Masimo Radius PPG Manual

Apply Sensor
Pair Radius PPG
1
2
3
Setup Instructions
GET TO KNOW YOUR SYSTEM
see back for sensor application
Sensor
Worn on your wrist and fingertip,
the sensor collects your data.
Snapped into the wrist portion
of the sensor, the chip sends your
data to the Masimo SafetyNet App.
Chip
Masimo SafetyNet displays Oxygen Saturation,
Pulse Rate, Respiration Rate and other data from
Radius PPG. It also allows data updates to your
care provider.
Masimo SafetyNet App
Radius PPG
Accept Masimo SafetyNet
Invitation
See instructions on the back
showing how to apply the sensor
to your wrist and finger
and insert the chip.
The invite will come to your email.
After you accept, download the
Masimo SafetyNet App and follow
setup instructions.
page 1 of 2
Getting Started
Masimo SafetyNet™
Warning: Do not self-diagnose or self-medicate on the basis of the
measurements. Always consult your doctor.
Under Masimo SafetyNet App
Settings, enter the Add Device
menu, and follow instructions
for pairing the Radius PPG to
your phone.
For more info go to:
masimo.com/masimo-safetynet
301295/10689B-0320
Masimo Safetynet | Build 1.0.0.0
To Purchase, Visit Avobus.com or call 1-800-674-3655

2.1 Sensor Set Up
How to Apply your Sensor
2.2 Apply Finger Sensor
2.3 Insert Chip
3. Place sensor on wrist as shown and
carefully thread the tip of the strap
through the open red loop
4. Wrap the loose end of the strap
around your wrist and press
1. Remove sensor from pouch 2. Peel off yellow label
to activate battery
Listen for
click to secure.
Look for light
to confirm
connection.
1. Insert the chip into the open
compartment on the sensor
2. Press down on the chip to secure
page 2 of 2
Place black
square ( )
on finger pad
1. Remove part of release liner
and place star ( ) on top
of fingernail of ring finger
2. Wrap halfway around finger. Make
sure the star and square are lined
up directly across from each other
4. Remove release liner
and continue to
wrap remainder
around finger
3. Squeeze top and
bottom of wrap
to secure
5. Adjust cable to
comfortable length
