Medela lactrina Operating instructions

www.medela.com
Medela, Lactina and Symphony are registered trademarks and Quick Clean, Micro-Steam and
Maximum Comfort Vacuum are trademarks of Medela, Inc.
© 2009 Medela, Inc. Printed in the U.S.A.
1907626 C 1209 © 2009 Medela, Inc.
Medela, Inc.,
P.O. Box 660,
1101 Corporate Drive
McHenry, IL 60051-0660, USA
Ph: [phone] or [phone]
Fax: [phone]
Email: [email protected]

service instructions
lactina®
electric breastpump

Table of Contents
1. General Description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
2. Technical Description
2.1.1 Technical Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . 3
2.1.2 Exploded View Diagram & Parts List . . . . . . . . . . . . . . 4-5
2.1.3 Electric Circuit Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2.1.4 Dismantling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.1.5 Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2.1.6 Final Test Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3. Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-11
4. Precautionary Measures / Troubleshooting. . . . . . . . . . . . 12
5. Adjusting Vacuum . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
6. Service Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-14
7. Safety Tests . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14-15
8. Terms of Guarantee . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Valid as of October 2008
Lactina is a registered trademark of Medela, Inc.

1
1. General Description
Medela’s Lactina® Select breastpump has been specially developed
to meet the most stringent demands where hygiene and mobility are
concerned. The operating principle of the Medela Lactina is to simulate
the natural, physiological conditions encountered in breastfeeding.
The pump motor and the suction source are completely separate. All
components which can come into contact with the milk are part of the
accessories and can be very easily disconnected from the drive unit for
cleaning or sterilization. The accessory kit can also be used separately
as a manual pump.
Lactina Select includes the following general specifications:
– with variable vacuum.
– with variable speed, i.e. the number of suction cycles per minute
can be regulated.
– powered by regular electric outlet (120 VAC) or by using the
optional Medela Power Pack that provides 12 VDC with its
rechargeable battery or the vechicle lighter adapter.
The Lactina breastpump is for indoor use only.
Disposal
This breastpump is made of technical plastics and metals which
cannot be separated. It has to be disposed of in accordance with local
regulations.
WARNING
 • Donotuseorsitthepumpwhereitisexposedtodirect 
sunlight or any other source of heat.
 • Thisequipmentisnotsuitableforuseinthepresenceof 
flammable materials.
 • Ifthepowercordisdamaged,ithastobereplacedbya 
  qualifiedserviceperson.
 • BeforetakingoffthebackoftheLactinahousingforservice 
purposes, do not forget to switch off the pump and to
disconnect the power cord from the main supply.

2
Warranty
This product is warranted by Medela, Inc., to the original retail purchaser
to be free from defects in material and workmanship for the period of
three (3) years from the date of purchase. In the event of a defect or
failure to conform to this warranty, Medela will, at Medela’s option,
repair or replace this product without charge for such replacement, on
parts or labor. The Purchaser shall bear all responsibility and expense
for returning this product to Medela, including risk of loss prior to receipt
by Medela, and shipping, packing, and insurance costs.
Medela will have no obligation under this warranty to repair any
malfunction or damage arising from any misuse, abuse, or alteration of
this product. Without limiting the generality of the foregoing, bending,
or dropping of this product or its components, visible cracking of the
equipmenthousingwillbepresumedtobedefectsresultingfrom
misuse or abuse. Accessories that are not expressly manufactured by
Medelaandsubsequentlyattachedtotheequipmentwillimmediately
void this warranty.
ANY AND ALL IMPLIED WARRANTIES ARE LIMITED TO THE
DURATION OF THREE YEARS FROM DATE OF PURCHASE.
SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN
IMPLIEDWARRANTYLASTS,SOTHEABOVELIMITATIONSMAYNOT
APPLY TO YOU.
THELIABILITYOFMEDELAFORBREACHOFANYWRITTENOR
IMPLIED WARRANTY IS LIMITED TO REPAIR OR REPLACEMENT
OFTHISPRODUCT,ANDMEDELAWILLHAVENOLIABILITYUNDER
ANY CIRCUMSTANCES FOR ANY INCIDENTAL OR CONSEQUENTIAL
DAMAGES. SOME STATES DO NOT ALLOW THE EXCLUSION OR
LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO
THEABOVELIMITATIONSOREXCLUSIONSMAYNOTAPPLYTO
YOU.
THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS AND YOU
MAY ALSO HAVE OTHER RIGHTS WHICH VARY FROM STATE
TO STATE.

2. Technical Description
2.1.1 Technical Specifications
3
vacuum (approx.)
…………… -240mmHg
…………… -32kPa
-100mmHg
-13.33kPa
kPa
70
106
FDA (GMP)
ISO 9001
ISO 13485
CE (93/42/EEC)
CLASS
Protection class
Ty pe B
900 410 410 mm
180 250 150 mm
100 – 240V
50 / 60
Hz
50VA
Alternating current
T 1.25 A 250 V
/ /
6.3 x32
12V DC
16W
T A1.25
Medela Art Nr. 928.7001
20
95 Transport/Storage
20
80 Operation
°C
+5
+40Operation
°C
-20
+50Transport/Storage
kg
5.29lbs
2.4Kg
Please see accompanying papers
Must not be disposed of together with household refuse
cycles
Latina Select 40 - 60 / min.
Tested according to
IEC 60601-1/A2:1995

4
2.1.2 Spare Parts List

Item Description Order #
1. Rubber clamp 820.0009
2. Pumping arm, complete 800.0111
3. Cotter 810.0179
 4.  Bearing 810.0153
5. Case complete variable SPS 800.0244
6. Elastic buffer 812.0025
7. Cover insert 810.0113
8. Fillister head self-tapping screw type 1, 2.9 x 13 426.5002
9. Fuse T 1.25 A USA 931.0012
10. Fuse holder complete, USA 900.0382
11. Gearbox with commutator motor 12 V 600.0923
12. Bearingpin 599.0028
14. Spring holder (special tool for fitting) 522.1433
15. Countersunk self-tapping screw M 2.9 x 6.5 429.0002
16. Cord clamp 599.0005
17. Cord sleeve 824.1326
18. Power cord USA 928.0026
19. Fillister head screw with cross-slot M4 x 8 411.1001
20.  Back 810.0107
21 Run-Stop rocker switch 934.0159
22. Protecting cover (transparent) 812.0007
23. Mains connecting cable 900.0332
24. SPS variable for 016 901.0034
25. Spacing piece complete 810.0351
26. Knob 699.0065
27. Nut cover with line 699.0064
28. Cover for knob 699.0066
29. Green LED lens 942.0009
*Not all items listed above may be available for purchase.
The company reserves the right to change technical specifications and
designations and/or order numbers without prior notice.
5

2.1.3 Electric Circuit Diagram
6
IO I
J1

2.1.4 Dismantling
Important:
BeforetakingoffthebackoftheLactina®housing for service purposes,
do not forget to switch off the pump and to disconnect the power cord
from the mains supply.
Gearbox unit:
– Remove the back (20) after releasing the screws (15 and 19).
– Release power cord with cable tension relief (16 to 18) from the
back (20) and gearbox unit (11).
– Turn the gearwheel until the pumping arm (2) is swung in fully.
– Swing out the pumping arm (2) fully by hand.
– Lock the return spring by inserting the spring holder (14)
obtainable from Medela in the slot provided for this purpose (see
exploded view diagram).
– Swing in pumping arm (2).
– Withdraw bearing pin (12).
– Swing out pumping arm (2) again fully.
– Detach electrical connections on right-hand side from main
terminal and withdraw.
– Remove gearbox unit (11).
Electronics:
– Remove gearbox (11) as described above.
– Compress retainer of switch case and press out switch (21) from
inside to outside.
– Remove SPS red + blue connections from switch (21).
– Disconnect motor leads from switch (21).
– Withdraw LED (D1) (fuse holder 9/10 + 23 is also preferably
dismantled beforehand).
– Detach SPS cable (24) from its holders.
– Remove cover (28) from knob (26 + 27).
– Release screw in knob (26 + 27) and remove knob.
– Release nut under knob (26 + 27) and draw off
potentiometer inwards.
– Swing in pumping arm (2) fully.
– Hold pump case (5) by handle and withdraw SPS (24) with
other hand.
Pump arm:
– Remove gearbox (11), preferably also SPS (24) according to
description above.
– Dismantle cover insert (7) after releasing the screws (8).
7

8
2.1.5 Assembly
Assemblyisperformedinthereversesequencetodismantling.The
following points should also be noted:
– Sequenceofcableroutingfromtoptobottom:mainsleadfrom 
SPS, potentiometer (RV1), switch, LED (D1).
– The SPS must be placed right at the rear of the case and the
cables must be pressed fully into their holders.
– Insert potentiometer (RV1) in spacing piece (25) in positioning pin
from inside to outside. The potentiometer must lie flat on the
spacing piece. Place nuts on from outside and tighten.
– Turn potentiometer clockwise to stop, fit knob (26 + 27) and turn
clockwise until line is at 7. Tighten screw.
– Beforefittingthebackcheckwhethertheinternalpartsofthe 
pumping arm (2) do not touch anywhere.
– Connections on right-hand side of mains terminal strip (KL1) from
top to bottom: Power cord no. 1, power cord no. 2 and SPS
brown, SPS blue.
– Connections on left-hand side of mains terminal strip from top to
bottom: black, blank, white.
– Fitting of the cover insert (7) is simplified if the pumping arm (2) is
not swung in completely, but only set to the final position together
with the cover insert (7).
Breastpump Systems
BreastmilkInitiationSystemforSymphonyorLactina 67340S
______________________________________________________________
Symphony / Lactina 67116
67116-06
67116S
67340S
______________________________________________________________
Lactina 67094
67094-06
67094S
______________________________________________________________
Symphony / Lactina Rental Kit 67206-03

2.1.6 Final Test Procedure
a) General checks
– 100% check (visual) of type designation, serial no., DC plate 12 V
and labeling on back.
– 100% check with respect to air gap between swivel arm and case
with leaf gauge. Permissible air gap 0.2–1.5 mm; if the air gap is
outside this range reject unit and replace.
– 100% check with respect to gap between case and back,
permissible gap 0.8 mm.
If gap > 0.8 mm, the back must be adjusted or replaced.
– 100% check high voltage test.
Test points: 4 screw heads on back
2 screw heads case floor
– 100% check rubber protection to switch for tightness.
– 100% check tightness of rotary knob with cover.
b) Running test A 100% check
Allow unit to run for 4 hours without cylinder. Set on position 4
(standard). LED must light.
c) Running test B 100% check
Check for running noise:
Functional check:
– Mains plug inserted (SPS active)
•Switchat“RUN”unitrunsandLEDlights
•Switchat“STOP”LEDlights,unitstationary
– DC inserted (12 V) (SPS not active)
•Switchat“RUN”unitruns,LEDdoesnotlight
•Switchat“STOP”LEDdoesnotlight,unitstationary
9

10
Uses
•To initiate and maintain a milk supply as well as collect breastmilk at
work or during other absences from the baby.
•To initiate and maintain a milk supply if direct breastfeeding is not pos-
sible.
•To relieve engorgement. Single pumping with simultaneous massage is
helpful to relieve engorgement.
Cleaning and Sterilization
Unless instructed otherwise by your healthcare provider.
Hygiene
Wash hands before touching breasts or containers,
and avoid touching the inside of containers or lids.
Preparation
Follow these cleaning instructions unless you are told otherwise by your
healthcare professional. Prior to cleaning, take apart all parts of your
breastpumpaccessorykit.Beespeciallysuretoremovetheyellowvalve
from the breastshield and separate the white membrane from the valve
prior to cleaning.
Prior To First Use
The Lactina®sanitizedorsterilizedkitversionsdonotrequirewashing
before first use.
To Sterilize in the Hospital:
All disassembled parts can be autoclaved to a maximum of 272° F for 3
minutes at 29 PSIG or 250° F for 15-20 minutes at 15 PSIG.
To avoid damage during and immediately after sterilization:
•Sterilize parts without applying external pressure to them.
•Allow parts to cool before applying external pressure.
If gas sterilization is used, residual testing is recommended to determine
the proper length of aeration.
This product’s kit is a single-user item unless properly sterilized
between users. Use by more than one user without adequate
sterilization may pose a health risk and voids the warranty .
IMPORTANT

11
To Sanitize at Home:
Disassemble and sanitize by boiling for 10 minutes.
After each use:
•Disassemble and wash all parts that come in contact with the breast
and milk in warm soapy water.
•Rinse in clear water.
•Air-dry on clean towel and cover parts when not in use.
All parts may also be washed in top rack of dishwasher.
For Quicker Cleaning:
Medela offers Quick Clean™Micro-Steam™bags for daily kit
disinfection.
Tubing Care:
Inspect tubing after each pumping session for condensation
and/or or milk.
If condensation appears in tubing:
To eliminate condensation after you have completed pumping, continue
running the pump with the tubing(s) attached for another 1-2 minutes
or until dry, while you attend to storing your pumped breastmilk.
If milk appears in tubing:
1. Turn off the pump and unplug from power source.
2. Remove and disassemble the tubing and kit parts. Wash in soapy
water then rinse in cold clear water.
3. Shake water droplets out and hang to air-dry. For faster drying,
attach tubings to pump and run pump 1-2 minutes or until dry, or
pour a small amount of isopropyl alcohol through the tubings to dry.
4. Make sure that valve membranes are undamaged and clean.
Replace if necessary.
5. Use a damp cloth to wipe the pump. Do not immerse the pump
in water.
6. When components are completely dry, reassemble breastpump
and kit.

12
4. Precautionary Measures / Troubleshooting
The breastpump should only be used in a dust-free environment. Do
not use or set the pump where it is exposed to direct sunlight or any
other source of heat.
What to do when...
– the pump does not run when it is switched on:
Check whether the Lactina®breastpump is properly connected to
the electric supply. Check the fuse. Besurethatthepumpis
plugged in.
– pump action is too weak:
Suction strength can be adjusted using the vacuum regulator.
Maximum suction is achieved by setting the pointer on the
 regulatorringtoMAX.Ifsuctionstrengthisstillinadequateatthis
setting, please check whether:
 •thevacuumregulatorringhasbeenturnedbeyondthestop,has
been displaced, is no longer a close fit or is dirty on the inside.
 •therubbersealofthepistonisseatingcorrectlyandisingood
condition.
 •thevalvehasbeencorrectlyfittedtothebreastshield.Isthevalve
membrane clean and closing properly when in resting position?
 •thecylinderhasbeenscrewedtightlyintothecylinderholder(orinto
the breastshield in the case of manual operation).
 •thereisnoleakinthetubeconnectionbetweencylinderholderand
breastshield.
 •thebreastshieldfitscloselytothebreast.
– the vacuum cannot be regulated:
The two holes in the cylinder under the vacuum regulator ring may
be blocked with dirt. Clean them using a brush and soapy water.
The points listed above should also be checked.
– the vacuum is not released at the end of the suction stroke:
The ventilation hole at the bottom of the cylinder may be blocked
with dirt; or the piston has not been drawn right to the end during
manual operation.
– the piston does not return after the suction phase:
Check whether the suction circuit is blocked or whether there is a
kink in the tubing.

5. Adjusting Vacuum
The Lactina®Select features a knob to adjust the pumping speed.
Choose a fast pumping rhythm to start your milk flowing (setting 7
corresponds to highest speed level). Once your milk starts to flow or
you sense milk ejection you may adjust the rhythm by decreasing speed
slightly (e.g. setting 4).
To adjust vacuum set the vacuum regulator
to minimum and start pumping. Adjust
the vacuum to your Maximum Comfort
Vacuum™. This is the highest vacuum you
can use and still feel comfortable (different
for every mother). To find your Maximum
Comfort Vacuum increase vacuum until
pumping feels slightly uncomfortable (not
painful), then decrease.
6. Service Information
Important:
Before starting the procedure described below, do not forget to
switch off the pump and to disconnect the power cord from the
main supply!
The design of your Medela Lactina breastpump means that routine
servicing is not normally uneccessary. All bearings are maintenance-free
and, when used as directed (i.e. only in a dust-free environment and
in the normal operating position), there is almost no dirt entering the
drive unit. Cleaning the outside of the pump is the only care needed,
particularly around the pivot arm and the guide slot for the cylinder
holder.
13

To ensure that the breastpump will provide trouble-free operation for
years to come, it should be examined periodically according to the
following checklist.
Checklist:
1.The specification of the fuse employed as well as the power supply
to which the pump is connected must match the data on the pump
specification plate.
2.Fit the accessories to the breastpump as described in the
instructions for use (included with the accessory kit). The
breastshield should then be connected to a vacuum gauge.
3.Connect the power cord to the main supply and switch on the unit.
The pivot arm must operate with a pumping motion.
4.The following values must be attained:
Suction rate: Lactina Select approx. 40–60 cycles/min.,
mains
approx. 50 cycles/min.,
battery
Suction strength at MAX setting:
6. Safety Tests
The following safety tests should be performed yearly:
1. Visual check
The breastpump should be examined for damage and dirt on the inside
and outside and repaired or cleaned if necessary.
2. Functional test
Every function of the breastpump must be controlled according to the
Instructions for Use and Service Instructions.
3. Electrical tests
• Enclosureleakagecurrent:Thistestshouldbeperformedunder
normal conditions and under the conditions of Single Fault.
Conditions of Single Fault: The interruption of each supply conductor
one at a time.
14
Location 0 m above 500 m above 1000 m above 2000 m above
sea level sea level sea level sea level
Factor 1.00 0.94 0.88 0.78
Lactina Select (+/- 20 mmHg) 255 mmHg 240 mmHg 225 mmHg 199 mmHg

• Patientleakagecurrent.
• Thedialectricstrengthbetweenlivepartsandthehousing.This 
insulation shall be double insulation.
The allowable values are defined according to the chart below:
NC: Normal Condition
SFC: Single Fault Condition
U: Reference voltage
7. Terms of Guarantee
MedelaguaranteestheperfectqualityandfinishofeachLactina®
breastpump for a period of 3 years from the factory delivery date. During
this period, all faulty components will be replaced free of charge. This
guarantee does not extend to components which are subject to wear
and tear or which have been damaged due to incorrect use.
Further conditions according to International Standard IEC 601.1, Item
6.8.2b:
Themanufacturermayonlybeheldresponsibleforinadequatesafety,
reliability and performance of the unit if
– assembly
– additional items
– adjustments
– alterations or repairs
have been carried out by persons authorized by the manufacturer and
– the electrical installation within the room concerned satisfies IEC
requirements(inthecourseofpreparation).
– the unit is used as specified in the instructions for use.
– accessory kits used on Lactina breastpumps are authorized by
Medela, Inc.
15
Test Allowable Value Chapter IEC 601-1
Enclosure leakage current NC SFC 19.1
0,1 mA 0,5 mA 19.2
19.3
Patient leakage current DC NC SFC 19.1
0,1 mA 0,5 mA 19.2
AC NC SFC 19.3
0,1 mA 0,5 mA 19.4
Dialectric Strength 50 <U ≤150V 3000V 20.1
(double insulation) 20.3
150 <U ≤250V 4000V 20.4
(double insulation)
