Service Manual
Rad-97®
Pulse CO-Oximeter®

Masimo Corporation 3 www.masimo.com
The Rad-97® Pulse CO-Oximeter® Service Manual provides the necessary information for proper service of Rad-97. There may be information provided in this Service
Manual that is not relevant for your system.
Notice: Purchase or possession of this device does not carry any express or implied license to use with replacement parts which would, alone or in combination with this
device, fall within the scope of one of the relating patents.
Masimo Corporation
52 Discovery
Irvine, CA 92618, USA
Tel.: [phone]
Fax.: [phone]
www.masimo.com
EU authorized representative for Masimo Corporation:
MDSS GmbH
Schiffgraben 41
D-30175 Hannover, Germany
3149433
MEDICAL ELECTRICAL EQUIPMENT
WITH RESPECT TO ELECTRIC SHOCK, FIRE AND MECHANICAL HAZARDS ONLY IN ACCORDANCE WITH
ANSI/AAMI ES 60601-1:2005, CAN/CSA C22.2 No. 60601-1:2008, and applicable Particular (EN/ISO 80601-2-61:2011) and related Collateral (IEC 60601-1-8:2006) Standards for
which the product has been found to comply by Intertek.
Patents: www.masimo.com/patents.htm
® , Masimo® and Rad-97® are federally registered trademarks of Masimo Corporation.
© 2023 Masimo Corporation
Service Manual, Rad-97
This Service Manual provides information to perform basic service procedures on the following devices:
•Rad-97® Pulse CO-Oximeter®
•Rad-97® Pulse CO-Oximeter® with noninvasive blood pressure
•Rad-97® Pulse CO-Oximeter® with NomoLine® Capnography
Refer to the Rad-97 Operator’s Manual for comprehensive list of safety information, warnings, and cautions.

Masimo Corporation 5 www.masimo.com
Contents
Service Manual, Rad-97............................................................................................................................................................................................................................................ 3
About This Manual.................................................................................................................................................................................................................................................... 7
Safety Information, Warnings and Cautions.......................................................................................................................................................................................................... 7
Identify Rad-97 Version............................................................................................................................................................................................................................................ 9
Chapter 1: Maintenance Procedures .................................................................................................................................................................................................................... 11
Cleaning............................................................................................................................................................................................................................................................... 11
Chapter 2: Software Procedures........................................................................................................................................................................................................................... 13
Software Upgrade................................................................................................................................................................................................................................................ 13
Software Verification............................................................................................................................................................................................................................................ 13
Chapter 3: Service Procedures ............................................................................................................................................................................................................................. 15
Rad-97 Disassembly and Reassembly - All Versions and Models..................................................................................................................................................................... 15
Rad-97 Battery Replacement.............................................................................................................................................................................................................................. 19
Rad-97 TB-20 Connector Replacement.............................................................................................................................................................................................................. 35
Chapter 4: Electrical Safety Testing ..................................................................................................................................................................................................................... 49
Electrical Safety Testing...................................................................................................................................................................................................................................... 49
Chapter 5: Performance Verification Procedures ............................................................................................................................................................................................... 53
Battery Test ......................................................................................................................................................................................................................................................... 53
Power-On Self Test ............................................................................................................................................................................................................................................. 54
Touchscreen Function Test................................................................................................................................................................................................................................. 54
Noninvasive Blood Pressure Module Tests ........................................................................................................................................................................................................ 55
NomoLine® Capnography Verification................................................................................................................................................................................................................ 61
Alarm Limit Test................................................................................................................................................................................................................................................... 61
Nurse Call Setting Connections .......................................................................................................................................................................................................................... 61
Chapter 6: Troubleshooting and Repair............................................................................................................................................................................................................... 63
Repair .................................................................................................................................................................................................................................................................. 63
Troubleshooting................................................................................................................................................................................................................................................... 63
Chapter 7: Warranty and Service Information ..................................................................................................................................................................................................... 65
Repair Policy ....................................................................................................................................................................................................................................................... 65
Return Procedure ................................................................................................................................................................................................................................................ 65
Contacting Masimo.............................................................................................................................................................................................................................................. 65
Appendix: Rad-97 Component Diagrams............................................................................................................................................................................................................. 67
Rad-97 - Version 1 .............................................................................................................................................................................................................................................. 67
Rad-97 - Version 2 .............................................................................................................................................................................................................................................. 70
Index......................................................................................................................................................................................................................................................................... 73

Masimo Corporation 7 www.masimo.com
About This Manual
This Service Manual may contain technical information regarding troubleshooting, cleaning, electrical safety testing, functional verification and other pertinent service
guidance. Keep this Service Manual in a convenient location for ready reference during service and maintenance. This Service Manual is intended for technical service, repair
and biomedical personnel who maintain, troubleshoot and service this product as needed.
Important safety information relating to general servicing of Rad-97 appears in this manual. Read and follow any warnings, cautions, and notes presented throughout this
manual. The following are explanations of warnings, cautions, and notes.
A Warning is given when actions may result in a serious outcome (for example, injury, serious adverse effect, death) to the user.
WARNING: This is an example of a warning statement.
A Caution is given when any special care is to be exercised by the or user to avoid injury, damage to this device, or damage to other property.
CAUTION: This is an example of a caution statement.
A Note is given when additional general information is applicable.
Note: This is an example of a note.
A Service Warning is given when service and maintenance actions may result in a serious outcome (for example, injury, serious adverse effect, and death) to the patient or
user. The following is an example of a warning:
Service Warning: This is a sample of a service warning statement.
Authorized Service Personnel: Authorized Service Personnel is a user the manufacturer has deemed authorized to service products covered under the manufacturer’s
warranty. Service conducted by anyone other than an authorized service personnel voids the warranty. The authorized service personnel are allowed to only perform tasks
outlined in this service manual.
Safety Information, Warnings and Cautions
WARNING: This manual is intended for use by authorized service personnel only.
WARNING: DO NOT service or make any modifications to Rad-97 other than those described in this manual.
WARNING: Always ensure that the AC power has been disconnected from Rad-97 prior to opening up the device for service.
WARNING: DO NOT use any device that appears to be damaged. Contact Masimo Technical Support in regards to any device that appears damaged.
CAUTION: Prior to service, precautions must be taken to minimize potential damage to the device through electrostatic discharge (ESD):
•Use a conductive wrist strap attached to a good earth ground.
•Always discharge yourself by touching a grounded bare metal surface or approved anti-static mat before working with the device.
•Use an approved anti-static mat to cover your work surface.

Masimo Corporation 9 www.masimo.com
Identify Rad-97 Version
Two (2) versions of the Rad-97 device exist. The following procedure provides instructions for determining the version of the Rad-97. Determining the version of a Rad-97
determines how to follow the proper procedures for the device being serviced.
A simple way determine the version of the Rad-97 device is to look at the vents at the rear of the device:
•Version 1 - The back of the device has three columns of vents.
•Version 2 - The back of the device has two columns of vents.

Masimo Corporation 11 www.masimo.com
Chapter 1: Maintenance Procedures
This chapter covers how to properly clean Rad-97.
WARNING: Electrical shock and flammability hazard. Before cleaning Rad-97, always turn the unit off and disconnect the power cord from the back of the unit.
CAUTION: Do not autoclave, pressure sterilize, or gas sterilize Rad-97.
CAUTION: Do not soak or immerse Rad-97 in any liquid.
CAUTION: Use the cleaning solution sparingly. Allow unit to air dry. Excessive solution can flow into Rad-97 and cause damage to internal components.
CAUTION: Do not touch, press, or rub the display panels with abrasive cleaning compounds, instruments, brushes, rough-surface materials, or bring them into contact with
anything that could scratch the panel.
CAUTION: Do not use petroleum-based or acetone solutions, or other harsh solvents, to clean Rad-97. These substances attack the device’s materials and device failure
can result.
Cleaning
Rad-97 is a non-sterile and reusable device. The surface of the Rad-97 should be cleaned when the device is visibly dirty, before and after each procedure, and/or according
to hospital practice.
Do not allow liquids to enter the interior of Rad-97. Using the recommended cleaning solutions on the touchscreen will not affect the performance of Rad-97.
To clean the device:
1. Disconnect the AC Power Supply and ensure the sensor is not applied to the patient.
2. Wipe the outer surfaces using a dampened soft cloth with one of the recommended cleaning solutions twice or until the surfaces are free of any visible residue.
3. Dry the device thoroughly prior to using on a patient.
The surfaces of the Rad-97 may be cleaned with the following solvents or cleaning agents:
•70% Isopropyl Alcohol
•Glutaraldehyde
•10% bleach (5% - 5.25% sodium hypochlorite) to 90% water solution
•Quaternary ammonium chloride solutions
•0.5% hydrogen peroxide
CAUTION: Do not use undiluted bleach (5% - 5.25% sodium hypochlorite) or any cleaning solution other than those recommended here because permanent damage to the
device may occur.
CAUTION: To prevent damage, do not soak or immerse the device in any liquid solution.
CAUTION: Do not sterilize by irradiation, steam, and autoclave or ethylene oxide.
Vent Cleaning
The following procedure applies to Version 1 of Rad-97. Version 2 does not have these vents.
Vents may be cleaned using a small vacuum with brush attachment.
To clean, vacuum over the vents using a brush attachment, if available, to clear any debris.

Masimo Corporation 13 www.masimo.com
Chapter 2: Software Procedures
This chapter covers how to properly upgrade the software on Rad-97 and verify the upgrade is successful. These procedures should be performed by authorized service
personnel only.
Rad-97 software is updated using the Rad-97 Software Upgrade USB Drive and the USB port on the rear of Rad-97. The Software Upgrade USB Drive is available from
Masimo for authorized service personnel by calling Masimo Technical Support. See Contacting Masimo on page 65.
Software Upgrade
Before performing the upgrade procedure, ensure Rad-97 is plugged in and has power.
CAUTION: Do not turn off Rad-97 during the upgrade process. Interruption of the Rad-97 software upgrade may cause a corruption of the device.
1. Completely turn off Rad-97 by holding down the Power Button for 8 seconds, until the device emits two beeps.
2. Place the upgrade USB drive into the USB port on the back of Rad-97.
3. Turn on Rad-97 by pressing the Power Button once, and the upgrading process will initiate automatically. This process lasts approximately two minutes, and a
programming message is displayed on the screen during that time. Once programming is completed, Rad-97 will automatically power off, indicating that the
software upgrade has successfully completed.
4. Remove the upgrade USB drive from Rad-97 and verify the software is now at the proper version. See Software Verification on page 13.
Software Verification
To verify the software version, perform the following:
1. Turn on Rad-97 by pressing the Power Button once.
2. From the Main Screen, access the Main Menu and navigate to the About screen.
3. On the About screen in the Processor field, view the software version and confirm the software matches what has been installed.

Masimo Corporation 15 www.masimo.com
Chapter 3: Service Procedures
This chapter covers how to service components on both Version 1 and Version 2 of the Rad-97. No internal adjustment or recalibration is required. Service should be done by
authorized service personnel only.
Safety checks should be performed at regular intervals or in accordance with local and governmental regulations.
Rad-97 Disassembly and Reassembly - All Versions and Models
The following procedures instruct on opening up the device for service and assembling when service is complete. These procedures apply to all versions (V1 and V2) and all
models (base, NIBP and ISA) of the Rad-97.
Required Tools
The following tools are required when disassembling and reassembling the Rad-97:
•Needle-nose pliers
•3/32” Allen wrench (key)
•ESD conductive wrist strap
•ESD surface
•Small, flat-tipped screwdriver
Disassembly
CAUTION: Prior to service, precautions must be taken to minimize potential damage to the device through electrostatic discharge (ESD):
•Use a conductive wrist strap attached to a good earth ground.
•Always discharge yourself by touching a grounded bare metal surface or approved anti-static mat before working with the device.
•Use an approved anti-static work surface.
1. Turn off the device and unplug the power cord from the power entry module on the rear of the device.
2. Place the device on a anti-static surface.
3. Carefully pull the two (2) foot pads away from the case from to expose the housing screws.
CAUTION: The foot pads are easily damaged. Pull up from the outer end as indicated in the image.

Rad-97 Service Manual Chapter 3: Service Procedures
Masimo Corporation 16 www.masimo.com
4. Using the Allen wrench, remove the four (4) case screws (A).
5. Separate the case halves by gently pulling upwards on the loose case half. Take care not to pull the speaker cable out when lifting this case half.
6. Disconnect the speaker connector from the circuit board and set the case half aside.
Note: Use care to not lose the case screws when handling the case half.
Speaker Connector Rad-97 Version 1 Speaker Connector Rad-97 Version 2
7. Remove the swivel foot from the case by pulling upwards (Version 1 shown, Version 2 similar).
8. After disassembly, follow the procedure for the service required.

Rad-97 Service Manual Chapter 3: Service Procedures
Masimo Corporation 17 www.masimo.com
Reassembly
1. If removed, install the swivel foot into the case (Version 1 shown, Version 2 similar).
2. Verify that the status light is oriented in the case properly as shown.
•Status Light Rad-97 Version 1
•Status Light Rad-97 Version 2
3. Verify that all cable connections within the device are securely connected before proceeding.
•If any cables are not securely connected, adjust the cable such that it is reconnected securely.
4. For Rad-97 Version 1: Verify that this component in the picture below fits within the allotted slot in the chassis before proceeding.
If the component is not aligned properly, push it into place gently.
•In image A, the component sits within the slot and is not protruding outside of the designated area. This is the correct placement.

Rad-97 Service Manual Chapter 3: Service Procedures
Masimo Corporation 18 www.masimo.com
•In image B, the component is improperly aligned and protruding outside of the designated area. This is incorrect placement and must be corrected.
5. Connect the speaker connector.
Speaker Connector Rad-97 Version 1 Speaker Connector Rad-97 Version 2
6. Place the case halves together. Ensure no components or wiring become pinched between the case halves or any components before installing the screws.
7. Install the four (4) case screws (A) and tighten using the Allen wrench.

Rad-97 Service Manual Chapter 3: Service Procedures
Masimo Corporation 19 www.masimo.com
CAUTION: DO NOT exceed 28 oz-in (1.75 in-lbs) of torque to the case screws or the Rad-97 case may be damaged.
8. Press the foot pads into the case.
9. This completes the Rad-97 service procedure. Perform electrical safety testing and verify proper operation of Rad-97. See Chapter 4: Electrical Safety Testing
on page 49 and Chapter 5: Performance Verification Procedures on page 53.
Rad-97 Battery Replacement
The following procedure provides instructions for removing the existing battery and installing a replacement battery in Rad-97 devices.
Contact Global Services with questions regarding the Rad-97 battery replacement kit and/or the required tools part numbers. Contact information can be found at
http://service.masimo.com.
Supplied Parts List
The following parts are supplied in the Rad-97 Battery Replacement Kit:
1Battery
2Battery Update USB Drive
Required Tools
The following tools are required when servicing the battery on Rad-97:
•Needle-nose pliers
•3/32” Allen wrench (key)
•ESD conductive wrist strap
•ESD surface
•Small, flat-tipped screwdriver

Rad-97 Service Manual Chapter 3: Service Procedures
Masimo Corporation 20 www.masimo.com
Battery Removal (Version 1)
1. Disassemble the Rad-97 as instructed in Disassembly on page 15.
2. On Rad-97 with NomoLine Capnography, disconnect the capnography module electrical connector.
3. Lift the faceplate upwards from the case to disengage from the plastic T connections.
•For Rad-97 with noninvasive blood pressure, the NIBP tube can remain connected during the battery replacement procedure.
•For Rad-97 with NomoLine Capnography, the tubing will remain connected during the battery replacement procedure. Lift the faceplate very gently upwards
to disengage from the plastic T connections. Do not force the front assembly upwards. The capnography module will hit the rest of the assembly if forced.
Once the plastic T connections are disengaged, move the front assembly away from the rest of the assembly, being careful not to hit the capnography module
against anything or to disconnect the capnography tubing by pulling the front assembly too far away from the rest of the assembly.
CAUTION: Use care not to pull the bezel off of the faceplate when removing from the case.
