Mercia Garden Products 03DTSHHP0806HGD4MW-V1 User manual

P 1
Please retain product label and instructions for future reference
General Instructions
Measure
under the
head
Measure
overall
length
Screws & Nails Bolts To identify the
xings required
for each step use a
measuring tape.
REGISTER FOR YOUR
ANTI-ROT
GUARANTEE TODAY
PLEASE SCAN HERE:
03DTSHHP0806HGD4MW-V1 & 03DTMBHP0806RFP-V1
8x6 Clover Summerhouse
2mm Drill bit
x2 Winter = High Moisture = Expansion
Summer = Low Moisture = Contraction
All building’s should be
erected by two adults
For ease of assembly, you
MUST pilot drill all screw
holes and ensure all screw
heads are countersunk.
CAUTION
Every eort has been made during the
manufacturing process to eliminate the
prospect of splinters on rough surfaces of the
timber. You are strongly advised to wear gloves
when working with or handling rough sawn
timber.
For ease of assembly, you
will need a tape measure to
check dimensions of
components.
For assistance please contact customer care on: 01636 821215
Mercia Garden Products Limited,
Sutton On Trent,
Newark,
Nottinghamshire,
NG23 6QN
www.merciagardenproducts.co.uk
BEFORE YOU START PLEASE READ INSTRUCTIONS CAREFULLY
- Check the pack and make sure you have all the parts listed.
- When you are ready to start, make sure you have the right tools at hand (not supplied) including a Phillips screw-
driver, Stanley knife, Wood saw, Step ladder, Hammer and a Drill with 2mm bit.
- Ensure there is plenty of space and a clean dry area for assembly.
LOCATION FOR YOUR GARDEN BUILDING
A minimum of 60cm should be left around the perimeter of your garden building to allow access for maintenance,
annual treatment and to allow air ow around the building.
Where possible you should avoid placing your garden building underneath large trees to prevent the tree causing
damage to the building.
TIMBER
As with all natural materials, timber can be aected during various weather conditions. For the duration of heavy or
extended periods of rain, swelling of the wood panels may occur. Warping of the wood may also occur during
excessive dry spells due to an interior moisture loss. Unfortunately, these processes cannot be avoided but can be
helped. It is suggested that the outdoor building is sprayed with water during extended periods of warm sunshine
and sheltered as much as possible during rain or snow.
Once your garden building has been installed it will need to be treated as soon as possible and annually to prevent
the timber from deteriorating and to waterproof it. This is required to maintain the anti-rot guarantee.
Dip Treated buildings - Require a preservative treatment to protect against rot and decay and a waterproof treatment
to prevent water ingress
Pressure Treated buildings - Require a waterproof treatment to prevent water ingress
Log Cabins - Are supplied untreated and require a preservative and waterproong treatment.
BUILDING A BASE
When thinking about where the building and base is going to be constructed:
Ensure that there will be access to all sides for maintenance work and annual
treatment.
Ensure the base is level and is built on rm ground, to prevent distortion. Refer to diagrams for the base dimensions,
The base should be slightly smaller than the external measurement of the building, i.e. The cladding should overlap
the base, creating a run o for water. It is also recommended that the oor be at least 25mm above the surrounding
ground level to avoid ooding.
TYPES OF BASE
- Concrete 75mm laid on top of 75mm hard-core.
- Slabs laid on 50mm of sharp sand.
Whilst all products manufactured are made to the highest standards of Safety and in the case of childrens
products independently tested to EN71 level, we cannot accept responsibility for your safety whilst erecting or
using this product.
Refer to the instructions pages for your specic product code
**Protim Aquatan T5 (621)**
Your building has been dip treated with Aquatan.
Aquatan is a water-based concentrate which is diluted with water, the building as been treated by the correct
application of Aquatan solution and then allowed to dry.
Aquatan is a decorative nish to colour the wood, which is applied industrially to timber fence panels and
garden buildings.
Aquatan undiluted contains: boric acid, sodium hydroxide 32% solution, aqueos mixture of sodium dioctyl
sulphosuccinat and alcohols: 2, 4, 6-trichlorophenol.

P 2
Please retain product label and instructions for future reference
03DTSHHP0806HGD4MW-V1 & 03DTMBHP0806RFP-V1
Finial QTY 2
PI-04-0023
Felt
30
31
32
33
34
35
36
37
Floor Panel
AI-R11MBF1175X1753-V1
QTY 2
Back Panel
AI-S11SHPP1180X2016
QTY 2
Side Window Panel
AI-03S11SH1SFWC1094X2016
QTY 2
Plain Panel
AI-S11SHPP613X2016-V1
QTY 2
Left Roof 8Ft
AI-S11MBANGRL1213X1028-V1
QTY 2
Right Roof 8Ft
AI-S11MBANGRR1213X1028-V1
QTY 2
6Ft Roof
AI-S11MBDANGR1830X1028-V1
QTY 2
Upper Door Panel
AI-S11SHPPBF940X242-V1
QTY 1
Master Door
AI-STDHGMD475X1720-V1
QTY 1
Secondary Door
AI-STDHGPD475X1720-V1
QTY 1
12345
679
12
21
T-Hinge QTY 6
PI-07-0185
23
Door Handle QTY 2
PI-07-0081
25
22
Turn Button QTY 2
PI-07-0034
24
Press Lock QTY 1
PI-07-0162
Tower Bolt QTY 2
PI-07-0114
13
14
15
16
17
18
Roof Cap - 12x95x695mm QTY 1
SR1295-695mm
Fascia - 12x95x1920mm QTY 2
SR1295-1920mm
Cover Trim - 12x40x1970mm QTY 8
S1240-1970mm
Roof Bearer A - 44x58x985mm QTY 1
F4458-G-1025mm (2x32° CUTS)
26
Unequal Hinge QTY 4
PI-07-0184
Window QTY 2
AI-FW540X1132-V1
8
19
Eaves Frame - 28x28x1784mm QTY 2
FS2828-1784mm
27
Casement Stay QTY 2
PI-07-0007
38
29
10
11
Eaves Frame - 28x28x2406mm QTY 2
FS2828-2406mm
20
Front Window Panel
AI-03S11SH1FSFWC710X2016-V1
QTY 2
Building Content:
Roof Bearer B - 44x58x528mm QTY 3
F4458-G-568mm (2x32° CUTS)
Fascia - 12x95x1260mm QTY 4
SR1295-1260mm
Roof Bearer Block - 44x58x84mm QTY 3
F4458-84mm
Window Strip - 16x27x1094mm QTY 4
WC1627-1094mm
Window Strip - 16x27x500mm QTY 8
WC1627-500mm
Door Stop Frame - 28x28x940mm QTY 1
FS2828-940mm
Window Strip - 12x56x576mm QTY 2
S1256-576mm
Door Strip - 12x49x940mm QTY 1
S1249-940mm
Flat Roof Strip - 12x120x724mm QTY 1
S12120-724mm
Door Frame Strip - 12x40x1740mm QTY 2
S1240-1740mm
Door Frame Strip - 12x40x996mm QTY 1
S1240-996mm
28
Overall Dimensions:
Width = 2464mm
Depth = 1880mm
Height = 2584mm
Base Dimensions:
Width = 2350mm
Depth = 1753mm
Before assembly
please make sure you have a
suitable base ready to erect your
building
MADE IN GREAT BRITAIN

P 3
Please retain product label and instructions for future reference
Nail Bag
There may be extra screws present in the nail bag
50mm Screw x 93
20mm Screw x 64
10mm Screw x 8
40mm Screw x 38
30mm Screw x 114
70mm Screw x 9
60mm Screw x 8
Felt Tacks x 270
Pre Assembly
Remove the transportation blocks from
the bottom of each panel before
beginning assembly.
Step 1
Parts needed - No. 20 QTY 1
No. 24 QTY 1
Secure the Door Strip (No.
24) with the edges being
ush to the Door Stop Frame
(No. 20) using 5x30mm
screws.
5 x 30mm Screws
Pre drill
hole
30mm
screw
20
20
24
24
SIDE VIEW
Step 2
Parts needed - No. 4 QTY 2
No. 11 QTY 1
No. 20 QTY 1
No. 24 QTY 1
Lay all of the required parts on to a
at level surface and x the Upper
Door Panel (No. 11) in the centre of
the two Front Window Panels (No.
4) with 3x50mm screws per side.
The Upper Door Panel should be
ush with the top of the left and
right Panels.
Fix the (already assembled in the
Step 1.) Door Strip (No. 24) and the
Door Stop Frame (No. 20) to the
bottom of the Front Window Panels
(No. 4) with 2x50mm screws per
side. The Door Stop Frame should
be ush with the bottom framing of
the Front Window Panels (No. 4).
10 x 50mm Screws
Pre drill
hole
50mm
screw
20
24
411 4

P 4
Please retain product label and instructions for future reference
For assistance please contact customer care on: 01636 821215
Mercia Garden Products Limited,
Sutton On Trent,
Newark,
Nottinghamshire,
NG23 6QN
www.merciagardenproducts.co.uk
Step 3
Parts needed - No. 4 QTY 2
No. 9 QTY 1
No. 10 QTY 1
No. 36 QTY 6
Fix the Secondary Door (No. 10) to
the Front Window Panel (No. 4).
Secure the T-hinges (No. 36) to the
Front Window Panel (No. 4) with
3x30mm screws per hinge.
Then x the T-hinges (No. 36) to
the door with 3x30mm screws per
hinge.
Repeat the process for the Master
Door (No. 9)
36 x 30mm Screws
36 36
Pre drill
hole
30mm
screw
9
10
secondary Door Master Door
44
1
1
1
1
Step 4
Parts needed - No. 1 QTY 2
Secure the oors (No. 1) together
using 8x50mm screws through the
oor bearers in an alternating
pattern.
Place the assembled oor panels
(No. 1) onto a rm and level base.
Ensure the base has suitable drain-
age, free from areas where stand-
ing water can collect.
8x50mm Screws
Pre drill
hole
50mm
screw

Please retain product label and instructions for future reference
P 5
Step 5
Parts needed - No. 3 QTY 2
No. 5 QTY 2
Fix the Side Window Panel (No. 3)
and the Plain Panel (No. 5) togeth-
er by screwing through the fram-
ing using 5x50mm screws.
Ensure to stagger screws to avoid
colliding.
Repeat this with the second Side
Window Panel and the Plain Panel
but the opposite way round, as
shown in the diagram.
10x50mm Screws
Pre drill
hole
50mm
screw
**Please note that when you
x the Plain Panel (No. 5) to the
second Side Window Panel (No. 3),
this is to be tted to the opposite
side.
35
35
3
2
Step 6
Parts needed - No. 2 QTY 1
No. 3 QTY 1
No. 5 QTY 1
Place the Back Panel (No. 2) the
Plain Panel (No. 5) with the
Window Side Panel (No. 3) (that
was assembled with in Step 5.) into
position and x together with
3x50mm screws.
**Do not secure to the Floor until
the Roof is xed in position
3x50mm Screws
Pre drill
hole
50mm
screw
5
Step 7
Parts needed - No. 2 QTY 1
Place the second Back Panel
(No. 2) in position and x with
6x50mm screws.
**Ensure to stagger screws to
avoid colliding.
**Do not secure to the Floor
until the Roof is xed in
position
6x50mm Screws
Pre drill
hole
50mm
screw
2
2

Please retain product label and instructions for future reference
P 6
Step 8
Parts needed - No. 3 QTY 1
No. 5 QTY 1
Place the Plain Panel (No. 5) that is
already assembled with the Side
Window Panel (No. 3) (that was
assembled with in Step 5.) in posi-
tion in a previous step and x
together with the Plain Panel (No.
5) using 3x50mm screws.
**Do not secure to the Floor until
the Roof is xed in position.
3x50mm Screws
Pre drill
hole
50mm
screw
3
5
5
Step 9
Parts needed - No. 4 QTY 2
Place the already assembled Door
Panel (No. 4, 9, 10 and 11). into posi-
tion and x together with the two Side
Window Panels (No. 3) 3x50mm screws
per side.
If the door has not been assembled yet,
please refer to Step 1, 2 & 3.
**Do not secure to the Floor until the
Roof is xed in position.
6x50mm Screws
Pre drill
hole
50mm
screw
4
4
3
3
Step 10
Parts needed - No. 7 QTY 2
No. 8 QTY 2
Fix the Left and Right Roof Panels
(No. 7 & 8) together by screwing
through the framing using 4x50mm
screws per assembly.
repeat this action for the other roof
side.
Ensure to stagger screws to avoid
colliding.
8x50mm Screws
Pre drill
hole
50mm
screw
7
8
7
8

Please retain product label and instructions for future reference
P 7
Step 11
Parts needed - No. 6 QTY 2
No. 7 QTY 2
No. 8 QTY 2
No. 34 QTY 1
Roll out the Felt (No. 34) and use the Roof Panels
(No. 6, 7 & 8) as shown in the illustration so you
can accuartely cut the felt before tting.
Leave a 100mm space between each panel and
cut through the centre to create 50mm overhang
for each strip. Make sure that there is a 50mm
overhang under each panel
Measure and cut four strips of felt (No. 34) at
1600x200mm.
Measure and cut one full width strip of felt (No.
34) at 1400mm long.
Once all the pieces of felt have been cut keep
these to one side whilst you construct the roof.
1600x200mm
QTY 4
1400mm
QTY 1
100mm gap between
each panel
100mm gap between
each panel
50mm overhang
below each panel
50mm overhang
below each panel
50mm overhang
below each panel
50mm overhang
below each panel
1
2
3
4
34
HANDLE
WITH CARE
12
3
4
Step 12
Parts needed - No. 12 QTY 1
No. 13 QTY 3
Pre drill holes in the underside of
Roof Bearer A (No. 12) and all 3 of
the Roof Bearer B (No. 13) parts
with an oset position of 40mm
from each of the pointed ends in
the centre of the bearers. These
holes are going to later recieve
60mm screws.
Pre drill
hole
12
13
13
12
SIDE VIEW
UNDERNEATH VIEW
SIDE VIEW
UNDERNEATH VIEW
40mm
Step 13
Parts needed - No. 6 QTY 2
Place both 6Ft Roof Panels (No. 6)
on the oor and measure 195mm
from the top of the Framing and
mark the distance on the vertical
framing with a line.
Repeat this step for both roof 6Ft
Roof Panels (No. 6) .
6
195mm

Please retain product label and instructions for future reference
P 8
Step 14
Parts needed - No. 7 QTY 2
No. 8 QTY 2
Place the recently assembled roof
panels (No. 7 & 8) on the oor and measure
280mm from the top of the Framing and
mark the distance on all of the vertical
framings with a line.
If these panels have not been assembled
yet, please refer to step 10.
Repeat this step for both sets of
assembled roof panels (No. 7 & 8).
7
8
280mm
Step 15
Parts needed - No. 12 QTY 1
No. 14 QTY 3
Fix the Roof Blocks (No. 14) to Roof
Bearer A (No. 12) using 2x70mm
screws per roof block. Screw up
through the bearer into the block
using the dimensions shown.
**Place tape measure under the
bottom pointed corner and
measure and mark from this
point.
6x70mm Screws
Pre drill
hole
70mm
screw
14
14
12
14
165 471 165
471

Please retain product label and instructions for future reference
P 9
Step 16
Parts needed - No. 6 QTY 1
No. 12 QTY 1
Place one of the 6Ft Roof Panels
(No. 6) on the oor. Place the main
Roof Bearer A (No. 12) at on the
bevelled end with the pointed
corner meeting the line drawn in
Step 13.
Fix Roof Bearer A (No. 12) to the 6Ft
Roof Panels (No. 6) by using a
60mm screw in the pre drilled hole
that was made in Step 12.
1x60mm Screws
Pre drill
hole
60mm
screw
Position Roof Bearer A
up against drawn line
and x to 6Ft Roof
12
12
6
6
SIDE VIEW
VIEW FROM ABOVE
Step 17
Parts needed - No. 6 QTY 2
No. 7 QTY 1
No. 8 QTY 1
No. 12 QTY 1
No. 14 QTY 3
*The use of a step ladder is
essential to construct the roof.*
To construct the Roof,
place the previously assembled
(in Step 16) 6ft Roof Panel (No. 6)
and Roof Bearer A (No. 12) on top
of the Summer House and let the
pointed edge on the other end of
the bearer meet the line drawn (in
Step 13) on the second 6ft Roof
Panel (No. 6).
When in position, Use
1x60mm screw to x up through
the previous drilled hole (in Step
12) of the bearer into the roof
frames. The beveled end of the
bearer must be at against the
roof.
Once secure, place the third
set of roof panels (No. 7 & 8)
previously assembled (in Step 10)
onto the building as shown.
You will secure it in the next
couple of steps.
1x60mm Screws
Pre drill
hole
60mm
screw
A
B
A
B
C
C
6
6
6
6
6
7
8
12
14

Please retain product label and instructions for future reference
P 10
Step 18
Parts needed - No. 7 QTY 1
No. 8 QTY 1
Place the remaining set of roof
panels (No. 7 & 8) (previously
assembled in Step 10) on to the
Summer House using the same
method mentioned in the previous
step. 7
8
Step 19
Parts needed - No. 13 QTY 3
Secure the Roof bearer B’s (No. 13)
underneath Roof bearer A (No. 12)
using 2x60mm screws per bearer
through the previously drilled
holes (in Step 12) up into the roof
panels. Make sure that the Roof
bearer B (No. 13) parts t evenly
under the framing of the roof
panels and that the pointed
corners meet the line that was
drawn in a Step 14.
The underside of the roof should
look as shown.
6x60mm Screws
Pre drill
hole
60mm
screw
13
13
13
Step 20
Once all four roof sides are on the
building, pull the corners together and
secure underneath the roof as shown. Fix
using 3x50mm screws per join.
The Roof bearers may need to be
unscrewed and repositioned to ensure all
the roof panels sit level with each other.
*Roof panels will support each other if
bearers are unscrewed.
Once the panels are secure,
re-screw the bearers if necessary, and
secure the threes Roof Bearers B (No. 13)
through their centres together with the
Roof Bearer A using 3x70mm screw.
12x50mm Screws
3x70mm Screws
Pre drill
hole
50mm
screw
70mm
screw
13
13
B
A
B
A
