Matrix G7-S55 User manual

G7 SINGLE-STATION STRENGTH
GLUTE
MATRIX FITNESS SYSTEMS | 1600 LANDMARK DRIVE COTTAGE GROVE WI 53527 USA
To l l Fr ee 866.693.4863 matrixfitness.com Fax [phone]
PART # 0000088210
REV. 1.1
IMPORTANT SAFETY INFORMATION
It is the sole responsibility of the purchaser of MATRIX Fitness Systems products to instruct all individuals, whether they
are the end user or supervising personnel on proper usage of the equipment.
It is recommended that all users of MATRIX Fitness Systems exercise equipment be informed of the following information
prior to its use.
PROPER USAGE
Do not use any equipment in any way other than designed or intended by the manufacturer. It is imperative that MATRIX
Fitness Systems equipment be used properly to avoid injury.
Keep hands and feet clear at all times from moving parts to avoid injury.
CHECK FOR DAMAGED PARTS
1. DO NOT use any equipment that is damaged and or has worn or broken parts. Use only replacement parts supplied by
your country’s local MATRIX Fitness Systems dealer.
2. MAINTAIN LABELS AND NAMEPLATES: Do not remove labels for any reason. They contain important information.
If unreadable or missing, contact your MATRIX Fitness Systems dealer for a replacement.
3. SECURING EQUIPMENT: All equipment MUST be secured to the floor to stabilize and eliminate rocking or tipping over.
This must be performed by a licensed contractor.
4. MAINTAIN ALL EQUIPMENT: Preventative maintenance is the key to smooth operating equipment as well as keeping
your liability to a minimum. Equipment needs to be inspected at regular intervals.
5. Ensure that any person(s) making adjustments or performing maintenance or repair of any kind is qualified to do so.
MATRIX Fitness Systems dealers will provide service and maintenance training at our corporate facility upon request.
WARNING: SERIOUS INJURY CAN OCCUR ON THIS EQUIPMENT. FOLLOW THESE PRECAUTIONS TO
AVOID INJURY!
1. Never allow children on selectorized strength equipment. Teenagers must be supervised at all times while using
this equipment.
2. All warnings and instructions should be read and proper instruction obtained prior to use.
3. Cease exercise if you feel faint or dizzy. Obtain a medical exam before beginning an exercise program
4. Keep body, hair, clothing and fitness accessories free and clear of all moving parts.
5. Inspect the machine before use. DO NOT use machine if it appears damaged or inoperable.
6. Check to see that the selector pin is completely inserted into the weight stack.
7. NEVER use the machine with the weight stack pinned in an elevated position.
8. Never use dumbbells or other means to incrementally increase the weight resistance. Only use the means provided
directly from the manufacturer.
9. This equipment should only be used in supervised areas where access and control are regulated by the owner.
GLUTE PLACARD
ACTION FREQUENCY
Clean Upholstery Daily
Inspect Cables Daily
Clean Guide Rods Monthly
Inspect Hardware Monthly
Inspect Frame Bi-Annually
Clean Machine As Needed
Clean Grips As Needed
Lubricate Guide Rods As Needed
Upholstery & Grips should be cleaned with a non-ammonia based cleaner (like Simple Green) or a mild soap and water.
Guide rods should be lubricated with Teflon based lubricant. Apply the lubricant to a cotton cloth and then apply up and
down the guide rods.
MAINTENANCE CHECKLIST
PRODUCT SPECIFICATIONS
TECH SPECS
Overall dimensions 80”L X 38”W x 54”H
Weight 511 lbs
Shipping weight 544 lbs
WARRANTY (Valid in USA only)
Frame (not coatings) 10 years
Structural parts 10 years
Weight stacks 5 years
Pulleys 5 years
Pivot bearings 5 years
Any items not specified 3 years
Labor (excluding upholstery/cables/grips) 3 years
Upholstery/grips/springs 1 year
glute_091123.indd 1 11/24/09 1:57 PM

G7-S78 GLUTE
UNPACKING G7-S78 GLUTE
Thank you for purchasing a MATRIX Fitness product. This machine is an EN957-1 and EN957-2 complaint Class S product. Your
MATRIX G7-S78 GLUTE is inspected before it is packaged. It is shipped in multiple pieces to facilitate the compact
packaging of the machine. Prior to assembly, confirm all the components by matching them with the exploded diagrams. The
weight stack is shipped in separate packaging to reduce the weight of this box. Carefully unpack the unit from this box and
dispose of the packing materials in accordance with your local laws.
CAUTION
The weight of the G7-S78 GLUTE is 372 lbs. (169 kg) not including the weight stack. The weight stack tower is packaged
completely assembled for ease of installation; use extra caution when removing from its pallet during assembly. The weight stack
for this machine is 199 lbs. (90.2 kg). To avoid injury to yourself and prevent damage to the frame components, be sure to have
proper assistance removing the frame pieces from this box. Please be sure to install the equipment on a stable base, properly
level the machine and leave at least two feet of clearance to enter and exit the machine. Maximum user weight for this machine
is300 lbs.
INCLUDED TOOLS REQUIRED FOR ASSEMBLY
3MM L-Shaped Allen Wrench
4MM L-Shaped Allen Wrench
5MM L-Shaped Allen Wrench
6MM L-Shaped Allen Wrench
8MM L-Shaped Allen Wrench
10MM L-Shaped Allen Wrench
Phillips Screwdriver
8MM Open-End Wrench
17MM Open-End Wrench
If any items are missing please contact your country’s local MATRIX dealer for assistance.
0mm 10 20 30 40 50 60 70 80 90 100 1
10 120 130 140 150 160
Step 1
2Screw (M10X30L)Z02
Screw (M10X85L)
Nylon Nut (M10)B20
Screw (M8X75L)Q11
Lock Washer
Flat Washer (M10)
Z03
B24
Z09
QtyDescriptionItem
8
4
4
4
2
Frame Detail
60
wing and cover re-assembly.Q11 bolts won't be used anymore for the
then take apart the front and rear shields.Lift the aluminum wing and top cover,
Q11 Q11
Q11 Q11
B20
B24
Z02
Z03
Z03
B24 B20
B24
B24
Z03
Z09
Step 2
4Screw (M10X80L)Z08
4
8
16
4
16
Item Description Qty
Z01
B24
Z03
Flat Washer (M10)
Lock Washer
Z23 Arc-flat Washer
B20 Nylon Nut (M10)
Screw (M10X75L)
Z02 Screw (M10X30L) 4
Connect Detail
Z01
Z03
B24
B24
B20
B20 B24
B24 Z03 Z01
Z02
Z23
Z23 Z02
Z02
Z23
Z08 Z03 B24
B20
B20
B24
B24
B24
Z03
Z08
Step 3
2
2
2
2
2
Item Description Qty
C11
C54
M05
Fixing Plate
Thick Fixing Sleeve
C53 Cap End
C55 Internal C Clamp
Thin Fixing Sleeve
C49 Axle Sleeve 4
Pedal Detail
C11
C11
C49
C49
C53
C55
C54
M05
C49
C49 M05
C54C55 C53
Step 4
1Fixing PinZ102
Z14 1E Clip
2
Stopper Plate 1
1Nylon Nut (M10)
F06
B20
Small CamF05 Big CamF12 1
1
4
1
2
5
Item Description Qty
Z10
B24
F07 Flat Washer (M10) Screw (£X10XM8X46L)
F14 Flat Washer (M8)
F13 Fixing Block
Screw (M10X110L)
C52 Pulley Cover 1
Cable Routing Detail
F05
F12
F13
Z102 Z14
F13 F06 F07
F07 F14F07
B20
B24
B24
F07 B24
B24
F07
C52
Z10
F13Cable
Step 5
1
4
6
Item Description Qty
C51
Z06
Z05
Screw (M10X25L)
Screw (M10X20L)
Special Screw
C59 Flat Washer (M8) 1
Pad Detail
C51
C59
Z06
Z05
Z05
Hand Pad
Hand Pad
Chest Pad
Step 6
Fixing Plate
Rubber Pad
4
Item Description Qty
Z12 Screw (M10X60L)
Shield Detail
Lift the wing and top cover ,then assemble the front and rear shields to the frame.
60
Z12
Z12
Z12
Z12
