Matrix ULTRA Series User manual

MATRIX FITNESS | 1600 LANDMARK DRIVE COTTAGE GROVE WI 53527 USA
Toll Free 866.693.4863 | matrixfitness.com | Fax [phone]
PART # 0000088210
REV. 1.7
ULTRA SERIES
G7-S40 BICEPS CURL
PROPER USAGE
1. Do not exceed weight limits of the exercise device.
2. If applicable, set safety stops to appropriate height.
3. If applicable, adjust seat pads, leg pads, foot pads, range of motion
adjustment, or any other type of adjustment mechanisms to a
comfortable start position. Make certain that the adjusting mechanism is
fully engaged to prevent unintentional movement and to avoid injury.
4. Sit on bench (if applicable) and get into appropriate position for exercise.
5. Exercise using no more weight than you can safely lift and control.
6. In a controlled manner, perform exercise.
7. Return weight to its fully-supported start position.
MAINTENANCE CHECKLIST
ACTION FREQUENCY
Clean Upholstery * Daily
Inspect Cables Daily
Clean Guide Rods Monthly
Inspect Hardware Monthly
Inspect Frame Bi-Annually
Clean Machine As Needed
Clean Grips * As Needed
Lubricate Guide Rods † As Needed
* Upholstery & Grips should be cleaned with a mild soap and water
or a non-ammonia based cleaner.
† Guide rods should be lubricated with Teon based lubricant. Apply the
lubricant to a cotton cloth and then apply up and down the guide rods.
PRODUCT SPECIFICATIONS
TECH SPECS
Maximum User Weight 136 kg / 300 lbs.
Maximum Training Weight 91 kg / 200 lbs.
Product Weight 251 kg / 554 lbs.
Overall Dimensions (L x W x H)* 138 x 160 x 130 cm /
55” x 63” x 51”
* Ensure a minimum clearance width of 914 mm / 36” for access to and
passage around MATRIX strength equipment.
WARRANTY
Valid in North America only
Frame (not coatings) * 10 years
Weight stacks 5 years
Pulleys 5 years
Pivot bearings 5 years
Any items not specied 3 years
Labor (excluding upholstery/cables/grips) 3 years
Upholstery/cables/grips/springs 1 year
Accessories 6 months
* Frame is dened as the welded metal base of the unit and does not include
removable parts.
Product specications subject to change without notice.
IMPORTANT SAFETY INFORMATION
It is the sole responsibility of the purchaser of MATRIX products to instruct all
individuals, whether they are the end user or supervising personnel on proper usage
of the equipment.
It is recommended that all users of MATRIX exercise equipment be informed of the
following information prior to its use.
Do not use any equipment in any way other than designed or intended by the
manufacturer. It is imperative that MATRIX equipment be used properly to avoid injury.
INSTALLATION
1. STABLE AND LEVEL SURFACE: MATRIX exercise equipment must be installed
on a stable base and properly leveled.
2. SECURING EQUIPMENT: Manufacturer recommends that all stationary MATRIX
strength equipment be secured to the oor to stabilize equipment and eliminate
rocking or tipping over. This must be performed by a licensed contractor.
All anchor points must be able to withstand 750 lbs. (3.3 kN) pull-out force.
MAINTENANCE
1. DO NOT use any equipment that is damaged and or has worn or broken parts.
Use only replacement parts supplied by your country’s local MATRIX dealer.
2. MAINTAIN LABELS AND NAMEPLATES: Do not remove labels for any reason.
They contain important information. If unreadable or missing, contact your
MATRIX dealer for a replacement.
3. MAINTAIN ALL EQUIPMENT: Preventative maintenance is the key to smooth
operating equipment as well as keeping your liability to a minimum. Equipment
needs to be inspected at regular intervals.
4. Ensure that any person(s) making adjustments or performing maintenance or
repair of any kind is qualied to do so. MATRIX dealers will provide service and
maintenance training at our corporate facility upon request.
ADDITIONAL NOTES
This equipment should only be used in supervised areas where access and control is
specically regulated by the owner. It is up to the owner to determine who is allowed
access to this training equipment. The owner should consider a user’s: degree of
reliability, age, experience, etc.
This training equipment meets industry standards for stability when used for its
intended purpose in accordance with the instructions provided by the manufacturer.
This training equipment is in compliance with EN 957-1 and the relevant portions of
EN 957-2 and EN 957-4.
WARNING
DEATH OR SERIOUS INJURY CAN OCCUR ON THIS EQUIPMENT. FOLLOW THESE PRECAUTIONS
TO AVOID INJURY!
1. NEVER allow children on strength training equipment. Teenagers must be supervised at all times
while using this equipment.
2. All warnings and instructions should be read and proper instruction obtained prior to use. Use this
equipment for its intended purpose ONLY.
3. Inspect the machine before use. DO NOT use machine if it appears damaged or inoperable.
4. NEVER allow resistance straps, ropes or other means to be attached to this equipment, as this may
result in serious injury. NEVER use this equipment for support during stretching, as this may result in
serious injury.
5. ALWAYS use a spotter.
6. Do not exceed the weight capacity of this equipment.
7. Balance the weight applied to this equipment and/or any barbell. Where applicable, use retention
devices to retain weight discs.
8. Injuries to health may result from incorrect or excessive training. Cease exercise if you feel faint or
dizzy. Obtain a medical exam before beginning an exercise program.
9. Keep body, hair, clothing, and tness accessories free and clear of all moving parts.
10. Manufacturer recommends that all equipment be secured to the oor to stabilize and eliminate
rocking or tipping over. Use a licensed contractor.
11. DO NOT REMOVE THIS LABEL. REPLACE IF DAMAGED OR ILLEGIBLE.
12. For Smith Machines: Visually ensure lifting bar catch rods are fully engaged and seated in the hooks
before releasing the load and exiting the machine.
13. For Smith Machines: ALWAYS set both adjustable stops to the same height when using this machine.
14. Adjustable safety stops, if present, must be used at all times.
15. For equipment with adjustable stops: PROPER adjustable stop height depends on the exercise
performed.Adjust as follows:
• Remove weight from lifting bar.
• For squats, perform the exercise and determine the lowest comfortable position of the bar that
ensures no spinal compression. For other exercises, perform the movement and determine the
lowest point of bar travel that is comfortable without the bar contacting your body.
• Position both stop catches to stop the bar at this point. Ensure that they are completely seated on
the stop rods or catch plate.
• Load weights onto the lifting bar and carefully perform the exercise.
16. When adjusting any adjustable mechanism (seat position, pad location, range of motion limiter, pulley
carriage, or any other type of adjuster), make certain that the adjusting pin is fully engaged in the hole
to avoid injury.
17. Keep hands and feet clear at all times from moving parts to avoid injury.
MX14_Ultra_G7-S40_OM_r1_7.indd 1 7/22/15 8:59 AM

ULTRA SERIES (G7-S40) BICEPS CURL
UNPACKING ULTRA (G7-S40) BICEPS CURL
Thank you for purchasing a MATRIX Fitness product. Your ULTRA SERIES (G7-S40) Biceps Curl is inspected before it is packaged. It is shipped in multiple
pieces to facilitate the compact packaging of the machine. Prior to assembly, conrm all the components by matching them with the exploded diagrams. Carefully
unpack the unit from this box and dispose of the packing materials in accordance with your local laws.
CAUTION
To avoid injury to yourself and prevent damage to the frame components, be sure to have proper assistance removing the frame pieces from this box. Please be
sure to install the equipment on a stable base, properly level the machine and leave at least two feet of clearance to enter and exit the machine.
TOOLS REQUIRED FOR ASSEMBLY
3MM L-Shaped Allen Wrench 10MM L-Shaped Allen Wrench
4MM L-Shaped Allen Wrench Phillips Screwdriver
5MM L-Shaped Allen Wrench 8MM Open-End Wrench
6MM L-Shaped Allen Wrench 17MM Open-End Wrench
8MM L-Shaped Allen Wrench Guide Rod Lubrication
If any items are missing please contact your country’s local MATRIX dealer for assistance.
Step 3
8
8
4
2
4
C17
C30
J18
J20
J32 Shaft
Swirl Spring
Connect Rod
Screw (M8x25L)
Pulley Cover
Item Description Qty
J20
J18
C30 C17
C30C17
C30C17
C17
C30
C30
C30
C30
J35
J32
J20
C30
C17
C17
J18
C17
C17
J33
J32
Step 1
Lift the aluminumn wing and top cover,
then take apart the front and rear sheilds.
Q11 bolts won't be used anymore for the
wing and cover re-assembly.
60
Q11
Q11
Item Description Qty
B22 Flat Washer(M10) 18
B23 Nut(M10)
Z02 Screw (M10X30L)
Z04 Lock Washer(M10) 14
Z05 Screw (M10X90L)
Z23 Arc-Flat Washer
Z11 Screw (M10X75L) 4
6
2
12
6
Z23
Z02
Z23
Z02
B22Z04
Z11
B22
Z04
B22
Z11 Z04 Z11
B23
B22
B22
B23 B23 B22
B23
B22
Z02
Z02
Z02 Z23
Z23
Z02
Z04
B22
Z04
B22
Z02
Z04
B22
Z02
Z02
B22Z04
B23
Z23
B23
Z23
Z05
Z04
B22
Step 4
Item Description Qty
2
Z03 Screw (M10X20L) 4
Screw (M10X75L)Z17
Z06 Screw (M10X20L) 4
Z03 Z03
Seat Pad
Back Pad
Z04
Z04
Z06
Z06
Step 5
Q02
Q03
Q04
60
Z12
Z12
Z12
Z12
Item Description Qty
Lift the wing and top cover ,then assemble
the front and rear shields to the frame.
Screw (M8X60L) 4
Q02 Right-Front Shield 1
Q03 Rear Shield 1
Q04 Left-Front Shield 1
Z12
Rubber Pad
Fixing Plate
Adjustable
Step 2
F11
B23
B23 F06
F05
Take apart from the cam
F13
F12
B25
B44
B44
B44
Item Qty
Description
B44 Flat Washer (M10)
B23 Nut (M10)
B25 Flat Washer (M8)
F05 Cam Stopper Rubber
F06 Screw (M8)
F11 Cap Nut (M10)
F12 Button Screw (M10X40L)
F13 Stopper plate
Z44 Screw (M10X22L)
Q14 Screw (M8X20L)
Z32 Round Plate (φ32xφ20.2x2.0T)
Z25 Flat Washer (φ8.2xφ30.0x1.5T)
Z10 Screw (M10X45L)
C17 Cover
Z15 External C type clamp S-25
Z16 Washer (φ35.0x0.3T)
D18 Cap
Z33 External C type Clamp S-20
10
6
2
2
2
2
4
2
2
2
2
2
2
2
2
2
4
2
Z16 Z15 C17
Z15
F06
F05
B23
B23
F11
F13
B23
F12
B25
B25
F12
Z10
Q14 Z33
Z25 Z32
F13
F11
B23
F06 F05
B23
Z33
C17
Z16
B44
B44
B44
B44
B44
B44
B44
Cable Rounting Detail
Z10
Z44
D18
D18
Z44
Z44
Z44
Z32
Q14
Z25
IMPORTANT NOTICE
PLEASE NOTE:
Be sure to remove the insulating
sheet when installing the
Rep Counter.
PLACARD
0mm 10 20 30 40 50 60 70 80 90 100 110 120 130
