Max SuperFramer SN883RH2 Operating instructions

SN883RH2
SN890CH2<34>
PNEUMATIC NAILER
CLOUEUSE PNEUMATIQUES
CLAVADORAS NEUMATICAS
PARA PEINES DE CLAVO
OPERATING AND MAINTENANCE MANUAL
MANUEL D'UTILISATION ET D'ENTRETIEN
MANUAL DE OPERACIONES Y MANTENIMIENTO
BEFORE USING THIS TOOL, STUDY THIS MANUAL TO ENSURE SAFETY WARNING AND IN-
STRUCTIONS.
KEEP THESE INSTRUCTIONS WITH THE TOOL FOR FUTURE REFERENCE.
AVANT D’UTILISER CET OUTIL, LIRE CE MANUEL ET LES CONSIGNES DE SÉCURITÉ AFIN DE
GARANTIR UN FONCTIONNEMENT SÛR.
CONSERVER CE MANUEL EN LIEU SÛR AVEC L’OUTIL AFIN DE POUVOIR LE CONSULTER UL-
TÉRIEUREMENT.
ANTES DE UTILIZAR ESTA HERRAMIENTA, LEA DETENIDAMENTE ESTE MANUAL PARA FAMILIARIZARSE CON
LAS ADVERTENCIAS E INSTRUCCIONES DE SEGURIDAD.
CONSERVE ESTAS INSTRUCCIONES JUNTO CON LA HERRAMIENTA PARA FUTURAS CONSULTAS.
SN883RH2 SN890CH2<34>
WARNING
AVERTISSEMENT
ADVERTENCIA
SN883RH2_SN890CH2(34).book 1 ページ ２０１１年７月８日 金曜日 午後６時１分

2
INDEX INDEX ÍNDICE
ENGLISH Page 3 to 18
FRANÇAIS Page 19 to 34
ESPAÑOL Page 35 to 50
DEFINITIONS OF SIGNAL WORDS
WARNING: Indicates a potentially hazardous situation which, if not avoided, could result in death or
serious injury.
CAUTION: Indicates a potentially hazardous situation which, if not avoided, may result in minor or
moderate injury.
NOTE: Emphasizes essential information.
DÉFINITIONS DES DIFFERÉNTS DEGRÉS D’ AVERTISSEMENTS
AVERTISSEMENT Indique une situation éventuellement dangereuse qui, si elle n’est pas contournée, pour-
rait provoquer la mort ou des blessure sérieuses.
ATTENTION Indique une situation éventuellement dangereuse qui, si elle n’est pas contournée, pour-
rait provoquer des blessures légères à moyennement sérieuses.
REMARQUE Souligne des informations importantes.
DEFINICIÓN DE LAS INDICACIONES DE ADVERTENCIA
!ATENCION! Indica una situación potencialmente peligrosa que podría causar la muerte o graves le-
siones si no se evita.
!PRECAUCIÓN! Indica una situación potencialmente peligrosa que podría causar lesiones menos graves
o leves si no se evita.
NOTA: Resalta informaciones importantes.
SN883RH2_SN890CH2(34).book 2 ページ ２０１１年７月８日 金曜日 午後６時１分

3
INDEX
1. SAFETY INSTRUCTIONS ..................................................3
2. SPECIFICATIONS AND TECHNICAL DATA ....................7
3. AIR SUPPLY AND CONNECTIONS ..................................8
4. INSTRUCTIONS FOR OPERATION ................................10
5. MAINTENANCE FOR PERFORMANCE..........................18
6. STORAGE ........................................................................18
7. TROUBLE SHOOTING/REPAIRS....................................18
1. SAFETY INSTRUCTIONS PRECAUTIONS ON USING THE TOOL
1. WEAR SAFETY GLASSES OR GOGGLES
Danger to the eyes always exists due to the
possibility of dust being blown up by the ex-
hausted air or of a fastener flying up due to
the improper handling of the tool. For these
reasons, safety glasses or goggles shall al-
ways be worn when operating the tool.
The employer and/or user must ensure that
proper eye protection is worn. Eye protection
equipment must conform to the require-
ments of the American National Standards
Institute, ANSI Z87.1 (Council Directive 89/
686/EEC of 21 DEC. 1989) and provide both
frontal and side protection.
The employer is responsible to enforce the
use of eye protection equipment by the tool
operator and all other personnel in the work
area.
ENGLISH
OPERATING AND MAINTENANCE MANUAL
BEFORE USING THIS TOOL, STUDY THIS MANUAL TO ENSURE SAFETY WARNING AND IN-
STRUCTIONS.
KEEP THESE INSTRUCTIONS WITH THE TOOL FOR FUTURE REFERENCE.
WARNING
TO AVOID SEVERE PERSONAL INJURY
OR PROPERTY DAMAGE
BEFORE USING THE TOOL, READ CARE-
FULLY AND UNDERSTAND THE FOLLOW-
ING "SAFETY INSTRUCTIONS". FAILURE
TO FOLLOW WARNINGS COULD RESULT
IN DEATH OR SERIOUS INJURY.
WARNING
SN883RH2_SN890CH2(34).book 3 ページ ２０１１年７月８日 金曜日 午後６時１分

4
NOTE: Non-side shielded spectacles and
face shields alone do not provide adequate
protection.
2. EAR PROTECTION MAY BE REQUIRED
IN SOME ENVIRONMENTS
As the working condition may include expo-
sure to high noise levels which can lead to
hearing damage, the employer and user
should ensure that any necessary hearing
protection is provided and used by the oper-
ator and others in the work area.
3. DO NOT USE ANY POWER SOURCE EX-
CEPT AN AIR COMPRESSOR
The tool is designed to operate on com-
pressed air. Do not operate the tool on any
other highpressure gas, combustible gases
(e.g., oxygen, acetylene, etc.) since there is
the danger of an explosion. For this reason,
absolutely do not use anything other than an
air compressor to operate the tool.
4. OPERATE WITHIN THE PROPER AIR
PRESSURE RANGE
The tool is designed to operate within an air
pressure range of 70 to 100 p.s.i. (5 to 7 bar).
The pressure should be adjusted to the type
of the work being fastened. The tool shall
never be operated when the operating pres-
sure exceeds 120 p.s.i. (8 bar).
Never connect the tool to air pressure which
potentially exceeds 200 p.s.i. (14 bar) as the
tool can burst.
5. DO NOT OPERATE THE TOOL NEAR A
FLAMMABLE SUBSTANCE
Never operate the tool near a flammable
substance (e.g., thinner, gasoline, etc.). Vol-
atile fumes from these substances could be
drawn into the compressor and compressed
together with the air and this could result in
an explosion.
6. NEVER USE THE TOOL IN AN EXPLO-
SIVE ATMOSPHERE
Sparks from the tool may ignite atmospheric
gases, dust or other combustible materials.
7. DO NOT USE A WRONG FITTINGS
The connector on the tool must not hold
pressure when air supply is disconnected. If
a wrong fitting is used, the tool can remain
charged with air after disconnecting and thus
will be able to drive a fastener even after the
air line is disconnected, possibly causing in-
jury.
8. DISCONNECT THE AIR SUPPLY AND
EMPTY THE MAGAZINE WHEN THE
TOOL IS NOT IN USE
Always disconnect the air supply from the
tool and empty the magazine when operation
has been completed or suspended, when un-
attended, moving to a different work area, ad-
justing, disassembling, or repairing the tool,
and when clearing a jammed fastener.
5
7
70
100
Thinner Gasoline
SN883RH2_SN890CH2(34).book 4 ページ ２０１１年７月８日 金曜日 午後６時１分

5
9. INSPECT SCREW TIGHTNESS
Loose or improperly installed screws or bolts
cause accidents and tool damage when the
tool is put into operation. Inspect to confirm
that all screws and bolts are tight and prop-
erly installed prior to operating the tool.
10. DO NOT TOUCH THE TRIGGER UNLESS
YOU INTEND TO DRIVE A FASTENER
Whenever the air supply is connected to the
tool, never touch the trigger unless you in-
tend to drive a fastener into the work. It is
dangerous to walk around carrying the tool
with the trigger pulled, and this and similar
actions should be avoided.
11. NEVER POINT THE DISCHARGE OUTLET
TOWARD YOURSELF AND OTHER PER-
SONNEL
If the discharge outlet is pointed toward peo-
ple, serious accidents may be caused when
misfiring. Be sure the discharge outlet is not
pointed toward people when connecting and
disconnecting the hose, loading and unload-
ing the fasteners or similar operations.
12. USE SPECIFIED FASTENERS
(SEE PAGE 7)
The use of fasteners other than specified
fasteners will cause the tool malfunction. Be
sure to use only specified fasteners when
operating the tool.
13. PLACE THE DISCHARGE OUTLET ON
THE WORK SURFACE PROPERLY
Failure to place the discharge outlet of the
nose in a proper manner can result in a fas-
tener flying up and is extremely dangerous.
14. KEEP HANDS AND BODY AWAY FROM
THE DISCHARGE OUTLET
When loading and using the tool, never
place a hand or any part of body in fastener
discharge area of the tool. It is very danger-
ous to hit the hands or body by mistake.
15. DO NOT DRIVE FASTENERS CLOSE TO
THE EDGE AND CORNER OF THE WORK
AND THIN MATERIAL
The workpiece is likely to split and the fas-
tener could fly free and hit someone.
SN883RH2_SN890CH2(34).book 5 ページ ２０１１年７月８日 金曜日 午後６時１分

6
16. DO NOT DRIVE FASTENERS ON TOP OF
OTHER FASTENERS
Driving fasteners on the top of other fasten-
ers may cause deflection fasteners which
could cause injury.
17. REMOVING THE FASTENERS AFTER
COMPLETING OPERATION
If fasteners are left in the magazine after the
completion of operation, there is the danger
of a serious accident occurring prior to the
resumption of operation, should the tool be
handled carelessly, or when connecting the
air fitting. For this reason, always remove all
fasteners remaining in the magazine after
completion of the operation.
18. CHECK OPERATION OF THE CONTACT
TRIP MECHANISM FREQUENTLY IN
CASE OF USING A CONTACT TRIP TYPE
TOOL
Do not use the tool if the trip is not working
correctly as accidental driving of a fastener
may result. Do not interfere with the proper
operation of the contact trip mechanism.
19. WHEN USING THE TOOL OUTSIDE OR
ELEVATED PLACE
When fastening roofs or similar slanted sur-
face, start fastening at the lower part and
gradually work your way up. Fastening back-
ward is dangerous as you may lose your foot
place.
Secure the hose at a point close to the area
you are going to drive fasteners. Accidents
may be caused due to the hose being pulled
inadvertently or getting caught.
20. NEVER USE THE TOOL IF ANY PORTION
OF THE TOOL CONTROLS (e.g., TRIG-
GER, CONTACT ARM) IS INOPERABLE,
DISCONNECTED, ALTERED OR NOT
WOKING PROPERLY
21. NEVER ACTUATE THE TOOL INTO FREE
SPACE
This will avoid any hazard caused by free fly-
ing fasteners and excessive strain of the
tool.
22. ALWAYS ASSUME THAT THE TOOL
CONTAINS FASTENERS
23. RESPECT THE TOOL AS A WORKING IM-
PLEMENT
24. NO HORSEPLAY
25. NEVER LOAD THE TOOL WITH FASTEN-
ERS WHEN ANY ONE OF THE OPERAT-
ING CONTROLS (e.g., TRIGGER,
CONTACT ARM) IS ACTIVATED
26. WEAR THE GLOVES DEPENDING ON
THE WORKING CONDITION
27. WHEN DISPOSING THE MACHINE OR ITS
PARTS, FOLLOW THE RELEVANT NA-
TIONAL RULES
OBSERVE THE FOLLOWING GENER-
AL CAUTION IN ADDITION TO THE
OTHER WARNINGS CONTAINED IN
THIS MANUAL
•Do not use the tool as a hammer.
•Always carry the tool by the grip, never car-
ry the tool by the air hose.
•The tool must be used only for the purpose
it was designed.
•Never remove, tamper with the operating
controls (e.g., TRIGGER, CONTACT ARM)
•Keep the tool in a dry place out of reach of
children when not in use.
•Do not use the tool without Safety Warning
label.
•Do not modify the tool from original design
or function without approval by MAX CO.,
LTD.
SN883RH2_SN890CH2(34).book 6 ページ ２０１１年７月８日 金曜日 午後６時１分

7
2. SPECIFICATIONS AND TECHNICAL DATA
1. NAME OF PARTS
2. TOOL SPECIFICATIONS
3. FASTENER SPECIFICATIONS
1Frame
2Cylinder Cap
3Contact Arm
4Nose
5Magazine
6Trigger
7Grip
8Exhaust Cover
9Pusher
0Adjustment Dial
PRODUCT NO. SN883RH2 SN890CH2<34>
HEIGHT 11-7/8" (300 mm) 12-1/2" (316 mm)
WIDTH 4-3/4" (121 mm) 4-3/4" (121 mm)
LENGTH 20-3/4" (526 mm) 17-1/8" (435 mm)
WEIGHT 7.2 lbs. (3.3 kg) 7.3 lbs. (3.3 kg)
RECOMMENDED
OPERATING PRESSURE 70 to 100 p.s.i. (5 to 7 bar)
LOADING CAPACITY 64 nails 90 nails
AIR CONSUMPTION 0.077 ft3at 90 p.s.i. (2.1 at 6 bar) operating pressure
PRODUCT NO. SN883RH2 SN890CH2<34>
NAIL LENGTH 2" to 3-1/4" (50 to 83 mm) 2" to 3-1/2" (50 to 90 mm)
SHANK DIAMETER .113" to .148" (2.9 to 3.8 mm) .110" to .131" (2.8 to 3.3 mm)
SHANK TYPE Smooth, Ring, Screw
HEAD DIAMETER .267" to .295" (6.8 to 7.5 mm) .256" to .303" (6.5 to 7.7 mm)
COLLATION ANGLE 21 degree 34 degree
HEAD Full round head Clipped head
87
2
1
4
36
950
SN883RH2_SN890CH2(34).book 7 ページ ２０１１年７月８日 金曜日 午後６時１分

8
TOOL AIR FITTINGS:
This tool uses a 3/8" N.P.T. male plug. The in-
side diameter should be .39" (9.9mm) or larger.
The fitting must be capable of discharging tool air
pressure when disconnected from the air supply.
RECOMMENDED OPERATING PRES-
SURE:
70 to 100 p.s.i. (5 to 7 bar). Select the operating
air pressure within this range for best fastener
performance.
DO NOT EXCEED 120 p.s.i. (8 bar).
4. TECHNICAL DATA
1NOISE
A-weighted single-event sound power level
------ LWA, 1s, d 101.03 dB (SN883RH2)
------ LWA, 1s, d 96.9 dB (SN890CH2<34>)
A-weighted single-event emission sound
pressure level at work station
------ LpA, 1s, d 92.72 dB (SN883RH2)
------ LpA, 1s, d 86.5 dB (SN890CH2<34>)
These values are determined and docu-
mented in accordance to EN12549 : 1999.
2VIBRATION
Vibration characteristic value
= 4.26 m/s2(SN883RH2)
= 4.5 m/s2(SN890CH2<34>)
These values are determined and document-
ed in accordance to ISO 8662-11.
This value is a tool-related characteristic val-
ue and does not represent the influence to the
hand-arm-system when using the tool. An in-
fluence to the hand-arm-system when using
the tool will for example depend on the grip-
ping force, the contact pressure force, the
working direction, the adjustment of mains
supply, the workpiece, the workpiece support.
5. APPLICATIONS
∗Floor and wall framing
∗Subflooring
∗Roof and wall sheathing
∗Fencing
3. AIR SUPPLY AND CON-
NECTIONS
READ SECTION TITLED "SAFETY IN-
STRUCTIONS"
DO NOT USE ANY POWER SOURCE EXCEPT
AN AIR COMPRESSOR
The tool is designed to operate on compressed
air. Do not operate the tool on any other high-
pressure gas, combustible gases (e.g., oxygen,
acetylene, etc.) since there is the danger of an
explosion. For this reason, absolutely do not use
anything other than an air compressor to operate
the tool.
OPERATE WITHIN THE PROPER AIR PRES-
SURE RANGE
The tool designed to operate within an air pres-
sure range of 70 to 100 p.s.i. (5 to 7 bar).
The pressure should be adjusted to the type of
the work being fastened. The tool shall never be
operated when the operating pressure exceeds
120 p.s.i. (8 bar).
WARNING
5
7
70
100
SN883RH2_SN890CH2(34).book 8 ページ ２０１１年７月８日 金曜日 午後６時１分

9
DO NOT OPERATE THE TOOL NEAR A FLAM-
MABLE SUBSTANCE
Never operate the tool near a flammable sub-
stance (e.g., thinner, gasoline, etc.). Volatile
fumes from these substances could be drawn
into the compressor and compressed together
with the air and this could result in an explosion.
DO NOT USE A WRONG FITTINGS
The connector on the tool must not hold pressure
when air supply is disconnected. If a wrong fitting
is used, the tool can remain charged with air after
disconnecting and thus will be able to drive a fas-
tener even after the air line is disconnected, pos-
sibly causing injury.
DISCONNECT THE AIR SUPPLY AND EMPTY
THE MAGAZINE WHEN THE TOOL IS NOT IN
USE
Always disconnect the air supply from the tool
and empty the magazine when operation has
been completed or suspended, when unattend-
ed, moving to a different work area, adjusting,
disassembling, or repairing the tool, and when
clearing a jammed fastener.
FITTINGS: Install a male plug on the tool which
is free flowing and which will release air pressure
from the tool when disconnected from the supply
source.
HOSES: Hose has a min. ID of 1/4" (6 mm) and
max. length of no more than 17" (5 meters).
The supply hose should contain a fitting that will
provide "quick disconnecting" from the male plug
on the tool.
SUPPLY SOURCE: Use only clean regulated
compressed air as a power source for the tool.
3-PIECE AIRSET (Air filter, Regulator, Oiler):
Refer to TOOL SPECIFICATIONS for setting the
correct operating pressure for the tool.
NOTE:
A filter will help to get the best performance and
minimum wear from the tool because dirt and
water in the air supply are major causes of wear
in the tool.
Frequent, but not excessive, lubrication is re-
quired for the best performance. Oil added thru
the air line connection will lubricate the internal
parts.
Thinner Gasoline
[AIR SUPPLY & CONNECTIONS]
Air filter
Air hose
Regulator
Oiler
3-piece airset
Used at 70 to 100 p.s.i. (5 to 7 bar)
Air compressor
SN883RH2_SN890CH2(34).book 9 ページ ２０１１年７月８日 金曜日 午後６時１分

10
4. INSTRUCTIONS FOR OP-
ERATION
READ SECTION TITLED "SAFETY IN-
STRUCTIONS".
1. BEFORE OPERATION
Check the following prior operation.
1Wear Safety Glasses or Goggles.
2Do not connect the air supply.
3Inspect screw tightness.
4Check operation of the contact arm & trigger
if moving smoothly.
5Connect the air supply.
6Check the air-leakage. (The Tool must not
have the air-leakage.)
7Hold the Tool with finger-off the trigger, then
push the contact arm against the work-piece.
(The tool must not operate.)
8Hold the Tool with contact arm free from
work-piece and pull the trigger. (The Tool
must not operate.)
9Disconnect the air supply.
2. OPERATION
Wear safety glasses or goggles danger to the
eyes always exists due to the possibility of dust
being blown up by the exhausted air or of a fas-
tener flying up due to the improper handling of
the tool. For these reasons, safety glasses or
goggles shall always be worn when operating
the tool.
The employer and/or user must ensure that
proper eye protection is worn. Eye protection
equipment must conform to the requirements of
the American National Standards Institute, ANSI
Z87.1 (Council Directive 89/686/EEC of 21 DEC.
1989) and provide both frontal and side protec-
tion.
The employer is responsible to enforce the use
of eye protection equipment by the tool operator
and all other personnel in the work area.
NOTE: Non-side shielded spectacles and face
shields alone do not provide adequate protection.
Keep hands and body away from the discharge
outlet when driving the fasteners because of
dangerous of hitting the hands or body by mis-
take.
NAIL LOADING
• When loading the nails, be sure to release
the finger from the Trigger.
• Do not press the Contact Arm against the
object.
PROCEDURE
1Load the nails into the slot in the rear of the
Magazine until they go over the Nail Stopper.
WARNING
WARNING
WARNING
Nail Stopper
Nails
SN883RH2_SN890CH2(34).book 10 ページ ２０１１年７月８日 金曜日 午後６時１分
