Medeli M311 User manual

ELECTRONIC
KEYBOARD
M U S I C A L K E Y B O A R D
0
5
25
75
95
100
AW_M311_Manual_G05_160201
2016󾾠󾾠2󾾠󾾠1󾾠󾾠 10:37:10

INFORMATION FOR YOUR SAFETY!
PRECAUTIONS
PLEASE READ CAREFULLY BEFORE PROCEEDING
Please keep this manual in a safe place for future reference.
Power Supply
Please connect the designated AC adaptor to an AC outlet
of the correct voltage.
Do not connect it to an AC outlet of voltage other than that
for which your instrument is intended.
Unplug the AC power adaptor when not using the
instrument, or during electrical storms.
Connections
Before connecting the instrument to other devices, turn off
the power to all units. This will help prevent malfunction and
/ or damage to other devices.
Location
Do not expose the instrument to the following conditions to
avoid deformation, discoloration, or more serious damage:
Direct sunlight
Extreme temperature or humidity
Excessive dusty or dirty location
Strong vibrations or shocks
Close to magnetic fields
Interference with other electrical devices
Radios and televisions placed nearby may experience
reception interference. Operate this unit at a suitable
distance from radios and televisions.
Cleaning
Clean only with a soft, dry cloth.
Do not use paint thinners, solvents, cleaning fluids, or
chemical-impregnated wiping cloths.
Handling
Do not apply excessive force to the switches or controls.
Do not let paper, metallic, or other objects into the
instrument. If this happens, unplug the AC adaptor from the
wall outlet. Then have the instrument inspected by qualified
service personnel.
Disconnect all cables before moving the instrument.
2
THE FCC REGULATION WARNING (for USA)
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of
the FCC Rules.
These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and
receiver.
Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician
for help.
Unauthorized changes or modification to this system can
void the user's authority to operate this equipment.
CAUTION
The normal function of the product may be disturbed by
Strong Electro Magnetic Interference. If so, simply reset
the product to resume normal operation by following the
owner's manual. In case the function could not resume,
please use the product in other location.
0
5
25
75
95
100
AW_M311_Manual_G05_160201
2016󾾠󾾠2󾾠󾾠1󾾠󾾠 10:37:11

Contents
3
Panel & Display Description
Front Panel..................................................................4
Rear Panel...................................................................4
Display.........................................................................5
Setup
Power Supply...............................................................6
Connections
Connecting a Footswitch.............................................7
Connecting a pair of Headphones...............................7
Connecting an Audio Equipment.................................7
Connecting a Computer...............................................7
Playing the Demos....................................................8
Playing the Voices
.............................................................8
Playing Two Voice Simultaneously-DUAL...................8
Lower...........................................................................9
Touch...........................................................................9
Sustain.........................................................................9
DSP Effect...................................................................9
.............................................10
Playing a Fill..............................................................10
Intro/Ending...............................................................10
Sync Start..................................................................11
Fade In/Out................................................................11
Tempo........................................................................11
One Touch Setting.....................................................11
Auto Bass Chord.......................................................12
Playing Voices
Auto Accompaniment
Play Auto Accompaniment
Other Function
Function Menu...........................................................13
Mixer..........................................................................14
Memory
Memory......................................................................15
Chord Dictionary.....................................................15
Songs
Listening to the Songs...............................................16
Lesson Mode.............................................................16
.......................................................17
MIDI Functions
What’s MIDI?.............................................................18
MIDI Terminals...........................................................18
Trouble Shooting.....................................................19
Specifications..........................................................19
Appendices
Voice List...................................................................20
Style List....................................................................22
Song List...................................................................23
MIDI Implementation Chart........................................24
Song Recording
0
5
25
75
95
100
AW_M311_Manual_G05_160201
2016󾾠󾾠2󾾠󾾠1󾾠󾾠 10:37:11

M U S I C A L K E Y B O A R D
Panel & Display Description
Front Panel
4
28. USB
Connect to a computer.
29. SUSTAIN
Connect a sustain pedal.
30. PHONE
Connect a pair of headphones.
31. DC IN
Connect DC IN power adaptor (optional).
Rear Panel
28 29 30 31
When the [SHIFT] button is released
13. FADE IN/OUT
Turn the Fade In or Fade Out on.
14. CHORD
Enter the chord mode.
15. STORE
Register the current panel settings.
16~19. M1-M4
Recall the memory settings.
1. POWER ON/OFF
Turn the power on or off.
2. MASTER VOLUME
Adjust the master volume.
3. LESSON
the Lesson Mode.
4. L/R PART
in Lesson Mode.
5. CHORD DICT.
Enter the Chord Dictionary.
6. TEMPO + / -
Change the current tempo.
7.
8. START/STOP
Start or stop playing the song in
Song Mode.
Start or stop playing the style in
Style Mode.
Enter
Select the left / right-hand part
SHIFT
Press and hold it to access
secondary functions of other
buttons.
1
12
3 4 5
6 7
8 9 10 11 12 13 14 15 16 17 18 19
When the [SHIFT] button is pressed
13. DSP
Turn the DSP effect on and off.
14. O.T.S.
Enter the One Touch Setting Mode.
15. RECORD
Start or stop real-time recording.
16. PLAY
Play back the recorded user song.
17. DUAL
Turn the DUAL voice on or off.
18. LOWER
Turn the LOWER voice on or off.
19. SUSTAIN
Turn the Sustain effect on or off.
9. SYNC START
Turn the SYNC START on or off.
10. INTRO / ENDING
11. FILL A
12. FILL B
B.
Play the Intro or Ending.
Play the fill-in pattern A.
Play the fill-in pattern
0
5
25
75
95
100
AW_M311_Manual_G05_160201
2016󾾠󾾠2󾾠󾾠1󾾠󾾠 10:37:12

M U S I C A L K E Y B O A R D
Panel & Display Description
Display
5
1. A.B.C.
2. FADE
3. DUAL
4. LOWER
5. DSP
6. TOUCH
7. SUSTAIN
8. MODULATION
20. FUNCTION
Enter the Function .
21. MIXER
Enter the Mixer
22. METRONOME
Turn the metronome on and off.
23. TOUCH
Turn the Touch response on and off.
Menu
Menu.
24. VOICE
Enter the Voice Mode.
25. STYLE
Enter the Style Mode.
DEMO
Press VOICE and STYLE buttons simultaneously
will start the DEMO playback.
26. SONG
Enter the Song Mode.
27. +,-,NUMBER KEYS
Select the number or set parameters value.
9. CHORD
10. VOICE/STYLE/DEMO/SONG
11. TEMPO/COUNT
12. BEAT
13. STROE M1-M4/
ONE TOUCH SETTING
14. RECORD
15. NOR/VAR
16. BASS CLEF
17. TREBLE CLEF
18. USB CABLE
19. LEFT
20. RIGHT
21. LESSON 1/2/3
22. 61-KEY KEYBOARD
24 25 26
23
20 21
22
27
7
8
910 11 12 13
14 15
16 17
19
18
A.B.C.
FADE
DUAL
LOWER
DSP
TOUCH
SUSTAIN
MODULATION
1
2
3
4
5
6
20 21
22
0
5
25
75
95
100
AW_M311_Manual_G05_160201
2016󾾠󾾠2󾾠󾾠1󾾠󾾠 10:37:14

6
Setup
This section contains information about setting up your instrument and preparing to play. Please go through this section carefully
before turning the power on.
Power Supply
You can power the unit either by batteries or by power adaptor. Follow
the instructions described below.
Using Batteries
6 pieces of AA size (SUM-3 or Lr6) or equivalent alkaline batteries
must first be installed into the battery compartment.
1. Open the battery compartment cover located on the bottom
.
2. Insert the batteries, carefully follow the polarity markings on the
cabinet.
3. Replace the compartment cover, it locks firmly in place.
Caution:
Do not mix and new batteries.
Always use same types of batteries.
Always remove the batteries from the unit when it is not used for an
extended period of time.
Using Power Adapter
1. First, please make sure that POWER ON/OFF switch of the
instrument is set to OFF.
2. Connect the AC adaptor to the power supply jack.
3. Plug the AC adaptor into an AC outlet. This will automatically cut off
the battery power supply.
4.
Note:
When the keyboard is not in use or in the time of thunderstorm, please
disconnect the power for safety purpose.
of the
instrument
make sure
used
Turn on the instrument.
The instrument will automatically shut down in about 30 minutes if it is
not used.
SUM-3, LR6, “AA” SIZE OR EQUIV.
0
5
25
75
95
100
AW_M311_Manual_G05_160201
2016󾾠󾾠2󾾠󾾠1󾾠󾾠 10:37:14

Connections
Connecting a Computer
7
Use a USB cable to connect the instrument to a computer. The
instrument receives and transmits MIDI messages via the USB
connector.
Connecting a pair of Headphones
A standard pair of stereo headphones can be connected to the
PHONES jack for private practice or late-night playing. The internal
stereo speaker system is automatically shut off when a pair of head
phones is plugged into this jack.
Note:
Do not listen with the headphones at high volume for long periods
of time. Doing so may cause hearing loss.
Connecting an Audio Equipment
The PHONES jack can be also connected with an audio equipment,
such as an amplifier, mixer, recorder,etc.
Note:
To avoid damaging the speakers, the volume has been set
to the minimum level before connecting the power and other devices.
make sure
Connecting a Footswitch
An optional footswitch can be plugged into the sustain jack and be
used to switch sustain on or off. Simply by pressing a sustain
footswitch, you will have a natural sustain as you play.
0
5
25
75
95
100
AW_M311_Manual_G05_160201
2016󾾠󾾠2󾾠󾾠1󾾠󾾠 10:37:15

8
Playing the Demos
Playing Voices
The keyboard has 320 remarkably realistic built-in voices, including Piano, Woodwind, Saxophone, Drum
Kits and many more. Please refer to Voice List.
Playing Voices
8
The instrument features 100 demo songs.
1. Press the [STYLE] and [VOICE] buttons simultaneously to start
playing the demo.
2. Select a demo song.
Use the data dial, the number keys, the [+] button or the [-] button to
select the desired demo song.
3. Adjust the volume with the [VOLUME] knob.
4. Press the [STYLE] and [VOICE] buttons simultaneously again or
press the [START/STOP] button to stop playing and exit the demo
mode.
Note:
In the DEMO mode, all buttons except START/STOP, TEMPO+,
TEMPO-, +, -, DSP, VOLUME, POWER ON/OFF will not be available.
1. Press the [VOICE] button.
Enter the VOICE mode. LCD shows “ ”, the voice
number.
2. Select a voice.
Use the number keys, the [+] button or the [-] button to select the
voice you want to play.
3. Play the voice.
Note:
VOICE 1
When both Voice 1 and Voice 2 are on, you can press the [VOICE]
button to shift between the two voices.
Play the keyboard and enjoy the wonderful voice.
Playing Two Voice Simultaneously-DUAL
1. Holding down the [SHIFT] button and press the [DUAL] button to
turn the function on. LCD shows “VOICE 2” and the dual voice number.
0
5
25
75
95
100
AW_M311_Manual_G05_160201
2016󾾠󾾠2󾾠󾾠1󾾠󾾠 10:37:16

Playing the Voices
9
2. Selecting a voice for VOICE 2.
Use the data dial, the number keys, the [+] button or the [-] button
3. Play the voices.
to
select the desired dual voice.
You will hear two different voices layered together, just like two
instruments playing at the same time.
Touch
The keyboard is equipped with a touch response feature that lets you
dynamically and expressively controls the level of the voice with your
playing strength – just as on an acoustic instrument. Press the
[TOUCH] button to adjust touch parameter: OFF, 1, 2,3. Press [+] and
[-] buttons simultaneously to its default value.restore
Sustain
When the Sustain feature is ON, all notes played on the keyboard
would have a longer sustain.
to turn the SUSTAIN effect ON or
OFF.
Note:
When you step on the “sustain pedal”, the sustain effect is stronger
than the effect by pressing the [SUSTAIN] button.
Holding down the [SHIFT] button and
then press the [SUSTAIN] button
DSP Effect
The DSP simulates sounds in the real environment. With the DSP
effect, you can add ambiance and depth to your performance.
you turn on the instrument Holding
down the [SHIFT] button and then press the [DSP] button
The DSP effect is set to ON when .
to turn on or
off the DSP effect.
Lower
The lower function splits the keyboard into the left and the right hand
areas, each with a different voice.
.
Holding down the [SHIFT] button and press the [LOWER] button to
turn on the LOWER VOICE, LCD lights the LOWER VOICE icon and
displays “VOICE L” and its number.
The left hand voice is the lower voice
“VOICE L”
The default split point is #F3.
1.
When you play in real time, you can activate Split Mode simply by
pressing this button.
2. Press [+]/[-] button, or numeric button to select the voice you want.
DUAL
LOWER
TO UCH
SUSTAIN
DSP
0
5
25
75
95
100
AW_M311_Manual_G05_160201
2016󾾠󾾠2󾾠󾾠1󾾠󾾠 10:37:16

10
Auto Accompaniment
The instrument features 110 styles of different musical genres. Try selecting some of the different styles (Refer to Style List)
and play with the auto accompaniment.
Play Auto Accompaniment
1. Press the [STYLE] button.
Enter the STYLE mode. LCD shows “STYLE”, the style number.
2. Use the number keys, the [+] button, the [-] button to select the
style you want to play.
3. Press the [START/STOP] button to start the rhythm tracks of the
auto accompaniment.
Playing a Fill
Auto fill in function automatically adds a fill to your performance. When
the fill-in is finished, accompaniment shifts to the Main section (A,B).
Note:
Hold down the FILL-IN A/B button when the style is playing, the
selected FILL pattern repeats continuously until button is released.
Press FILL-IN A/B when style stop, it will change to the normal section.
Intro/Ending
The intro is an opening section of the song.Each preset style features
two different patterns. When the intro pattern finished, the system will
automatically shift to the main section.Ending is used for the ending of
the song. When the ending is finished, accompaniment automatically
stops.The length of the ending differs depending on the selected style.
1. Press the [STYLE] button.
2. Select a style
3. Turn the Chord Mode on.
4. Turn SYNCHRONIZED START on.
5. Press the [INTRO/ENDING], the “ ” flashes on LCD, the style
is ready to play.
6. It will start the accompaniment as soon as you start playing in
Chord section. When the playback of the intro is finished, it
automatically leads into main A or B section.
7. Press the [INTRO/ENDING] again will lead it into the ending
section. When the ending is finished, the auto accompaniment
automatically stops.
Note:
Press [FILL A] or [FILL B] before the ending finished will lead it into
main A or main B section.
VAR
0
5
25
75
95
100
AW_M311_Manual_G05_160201
2016󾾠󾾠2󾾠󾾠1󾾠󾾠 10:37:17

11
Auto Accompaniment
Sync Start
While the style , press the [SYNC] button. The black dots below
the tempo and the metronome flash, indicating
1. If the Chord Mode is OFF, pressing any key will automatically
begins to play the style (rhythm track).
2. If the Chord Mode is ON, pressing any key in the left-hand range of
the keyboard will automatically begins to play the style (all tracks).
stops
the style is ready to
play.
Fade In/Out
Fade In
Starting the style with fade in produces a smooth beginning, the
volume increases from low to high.
The Accompaniment Volume will change from 0 to the set value in
about 8 seconds. The keyboard volume will change from 0 to default
value at the same time.
Fade Out
Stopping the style with fade out produces a smooth ending, the volume
from high to low.
Press the [ ] button during Style playing.
The Accompaniment Volume will to 0 in about 8 seconds,
and the style stops. The keyboard volume will change from default
value to 0 at the same time.
Press the [FADE] button when Style is stopped, the fade indicator will
light up on LCD. Now press [START/STOP] button to start the style
playback, the fade indicator will flash.
decreases
FADE IN/OUT The fade
indicator will flash.
decrease
Tempo
Each style of the instrument has been programmed with a default
tempo; however, this can be changed by using the [TEMPO+] or
[TEMPO-] buttons.
1. Use the [TEMPO+] or [TEMPO-] button to change the tempo. The
value ranges from 30 to 280.
2. Hold down the [TEMPO] buttons can change the tempo quickly.
While the tempo is
change the tempo quickly.
3. Press the [TEMPO+] or [TEMPO-] buttons simultaneously to restore
the default tempo setting.
flashing on LCD, you can also use the data dial
to
One Touch Setting
When One Touch Setting is switched on, you can instantly recall all
auto accompaniment related settings including voices selection and
digital effects simply with a single touch of a button.
1.
to turns on the One Touch Setting for current style. LCD show
O.T.S. 1.
2. Press one of the [ONE TOUCH SETTING] buttons [M1]-[M4]. Voice
match the selected style can be instantly recalled.
3. Chord Mode is automatically turned on during O.T.S. mode.
4.
again to quit One Touch Setting mode, “O.T.S.” disappears.
Holding down the [SHIFT] button and then press the [O.T.S.] button
Holding down the [SHIFT] button and then press the [O.T.S.] button
FADE
A.B.C.
0
5
25
75
95
100
AW_M311_Manual_G05_160201
2016󾾠󾾠2󾾠󾾠1󾾠󾾠 10:37:17

12
Auto Accompaniment
1. When the [CHORD] is switched on, the chords you played in the
specified Chord section of the keyboard will be automatically
detected and will be used to control the playback of the selected
style.
2. Press the accompaniment keys, the corresponding chord will
display on LCD.
3. Split Point Set
SINGLE FINGER
Single finger type not only can detect single finger but also can detect
multi finger. And the single finger makes it easily to play chords through
only one, two or three keys. Including major, minor, seventh, and minor
seventh chord. Refer to relevant picture on the right for details.
MULTI FINGER
Multi finger type only can recognize those chords have listed in the
chord list, and also can be found in the dictionary function.
The default split key is F#3(19), Turn to “Function Menu” page for
more detail. The split point key and the other keys on the left of it
are accompaniment keys.
Auto Bass Chord
Major Triad
Only press the root note on the
keyboard.
Minor Triad
Press the root note and the nearest
left black key simultaneously.
Seventh chord
Minor seventh chord
Press the root note and the nearest
left white key simultaneously.
Press the root note and the nearest
left white and black keys
simultaneously.
C7
Cm7
Cm
C
C
0
C6
1 2
CM7CM7(#11)
3
CM(9)
45
CM7(9)
Caug
78
Cm Cm6
911
Cm7(b5)
6
C6(9) Cm7
10
13
Cm7(9) 14 Cm7(11)
15
CmM7
16
CmM7(9) 17
Cdim
Cm(9)
12
18
Cdim7
19
C7
20
C7sus4
21
C7(b5) C7(9)
22 23
C7(#11)
7aug
C
2928
7aug
CM
27
C7(#9)
26
C7(b13)
25
C7(b9)
C7(13)
24
30
Csus 4C1+2+5
31
Split Point
A.B.C.
0
5
25
75
95
100
AW_M311_Manual_G05_160201
2016󾾠󾾠2󾾠󾾠1󾾠󾾠 10:37:17

13
Other Function
Function Menu
Press [FUNCTION] button to enter the . The default
option of the menu is “Transpose”. When you enter the menu next
time, . Press
[FUNCTION] button repeatedly . Use [+]/[-] button to
set the parameter.
The option and the parameters are as the follows:
function menu
it will display the same option of you last operation
to select an option
Content
Transpose
Octave
Modulation
Beat
Split Point
Tune
MIDI Receive
MIDI Transmit
Automatic Shutdown
LCD Display
xPS 00
OCt 00
Mod off
bEt 04
SPt 19
TUE 00
CHI ALL
CHo 01
PWF 30
Range
-12~0~12
-1~0~1
ON/OFF
0,2…9
1~61
-50~50
01~16,ALL
01~16
30,60,OFF
Note:
TRANSPOSE
Press the [FUNCTION] button to set the transpose. The LCD displays
the current transpose value. Use [+]/[-] button to
from –12 to +12.
Press [+] and [-] buttons simultaneously to set its default value "0".
OCTAVE
Press the [FUNCTION] button to set the octave. The LCD displays the
current octave value. Use [+]/[-] button to
from –1 to +1 octaves.
Press [+] and [-] buttons simultaneously to set its default value.
MODULATION
Press the [FUNCTION] button to set the modulation. The LCD
currently display “ . Use [+]/[-] button to set modulation ON/ OFF.
Note: This modulation effect is unavailable to percussion.
BEAT
Press the [FUNCTION] button to set the beat function, LCD displays
. Press the [+] or [-] button to change the beat
value: 0, 2, 3, 4, 5, 6, 7, 8, 9. The default value is 4.
It will automatically quit the function menu if there is no operation in 3
seconds.
set the transpose
value over the range
set the octave value over the
range
MOD”
the current beat value
SPLIT POINT
Press the [FUNCTION] button to enter SPLIT POINT sub-menu. The
LCD displays the current split point value.
Use [+/YES] / [-/NO] button to adjust the split point value from 1 to 61.
The keyboard can be also used to set the split point.
The key of the split point is the part of the left area.
The default setting is 019.
0
5
25
75
95
100
AW_M311_Manual_G05_160201
2016󾾠󾾠2󾾠󾾠1󾾠󾾠 10:37:18

14
TUNE
Press the [FUNCTION] button to select the Tune
The LCD displays the tune value. Use [+]/[-] to change the tune value.
Its range is from –50 to +50 cents. Press [+] and [-] buttons together
will set the TUNE to its default value.
Note:
The tune setting will to both keyboard and style.
MIDI SETTING
Automatic Power Off
1. Press the [FUNCTION] button repeatedly until the LCD displays
“ .
2. The LCD displays the time value. The OFF, 30 and 60,
the default value is 30.
3. Use [+] or [-] button to change the Power Off time value.
Press [+] and [-] simultaneously to restore the default value: 30.
menu.
apply
1. Press the [FUNCTION] button to select the MIDI IN/OUT menu. LCD
displays “CHI ALL” or “CHo 01” respectively.
2. Use the [+]/[-] button to select a desired channel.
Channels for MIDI IN:
PWF 30”
options are
1~16, ALL, the default setting is All.
Channels for MIDI OUT: 1~16, the default setting is 01.
Mixer
Content
Accompaniment VOLUME
Rhythm Main VOLUME
Bass VOLUME
Chord 1 VOLUME
Chord 2 VOLUME
Chord 3 VOLUME
Voice R1 VOLUME
Voice R2 VOLUME
Voice L VOLUME
LCD Display
AVL 25
RTh 31
bAS 31
CH1 31
CH2 31
CH3 31
UP1 28
UP2 20
LOE 20
Range
0-32
0-32
0-32
0-32
0-32
0-32
0-32
0-32
0-32
Press [MIXER] button to enter the . The default option
of the menu is " Accomp", When you enter this menu next time,
Press [MIXER] button,
select the option you want to set. Use [+]/[-] to set the parameter.
The option and the parameters are as the follows:
Mixer menu
it will
display the same option of your last operation.
Note:
Press [+] and [-] buttons simultaneously, the LCD displays "OFF", it
means this parameter volume is turned off. Press [+] and [-] buttons
simultaneously again, the LCD will display the last volume level.
It will quit the Mixer menu if there is no operation in 3 seconds.
Other Function
0
5
25
75
95
100
AW_M311_Manual_G05_160201
2016󾾠󾾠2󾾠󾾠1󾾠󾾠 10:37:18

15
Memory
There are 4 memories (M1-M4).
1. While holding the [STORE] button, press one of the MEMORY
buttons: [M1] - [M4] to register the panel settings. The new settings
will replace the previous memory data. LCD show “Mem Stor”.
The settings include tempo, beat
value, sustain effect, etc.
2. Press one of the MEMORY buttons: [M1] - [M4] to recall the panel
settings.
Note:
The stored settings can not be recalled when the One Touch Setting
function is on.
The stored settings will be returned to the default settings after you
turned off the power.
voice number, style number,
Chord Dictionary
If you know the name of a chord but don't know how to play it, you can
use the Chord Dictionary function.
1. Press the [CHORD DICT.] button to enter this mode. The LCD
displays the Chord Type and Chord Notes.
2. The keys on and above the C4 are used to assign the Chord Type,
the keys on and above C5 are used to assign the Chord Root.
When the chord Type and Chord Root are confirmed, the LCD will
display the Chord and its staff position.
3. Play the chords on the keyboard according to the display. If you
press the correct notes, you will hear a prompt applause sound.
4. Press the [CHORD DICT.] button again to exit this mode.
24 Chords will be displayed in the dictionary mode as follows:
Note
C6
C#6
D6
Eb6
E6
F6
F#6
G6
Ab6
A6
Bb6
B6
Chord root
C
C#/Db
D
Eb/D#
E
F
F#/Gb
G
Ab/G#
A
Bb/A#
B
Note
C4
C#4
D4
Eb4
E4
F4
F#4
G4
Ab4
A4
Bb4
B4
Chord root
m
m
M
M(9)
6
mM7
M7
(9)
m6
m7(9)
m7
m7b5
7
Note
C5
C#5
D5
Eb5
E5
F5
F#5
G5
Ab5
A5
Bb5
B5
Chord root
7(b9)
7(9)
7(#9)
7(b13)
7(13)
7(#11)
dim7
dim
7aug
aug
7sus4
sus4
0
5
25
75
95
100
AW_M311_Manual_G05_160201
2016󾾠󾾠2󾾠󾾠1󾾠󾾠 10:37:19

Song
The instrument features 100 songs (Refer to Song List). Each song can be practiced in LESSON mode.
Listening to the Songs
1. Press the [SONG] button to enter the song mode. It will play all
songs circularly. Press the [SONG] button again, it will stop the
song and exit the song mode.
2. In song mode, use the number keys and [+] or [-] button to select a
song.
3. Once you start playing a song by pressing [START/STOP] button, it
will play current song repeatedly. Press the [START/STOP] button
again, it will stop the current song but not exit the song mode.
4. Use the [TEMPO+] or [TEMPO-] button to change the tempo of the
current song.
5. When the song is stopped, press [STYLE], [VOICE],
, [M1] - [M4] to exit the song
mode.
[SHIFT]+[DUAL], [SHIFT]+[LOWER]
Lesson Mode
In the instrument, there are 3 different ways to practice the songs: time
value training, note correction training, melody off.
1. In Song mode, press the [LESSON] button to enter the lesson mode
or switch the lesson mode.
2. Press the [START/STOP] button to start learning. The LCD will
display the note .
3. Press the [START/STOP] button again to stop learning.
4. There are 3 lesson modes and a grading system.
Lesson 1:
Lesson 2:
Lesson 3: the keyboard will score your practice by the correction of
the time value and note.
Grade: In lesson mode, the
keyboard will play the prompt sound to tell you the level
you get.
Level 1: Ok
Level 2: Good
Level 3: Very Good
Level 4: Excellent
After grading, the song will be playing again, you can learn it again.
The grading system
will help you keep track of your progress.
to play
you need to play at the correct time value. As long as
you play any key at the right time, the correct note will
sound.
you need to play the correct notes. The lesson will
continue only when you have played the note displayed
on LCD, otherwise the song will stop and wait.
each time when you finish a lesson,
16
0
5
25
75
95
100
AW_M311_Manual_G05_160201
2016󾾠󾾠2󾾠󾾠1󾾠󾾠 10:37:19

17
Song Recording
You can record your performance (up to 350 notes), and the
accompaniment.
1. ,
the record flag appears on the LCD, the beat flashes.
2. Play the notes you want to record or press the [START/STOP]
button to start recording. turn on the
chord mode, and play the chords on the left of the keyboard.
3.
again to stop recording. The record flag disappears.
4. to
play the notes you recorded.
5.
6. recording,
can stop recording and play the notes you recorded.
Note:
If you turned off the keyboard, the data you have recorded will be lost.
Holding down the [SHIFT] button and press the [RECORD] button
To record accompaniment,
Holding down the [SHIFT] button and press the [RECORD] button
Holding down the [SHIFT] button and press the [PLAY] button
Holding down the [SHIFT] button and press the [PLAY] button
again to stop it.
During holding down the [SHIFT] button and press the
[PLAY] button
0
5
25
75
95
100
AW_M311_Manual_G05_160201
2016󾾠󾾠2󾾠󾾠1󾾠󾾠 10:37:20

18
MIDI Functions
By using the MIDI functions you can expand your musical possibilities. This section explains what MIDI is, and what it can do, as
well as how you can use MIDI on your instrument.
MIDI (short for Musical Instrument Digital Interface) allows a wide
variety of electronic musical instruments, computers and other related
devices to connect and communicate with one another. MIDI carries
event messages that specify notation, pitch and velocity, control
signals for parameters such as volume, vibrato, audio panning, and
program change information to change the voice selections.
The instrument can output the real-time playback information via
and control external MIDI devices. The instrument can also
accept incoming MIDI messages and generate sound accordingly.
MIDI
messages
What's MIDI?
MIDI Terminals
MIDI Connection
The electronic keyboard is equipped with a standard USB interface
instead of conventional MIDI IN and MIDI out connectors. The USB
interface allows the keyboard to be connected to a computer without
the need to separately purchase a MIDI interface for the computer.
Most computers will automatically recognize the keyboard as a MIDI
interface, allowing MIDI messages to be received from, or sent to,
music programs running on the computer.
To connect the keyboard to a computer you will need a standard USB
A-B cable and suitable software such a music sequencing program.
Note:
Activate the computer from a sleep/suspended/standby mode before
connecting the USB cable.
Connect the USB cable to the instrument and a computer before
turning the power of the instrument on.
0
5
25
75
95
100
AW_M311_Manual_G05_160201
2016󾾠󾾠2󾾠󾾠1󾾠󾾠 10:37:21

19
Trouble Shooting
Specifications
Keyboard
61
Display
Multi-functional LCD
Polyphony
32
Voice
320, including 4 drum kits
Style
110
Song
100
Demo
100
Tempo
30-280
Registration Memory
4
Problem
The speakers produce a “pop” sound whenever
the power is turned ON or OFF.
No sound results when the keyboard is played.
When using a mobile phone, noise is produced.
The auto accompaniment does not play back
even Sync is in standby condition and a key is
pressed.
Possible Cause and Solution
This is normal and is no cause for alarm.
Make sure the master volume is set at appropriate levels.
Using a mobile phone in close proximity to the instrument may
produce interference. To prevent this, turn off the mobile phone or
use it further away from the instrument.
You may be trying to start accompaniment by playing a key in the
right-hand range of the keyboard. To start the accompaniment with
Sync Start, make sure to play a key in the left-hand range of the
keyboard.
Control button
Power on/off switch, Function,Mixer,Tempo+/-,
ChordDict, Lesson, L/R Part, DSP, Style, Voice, Song,
Memory, M1-M4, O.T.S., Dual, Sustain, Touch,
Metro,Lower
Accompaniment Control
Start/Stop, Sync Start, Intro/Ending, Fill A, Fill B, Fade
In/Out, Chord
Record Function
Record, Play
Connectors
DC IN, Phones, USB, Sustain
Power Supply
DC IN 12V
Speaker
4Ω 3W + 3W
Dimensions
Weight
(without batteries)
940(W) x 360(D) x 145(H)mm
4.5kg
* All specifications and appearances are subject to change without notice.
0
5
25
75
95
100
AW_M311_Manual_G05_160201
2016󾾠󾾠2󾾠󾾠1󾾠󾾠 10:37:21

20
Voice List
No
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
PIANO
CHROMATIC PERCUSSION
STRINGS & ORCHESTRAL INSTRUMENTS
GUITAR
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
Vibraphone & Harpsichord
Marimba
Marimba (wide)
Sine Marimba
Marimba (stereo)
Marimba & Vibraphone
Wood Drum
Xylophone
Tubular Bells 1
Tubular Bells 2
Tubular Bells 3
Dulcimer
Drawbar Organ
Drawbar Organ (stereo)
Soft Stereo Drawbar Organ
Mellow Drawbar Organ
Bright Drawbar Organ
Percussive Organ
Detuned Percussive Organ
Rock Organ
Church Organ
Detuned Church Organ
Church Organ (octave mix) 1
Church Organ (octave mix) 2
Reed Organ
Reed Organ (stereo)
Accordion 1
Accordion 2
Accordion (stereo)
Harmonica
Harmonica (dark)
Tango Accordion
Tango Accordion (dark)
Acoustic Guitar (nylon) 1
Acoustic Guitar (nylon) 2
Chorus Nylon Guitar 1
Chorus Nylon Guitar 2
Nylon Guitar (stereo) 1
Nylon Guitar (stereo) 2
Acoustic Guitar (steel) 1
Acoustic Guitar (steel) 2
12-Strings Guitar
Detuned Steel Guitar
Electric Guitar (jazz) 1
Electric Guitar (jazz) 2
Electric Guitar (clean)
Clean Guitar (stereo)
Soft Clean Guitar
Chord Clean Guitar
Electric Guitar (muted)
Stereo Muted Guitar
Chord Muted Guitar
Overdriven Guitar
Distortion Guitar
Guitar Harmonics
Acoustic Bass 1
Acoustic Bass 2
Vibr&Hrp
Marimba
MarimbaW
SinMarmb
MarimbaS
Marm&Vib
WoodDrum
Xylophon
TubuBel1
TubuBel2
TubuBel3
Dulcimer
DrawOrgn
DrawOrgS
DrawOgSf
MellDOrg
DrawOrgB
PercOrgn
DePerOrg
RockOrgn
ChurOrgn
DeChuOrg
ChrOrgO1
ChrOrgO2
ReedOrgn
ReedOrgS
Acordin1
Acordin2
AcordinS
Harmnica
HarmnicD
TangoAcd
TangAcdD
NylnGtr1
NylnGtr2
NylnGtC1
NylnGtC2
NylnGtS1
NylnGtS2
SteelGt1
SteelGt2
12StrGtr
DetStlGt
JazzGtr1
JazzGtr2
CleanGtr
CleanGtS
ClnGtSof
ClnGtCho
MutedGtr
MutedGtS
MutGtCho
Ovrdrive
DistGtr
GtrHarmo
AcoBass1
AcoBass2
BASS
ORGAN
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
168
169
170
171
172
Acoustic Bass 3
Acoustic Bass 4
Acoustic Bass Detuned
Velocity Crossfade Bass
Jazz Style
Acoustic Bass & Mute Guitar
Electric Bass (finger) 1
Electric Bass (finger) 2
Electric Bass (finger) 3
Electric Bass (finger) 4
Finger Bass (dark) 1
Finger Bass (dark) 2
Detuned Finger Bass 1
Detuned Finger Bass 2
Velocity Bass
Bass & Distortion Guitar
Electric Bass (pick) 1
Electric Bass (pick) 2
Mute Pick Bass
Pick & Finger Bass
Pick Bass & Clean Guitar
Detuned Pick Bass
Fretless Bass 1
Fretless Bass 2
Slap Bass 1
Slap Bass 2
Slap Bass 3
Slap Bass 4
Synth Bass 1
Synth Bass 2
Synth Bass 3
Synth Bass 4
Violin 1
Violin 2
Two Violin
Viola 1
Viola 2
Two Viola
Cello 1
Cello 2
Contrabass 1
Contrabass 2
Tremolo Strings 1
Tremolo Strings 2
Pizzicato Strings 1
Pizzicato Strings 2
Orchestral Harp 1
Orchestral Harp 2
Orchestral Harp (stereo)
Timpani 1
Timpani 2
Strings Ensemble 1
Strings Ensemble 2
Strings Ensemble 3
Strings Ensemble 4
Stereo Strings 1
Stereo Strings 2
Synth Strings 1
AcoBass3
AcoBass4
DetAcoBs
VelCroBs
JazzSty
ABs&MtGT
FngrBs1
FngrBs2
FngrBs3
FngrBs4
FngrBsD1
FngrBsD2
DeFngBs1
DeFngBs2
VelBass
Bs&DisGt
PickBs1
PickBs2
PickBsM
Pk&FgBs
PBs&ClGt
DetPkBs
Fretles1
Fretles2
SlapBas1
SlapBas2
SlapBas3
SlapBas4
SynBass1
SynBass2
SynBass3
SynBass4
Violin1
Violin2
TwoVioln
Viola1
Viola2
TwoViola
Cello1
Cello2
Contrbs1
Contrbs2
TremStr1
TremStr2
PizzStr1
PizzStr2
Harp1
Harp2
HarpS
Timpani1
Timpani2
Strings1
Strings2
Strings3
Strings4
StringS1
StringS2
SynStrs1
ENSEMBLE
Name
Acoustic Grand Piano 1
Acoustic Grand Piano 2
Acoustic Grand Piano (dark)
Octave Grand Piano 1
Octave Grand Piano 2
Octave Grand Piano 3
Piano & Choir
Acoustic Grand Piano (wide)
Bright Acoustic Piano 1
Bright Acoustic Piano 2
Bright Acoustic Piano 3
Bright Acoustic Piano 4
Bright Acoustic Piano 5
Bright Piano (stereo) 1
Bright Piano (stereo) 2
Detuned Electric Piano 1
Detuned Electric Piano 2
Chorus Piano
Bright Acoustic Piano (wide) 1
Bright Acoustic Piano (wide) 2
Piano & Vibraphone
Electric Grand Piano
Electric Grand Piano (wide)
Honky-tonk Piano
Honky Tonk Piano (dark)
Honky Tonk Piano (wide) 1
Honky Tonk Piano (wide) 2
Electric Piano 1
Electric Piano (stereo)
50's Electric Piano
Electric Piano (wide) 1
Electric Piano (wide) 2
Electric Piano (wide) 3
Electric Piano (wide) 4
Electric Piano 2
Detuned Electric Piano 1
Detuned Electric Piano 2
Harpsichord
Harpsichord (wide)
Harpsichord (octave mix) 1
Harpsichord (octave mix) 2
Harpsichord (with key off)
Clavi
Clavi (stereo)
Clavi (wide)
Wah Clavi
Celesta
Celesta (dark)
Celesta & Sine
Reecho Bell
Celesta & Music Box
Glockenspiel
Glockenspiel & Sine
Music Box
Vibraphone
Vibraphone (wide)
Vibraphone & Bell
LCD Name
GrandPn1
GrandPn2
GrandPnD
OctPno1
OctPno2
OctPno3
Pno&Cho
GrandPnW
BritPno1
BritPno2
BritPno3
BritPno4
BritPno5
BritPnS1
BritPnS2
DetunEP1
DetunEP2
ChoruPno
BritPnW1
BritPnW2
Pno&Vib
E.Grand
E.GrandW
HnkyTonk
HnkTonkD
HnkyTkW1
HnkyTkW2
E.Piano1
E.PianoS
50'sEP
EPianoW1
EPianoW2
EPianoW3
EPianoW4
E.Piano2
DetunEP1
DetunEP2
Harpsi
HarpsiW
HarpsiO1
HarpsiO2
HarpsiOf
Clavi
ClaviS
ClaviW
WahClavi
Celesta
CelestaD
Cele&Sin
ReBell
Cel&Mbox
Glocken
Glkn&Sin
MusicBox
Vibra
VibraW
Vibr&Bel
0
5
25
75
95
100
AW_M311_Manual_G05_160201
2016󾾠󾾠2󾾠󾾠1󾾠󾾠 10:37:21
