III. Layout of Terminals
- Mains Power Supply (16 V to 24 V DC or 12 V to 18 V AC) separatel fused
- 3 Bus Outlets on the Front (e.g. for Handheld Controller)
- Tra k Power Terminal
- Program Terminal
- Booster Interfa e (on the back)
- PC Interfa e RS232 (for Updates and PC-Controlling)
The bus outlets for handheld controllers, RC receivers, feedback modules etc. ma be
extended b an additional DiMAX® Adapter (Item No. 8138001).
1 Please read this hapter thoroughly before starting the operation!
1.1 Safety Details and Warnings
1.1.1 This Product is not suitable for children under the age of 8 ears. This product ma have sharp edges. In-
appropriate handling ma cause injuries. Operate this product only with products posted in this
manual. Measurements and electrical data are subject to change without further notice.
1.1.2 The DiMAX® 1210Z Central Station ma onl be used for the operation of digitall controlled model
railroads. Do never connect the bus connectors to our telephone line! This will result in irreparable and
costl damages.
1.1.3 The DiMAX® 1210Z Central Station ma onl be operated with digital components posted in this
manual. Even if other devices ma have the same connectors, an operation will not be possible and ma
result in damage of the DiMAX® 1210Z Central Station and other components.
1.1.4 Do not drop this product. Do not expose the DiMAX® 1210Z Central Station to shocks and do not shake
it. This ma result in damage.
1.1.5 Do not expose the DiMAX® 1210Z Central Station to direct heat, sunlight or a damp environment. This
ma affect the operation.
1.1.6 Do not open the DiMAX® 1210Z Central Station. There are no user-serviceable components inside. This
will void our warrant and ma result in damage.
1.1.7 Do not clean the DiMAX® 1210Z Central Station with abrasive cleaners, strong acids or corrosive clea-
ners. Use a plastic-compatible cleaner or dr soft cloth onl .
1.1.8 We stress the fact that this product is not a to . Do never leave our children unattended when operating
the DiMAX® 1210Z Central Station. Children should operate this item onl under supervision of adults.
1.1.9 Never use analog transformers on the same track with digital components. This goes for the operation
of catenar lines also.
1.1.10 Keep the ventilation grilles free of obstructions. These vents are needed for cooling the DiMAX® 1210Z
Central Station. Do not pour an liquids into these grilles; keep the DiMAX® 1210Z Central Station in a
dr environment.
1.1.11 Visuall inspect our digital components regularl , remove damaged items immediatel .
1.1.12 The right to change this product in accordance with technical progress is reserved b MASSOTH
ELEKTRONIK, Seeheim, German . We can not compensate for damages resulting from inappropriate
handling, non-observance of this manual, operation with altered or damaged items or items not suitable
for the DiMAX® 1210Z Central Station. We do not compensate for damages resulting from overheating
DiMAX® 1210Z Digital Central Station 4
