Matco Tools MSC4RFFDP18 User manual

MSC4RFFDP18 1 04/18/18
MSC4RFFDP18
Full Drawer Service Cart With Power Prep
Rat Fink 2018
Copyright © Professional Tool Products, 2018
All rights reserved
It is the responsibility of the owner to make sure all personnel read this manual prior to using the device. It is also the responsibility of the
device owner to keep this manual intact and in a convenient location for all to see and read. If the manual or product labels are lost or not
legible, contact Matco Tools for replacements. If the operator is not fluent in English, the product and safety instructions shall be read and
discussed with the operator in the operator's native language by the purchaser/owner or his designee, making sure that the operator
comprehends its contents. PLEASE NOTE: Loading cart beyond rated capacity may cause structural damage to the cart as well as personal
and /or property damage. Please educate your customers to the dangers of overloading.
• Read and follow all instructions in User's Manual.
• Do not load carts beyond rated capacity:
Overall Load Capacity ................................................. 600 LBS
Top Compartment ........................................................ 180 LBS
Drawers................................................................ 70 LBS each
PLEASE NOTE: Loading cart beyond rated capacity may cause structural damage to the cart as well as personal and/or property damage.
Please educate your customers to the "dangers of overloading".
• Lock lid and drawers before moving. • Apply brake on locking casters anytime cart is in place. • Do not pull cart. Push from handle on
end to move. • Units can tip or fall causing damage or personal injury. • Cart is designed to roll easily on flat surfaces and should not be
used on uneven or inclined surfaces. • Do not open more than one loaded drawer at a time. • Do not stand on or step in drawers. • Keep
children away from unit. • Wear gloves when lifting edges. • Before connecting to a power supply, always check to make sure the power
supply corresponds to the voltage required on the product. • Fully insert plug to reduce the risk of electric shock. • Always unplug when not
in use. • Disconnect power before installing or servicing. • Do not try to plug in unit or product when hands are wet or damp, or if standing
on a wet or damp surface or in water. • Never attempt to pick up unit or plugged in product that should fall in standing water. • This unit
is not waterproof and is intended for general use indoors. • Do not use in potentially dangerous locations, such as flammable or explosive
atmospheres. • Keep cord away from heat, oil, sharp edges or moving parts. • Failure to heed these warnings may result in personal injury
and/or property damage.
WARNING
WARNING: This product can expose you to chemicals including
nickel which is known to the State of California to cause cancer
and birth defects or other reproductive harm. For more
information go to www.P65Warnings.ca.gov.
ADVERTENCIA: Este producto le podrá exponer a ciertos
químicos, para incluir el níquel, conocidos en el Estado de
California por ocasionar cáncer y defectos congénitos u otros
daños a la reproducción. Para mayores informes, visite:
www.P65Warnings.ca.gov.
MISE EN GARDE: Ce produit peut vous exposer à des produits
chimiques y compris le nickel, reconnu par l’État de la Californie
comme causant le cancer et des anomalies congénitales ou
d’autres effets nuisibles sur la reproduction. Pour de plus amples
informations, aller à www.P65Warnings.ca.gov.

MSC4RFFDP18 2 04/18/18
MSC4RFFDP18
Full Drawer Service Cart With Power Prep
Rat Fink 2018
ASSEMBLY INSTRUCTIONS
SWIVEL CASTER with LOCKSWIVEL CASTER
M
A
T
C
O
T
O
O
L
S
M
A
T
C
O
T
O
O
L
S
Mount push handle/brackets assembly
(Part #12, 13) to the same side of the cart
as the swivel locking casters using the four
stove bolts, washers, and nuts provided.
Using 13mm socket completely tighten
all nuts.
#13
TOOLS NEEDED FOR ASSEMBLY:
• 13mm Socket or wrench
#12
#13

MSC4RFFDP18 3 04/18/18
MSC4RFFDP18
Full Drawer Service Cart With Power Prep
Rat Fink 2018
HARDWARE SPECIFICATIONS
4 pcs.4 pcs. 4 pcs.
TROUBLESHOOTING
Problem: Drawers appear not to fit, do not slide in accurately
and bump the cart sides.
Solution: The roller bearing slides must be fully engaged into
the mounting slots on all drawers. They potentially could fall
out of position during shipment. Check the side of the cart to
determine which slide is out of position.
Remove the drawer that is out of position. The drawer is
removed by the two clips on the actual roller bearing slide.
Simply push the roller bearing slide back down into position.
Insert the drawer back onto the roller bearing slides.
Problem: Back Lock/Unlock Switch does not engage
the drawer.
Solution: The inside Lock/Unlock slide potentially could fall
out of its groove during shipment. Unscrew the four screws
that are holding the Lock/Unlock slide in place.
Once the screws are removed, simply place the latch back
onto the slide and tighten the four screws back down.
Mounting Slots
16 pcs 16 pcs 16 pcs
Handle Hardware
Caster Hardware

Also available:
RSRBSDET8PK Ball Bearing Slide Detents (Pk of 8)
RSMSC4SBP Stealth Black Touch Up Paint (1oz.)
MSC4FC Set of 2 Fixed 5" x 2" Casters (Optional - Not included)
(Incl. 16 Bolts, 16 Spring Washers, & 16 Flat Washers)
MSC4RFFDP18 4 04/18/18
MSC4RFFDP18
Full Drawer Service Cart With Power Prep
Rat Fink 2018
No. Part No. Description Qty
1 RSLKB Lock with Keys 1
2 RSMSC4FDBP Set of 4 Bumpers (Including #17, (16) fasteners) 1
These bumpers are attached to the legs with fasteners and may not be
used on carts which originally did not use these fasteners because the
legs were not made to accommodate them.
3 MSC4FDP3SB Stealth Black 3" Drawer 3
4 MSC4FDP4SB Stealth Black 4" Drawer 2
5 MSC4FDP5SB Stealth Black 5" Drawer 1
6 RSSWCSBK 5" Swivel Caster / each (Black) 2
7 MSC4HBK 6 Pc. set Black Drawer Handles 2
8 RSMSC4FDBK Caster Bolt Kit (M8 x 16) (Black) 1
9 RSSWLCSBK 5" Swivel Locking Caster / each (Black) 2
10 Frame 1
11 RSMSC4FDLMPG Green Locking Mechanism (Excludes Lock) 1
12 RSMSC4HDL Push Handle 1
13 MSC4HBBK Handle bracket/pr. with hardwared (Black) 1
14 RSMSC4FD7LK EVA Liners for Drawers and Top (7pc) 1
15 RSGP Gas Piston/each 2
16 RSRBS Roller Bearing Slides/pair 6
17 RSFDFK Fastener (set of 4) 4
18 RSFDPCK Plastic Cap (set of 4) 1
19 MSC4FDLIDSBRF Stealth Black Lid 1
20 RS4RCP Rubber Cord Protector 1
Only items identified by part number are available separately.
