Maxtang JSL-15 User manual

JSL-15 Mini ITX Motherboard

Copyright
© 2022 Shenzhen Maxtang Computer Co., Ltd. All rights reserved. No part of this publication may be
reproduced, copied, stored in a retrieval system, translated into any language or transmitted in any
form or by any means, electronic, mechanical, photocopying, or otherwise, without the prior written
consent of Shenzhen Maxtang Computer Co., Ltd (hereinafter referred to as “Maxtang”).
Disclaimer
Maxtang reserves the right to make changes and improvements to the products described in this
document without prior notice. Every effort has been made to ensure the information in the document
is correct; however, Maxtang does not guarantee this document is error-free.
Maxtang assumes no liability for incidental or consequential damages arising from misapplication or
inability to use the product or the information contained herein, nor for any infringements of rights of
third parties, which may result from its use.
Trademarks
All the trademarks, registrations, and brands mentioned herein are used for identification purposes only
and may be trademarks and/or registered trademarks of their respective owners.

Shenzhen Maxtang Computer Co., Ltd
1
JSL-15 Mini ITX Motherboard
User Manual
(Version 0.5)
Version:
NO.
Description
Issue Date:
V0.5
Initial version (EN)
2022/01/22

Shenzhen Maxtang Computer Co., Ltd
2
Contents
JSL-15 Mini ITX Motherboard............................................................................................................1
Chapter 1 Product Introduction........................................................................................................3
1.1 Brief Introduction................................................................................................................3
1.2 Parameters..........................................................................................................................3
1.3 Connector Diagram .............................................................................................................4
Chapter 2 Hardware..........................................................................................................................5
2.1 Jumper Setting ....................................................................................................................5
2.2 Memory Slots......................................................................................................................5
2.3 Display Interface..................................................................................................................5
2.4 COM (optional)....................................................................................................................5
2.5 LVDS (Screen Printing: LVDS/EDP, L_VCC/BKL, L_BKL).........................................................6
2.6 eDP optional (Screen Printing: LVDS/EDP, L_VCC/BKL, L_BKL)............................................7
2.7 Storage Interface (Screen Printing: SATA, M.2_N, PWR_SATA) ...........................................8
2.8 Expansion Slot (Screen Printing: M.2_E).............................................................................8
2.9 USB Interface.......................................................................................................................9
2.10 LAN....................................................................................................................................9
2.11 Audio Interface (Screen Printing: FP_AUDIO, JAUD).........................................................9
2.12 Board Power Supply (Screen Printing: PWR1, PWR2).....................................................10
2.13 Switch Panel Pin (Screen Printing: JPOWER1).................................................................10
2.14 CPU FAN Socket (Screen Printing: CPU_FAN1, CPU_FAN2).............................................11
2.15 Hardware Auto Start (Screen Printing: JAT).....................................................................11
2.16 CMOS Clearance/Retention (Screen Printing: JCMOS) ...................................................11

Shenzhen Maxtang Computer Co., Ltd
3
Chapter 1 Product Introduction
1.1 Brief Introduction
The JSL15 is an mITX motherboard based on the Intel Jasper Lake Platform.
1.2 Parameters
CPU:
⚫Intel Celeron N5095A Quad-Cores, four-thread, Base Frequency 2.0GHz Turbo Frequency
2.9GHz, TDP 15W
⚫Intel Celeron N5095 Quad-Cores, four-thread, Base Frequency 2.0GHz Turbo Frequency
2.9GHz, TDP 15W
⚫Intel Celeron N5105 Quad-Cores, four-thread, Base Frequency 2.0GHz Turbo Frequency
2.9GHz, TDP 10W
⚫Intel Celeron N4500 Dual-Cores, two thread, Base Frequency 1.1GHz Turbo Frequency 2.8GHz,
TDP 16W
Memory: Single Channel SO-DIMM DDR4-2933MHz up to 16GB
GPU: Integrated Graphics based on CPU, Display via 1xHDMI2.0, 1xVGA (Optional with RS232 COM)
1xLVDS/eDP (header)
Storage: 1 x M.2 Key M for 2280/2242 SATA SSD, 1x Standard SATA3.0
USB: 4xUSB3.2 Gen1 (rear ports), 3xUSB2.0 (header)
Ethernet: 1x Onboard Gigabyte Network Controller RTL 8111H
Audio: High-definition audio chip, supports speaker-out, Mic-in (rear port), Front Line-out, Mic-in
(header), and power amplifier (onboard pin, for connecting to the passive speaker)
Expansion: 1xM.2 Key E for Wi-Fi and Bluetooth (Type 2230)
Dimension: 170mm x 170mm
Power: 12V/19V DC-in
Working Temperature: -20℃~60℃

Shenzhen Maxtang Computer Co., Ltd
4
1.3 Connector Diagram
DC_IN
HDMI2.0
VGA/COM
USB3.2
LAN
USB3.2
Line_out
FP-AUDIO
MIC_IN
JAUD
M.2_N
M.2 WIFI
CPU
CPU_FAN
1
LVDS/EDP
SO-DIMM
L_VCC/BKL
L_BKL
JPOWER
1*USB2.0
2*USB2.0
PWSATA
SATA
PWR2
JAT
CPU_FAN
2
JCMOS

Shenzhen Maxtang Computer Co., Ltd
5
Chapter 2 Hardware
2.1 Jumper Setting
Please configure the jumpers according to your requirements before installing the hardware.
How to identify the first header of jumpers and pins: Observe the mark beside the jumper or pins
and find the header marked by “1” or bold line or triangular symbol. Or observe the rear panel
and the header with a square solder pad is the first header.
2.2 Memory Slots
On-board 1 x SO-DIMM DDR4-2933MHz slots, supporting single channel, maximum capacity
16GB.
2.3 Display Interface
The board is equipped with an HDMI2.0 standard port plus 1x VGA (optional with RS232 COM)
and 1x LVDS interface (optional with eDP).
2.4 COM (optional)
The board supports 1xRS232 DB9 COM Port which is optional with VGA.
COM PORT DB9 Definition (screen printing: COM)
Pin
Signal
1
DCD#
2
RXD
3
TXD
4
DTR#
5
GND
6
DSR#
7
RTS#
8
CTS#
9
RI#

Shenzhen Maxtang Computer Co., Ltd
6
2.5 LVDS (Screen Printing: LVDS/EDP, L_VCC/BKL, L_BKL)
Dual-Channel 24bit LVDS interface, the power supply of the LVDS screen and backlight are
controlled by L_VCC/BKL jumper.
LVDS Data Pin (Screen Printing: LVDS/EDP)
Signal
Pin
Signal
VCC
1
2
VCC
VCC
3
4
GND
GND
5
6
GND
A_DATA0_DN
7
8
A_DATA0_DP
A_DATA1_DN
9
10
A_DATA1_DP
A_DATA2_DN
11
12
A_DATA2_DP
GND
13
14
GND
A_CLK_DN
15
16
A_CLK_DP
A_DATA3_DN
17
18
A_DATA3_DP
B_DATA0_DN
19
20
B_DATA0_DP
B_DATA1_DN
21
22
B_DATA1_DP
B_DATA2_DN
23
24
B_DATA2_DP
GND
25
26
GND
B_CLK_DN
27
28
B_CLK_DP
B_DATA3_DN
29
30
B_DATA3_DP
Display Backlight Brightness Adjustment Pin (Screen Printing: L_BKL)
Pin
Signal
1
GND
2
GND
3
LCD_BKL_ADJ
4
LCD_BKL_ON
5
12V/19V

Shenzhen Maxtang Computer Co., Ltd
7
6
12V/19V
Display Power Supply Jumper and Backlight Positive/Negative Adjustment (Screen Printing:
L_VCC/BKL)
Interface
Setting
Function
1-3
Close
VCC 3.3V
3-5
Close
VCC 5V
2-4
Close
REV (Backlight control reverse)
4-6
Close
STD (Backlight control standard)
2.6 eDP optional (Screen Printing: LVDS/EDP, L_VCC/BKL, L_BKL)
As an optional Function, it supports a 2 LANE eDP (1.3) interface, when configured as eDP, the
LVDS function is cancelled, and the screen’s power supply and backlight adjustment can be
controlled by the L_VCC/BKL jumper.
eDP Data Pin (Screen Printing: EDP/LVDS)
Signal
Pin
Signal
VCC
1
2
VCC
VCC
3
4
EDP_HPD
GND
5
6
GND
EDP_AUXN
7
8
EDP_AUXP
N/A
9
10
N/A
EDP_DATA0_P
11
12
EDP_DATA0_N
GND
13
14
GND
N/A
15
16
N/A
EDP_DATA1_P
17
18
EDP_DATA1_N
N/A
19
20
N/A
N/A
21
22
N/A
N/A
23
24
N/A
GND
25
26
GND
N/A
27
28
N/A
N/A
29
30
N/A

Shenzhen Maxtang Computer Co., Ltd
8
Display Backlight Brightness Adjustment Pin (Screen Printing: L_BKL)
Pin
Signal
1
GND
2
GND
3
LCD_BKL_ADJ
4
LCD_BKL_ON
5
12V/19V
6
12V/19V
Display Power Supply Jumper and Backlight Positive/Negative Adjustment (Screen Printing:
L_VCC/BKL)
Interface
Setting
Function
1-3
Close
VCC 3.3V
3-5
Close
VCC 5V
2-4
Close
REV (Backlight Control Reverse)
4-6
Close
STD (Backlight Control Standard)
2.7 Storage Interface (Screen Printing: SATA, M.2_N, PWR_SATA)
The board equips one M.2 Key M, supports 2280/2242 SATA SSD, one SATA3.0 Standard Ports,
and one disk power supply.
PWR_SATA (Screen Printing: PWR_SATA)
Pin
Signal
1
VCC 5V
2
GND
3
GND
4
NC
2.8 Expansion Slot (Screen Printing: M.2_E)
The board supports one M.2 key E for 2230 Wi-Fi module and Bluetooth.

Shenzhen Maxtang Computer Co., Ltd
9
2.9 USB Interface
The board is equipped with 4xUSB3.2 Gen1 rear ports, 3xUSB2.0 onboard Pin.
USB Pin (Screen Printing: USB20)
Signal
Pin
Signal
VCC 5V
1
2
VCC 5V
USB DATA-
3
4
USB DATA-
USB DATA+
5
6
USB DATA+
GND
7
8
GND
NC
9
10
(N/A)
USB Pin (Screen Printing: USB21)
Pin
Signal
1
VCC 5V
2
USB DATA-
3
USB DATA+
4
GND
2.10 LAN
High-performance Gigabyte Ethernet controlling RTL 8111H, with 1 x RJ45 interface. Supporting
Magic packet wake up, PXE network boot.
LED Status Indicators：
LINK_LED (Green) Status
Function
ACT_LED (Orange) Status
Function
Always on
Network Connected
Blinking
Data transfer
2.11 Audio Interface (Screen Printing: FP_AUDIO, JAUD)
ALC662 Audio Chip installed. The green interface is for audio output (Line-out), The pink interface
is for Mic input (Mic-in). The JAUD Pin is for the power amplifier.
FP_AUDIO (Screen Printing: FP_AUDIO)
Signal
Pin
Signal
MIC2-L
1
2
AGND

Shenzhen Maxtang Computer Co., Ltd
10
MIC2-R
3
4
AVCC
FRO-R
5
6
MIC2-JD
F-IO-SEN(AGNG)
7
8
(NC)
FRO-L
9
10
LIN2-JD
JAUD (Screen Printing: JAUD)
Pin
Signal
1
L+
2
L-
3
R-
4
R+
2.12 Board Power Supply (Screen Printing: PWR1, PWR2)
The board supports a 12V/19V DC-in power adapter or ATX supplementary (2x2PIN) for power
supply.
PWR1: 12V DC-in power socket
PWR2：ATX 12V supplementary power supply socket (2x2PIN)
2.13 Switch Panel Pin (Screen Printing: JPOWER1)
The front control panel interfaces are to connect the functional buttons and indicators on the
front panel.
JPOWER1 (Screen Printing: JPOWER1)
Signal
Pin
Signal
HDD_LED+
1
2
PWR_LED+
HDD_LED-
3
4
PWR_LED-
RSTBTN-
5
6
PWR_ON+
RSTBTN+
7
8
PWR_ON-

Shenzhen Maxtang Computer Co., Ltd
11
NC
9
10
(N/A)
2.14 CPU FAN Socket (Screen Printing: CPU_FAN1, CPU_FAN2)
The board provides a CPU Fan socket for cooling, default 5V power supply (12V Optional). Note:
for the fan socket, only one of CPU_FAN1 and CPU_FAN2 can be used.
CPU_FAN1 (Screen Printing: CPU_FAN1)
Pin
Signal
1
VCC
2
GND
3
TAC
4
CTL
CPU_FAN2 (Screen Printing: CPU_FAN2)
Pin
Signal
1
GND
2
VCC
3
TAC
4
CTL
2.15 Hardware Auto Start (Screen Printing: JAT)
JAT (Screen Printing: JAT)
Setting
JAT
Close
Hardware Auto Start
Please note that this jumper function is similar to the " State After G3" function in BIOS. When
the latter is set to S0 State, the device will also start automatically after power is connected.
2.16 CMOS Clearance/Retention (Screen Printing: JCMOS)
CMOS is powered by onboard button batteries. Clearing CMOS will permanently remove the
previous system settings and restore the board to the original (factory settings) system settings.
Step 1: Turn off the PC and disconnect the power adapter.
Step 2: Use the jumper cap to connect the 1st and 2nd header of CLR_CMOS for about 10

Shenzhen Maxtang Computer Co., Ltd
12
seconds, then disconnect.
Step 3: When restarting the device, press the <Del> button to enter the BIOS, load the optimal
default value, save, and exit the settings.
COMS (Screen Printing: CLR_CMOS)
Pin
Setting
Function
1-2
Close
Clear COMS
Please do not clear COMS when the PC is connected to power in case of any board damages.
