDICONFORMITA'
ECDECLARATIONOFCONFORMITY
Fabbricante/Manufacturer:MASEGENERATORSS.p.A.
Indirizzo/Address: ViaTortona 345, Pievesestina (FO)
IlsottoscrittoLuigi Foresti in qualitàdidirettore generale della MASEGENERATORSS.p.A., dichiara sotto la
propriaresponsabilitàcheilgruppoelettrogeno modello ......... :
The undersigned Luigi Foresti as MASE GENERATORS S.p.A. general manager declares, under his sole
responsability, that the generators model is..................:
Codice / Code Descrizione / Model Matricola/Serial N.
E'conformealle disposizionidelleDirettivedi seguitoelencate:
CEE89/392(come emendata delleDirettiveCEE 91/368 eCEE93/44)
CEE89/336(come emendata delleDirettiveCEE 92/31)
CEE73/23 modificatadaCEE 93/68.
Corresponds to the requirements of the following EEC Directives :
89/392/EEC (as amended by the Directive 91/368/EEC and 93/44/EEC)
89/336/EEC(as amended bythe Directive 92/31/EEC)
73/23//EEC as amended by 93/68/EEC.
Cesena, / / ......................................................
DirettoreTecnico
Technical Director
GENERATORS
MASE GENERATORS S.p.A.Sede legale ed Amm.: 47023 CESENA (FO) ITALY - Via Tortona, 345 - C.F./P.I. 00687150409 Cap. Soc. milioni
1250 interamente versato - Registro Società Tribunale Forl' n. 6818 - CCIAA Forl' n.164063 - c.c.p. n. 11541471 - EXPORT FO n. 006368
Nomefile: 41454.P65 Data di aggiornamento: 15/03/2000 Redatto: M.C.

- 3-
IS 3501 - 4501- 5501
mase
GENERATORS
1
3TAB "A"
S.A.E
Service
Grade
-30 -20 -10 0 10 20 30 40
Ambient temperature (
o
C)
40
20W
20W40
20
30
5W
5W30
10W
10W30
AAPERTO
OPEN
OUVERT
GEÖFNET
ABIERO
OPEN
2
1

IS 3501 - 4501- 5501
- 4 -
mase
GENERATORS
4
6
5
7
1
2
1
2
31

- 5-
IS 3501 - 4501- 5501
mase
GENERATORS
8
SCHEMAELETTRICO-WIRINGDIAGRAM-SCHEMAELECTRIQUE-SCHALTPLAN-ESQUEMAELE'CTRICO

IS 3501 - 4501- 5501
- 12 -
mase
GENERATORS
GB
CONTENTS
FIGURES .................................................... pag.2
TAB."A"TABLESUGGESTEDOILS ............ pag.2
WIRINGDIAGRAM ...................................... pag.4
1SAFETYREGULATIONS ............................. pag.13
2PRELIMINARYCHECKS ............................. pag.13
3GENERATORUSE ...................................... pag.13
Starting
GeneratorStop
4SAFETYDEVICES ...................................... pag.13
Low oilpressuredevice
Warning
Hightemperaturedevice
Alternatoroverload/overtemperaturedevice
Important
5MAINTENANCE ........................................... pag.14
Important
Enginemaintenance
Important
6INACTIVEPERIOD ...................................... pag.14
7CONTROLPANEL ....................................... pag.14
8PROTECTIONFUSE.................................... pag.8
9DIMENSIONANDWEIGHT .......................... pag.15
10 DESCRIPTIONWIRINGDIAGRAM ............... pag.15
11 TROUBLEMAINTENANCE .......................... pag.15
12 TROUBLESHOOTIN.................................... pag.15
13 TECHNICALFEATURES.............................. pag.16
A statement advising of the need to take care lest there be serious consequences resulting in
deathof personnelorinhazardto health.
A situation that could occur during the lifetime of a product, system or plant that has the
potentialforhumaninjury,damagetoproperty,damagetotheenvironment,oreconomicloss.
A statement advising of the need to take care lest serious consequences result in harm to
material items such as the asset or the product.
Importantinformation.
Drawingareprovidedbywayofexample.Shouldyourmachinebequitedifferentfromtheillustrationscontainedinthis
manual,thesafetyregulationsandrelevantinformationarealwaysgranted.
Themanufacturer'spolicyofconstantdevelopmentandupdatingmayleadtomodificationswithoutpriornotice.
DANGER
WARNING
CAUTION
INFORMATION

- 13 -
IS 3501 - 4501- 5501
mase
GENERATORS
GB
CONGRATULATIONSONHAVINGCHOSENAMASE
PRODUCT
This manual contains all the necessary information for
properinstallationanduseofthegenerator.It’sessential,
either for the customer’s safety and satisfaction or for
good reliability of the generator, to carry out proper
installationandacarefulpre-deliverytest.
A wrong installation or an oversight on testing may
compromise the efficiency of the generator and even
jeopardizethecustomer’ssafety.
Allinformationandillustrationsinthishandbookreferto
thelatestproduced model atthetime of printing.
Foranyfurtherinformation,pleasegetintouchwiththe
nearestMASESERVICECENTER,they’llbepleasedto
help you at any time.
MASEreservetherighttointroducechangeswithoutprior
notice.Nopartorillustrationcontainedinthishandbook
canbereproducedwithoutpreviousapprovalbyMASE
MASEGENERATORSS.p.A.
1SAFETYREGULATIONS
-Readcarefullyalltheinstructionsgiveninthishandbook
and in the installation manual; they are of the utmost
importanceforcorrectinstallationanduseoftheunitand
forpromptinterventionincaseofneed.
-Do not allow unskilled or untrained people to use the
unit.
-Do not allow children or animals to get close to the
generatorwhile itis working.
-Donothandlethegeneratorortheremotecontrolpanel
withwet hands;anymisuse maycauseelectric shocks.
-Anytestingoftheunitistobecarriedoutonlywhenthe
engine is stopped. Possible checks on the generator
when it’s running have to be performed only by skilled
workers.
2PRELIMINARYCHECKS
Onstarting thegeneratorforthefirst timeand afterany
servicing,itis advisable tomakesure that:
-Theoilisattherightlevelthroughtherodref.1Fig.1
, as per table for suggested oils.
-Thegeneratoriswellsecuredtothesoundproofingbox
by means of the proper bolts.
-The electric loads are disconnected so as to avoid
starting thegeneratoron load.
-Everyconnection(fuel,exhaust,remotecontrol,A.C.,
battery) has been properly carried out and there are no
connectionsinbad conditions.
-The water cock is open, as per (ref. 2 fig. 2)
-Ifanon-returnvalveisused,thecoolingcircuitfromthe
valveuptothepumphasbeenmanuallyfilled(ref.1fig.
2)
3GENERATORUSE
Beforestartingthegenerator,makesureallpreliminary
checks, as per item 1 , have been properly carried out
Starting
Tostarttheenginepushthebutton<<ON>>(fig.3ref.
4),allthepilotandwarninglampswillglowfor5sec.about
inaselfcontrolfunction,laterononlythe<<panelon>>
(fig.3ref.5)andthenstarttheenginepushingthebutton
<<Start >> (fig. 3 ref.3), for 5 sec. max. Release it only
whentheengineruns.Acorrectgeneratorfunctioningis
demostrated by the led (fig .3 ref. 6) glowing on. Once
started,thesafetydevicesofthegeneratorareautomaticily
activated(seeitem.4).
Generator Stop
The generator can be stopped ushing the <<OFF>>
buttonon thecontrolpanel (fig.3ref 2).
4SAFETYDEVICES
The generator has been equipped with a setof safety
devices in case ot any misuse or running trouble, as
follows:
- Low oil-pressure device:
itcausesthegeneratorshut-downincaseofinsufficient
oil pressure.Itsinterventionisshownbythewarninglight
going on(fig.3Ref.7). Itisusuallyenoughtotopupthe
oilbefore starting thegenerator again.
The low oil-pressure device does not necessarily show
the oil level; a check of the oil level is consequently
necessaryatregularintervals.
-High temperature device:
itcausesgeneratorshut-downincaseofhightemperatu-
reoftheengine.Itsinterventionisshownbythewarning
lightgoingon(fig.3ref.8).Shouldthisdevicecomeinto
operation,look for and eliminate the causes of the
interventionandthenstartthegeneratoragain.
-Alternator overload/over temperature device:
itcomesintooperation,stoppingthegenerator,incase
ofthermicorelectricoverloadofthealternator.
Itsinterventionisshownbytherelativewarninglightgoing
on(fig.3ref.9).Waituntilthetemperatureofthealternator
windings goes back to the normal values. It’s however
recommendedtolookforandeliminatethecausesofthe
interventionbeforestarting thegeneratoragain.
Ifoneoftheabovesafetydevicesintervenes,lookforand
eliminatethecausesoftheintervention,thenpushthe<<
STOP >> button to avoid that signal keeps stored.
WARNING
WARNING

IS 3501 - 4501- 5501
- 14 -
mase
GENERATORS
GB
WARNING
INFORMATION
7 CONTROL PANEL (fig. 3)
1)HOURSMETER
2)OFF BUTTON
3)START BUTTON
4)BUTTON ON
5)PANEL ONLED(GREEN)
6)GENERATOR OUTPUT LED(GREEN)
7)OIL PRESSURE LED(RED)
8)ENGINETEMPERATURELED (RED)
9)GENERATOR TEMPERATURE LED (RED)
When the unit stops because a circuit breaker trips, the
operatingtimeindicationdisappearsfromthecontrolpanel
displayandacodeappearstoindicate the cause of the
generatorstop.
In the table below all the codes and their meaning are
listed.
ALARMCODES
CODE CAUSEOF CIRCUIT-BREAKERTRIP
E - 80 Nopower ongenerator
E - 81 Lowoilpressure
E - 82 Highmotortemperature
E - 83 Highalternatortemperature
E - 85 Generatoroverload
E - 87 At 30" from start unit does not reach 80%
ofnominalvoltage
batt Low battery
Code E - 80 This code indicates that the unit has
stoppedbecauseof no voltage=0 Volt. Whenthiscode
appears, it means:
-thatthecontrolpanel isunabletomeasurethe alternator
voltagefor cut-offofan electricalconnection;
- that the alternator is damaged.
Code E - 81 Thiscodeindicates thattheunit has
stoppedbecausethe motorlubricationsystem pressure
is insufficient.
Code E - 82 Thiscodeindicates thattheunit has
stopped because the motor has reached too high
temperatures.
Code E - 83 Thiscodeindicates thattheunit has
stopped because the alternator has reached too high
temperatures.
In case of the two fuses (ref.1/2 Fig.4) got burnt,
a protectio inserts and does not allows the generator to
start.
5MAINTENANCE
Anyservicingistobecarriedoutwiththeenginestopped
after it has cooled enough, and only by skilled and
licensed staff.
Engine maintenance
The engine has to be serviced at regular intervals, as
shown in the table:
for any further and more detailed information,please
consult the handbook supplied by the engine
manufacturer, accompanying everygenerator.
Cheekoillevelbymeansoftheproperdipstick(fig.5ref.
1)andmakesureitisalwaysbetweentheminimumand
maximum levels of the dipstick.
Enginecartercapacity:
IS 3501 lt.1.1 IS 4501-5501 lt 1.65
Oiltoppingupandreplacementcanbecarriedoutthrough
thehole. (fig.1ref. 1).
Forchangingoil,removethelevelstickandreplaceoilwith
the special pipe..
We suggest to carry out the draining when the oil is still
warmenough, to allowan easy flowingout.
Beore executing the maintenance on the water-air
exchanger(rif.3fig.6),itisnecessarytoemptythewater
intake circuit throught the special cock.(ref. 3 fig. 2)
6INACTIVEPERIOD
Should the unit remain unused for a long time, it’s
necessary to act as follows:
-Replacesumpoil.
-Replaceoilfilter.
-Replacefuelfilter.
-Replacethezinc anodes (ref.1fig. 6)
-If the room temperature is near or below 0°C it is
indispensabletodraintheenginecoolingcircuitusingthe
levercock(ref.3fig.2)
-Lubrificatethewaterpumpimpeller.
CAUTION
INFORMATION

- 15 -
IS 3501 - 4501- 5501
mase
GENERATORS
GB
Code E - 85 Thiscodeindicatesthat theunithas
stoppedbecausethe voltagehasdropped tobelow70%
ofthenominal valueforlonger than15seconds.
Code E - 87 Thiscodeindicatesthat theunithas
stoppedbecausethegeneratorvoltage has not reached
80%ofthe nominalvalue30seconds afterstarting.This
could be caused by insufficient motor RPM or a broken
alternator.
batt This code indicates that the battery
is low. When this code appears, the generator is not
stopped.
When a circuit breaker has tripped with a consequent
generator stop, the panel must be reset by pressing the
“OFF” button in order to restart the unit.
If the unit is started and the alternator does not produce
voltage, or the control panel does not read voltage, the
latterswitchesoffcompletelyafter one minute, stopping
the unit.
8 PROTECTION FUSE ( fig. 4 )
1)RELAYCIRCUITFUSE
2)BATTERYCHARGERFUSE
9 DIMENSIONS AND WEIGHT( fig. 7 )
IS 3501 IS 4501-5501
L)Lengh mm.665(26.18") mm.733(28.8")
W)Width mm.423(16.65") mm.485(19")
H)Height mm.540(21.26") mm.578(22.7")
Weight Kg 78 (173lb) kg 110(244.4lb)
10 DESCRIPTION WIRING DIAGRAM (fig. 8 )
1ROTOR
2STATOR
3DIODE3A
4VARISTOR
5PRINTED CIRCUIT RELAY
6POWER TERMINAL BOARD
7RELAY CIRCUIT TERMINAL BOARD
8CONTROLPANELTERMINALBOARD
9FUSE 1A
10 CAPACITOR
11 BATTERY CHARGER REGULATOR
12 FUSE20A
13 STARTER
14 BATTERY
15 FUEL PUMP
16 FUEL SOLENOID
17 OIL PRESSURE SWITCH
18 OVERHEAD ENGINE THERMOSTAT
19 WATER TERMOSTAT
20 ALTERNATOR THERMOSTAT
11 TROUBLE MAINTENANCE
12 TROUBLE SHOOTING
INFORMATION
WARNING
COMPLAINT
PROBABLE REASON
Defective starting buttons l
Defective fuel solenoid l l
Defective battery Battery
cable section l
Defective starting motor l
Piping fuel filter choked l l
12V circuit fuse l
Avv./Ev.relay l
Too much oil in crankcase l l
Safety device intervention ll
Overload l
Defective governor linkage l
Worm valve guides l
Blocked valves l
Worm cylinder and position rings l
Defective injector ll
Defective injector pump ll l l
Defective feeding pump ll
BLACK SMOCKE START AND STOP UNSTABLE RUNNING DOES NOT START WHITE SMOCKE

IS 3501 - 4501- 5501
- 16 -
mase
GENERATORS
GB
13TECHNICALFEATURES
1cylinder,4stroke,internalcombustion
air-cooleddiesel
Displacement
Model
R.P.M.
Boreforstroke
PowerHp
Fuelconsumptiong./Hp.h
Starting system
Oil capacity
Maxinclination
ALTERNATOR
Continuousoutput
Powerfactor
Insulationclass
Frequecy Hz
Fuel
Synchronous,self-excited,single
phase, 2 poles, brushless
YANMAR YANMAR
L70AE L100AE
296cc 406cc
78 X 62
3000 3600 86 X 70
3000 3600
220 230
DIESEL
ELECTRIC
1,1 lt.
20°
5,5/6,1 6,0/6,7 220 230
DIESEL
ELECTRIC
1,65 lt.
20°
7,7/8,8 9/10
1
F 1
F
60
IS 3501 IS4501-5501
ENGINE
60
2700W 4800W
2900W 4000W

- 37 -
IS 3501 - 4501- 5501
mase
GENERATORS
IS 3501
Rif. Cod.Qty. Descrizione Description
190905 1Scatola filtro Air filter box
270812 1Massa filtrante Sponge
308900 1Piastra aspirazione Air intake protection
470802 1Cuffia in gomma Rubber cover
561156 1Collettore filtro aria Manifold
670543 cm 30 Tubo gasolio Pipe
770237 cm 25 Tubo gasolio Pipe
811067 2Fascetta Clamp
910812 1Portagomma Nipple
10 80120 1Sonda temp. cilindro Thermostat
11 10813 1Raccordo Fitting
12 10166 2Vite Screw
13 50257 1Puleggia pompa 50 HzPulley
50260 1Puleggia pompa 60 HzPulley
14 70196 1Cinghia 50 HzBelt
71010 1Cinghia 60 HzBelt
15 70808 1Cuffia in gomma Rubber cover
16 10814 1Gomito ottone Fitting
17 10614 2Portagomma Nipple
18 10825 4Fascetta 16x25 Clamp
19 61912 1Supporto pompa Pump bracket
20 61163 1Piastrina supporto pompa Plate
21 07166 1Staffa elettrovalvola Bracket
22 30647 1Elettrovalvola Fuel solenoid
23 30253 1Sonda temp. acqua 70 °C Thermostat
24 10342 1Rondella in rame Washer
25 62077 1Gomito miscelatore Exhaust manifold
26 97601 1Guarnizione scarico Gasket

IS 3501 - 4501- 5501
- 38 -
mase
GENERATORS
Rif. Cod. Qty. Descrizione Description
27 31001 1Pompa acqua mare Sea water pump
28 92819 1Tubo acqua d.15 Pipe
29 92738 1Anello elastico Snap ring
30 92603 1Anello elastico Snap ring
31 92734 1Alberino pompa Pump shaft
32 92604 2Cuscinetti Bearings
33 92737 1Distanziale Spacer
34 92602 1Anello OR OR-ring
35 92605 1Paraolio Oil seal
36 92735 1Corpo pompa Pump web
37 80161 1Girante Impeller
38 93312 1Guarnizione Gasket
39 92736 1Coperchietto Pump cover
40 92820 1Manicotto acqua Water pipe
41 10794 2Fascetta D 40/60 Clamp
42 70629 cm30 Tubo scarico Exhaust
43 97536 1Filtro olio Oil filter
44 10822 1Curva scarico Fitting
45 10303 2Rond.D10 Uni6592 Piana Zn Washer
46 31004 1Pompa gasolio Electric fuel pump
47 97502 1Raccordo elettrovalvola Union
48 97538 1Guarnizione OR Or gasket
49 07061 1Coperchio lato motore Alternator cover
50 02516 1Ventola Fan
51 04956 1Rotore IS3500 Rotor
52 97537 1Pressostato olio Oil pressure switch
53 06165 1Statore 115/230V 50Hz Stator 110/220V 50Hz
53 06015 1Statore 120/240V 60Hz Stator 120/240V 60Hz
54 10878 1Tirante centrale Central tie rod
55 80101 1Cuscinetto Bearing
56 10464 1Rond.Guida D24/10/8 H5 Zn Washer
57 70710 1Boccola Viton Viton Bushing
58 03768 1Coperchio lato cuscinetto Cover on bearing side
59 70647 1Passacavo Cable guide
60 08780 1Protezione alternatore Protection
61 80542 1Regolatore carica batt. Batt. charger regulator
62 11030 4Tirante alternatore Tie rod
63 10397 4Rond.D 6 Uni6592 Piana In Washer
64 20550 2Varistore Varistor
65 20549 2Diodo rotore Rotor diode
66 08875 1Cablaggio motore Electrical assy
67 70198 cm20 Tubo scarico olio Oil draining pipe
68 09020 1Griglia aspirazione alternatore Alternator protection
69 10791 2Fascetta D 8/16 Clamp
70 11048 1Raccordo Union
71 11071 1Vite Forata M16X 1,5 L.31 Screw
72 A10414 2Rondella Washer
73 50266 1Puleggia Pulley
74 10997 1Rond.Volano Motore Is3500 Zn Washer
75 20250 1Pompa olio Oil pump
76 10770 2Fascetta D 9.5 Clamp
77 71009 6x21 cm Spugna fonoassorbene Soundproof sponge
78 70220 cm20 Guarnizione adesiva 20x8 Gasket
79 70516 cm4 Guarnizione Gasket
80 70517 cm40 Guarnizione sportello Gasket
81 70210 cm70 Guarnizione adesiva 20x3 Gasket
80769 1Motore Yanmar L70 AE-DE Yanmar L70 AE-DE Engine

- 39 -
IS 3501 - 4501- 5501
mase
GENERATORS
58
IS 3501

IS 3501 - 4501- 5501
- 40 -
mase
GENERATORS
Rif. Cod. Qty. Descrizione Description
170854 1Scatola pannello comandi Printed circuit box
270786 40cm Guarnizione Gasket
391034 1Circuito stampato Printed circuit
431342 10mt Cavo pannello comandi Control panel cable
510844 4Supporto scheda relé Relay board support
630448 1Fusibile 5x20 1A Fuse
731003 1Scheda relè Relay board
831678 2Relè Relay
930921 1Fusibile lamellare 30A Fuse 30A
10 31973 1Coperchio fusibile Fuse cover
11 30925 1Portafusibile lamellare Fuse holder
12 30926 1Piastrina per portafusibile Fuse holder plate
13 31972 1Coperchio condensatore Capacitor cover
14 20206 1Condensatore 20 µF Capacitor 20 µF
15 70318 1Staffa condensatore Capacitor support
16 010432 2Lamierato cofano Box metal sheet
17 71069 88x4 cm Guarnizione sportello Box rubber gasket
18 71102* 1Serie spugne SP 19 Sponge set thickness 19
19 10092 28 Rivetto Rivet
20 10815 4Fermo cinghietta Plate
21 62212 1Scambiatore di calore Water-air heat exchanger
22 70211 16,5 cm Guarnizione adesiva 50x6 Adhesive gasket 50x6
23 010401 2Anello telaio Frame
24 62285 6Staffa battuta sportelli Plate
25 92837 1Pastiglia zinco Zinc anode element
26 80162 1Zinco con tappo Zinc anode with plug
27 04306 4Cinghietta in gomma Strap
28 08897 1Staffa fissaggio paratia motore Bracket
29 71001 1Spugna paratia Soundproof material
30 71068 1Paratia Bulkhead
31 70229 33 cm Guarnizione adesiva 10x3 Adhesive gasket 10x3
32 09135 2Staffa battuta cofani Bracket
33 71067 2Chiusura inferiore cassa nuda Bottom panel
34 10814 1Gomito Union
35 10614 1Portagomma Nipple
36 08609 1Supporto scambiatore Heat exchanger support
37 08898 1Staffa supporto alternatore Bracket
38 10566 1Passacavo DG29 Cable guide
39 70600 1Pomello Knob
40 71098 1Protezione scheda relè Relay board cover
41 11194 1Colonnetta Support
42 71037 2Pressacavo PG13,5 Cable guide
43 70128 4Antivibrante 40x30 Shock absorber
44 71082 1Fondo cassa Bottom soundproof box
45 62215 2Staffa di fissaggio cassa Bracket
46 62214 1Staffa antivibranti alternatore Shock absorbers bracket
47 70516 25 cm Guarnizione in gomma Rubber gasket
48 62213 1Staffa antivibranti motore Shock absorbers bracket
49 71084 2Chiusura portello Lock
50 010431 2Lamierato portello Front panel metal sheet
51 08904 2Staffa fissaggio sportello Bracket
52 92836 2Anello guarnizione sportello Gasket
53 70119 30x2 cm Profilato in gomma Rubber gasket
54 92835 1Cofano lato motore completo Soundproof cover eng. side
55 92833 2Sportello laterale Side panel assembly
56 92842 2Chiusura inferiore Bottom panel assembly
57 92834 1Cofano completo lato alternatore Soundproof cover alt. side
58 07664 1Comando a distanza 10mt. Remote control panel

- 41 -
IS 3501 - 4501- 5501
mase
GENERATORS
IS 4501-5501
79
Rif. Cod.Qty. Descrizione Description
190905 1Scatola filtro Air filter box
210770 2Fascetta 10x15 Clamp
370812 1Massa filtrante Sponge
470808 2Cuffia in gomma Rubber cover
507125 1Collettore filtro aria Manifold
670543 cm 37 Tubo gasolio Pipe
770237 cm 32 Tubo gasolio Pipe
811067 2Fascetta Clamp
910812 1Portagomma Nipple
10 80120 1Sonda temp. cilindro Thermostat
11 10813 1Raccordo Fitting
12 10166 2Vite Screw
13 50257 1Puleggia pompa 50 HzPulley
50260 1Puleggia pompa 60 HzPulley
14 71008 1Cinghia 50 HzBelt
71010 1Cinghia 60 HzBelt
70517 42 cm Guarnizione Gasket
16 10814 1Gomito ottone Fitting
17 10614 2Portagomma Nipple
18 10825 4Fascetta 16x25 Clamp
19 62058 1Supporto pompa Pump bracket
20 01584-0* 1Piastrina supporto pompa Plate
21 07166 1Staffa elettrovalvola Bracket
22 30647 1Elettrovalvola Fuel solenoid
23 30253 1Sonda temp. acqua 70 °C Thermostat
24 10342 1Rondella in rame Washer
25 62077 1Gomito miscelatore Exhaust manifold
26 92566 1Guarnizione scarico Gasket

IS 3501 - 4501- 5501
- 42 -
mase
GENERATORS
Rif. Cod. Qty. Descrizione Description
27 31001 1Pompa acqua Sea water pump
28 70442 cm34 Tubo D 15x23 Tube
29 92738 1Anello elastico Snap ring
30 92603 1Anello elastico Snap ring
31 92734 1Alberino pompa Pump shaft
32 92604 2Cuscinetti Bearings
33 92737 1Distanziale Spacer
34 92602 1Anello OR OR-ring
35 92605 1Paraolio Oil seal
36 92735 1Corpo pompa Pump web
37 80161 1Girante Impeller
38 93312 1Guarnizione Gasket
39 92736 1Coperchietto Pump cover
40 70442 cm34 Tubo D 15x23 Tube
41 10794 2Fascetta 30x60 Clamp
42 70629 cm30 Tubo d. 40 Pipe
43 97536 1Filtro olio Oil filter
44 10822 1Curva scarico Fitting
45 10303 2Rond.D10 Uni6592 Piana Zn Washer
46 97502 1Raccordo elettrovalvola Union
47 97538 1Guarnizione OR Or gasket
48 07061 1Coperchio lato motore Alternator cover
49 03750 1Ventola Fan
50 06489 1Rotore Rotor
51 97537 1Pressostato olio Oil pressure switch
53 08878 1Statore 115/230V 50Hz Stator 115/230V 50Hz
53 07161 1Statore 120/240V 50Hz Stator 120/240V 60Hz
54 10803 1Tirante centrale FM 5600 Central tie rod FM 5600
55 80101 1Cuscinetto Bearing
56 10464 1Rond.Guida D24/10/8 H5 Zn Washer
57 70710 1Boccola viton D 40,5 Bushing
58 03768 1Coperchio lato cuscinetto Cover on bearing side
59 70647 1Passacavo Cable guide
60 08780 4Protezione alternatore Protection
61 80542 4Regolatore carica batt. Batt. charger regulator
62 11069 2Tirante alternatore Tie rod
63 10397 2Rond.D 6 Uni6592 Piana In Washer
64 20550 1Varistore Varistor
65 20549 cm22 Diodo rotore Rotor diode
66 08875 1Cablaggio motore Electrical assy
67 70198 2Tubo scarico olio Oil draining pipe
68 09020 1Griglia aspirazione alternatore Alternator protection
69 10776 1Fascetta Clamp
70 11048 2Raccordo Union
71 11071 1Vite Forata M16X 1,5 L.31 Screw
72 A10414 1Rondella Washer
73 50268 1Puleggia Pulley
74 11032 1Adattatore puleggia Pulley adapter
75 20250 1Pompa olio Oil pump
76 70220 22cm Guarnizione adesiva 20x8 Adhesive gasket 20 x 8
77 71009 9x21 cm Spugna fonoassorbene Soundproof sponge
78 70516 7cm Guarnizione Gasket
79 70210 cm70 Guarnizione 20 X 3 Gasket
80755 1Motore Yanmar L100 AE-DEG Yanmar L100 AE-DEG Engine

- 43 -
IS 3501 - 4501- 5501
mase
GENERATORS
IS 4501-5501
58

IS 3501 - 4501- 5501
- 44 -
mase
GENERATORS
Rif. Cod. Qty. Descrizione Description
170854 1Scatola pannello comandi Printed circuit box
270786 40cm Guarnizione Gasket
391034 1Circuito stampato Printed circuit
431342 10mt Cavo pannello comandi Control panel cable
510844 4Supporto scheda relé Relay board support
630448 1Fusibile 5x20 1A Fuse
731003 1Scheda relè Relay board
831678 2Relè Relay
930921 1Fusibile lamellare 30A Fuse 30A
10 31973 1Coperchio fusibile Fuse cover
11 30925 1Portafusibile lamellare Fuse holder
12 30926 1Piastrina per portafusibile Fuse holder plate
13 31972 1Coperchio condensatore Capacitor cover
14 20209 1Condensatore 35 µF Capacitor 35 µF
15 70318 1Staffa condensatore Capacitor support
16 010434 2Lamierato cofano Box metal sheet
17 71070 73x4 cm Guarnizione sportello Box rubber gasket
18 71002* 1Serie spugne SP 19 Sponge set thickness 19
19 10092 28 Rivetto Rivet
20 10815 4Fermo cinghietta Plate
21 62218 1Scambiatore di calore Water-air heat exchanger
22 70211 17 cm Guarnizione adesiva 50x6 Adhesive gasket 50x6
23 010402 2Anello telaio Frame
24 62285 6Staffa battuta sportelli Plate
25 92837 1Pastiglia zinco Zinc anode element
26 80162 1Zinco con tappo Zinc anode with plug
27 04306 4Cinghietta in gomma Strap
28 08908 1Staffa fissaggio paratia motore Bracket
29 71000 1Spugna paratia Soundproof material
30 92846 1Paratia Bulkhead
31 70229 40 cm Guarnizione adesiva 10x3 Adhesive gasket 10x3
32 09134 2Staffa battuta cofani Bracket
33 71072 2Chiusura inferiore cassa nuda Bottom panel
34 10814 1Gomito Union
35 10614 1Portagomma Nipple
36 08603 1Supporto scambiatore Heat exchanger support
37 08763 1Staffa supporto alternatore Bracket
38 10566 1Passacavo DG29 Cable guide
39 70600 1Pomello Knob
40 71098 1Protezione scheda relè Relay board cover
41 11194 1Colonnetta Support
42 71037 2Pressacavo PG13,5 Cable guide
43 70650 4Antivibrante 40x30 Shock absorber
44 71083 1Fondo cassa Bottom soundproof box
45 62221 2Staffa di fissaggio cassa Bracket
46 62220 1Staffa antivibranti alternatore Shock absorbers bracket
47 70516 30 cm Guarnizione in gomma Rubber gasket
48 62219 1Staffa antivibranti motore Shock absorbers bracket
49 71084 2Chiusura portello Lock
50 010433 2Lamierato portello Front panel metal sheet
51 08904 2Staffa fissaggio sportello Bracket
52 92847 2Anello guarnizione sportello Gasket
53 70119 40x2 cm Profilato in gomma Rubber gasket
54 92848 1Cofano lato motore completo Soundproof cover eng. side
55 92849 2Sportello laterale Side panel assembly
56 92850 2Chiusura inferiore Bottom panel assembly
57 92851 1Cofano completo lato alternatore Soundproof cover alt. side
58 07664 1Comando a distanza 10mt. Remote control panel 10mt.
