Mercia Garden Products 010VLPA0305SDNW-V1 User manual







 

 
















  



2mm Drill bit
x2 





























































 

















































ANY QUESTIONS?
Scan the QR code to
contact us via our customer
portal.
PLEASE SCAN HERE:


 

8
Some steps within this set of instructions come with an added video guide for your
convenience. These can be accessed via the QR code and used to aid you in constructing that
step. See below for how to use.
You can also nd all the videos on our youtube channel:
https://www.youtube.com/@merciagardenproducts8716/videos
ACCESSING VIDEO GUIDES...
1.Find the QR code within the instruction step...
2. Open camera app...
3. Scan QR code...
4. Watch the video...
On your personal smart device (phone, tablet etc), open your camera app or QR code scanner
app.
To scan the QR code, hold the camera over the QR code so that it can be seen on the screen.
Once the QR code has been registered, follow the prompts on your device to open the video.
(This will vary depending on your device.)
Please note: Ensure to use the back camera of your smart device as this will scan the QR code more
accurately.

The video guide will now be displayed on your smart device.
Parts Needed- No. QTY 1
No. QTY 1
No. QTY 1
Step..... 
Within the instruction step, there will be an icon in the top right that has a QR code in. This
is where the video can be accessed from.
Please note: not every step has a video guide.
Disclaimer: The garden building constructed in the video guides may be
constructed dierently to your building. Please ensure to read your instructions
carefully to avoid error.
ACCESSING VIDEO GUIDES...

 

Before assembly
please make sure you have a
suitable base ready to erect your
building
MADE IN GREAT BRITAIN
Overall Dimensions:
Width = 859mm
Depth = 1604mm
Height = 1856mm
Base Dimensions:
Width = 804mm
Depth = 1470mm
13
14
15
50mm Screw x 24
Felt Tacks x 34
20mm Screw x 6
30mm Screw x 74
Door Gable QTY 1
AI-01OVLPDG1410X1887-V1
Plain Side QTY 2
AI-01OVLPPS800X1567-V1
Plain Gable QTY 1
AI-01OVLPPG1410X1887-V1
Floor QTY 1
AI-01OSBF1460X795-V1
Roof QTY 2
PI-03-0331
Door QTY 1
AI-01MBDR1660X660-V1
Ridge Bar - 28x28x744mm QTY 1
F2828-744mm
Eave Frame - 28x28x835mm QTY 2
F2828-835mm
Fascia - 12x60x851mm QTY 4
S1260-851mm
Door Strip - 12x28x1590mm QTY 2
S1228-1590mm
Cover Trim - 12x45x1560mm QTY 4
S1245-1560mm
Finial QTY 2
Shed Diamond Finial
T-hinge QTY 2
PI-02-1041
“L” Bracket QTY 2
PI-07-0012
Turn Button QTY 2
PI-07-0034
Nail Bag
2
134
56
Building Contents:
7
8
9
11
12
10
16
Felt
There may be more screws than required in the nail bag.

 

Pre Assembly
Before assembling remove the transportation blocks from the bottom of each
panel.
Take care removing the blocks as to not damage the panels. Tap with a at headed
screwdriver and hammer.
Dispose of the blocks once removed.
PLEASE SCAN HERE:
30mm
screw
Pre drill
hole
1
6
IMPORTANT: Pre-drill before xing screws.
Step 1
Parts Needed - No. 1 QTY 1
No. 6 QTY 1
No. 13 QTY 2
Rest the door (No. 6) into the door
gable (No. 1) opening, ensuring there
is equal spacing on each side.
Secure into place with 2 x T-hinges
(No. 13) using 7x30mm per hinge.
*Ensure to align the hinges and
screws with the framing on the back
of the door.
14x30mm Screws
13
PLEASE SCAN HERE:
IMPORTANT: Pre-drill before xing screws.
4
Step 2
Parts Needed - No. 4 QTY 1
Place the Floor (No. 4) onto a rm and
level base. Ensure your base has suitable
drainage and is free from areas where
standing water can collect.
IMPORTANT: Pre-drill before xing screws.
50mm
screw
Pre drill
hole
2
3
a
a
a
Step 3
Parts Needed - No. 2 QTY 1
No. 3 QTY 1
Sit the Plain Gable (No.3) and the
rst Plain Side (No. 2) onto the
oor.
*Ensure the plain gable sits inside
the plain side.
Fix the panels at the corner using
3x50mm screws.
Do NOT secure the building to
the oor until the roof has been
tted.
3x50mm Screws
a

 

IMPORTANT: Pre-drill before xing screws.
Step 4
Parts Needed - No. 1 QTY 1
No. 2 QTY 1
Rest the assembled door gable (No.1)
and the second plain side (No. 2) onto
the oor.
*Ensure the door gable sits inside the
plain sides.
Fix the panels at the corner using
9x50mm screws.
Do NOT secure the building to the
oor until the roof has been tted.
9x50mm Screws
a
a
a
a
a
a
a
aa
50mm
screw
Pre drill
hole
2
1
a
IMPORTANT: Pre-drill before xing screws.
Step 5
Parts Needed - No. 7 QTY 1
No. 14 QTY 2
14
7
a
b
Pre drill
hole
20mm
screw
30mm
screw
b
aAttach the “L” brackets (No. 14) to
each end of the ridge bar (No. 7),
ensuring the backs are ush with
the edge of the framing using
2x20mm screws per“L” bracket.
Locate the assembled Ridge Bar
between the central upright of
the gables.
Fix to both gables using the “L”
brackes using 2x30mm screws per
side.
4x20mm Screws
4x30mm Screws
PLEASE SCAN HERE:
IMPORTANT: Pre-drill before xing screws.
30mm
screw
Pre drill
hole
8
5
Step 6
Parts Needed - No. 5 QTY 2
No. 8 QTY 2
Attach an Eave frame (No. 8) to
each roof sheet (No. 5) using
3x30mm screws, as shown in the
illustration. Ensure the framing is
ush to the ends and side of the
Roof sheet.
Locate the assembled Roof sheets
onto the gables, and secure each
sheet to the building using
8x30mm screws, ensuring there is
no more than 300mm between
each screw.
22x30mm Screws
IMPORTANT: Pre-drill before xing screws.
50mm
screw
Pre drill
hole
b
b
b
b
b
b
Step 7
Once the roof has been xed into
position, secure the building to the
oor using 12x50mm screws.
*Ensure to align the screws with
the oor bearers.
12x50mm Screws
b

 

HANDLE
WITH CARE
12
3
4
Felt
tacks
16
Step 8
Parts Needed - No. 16 QTY 1
Cut the felt into 1 sheet measuring
1413mm (L) x 1000mm (W) and lay onto
the roof, allowing approximately 50mm
of overhang around the building.
Fix the felt into position using felt tacks at
100mm intervals.
32 x Felt Tacks
100mm
IMPORTANT: Pre-drill before xing screws.
11
11
11
11
30mm
screw
Pre drill
hole
Step 9
Parts Needed - No. 11 QTY 4
Fix the cover trims (No. 11) to the
corners of the building, securing
each trim using 3x30mm screws.
12x30mm Screws
IMPORTANT: Pre-drill before xing screws.
912
9
9
912
30mm
screw
Pre drill
hole
Step 10
Parts Needed - No. 9 QTY 4
No. 12 QTY 2
Attach the Fascia’s (No. 9) to the front and
back of the building using 2x30mm screws
per Fascia.
*Ensure to trap the felt between the fascia’s
and the building.
Locate the Finial’s (No. 12) centrally on top of
the Fascias and x in place using 2x30mm
screws per Finial.
12x30mm Screws

 

IMPORTANT: Pre-drill before xing screws.
30mm
screw
Pre drill
hole
10 10
10
Step 11
Parts Needed - No. 10 QTY 2
Locate the door strips (No. 10) to
the inside of the door gable, as
shown.
Fix each strip into place using
4x30mm screws.
8x30mm Screws
IMPORTANT: Pre-drill before xing screws.
Pre drill
hole
30mm
screw
Step 12
Parts Needed - No. 15 QTY 2
Locate a the Turn Buttons (No. 15)
to the top and bottom of the Door
Gable, as shown in the illustration.
Fix in place using 1x30mm screw
per Turn Button.
2x30mm Screws
It is ESSENTIAL that you apply wood
treatment immediately after the building
has been assembled.

