Mercia Garden Products 03HEL1008DDFW-V2 User manual

123456
10 11
28
We strongly recommend pre drilling
holes before xing screws.
50mm Screw x36
40mm Screw x100
Felt Tacks x185
30mm Screw x125
60mm Screw x50
30mm Black Screw x2
789
27
80mm Screw x6
03HEL1008DDFW-V2
For domestic and family use only
Retain Instructions for future reference
Dimensions
Length = 2416mm
Width = 2436mm
Height = 2124mm
For Assistance Please
Contact Customer Care on
01636 880514
2mm Drill bit
x2
Winter = High Moisture = Expansion
Summer = Low Moisture = Contraction
This building should be erected by
two people.
For ease of assembly, it is advisable to
pilot drill all screw holes and ensure
all screw heads are countersunk.
BEFORE YOU START PLEASE READ INSTRUCTIONS CAREFULLY
- Check the pack and make sure you have all the parts listed.
- When you are ready to start, make sure you have the right tools at hand
(not supplied) including a Phillips screwdriver, Stanley knife, wood saw,
step ladder and drill with 2mm bit.
- Ensure there is plenty of space and a clean dry area for assembly.
TIMBER
As with all natural materials, timber can be aected during various weather
conditions. For the duration of heavy or extended periods of rain, swelling of the
wood panels may occur. Warping of the wood may also occur during excessive
dry spells due to an interior moisture loss. Unfortunately, these processes cannot
be avoided but can be helped. It is suggested that the outdoor building is
sprayed with water during extended periods of warm sunshine and sheltered as
much as possible during rain or snow.
Our buildings are delivered pre-treated with a water based timber treatment
however this only helps to protect during transit of your garden item. To
validate your guarantee and for better protection against weathering it is
ESSENTIAL that you treat the garden building with a wood preserver within 3
months of assembly. This will need to be re-applied annually to ensure longevity
of your building. Care must be taken when constructing the garden building
that it is not touching the ground and is on a suitable base.
BUILDING A BASE
When thinking about where the building and base is going to be constructed: Ensure that there will be access to all sides for maintenance work and
annual treatment.
TYPES OF BASE
- Concrete 75mm laid on top of 75mm hard-core.
- Slabs laid on 50mm of sharp sand.
Ensure the base is level and is built on rm ground, to prevent distortion. Refer to diagrams for the base dimensions, The base should be slightly
smaller than the external measurement of the building, i.e. The cladding should overlap the base, creating a run o for water. It is also recommended
that the oor be at least 25mm above the surrounding ground level to avoid ooding.
Whilst all products manufactured are made to the highest standards of Safety and in the case of childrens products independently tested to EN71 level, we
cannot accept responsibility for your safety whilst erecting or using this product.
Before
assembly make sure you
have a suitable base
ready to erect your
building
2x Front Fascia 1650mm
Door panel Window
Gable R
Window
Gable L
Plain Side
QTY 2 Back Roof
Left
Back Roof
Right
Back
Floor
QTY 2
Slave
Door
Master
Door
4x Bottom Roof Trim 1455mm
12 4x Top Roof Trim 1510mm 13 2x Cover Trim 1783mm
14 2x Cover Trim 2059mm
15 Roof Support 2830mm QTY 3 16 2x Roof End 2960mm
17 Door Bar 1705mm 18 2x Door Beading 1711mm
Finial
23 Turn Button
QTY 2
22 Flush Hinge
QTY 6
Key Plate
21
20
Door Handle
QTY 2
24
Mortice Lock
25
Barrel Bolt
QTY 2
26 Felt
Nail Bag
x4 Rain Guard 580mm
19
Roof Block
QTY 6
Lrg Rain Guard - 1472mm
29

50mm
screw
Pre drill
hole
16x50mm screws
Remove transportation blocks
from the bottom of each panel
before beginning assembly.
Each Panel should have two
blocks.
Place floor on a firm and level
base, ensure base has suitable
drainage free from areas
where standing water can
collect. (See front page on
base requirements).
30mm
screw
Pre drill
hole
36x30mm screws
11
11
30mm
screw
Pre drill
hole
8x30mm screws
b
Position floor section a & b as in
diagram so that floors are flush to
each other, note that the floors do
not connect by a T&G joint.
Fix with 16x50mm screws alternate
the fixing positions along the
length of the floors.
Step 1 Floor Assembly
Pre Assembly
b
Join the flush hinges to the door
frames using 30mm screws. Ensure
hinges are attached using the
outer plate of the hinge.
Fit the doors to the door panel with
30mm screws making sure to use
the inner plate of the hinge.
Step 2 Door Fixings
1
23
9
The Mortice Lock is Reversible
Fit the mortice lock
into the recess and
fix in place with the
screws provided. Fit
the key plate to the
opposite door using
the screws provided.
25
25
Fix the door handles and the metal bar (spindle) using 8x30mm
screws. Ensure the mortice lock closes correctly. If not, remove
lock and turn the catch around using the small grub screw.
x4 Rain Guard 580mm
21

30mm
screw
Pre drill
hole
6x30mm screws
30mm
screw
Pre drill
hole
8x30mm screws
30mm
screw
Pre drill
hole
12x30mm screws
60mm
screw
Pre drill
hole
3x60mm screws
a
60mm
screw
Pre drill
hole
3x60mm screws
Fix the door bar to the inside of the
slave door using 6x30mm screws as
shown in the diagram.
Step 2 Continued...
17
18
18
Fit the door beading strips to the
inside of the door frame using
8x30mm screws, ensuring that they
sit flush with the frame and the
door.
Attach the tower bolts to the door
bar using 12x30mm screws.
Fix the plain side and window
gable at the corners 3x50mm
screws.
DO NOT secure to the floor until
the roof is fitted.
Step 3
4
2
Step 4
Fix the plain side and
window gable at the
corners 3x50mm screws.
26
3
4
a
a
a

60mm
screw
Pre drill
hole
6x60mm screws
40mm
screw
Pre drill
hole
20x40mm screws
40mm
screw
Pre drill
hole
8x40mm screws
40mm
screw
Pre drill
hole
28x40mm screws
40mm
screw
Pre drill
hole
80mm
screw
BUILDING A BASE
When thinking about where the building and base is going to be constructed: Ensure that there will be access to all sides for maintenance work and
annual treatment.
TYPES OF BASE
- Concrete 75mm laid on top of 75mm hard-core.
- Slabs laid on 50mm of sharp sand.
Ensure the base is level and is built on rm ground, to prevent distortion. Refer to diagrams for the base dimensions, The base should be slightly
smaller than the external measurement of the building, i.e. The cladding should overlap the base, creating a run o for water. It is also recommended
that the oor be at least 25mm above the surrounding ground level to avoid ooding.
Step 5
Fit the door panel inbetween the
left and right window panels using
6x50mm screws.
Ensure that the door is secure
before moving into place.
Place the first back roof panel onto
the supports (making sure the roof
framing sits behind the support
bar) and secure with 20x40mm
screws as shown in the diagram.
Ensure the screws line up with the
roof support bars.
Step 7
Fix the roof bar to the supports where
they meet (inside the building) using
8x40mm screws.
*Repeat this process with the second
roof panel.
a
15
28
15
Step 6
Place the first ridge bar
inside the building and
line up with the upright
framing on each gable.
Align the back edge of the
ridge bar with the top of the
gable. Once in place mark
the position on both sides
with a pencil.
Place the roof support block
to the pencil mark and
secure in place using
2x40mm screws per block.
*Repeat this process on both sides
with the remaining roof support
bars.
Place the ridge bar(s) on top
of the attached blocks and
secure through the outside
of both gables using
2x80mm screws per side.
12x40mm Screws
12x80mm Screws
b
a
b
*Hint: When tting the roof bar pencil mark the centre
of the roof support bar and follow down onto the gable
at a right angle, this will give you a guide to x the
support bars in place.
6
1
a
a
a
a
a
a
5
25
7

40mm
screw
Pre drill
hole
12x40mm screws
30mm
screw
Pre drill
hole
24x30mm screws
Step 8
Position the roof ends onto the
roof. Ensure the tongue and groove
meet and boards sit flush together.
Attach the boards using 12x40mm
screws, ensuring the boards are
screwed into the gable framing
To secure the roof felt, sandwhich
strips on top and underneath the
roof (each side) using 24x30mm
screws.
Step 10
60mm
screw
Pre drill
hole
36x60mm screws
Secure the building to the floor using
36x60mm screws in alignment with
the floor joists.
Step 11
Fix the door handles and the metal bar (spindle) using 8x30mm
screws. Ensure the mortice lock closes correctly. If not, remove
lock and turn the catch around using the small grub screw.
Cut the felt into 3 strips (3140mm).
Roll felt across from side to side in
order as shown in the diagram,
leaving a 50mm overhang at the
front and back.
Each sheet needs a 50mm overlap.
Secure the felt in place with felt
tacks at 100mm intervals
Step 9
185 Felt Tacks
16
16
12
11 11
12
a
a
aaaaaa

40mm
screw
Pre drill
hole
10x40mm screws
30mm
screw
Pre drill
hole
12x30mm screws
2x30mm Black Screws
Pre drill
hole
Fix fascia’s into place using
4x40mm screws per board.
Fit the finial over the join between
the fascias using 2x40mm screws.
Fix cover trims using 3x30mm
screws per trim.
Step 15
Attach the turn buttons to the top
and bottom of the slave door using
2x30mm black screws.
These turn buttons help to keep
your doors straight during high
and low levels of moisture content
in the air.
Step 14
Step 12
*Hint: Silicone seal the back of
each rain guard to help reduce
water running behind.
10
20
10
Slave Door
Locking Door
30mm
screw
14
13
Step 15
Attach the Rain Guards
centrally above the window
using 3 x 50mm screws per
guard.
12x50mm Screws
50mm
screw
Pre drill
hole
24
19
SILICONE
SEALANT
13
14

50mm
screw
Pre drill
hole
Step 16
Secure the larger rain guard
above the doors, xing into
place using 4x50mm screws.
*ensure to screw into the
framing above door.
14x50mm Screws
*Hint: Silicone seal the back of the
rain guard to help reduce water
running behind.
29
SILICONE
SEALANT
It is ESSENTIAL that you apply wood
treatment immediately after the building
has been assembled.
AFTER TREATMENT:
score around protective
cover on glazing and
carefuly peel
covering back
