Mercury VesselView 7 User manual

© 2014 Mercury Marine VesselView 7 8M0087258 1214 eng

90-8M0087258 eng DECEMBER 2014 Page i
TABLE OF CONTENTS
Section 1 - Getting Started
VesselView 7 Overview............................................................. 2
Front Controls.......................................................................2
Front Control Operations...................................................... 2
Rear Panel........................................................................... 3
VesselView 7 Screen Display Locations and Descriptions........ 4
Touch and Swipe Districts......................................................... 4
Touch Districts......................................................................5
Swipe Districts...................................................................... 6
How to Update Your VesselView 7 Software............................. 7
Backup Your Waypoints, Routes, and Tracks...................... 7
Obtaining the Latest Software.............................................. 8
Upgrading Vesselview.......................................................... 9
Touch‑Screen Calibration...................................................10
Maintenance............................................................................ 10
Display Screen Cleaning.................................................... 10
Media Port Cleaning........................................................... 10
Stuck Buttons..................................................................... 10
Section 2 - Initial Screens and Setup Wizard
VesselView 7 Startup Warning Screen.................................... 12
Splash Screen.......................................................................... 12
Setup Wizard........................................................................... 12
Import Configuration........................................................... 13
Engine Setup...................................................................... 13
Display Setup..................................................................... 14
Device Setup...................................................................... 14
Units Setup......................................................................... 15
Tank Configuration............................................................. 15
Speed Setup.......................................................................17
Finishing Setup Wizard...................................................... 18
Data Source Setup....................................................... 18
Settings Menu...............................................................20
Display Screens....................................................................... 23
Startup.............................................................................. 23
Engine Off, Ignition On................................................. 23
Engine Running at Idle................................................. 23
Engine Fault...................................................................... 24
Fault Navigation............................................................25
Engine Scheduled Maintenance....................................... 25
System Scan ‑ Scan Report............................................. 26
Communication Errors.................................................. 27
Section 3 - Screen Overview and Operation
System Status Field Functionality............................................ 30
Navigation of Data Fields......................................................... 31
Enlarging Data Fields............................................................... 31
Auto Cycle.......................................................................... 32
Scroller Bar Functionality......................................................... 32
Scroller Bar Activation and Navigation............................... 32
User‑Selected Data Area................................................... 33
Scroller Bar Icons..................................................................... 34
Economy Mode........................................................................ 35
ECO Mode........................................................................ 35
ECO Minimum and Maximum Values........................... 35
ECO RPM and Trim Targets............................................. 35
Target Colors................................................................ 35
ECO Navigation................................................................ 36
ECO Refresh................................................................ 37
Minimize....................................................................... 37
Changing ECO Targets.................................................... 37
Changing Target Values............................................... 38
Smart Tow Mode...................................................................... 38
Smart Tow........................................................................ 38
Smart Tow Targets....................................................... 38
Smart Tow User‑Selected Data Area............................... 39
Navigation.....................................................................39
Save............................................................................. 41
Create Custom Launch.................................................42
Cruise Control Mode................................................................ 42
Cruise Control................................................................... 42
Cruise Control Data Area.................................................. 42
Constant Data Area Change........................................ 42
Cruise—User‑Selected Data Area................................ 43
Cruise Navigation......................................................... 43
Autopilot Mode......................................................................... 43
Autopilot Screen Overview............................................... 43
Autopilot Screens Navigation............................................ 44
Minimize Autopilot........................................................ 44
Troll Control Mode................................................................... 44
Troll Control...................................................................... 44
Troll Control Data Area..................................................... 44
Constant Data Field Change........................................ 44
Troll—User‑Selected Data Area................................... 45
Troll Navigation.............................................................45
Section 4 - Setup and Calibrations
Settings Menu Navigation........................................................ 48 Navigation to Settings Menu............................................. 48

Page ii 90-8M0087258 eng DECEMBER 2014
System............................................................................ 48
Preferences..................................................................... 48
Vessel.............................................................................. 49
SmartCraft....................................................................... 49
Easy Links....................................................................... 52
Alarms............................................................................. 52
Units................................................................................ 52
Network........................................................................... 52
Personality File................................................................ 53
Section 5 - Warning Alarms
Warnings—Faults and Alarms................................................ 56
Fuel Critical Alarm........................................................... 56
Depth Alarm.................................................................... 57

Section 1 - Getting Started
90-8M0087258 eng DECEMBER 2014 Page 1
Section 1 - Getting Started
Table of Contents
VesselView 7 Overview.......................................................... 2
Front Controls ................................................................. 2
Front Control Operations ................................................ 2
Rear Panel ...................................................................... 3
VesselView 7 Screen Display Locations and Descriptions..... 4
Touch and Swipe Districts...................................................... 4
Touch Districts ................................................................ 5
Swipe Districts ................................................................ 6
How to Update Your VesselView 7 Software......................... 7
Backup Your Waypoints, Routes, and Tracks ................ 7
Obtaining the Latest Software ........................................ 8
Upgrading Vesselview .................................................... 9
Touch‑Screen Calibration ............................................. 10
Maintenance......................................................................... 10
Display Screen Cleaning .............................................. 10
Media Port Cleaning ..................................................... 10
Stuck Buttons ............................................................... 10
1

Section 1 - Getting Started
Page 2 90-8M0087258 eng DECEMBER 2014
VesselView 7 Overview
IMPORTANT: VesselView is a multifunction display (MFD) that is compatible with products manufactured by Mercury Marine
Outboards, Mercury MerCruiser, and Mercury Diesel. Some of the functions explained in this manual will be disabled
depending on the power package it is connected to.
VesselView 7 is a comprehensive boat information center that can display information for up to four gasoline or diesel engines.
It continuously monitors and reports operating data including detailed information such as water temperature and depth, trim
status, boat speed and steering angle, and the status of fuel, oil, water, and waste tanks.
VesselView can be fully integrated with a vessel’s global positioning system (GPS) or other NMEA‑compatible devices to
provide up to the minute navigation, speed, and fuel‑to‑destination information.
VesselView is a display extension for autopilot and joystick operations. All functionality of these piloting features are controlled
through Mercury Marine's autopilot control area network (CAN) pad. VesselView will show if a mode of control is active or in
standby; pop‑ups will appear as the vessel arrives at waypoints, prompting response to turns. Additional display text can be
used to adjust the engines and drives to achieve maximum efficiency.
VesselView is equipped with a micro SD card port that allows an authorized OEM or dealership to import the vessel personality
configuration. It can also be used by the owner to upgrade to the latest software version. When more than one VesselView is
used, either as a triple‑ or quad‑engine application, or a second helm, the same micro SD card can be used to download those
configurations.
Front Controls
a - Touch screen
b - MARK–MENU button
c - STBY–AUTO button
d - Exit button
e - Rotary knob (press for enter function)
f - GO TO–PAGES button
g - IN/OUT Zoom–MOB (man overboard)
h - Power–Brightness
i - Card reader door
Front Control Operations
Touch screen: The screen on VesselView 7 has numerous districts that are touch sensitive and operated with a touch, or with
a vertical or horizontal swipe.
a
b
cd
e
f
g
h
i
52293

Section 1 - Getting Started
90-8M0087258 eng DECEMBER 2014 Page 3
MARK–MENU: The MARK–MENU has two functions and is dependent on which screen mode is active. Press the MARK–
MENU button while the chartplotter is visible to access waypoints and other functions. Press the button while SmartCraft
information is visible to open the scroller bar.
STBY–AUTO: Allows the operator to suspend (standby) or engage Navico® systems operation.
Exit: Closes a menu and removes the cursor from the screen.
Rotary knob: Used for maneuvering in menus, zooming in charts, and can be pressed to enter a selection.
GO TO–PAGES: A short press displays the home panel pages and can be pressed multiple times to toggle through the home
page menus. A long press displays the Go To menu options.
IN OUT–MOB: Zoom buttons for various NMEA backbone components. Pushing the IN and OUT buttons at the same time will
mark the position of the vessel with a man overboard (MOB) icon.
Power–Standby–Brightness: Press once to access the standby mode, change the backlighting of the unit, or go to Night
mode.
Card reader: Allows VesselView software to be upgraded, to have navigation charts uploaded, and waypoints and settings to
be saved.
Rear Panel
abcde52298
Item Function Description
a SmartCraft Connects to the SmartCraft network, links SC 100 gauges
b Power Power input and external alarm
c Video in Provides two composite video inputs
d SIMNET/NMEA 2K Connects to NMEA 2K network
e Network Ethernet network ports

Section 1 - Getting Started
Page 4 90-8M0087258 eng DECEMBER 2014
VesselView 7 Screen Display Locations and Descriptions
VesselView has multiple fields that display specific engine information and active modes.
1
3
4
5
6
7
8
9
10
11
2
12
13
52301
8
1. Application swap: Touching this area of the screen will toggle between a Mercury application screen and the last Navico
screen.
2. Volts or depth: This data field is user definable. A list of all available display content is available in the Settings menu.
• The data field will only display voltage when a SmartCraft depth transducer is not installed.
• The data field will display depth if a SmartCraft depth transducer is installed.
3. Steering angle: If installed, the user can select maximum limits of 45° or 60°, and invert the angle. The steering angle will
be available if the installed sensor is connected to the SmartCraft control area network. Steering angle is turned off by
default, but can be manually turned on in the Settings menu.
4. Speed: Displays the speed of the vessel. If a speed source is not available, the display will show dashes. The display will
show the speed value, the speed source (paddle wheel, pitot, or GPS), and the units of measurement (MPH is the default).
A speed value greater than two integers will be shown in a smaller font.
5. RPM: Displays a moving bar representing the engine RPM. A dual‑engine application will show two separate moving bars,
a triple‑engine application will show three, a quad‑engine application will show four.
6. Fuel: This data field displays total fuel onboard.
• Displays total fuel only. Individual fuel data will be located in the selected data area under fuel management.
7. Scroller bar icon: Touch this area to show the scroller bar. The scroller bar allows the operator to select different Mercury
application screens to open in the user selected data area.
8. Tabs: This data field is user definable. A list of all available display content is available in the Settings menu.
• If installed, the port tab will be displayed on the left side of the trim data, and the starboard tab will be displayed on
the right side of the trim data.
9. Gear position: DTS products will display all gear positions for each engine. The positions are defined as F (forward), N
(neutral), and R (reverse). Non DTS products will show N (neutral) and G (in gear).
10. Trim: This data field is user definable. Displays trim for up to four engines. Trim pop‑up is available in the selected data
area. Trim pop‑up can be turned off or on in the Settings menu.
11. Selected data icon: Displays an icon representing the data currently being displayed in the selected data area of the
screen. It will also display the previously selected data icon if there is currently no selected data being displayed. Touch the
MENU arrow button to open the scroller bar. The user can select an icon in the scroller bar and the selected data will then
be displayed.
12. System status: Displays the current active mode and warnings.
13. Selected data area: Displays all selected data, including initial start up scan progress, good stewardship messages,
maintenance schedules, and warnings.
Touch and Swipe Districts
VesselView 7 incorporates touch‑sensitive districts within the screen. This allows the operator to open or interact with specific
items by using defined touch gestures on the screen. There are two types of gestures: touch and swipe.

Section 1 - Getting Started
90-8M0087258 eng DECEMBER 2014 Page 5
Touch Districts
Touch districts are used in both the constant and user‑selected data fields. These districts offer maximum usability and
enhance screen graphics.
123
4
5
6
7
8
9
10
11
52304
Quad engine example
District Description
1
Area that toggles the application
IMPORTANT: Other applications associated with VesselView may not be accessible. The vessel must have a
specific Navico® device connected to the NMEA 2K backbone to be able to toggle between applications.
2 Area that displays data field information
3 Area that displays speed information
4 Area that displays fuel information
5 Area that opens and closes the scroller bar
6 Area that displays data field information
7 Area that displays data field information
8 Area that toggles display of active menu
9 Area that displays variable system status information
10 Area that performs various tasks for selected data area
11 Area that performs various tasks for selected data area

Section 1 - Getting Started
Page 6 90-8M0087258 eng DECEMBER 2014
123
4
5
6
7
8
9
10
11
52305
Single-engine example
District Description
1
Area that toggles the application
IMPORTANT: Other applications associated with VesselView may not be accessible. The vessel must have a
specific Navico® device connected to the NMEA 2K backbone to be able to toggle between application.
2 Area that displays data field information
3 Area that displays fuel information
4 Area that displays speed information
5 Area that opens and closes the scroller bar
6 Area that displays data field information
7 Area that displays data field information
8 Area that toggles display of active menu
9 Area that displays system status information
10 Area that performs various tasks for selected data area
11 Area that performs various tasks for selected data area
Swipe Districts
Swipe districts are used in the user‑selected data area and in the scroller bar menu. There are two types of swipe gestures:
horizontal and vertical.
• Horizontal swipes will advance the available pages.
a. Pages will advance in the direction of the horizontal swipe.
b. When the end of the pages is reached, a horizontal swipe to the left will move the page from the last page to the first
page.
c. Auto‑cycle and exit cannot be activated or selected when a swipe action is performed.
• Vertical swipes allow the operator to navigate deeper into additional data pertaining to that specific field.
a. Swipe up will navigate deeper into additional data.
b. Swipe down will exit and return data to an overview status.
c. If deeper data is not available vertical swipes will not be acknowledged.
• The scroller bar menu utilizes a speed‑based swipe action to advance the menu selections.
a. Slow swipe = slower advancement.

Section 1 - Getting Started
90-8M0087258 eng DECEMBER 2014 Page 7
b. Fast swipe = faster advancement.
a
b52306
District Description
a Area for selected data horizontal and vertical transition
b Area for selected data horizontal transition
How to Update Your VesselView 7 Software
The following instructions explain how to upgrade the VesselView 7 software. Internet access is required along with a
communication port used to transfer the file to a FAT or FAT32 micro SD card.
Backup Your Waypoints, Routes, and Tracks
Although waypoints, routes, and tracks should not be affected, it is recommended that these are backed up before starting the
upgrade. The backup process copies all waypoints, routes, and tracks to a micro SD card. The card can be the same one that
has the upgrade files. Depending on the amount of information you will backup, the card must have the capacity to store it.
1. Turn the ignition key on and verify that the VesselView is on.
2. Insert the micro SD card into the card reader port all the way until it clicks and stays in place.
3. Press the PAGES button below the rotary knob.
4. Select Tools; then select Files.
5. Select Waypoints, Routes, and Tracks.
52711
6. Select the desired file format and then press Export.

Section 1 - Getting Started
Page 8 90-8M0087258 eng DECEMBER 2014
7. Select the micro SD card as the destination and select OK.
52713
8. Name the backup file using the on‑screen keyboard and then press Enter.
Obtaining the Latest Software
1. The latest software for the display is available on‑line for general download at Mercury's website;
www.mercurymarine.com/vesselview. To understand what software version is in VesselView, power up VesselView. While
the system boots up, the screen will show the software version in the lower right‑hand corner. If VesselView is already
powered up, select Settings>System>About to see the current operating version of VesselView software.
2.043.301
MERCURY MARINE
55829
56944
2. Select the VesselView 7 product and click on DOWNLOAD UPGRADE.
3. Depending on your computer’s security settings, a security warning may appear. Click Allow to continue.
4. Create a folder on your hard drive and save the file in this folder.
5. If you are asked to SAVE or RUN, select SAVE and save to your hard drive.
NOTE: The file is typically 70–100 MB in size.
IMPORTANT: Some browsers may change the file extension. Verify that the filename and extension have not changed.
The correct extension after the filename should be .upd. Do not rename the file or change the extension.
6. After the file is saved to the hard drive, copy the file to a 512 MB or higher capacity blank FAT or FAT 32 micro SD card
root. The root of the drive is the topmost level, where the file is not placed into a folder.

Section 1 - Getting Started
90-8M0087258 eng DECEMBER 2014 Page 9
Upgrading Vesselview
Important considerations before and during the upgrade process:
• Have you backed up your waypoints, routes, and tracks?
• Each display must be upgraded individually; there is no automatic network feature to upgrade multiple VesselViews
simultaneously.
• Do not turn off the display or disrupt the power during the upgrade process.
• Do not remove the micro SD card during the upgrade process.
1. Verify that the ignition key is off and that VesselView is not turned on.
NOTE: Some installations may have the VesselView powered up with a dedicated circuit, rather than by the ignition key‑on
circuit.
IMPORTANT: VesselView must be turned off for at least 30 seconds before upgrading the software.
2. Insert the micro SD card into the card reader port all the way until it clicks and stays in place.
3. Turn the ignition key on and verify that the VesselView is on.
4. Allow the system to boot up. A screen will prompt you to upgrade or cancel.
5. Use the rotary knob to highlight the upgrade file and press the knob to confirm.
Select update to run
0: Cancel (Do not run updater)
56565
*1: VesselView 7-X.0.XX.XXX-XXXXX
6. Do not turn the ignition key off, turn VesselView off, or remove the micro SD card while the software is uploading. The
upgrade process may take several minutes to complete.
Installing update. Please wait...
Do not turn off during update,
as this may damage your device.
56562
7. When the upload is finished, remove the micro SD card and the system will automatically reboot to complete the upgrade.
Update complete.
Please remove the SD card to finish.
56563
8. Verify that the software version upgraded is the correct version. Press the Go To button, press Settings, select Systems
and rotate knob to About. Press the knob to verify. The current software version is shown. Keying the vessel off for 30
seconds, then keying on will also display the software version in the lower right‑hand corner of the initial boot up screen.

Section 1 - Getting Started
Page 10 90-8M0087258 eng DECEMBER 2014
Touch‑Screen Calibration
1. Turn the unit off.
2. Press and hold the MENU button, then turn the unit on.
3. Hold the MENU button down during power on, until the calibration utility screen comes up (approximately 15 seconds).
56947
TSLIB calibration utility
Touch crosshair to calibrate
Calibration utility screen
4. Touch crosshair shown on screen to perform nine points of calibration.
5. After successful calibration, the unit will return to the normal application screen.
Maintenance
IMPORTANT: It is recommended that the supplied sun cover be installed for protection when the unit is not in service.
Display Screen Cleaning
Routine cleaning of the display screen is recommended to prevent a buildup of salt and other environmental debris. Crystalized
salt can scratch the display coating when using a dry or damp cloth. Ensure that the cloth has a sufficient amount of fresh water
to dissolve and remove salt deposits. Do not apply aggressive pressure on the screen while cleaning.
When water marks cannot be removed with the cloth, mix a 50/50 solution of warm water and isopropyl alcohol to clean the
screen. Do not use acetone, mineral spirits, turpentine type solvents, or ammonia based cleaning products. The use of strong
solvents or detergents may damage the anti‑glare coating, the plastics, or the rubber keys.
It is recommended that the sun cover be installed when the unit is not in use to prevent UV damage to the plastic bezels and
rubber keys.
Media Port Cleaning
The media port door area should be cleaned on a regular basis to prevent a buildup of crystalized salt and other debris.
Stuck Buttons
Verify that there are no buttons stuck in the down position. If a stuck button is found, wiggle the button to free it.

Section 2 - Initial Screens and Setup Wizard
90-8M0087258 eng DECEMBER 2014 Page 11
Section 2 - Initial Screens and Setup Wizard
Table of Contents
VesselView 7 Startup Warning Screen................................. 12
Splash Screen...................................................................... 12
Setup Wizard........................................................................ 12
Import Configuration ..................................................... 13
Engine Setup ................................................................ 13
Display Setup ............................................................... 14
Device Setup ................................................................ 14
Units Setup ................................................................... 15
Tank Configuration ....................................................... 15
Speed Setup ................................................................. 17
Finishing Setup Wizard ................................................. 18
Data Source Setup ................................................ 18
Settings Menu ....................................................... 20
Display Screens.................................................................... 23
Startup........................................................................... 23
Engine Off, Ignition On .......................................... 23
Engine Running at Idle .......................................... 23
Engine Fault...................................................................24
Fault Navigation .................................................... 25
Engine Scheduled Maintenance.................................... 25
System Scan ‑ Scan Report.......................................... 26
Communication Errors ........................................... 27
2

Section 2 - Initial Screens and Setup Wizard
Page 12 90-8M0087258 eng DECEMBER 2014
VesselView 7 Startup Warning Screen
When VesselView 7 is started, a warning screen pops up and advises the operator not to rely on the product as a primary
source of navigation and that the user assumes all liability for operation and associated risks.
Splash Screen
When the ignition key is turned on, a Mercury startup splash screen will appear. The number of engine hours will be displayed
for up to four engines. In the lower right‑hand corner of the screen is the software version. Power packages with emissions
control will show an engine icon in the lower left‑hand corner of the screen.
51617
Mercury splash screen
Setup Wizard
IMPORTANT: Do not rush VesselView by pressing buttons while the system is booting up to acquire vessel and engine data.
When VesselView is initially started or after a factory reset, the system will take a few seconds to complete the boot up
process.
The VesselView setup wizard guides you through the first steps of configuring the VesselView. The setup wizard can be
accessed at any time through the SETTINGS icon in the scroller menu. Touch the scroller bar arrow and swipe to the Settings
icon. To start the setup wizard, navigate to Settings>System>Setup Wizard. Touch Next to continue.
56740

Section 2 - Initial Screens and Setup Wizard
90-8M0087258 eng DECEMBER 2014 Page 13
Import Configuration
To import an existing vessel configuration, insert a FAT or FAT32 micro SD card with the configuration file and select this file in
the drop‑down menu. If there is no import file, touch Next to continue.
56741
Engine Setup
1. In the Engine Setup screen, use the rotary knob or touch the menu fields to select the correct option.
2. Complete selections in the Engine Setup screen. When finished making selections, touch Next to continue.
a - Engine type menu
b - Engine model menu
3. Open and select the appropriate option in the remainder of menu fields in the Engine Setup screen. When finished making
selections, touch Next to continue.
a - Engine model selection field
56742
a
b
56743
a

Section 2 - Initial Screens and Setup Wizard
Page 14 90-8M0087258 eng DECEMBER 2014
a - Joystick option field
b - Number of engines field
Display Setup
Depending on the number of engines indicated in the Engine Setup screen, select the engines to be displayed by this
VesselView unit. Up to four engines can be selected. Touch Next to continue.
a - Engines selected to be displayed
Device Setup
In the Device Setup screen, use the rotary knob or touch the menu fields to select the proper options. If using multiple
VesselView devices, be sure to assign unique numbers to each unit, to avoid data problems. Helm numbers should match the
location of the individual VesselView unit. Touch Next to continue.
a - VesselView option field
b - Helm option field
56745
a
b
56746
a
56747
a
b

Section 2 - Initial Screens and Setup Wizard
90-8M0087258 eng DECEMBER 2014 Page 15
Units Setup
Select the units of measure that VesselView will display on‑screen data; speed, distance, and volumes. Particular units of
measure can be changed later.
a - Units of measure selection field
Tank Configuration
Select the number of fuel tanks on the vessel in the drop‑down field. Touch Next to continue.
a - Number of tanks selection field
Use the rotary knob or touch the menu fields to select the Tank source, Tank type, and Tank capacity.
a - Tank source selection field
b - Tank type selection field
c - Tank capacity entry field
56748
a
56749
a
56750
a
b
c

Section 2 - Initial Screens and Setup Wizard
Page 16 90-8M0087258 eng DECEMBER 2014
Use the on‑screen keypad to enter the capacity. When finished entering tank capacity data, touch OK to close keypad. Touch
Next to continue.
a - Tank capacity entry field
b - On‑screen keypad
The tank name will populate the Name field. To change the name of the tank, touch the field and use the on‑screen keypad to
customize the tank name.
a - Tank name field
a - Tank name entry
b - Enter key to complete entry
Based on the number of tanks entered during configuration, the screen will return to the Tank source screen. All menu fields
need to be filled in with the appropriate information for each additional tank. When all menu fields are completed, touch Next to
continue.
56751
a
b
56752
a
56753
b
a
