1. Introduction
The GT-324 is a small lightweight four channel hand held particle counter. Key features
include:
Simple user interface with multifunction rotary dial (rotate and press)
8 hours continuous operation
4 count channels. All channels are user selectable to 1 of 7 preset sizes:
(0.3m, 0.5m, 0.7m, 1.0m, 2.5m, 5.0m and 10m)
Concentration and total count modes
Fully integrated temperature/relative humidity sensor
Password protection for user settings
2. Setup
The following sections cover unpacking, layout and performing a test run to verify
operation.
2.1. Unpacking
When unpacking the GT-324 and accessories, inspect the carton for obvious damage.
If the carton is damaged notify the carrier. Unpack everything and make a visual
inspection of the contents. Standard items (included) are shown in
Figure 1 –Standard Accessories. Optional accessories are shown in
Figure 2 –Optional Accessories.
ATTENTION:
The included USB drivers must be installed before connecting the GT-324 USB port to
your computer. If the supplied drivers are not installed first, Windows may install
generic drivers that are not compatible with this product. See section 6.1.
To install USB drivers:
Insert the Comet CD. The install program should run automatically and display the
screen below. If an AutoPlay pop-up window appears, select “Run AutoRun.exe”.
Finally, select “USB Drivers” to start the install process.

GT-324 Manual Page 6 GT-324-9800 Rev B
Figure 1 –Standard Accessories
GT-324 Standard Accessories
GT-324
MOI P/N: GT-324
Battery Charger
MOI P/N: 390031
USB Cable
MOI P/N: 500787
GT-324 Manual
MOI P/N GT-324-
9800
Calibration
Certificate
MOI P/N:
GT-324-9600
Comet Software
CD
MOI P/N: 80248
Carrying Case
MOI P/N: 8517
Particle View
Software CD
MOI P/N Particle
View
Power Cord
MOI P/N: 400113
IsoKinetic Probe
MOI P/N 83117
Zero Filter
MOI P/N G3111

GT-324 Manual Page 7 GT-324-9800 Rev B
Figure 2 –Optional Accessories
GT-324 Optional Accessories
Flow Meter
MOI P/N: 9801

GT-324 Manual Page 8 GT-324-9800 Rev B
2.2. Layout
The following figure shows the layout of the GT-324 and provides a description of the
components.
Figure 3 –GT-324 Layout
Component
Description
Display
2X16 character LCD display
Keyboard
2 key membrane keypad
Rotary dial
Multifunction dial (rotate and press)
Charger Jack
Input jack for external battery charger. This jack charges the internal
batteries and provides continuous operating power for the unit.
Flow Adjust
Adjusts the sample flow rate
Inlet Nozzle
Sample nozzle
USB Port
USB communication port
Temp/RH
Sensor
Integrated sensor that measures ambient temperature and relative
humidity.
USB Port
Display
Charger Jack
Inlet Nozzle with
Isokinetic Probe
Keyboard
Rotary Dial
Flow Adjust
Temp/RH Sensor

GT-324 Manual Page 9 GT-324-9800 Rev B
2.3. Default Settings
The GT-324 comes with the user settings configured as follows.
Parameter
Value
Sizes
0.3, 0.5, 5.0, 10 m
Temperature
C
Sample Location
1
Sample Mode
Manual
Sample Time
60 seconds
Count Units
CF
2.4. Initial Operation
The battery should be charged for 2.5 hours prior to use. Refer to Section 7.1 of this
manual for battery charging information.
Complete the following steps to verify proper operation.
1. Press the Power key for 0.5 seconds or more to turn on power.
2. Observe the Startup screen for 3 seconds then the Sample screen (Section 4.2)
3. Press Start / Stop key. The GT-324 will sample for 1 minute and stop.
4. Observe the counts on the display
5. Rotate the Select dial to view other sizes
6. The unit is ready for use
3. User Interface
The GT-324 user interface is composed of a rotary dial, 2 button keypad and an LCD
display. The keypad and rotary dial are described in the following table.
4. Operation
The following sections cover the basic operation of GT-324.
4.1. Power Up
Press the Power key to power up the GT-324. The first screen shown is the Startup
Screen (Figure 4). The Startup Screen displays the product type and company website
for approximately 3 seconds before loading the Sample Screen.
GT-324
WWW.METONE.COM
Figure 4 –Startup Screen
Control
Description
Power Key
Power the unit on or off. For power on, press for 0.5 seconds or more.
Start / Stop Key
Sample Screen
START / STOP a sample event
Settings Menu
Return to Sample screen
Edit Settings
Cancel edit mode and return to the Settings Menu
Select Dial
Rotate the dial to scroll through selections or change values. Press the dial
to select item or value.

GT-324 Manual Page 10 GT-324-9800 Rev B
4.1.1. Auto Power Off
The GT-324 will power down after 5 minutes to preserve battery power providing the
unit is stopped (not counting) and there is no keyboard activity or serial
communications.
4.2. Sample Screen
The Sample Screen displays sizes, counts, count units, and time remaining. The time
remaining is displayed during sample events. The Sample Screen is shown in Figure 5
below.
0.3u 2,889 CF
0.5u 997 60
Figure 5 –Sample Screen
Channel 1 (0.3) is displayed on Sample Screen Line 1. Rotate the Select dial to
display channels 2-4, battery status, ambient temperature, and relative humidity on line
2 (Figure 6).
0.3u 2,889 CF
BATTERY = 100%
Figure 6 –Battery Status
4.2.1. Warnings / Errors
The GT-324 has internal diagnostics to monitor critical functions such as low battery,
system noise and an optical engine failure. Warnings / errors are displayed on Sample
Screen Line 2. When this occurs, simply rotate the Select dial to view any size on the
top line.
A low battery warning occurs when there is approximately 15 minutes of sampling
remaining before the unit stops sampling. A low battery condition is shown in Figure 7
below.
0.5u 6,735 CF
Low Battery!
Figure 7 –Low Battery
Excessive system noise can result in false counts and reduced accuracy. The GT-324
automatically monitors system noise and displays a warning when the noise level is
high. The primary cause of this condition is contamination in the optical engine. Figure
7 shows the Sample screen with a System Noise warning.
0.5u 6,735 CF
System Noise!
Figure 8 –System Noise
Count Units (Section 4.3.3)
Time Remaining

GT-324 Manual Page 11 GT-324-9800 Rev B
A sensor error is reported when the GT-324 detects a failure in the optical sensor.
Figure 9 shows a sensor error.
0.5u 6,735 CF
Sensor Error!
Figure 9 –Sensor Error
4.3. Sampling
The following sub-sections cover sample related functions.
4.3.1. Starting/Stopping
Press the START/STOP key to start or stop a sample from the Sample Screen.
Depending on the sample mode, the unit will either run a single sample or continuous
samples. Sample modes are discussed in Section 4.3.2.
4.3.2. Sample Mode
The sample mode controls single or continuous sampling. The Manual setting
configures the unit for a single sample. The Continuous setting configures the unit for
nonstop sampling.
4.3.3. Count Units
The GT-324 supports total counts (TC), particles per cubic foot (CF), particles per cubic
meter (M3) and particles per liter (/L). Concentration values (CF, /L, M3) are time
dependent. These values may fluctuate early in the sample; however, after several
seconds the measurement will stabilize. Longer samples (e.g. 60 seconds) will improve
concentration measurement accuracy.
4.3.4. Sample Time
Sample time determines the sample duration. Sample time is user settable from 3 to 60
seconds and is discussed in Sample Timing below.
4.3.5. Sample Timing
The following figures depict the sample timing sequence for both manual and
continuous sampling. Figure 10 shows the timing for manual sample mode. Figure 11
shows the timing for continuous sample mode. The Start section includes a 3 second
purge time.
Start Stop
Sample Time
Figure 10 –Manual Sample Mode
Start Stop
Sample Time
Sample Time
//
Figure 11 –Continuous Sample Mode

GT-324 Manual Page 12 GT-324-9800 Rev B
5. Settings Menu
Use the Settings Menu to view or change configuration options.
5.1. View Settings
Press the Select dial to navigate to the Settings Menu. Rotate the Select dial to scroll
through the settings in the following table. To return to the Sample screen, press
Start/Stop or wait 7 seconds.
The Settings menu contains the following items.
Function
Description
LOCATION
Assign a unique number to a location or area. Range = 1 –999
SIZES
The GT-324 has four (4) programmable count channels. The
operator can assign one of seven preset sizes to each count
channel. Standard sizes: 0.3, 0.5, 0.7, 1.0, 2.5, 5.0, 10.
MODE
Manual or Continuous. The Manual setting configures the unit for a
single sample. The Continuous setting configures the unit for
nonstop sampling.
COUNT UNITS
Total Count (TC), Particles / cubic foot (CF), particles / L (/L).
See Section 4.3.3.
TEMP UNITS
Celsius (C) or Fahrenheit (F) temperature units. See Section 5.2.6
HISTORY
Display previous samples. See Section 5.1.1
SAMPLE TIME
See Section 4.3.4. Range = 3 –60 seconds
TIME
Display / enter time. Time format is HH:MM:SS
(HH = Hours, MM = Minutes, SS = Seconds).
DATE
Display / enter date. Date format is DD/MMM/YYYY
(DD = Day, MMM = Month, YYYY = Year)
FREE
MEMORY
Display the percentage of memory space which is available for data
storage. When Free Memory = 0%, the oldest data will be
overwritten with new data.
PASSWORD
Enter a four (4) digit numeric number to prevent unauthorized
changes to the user settings.
ABOUT
Display model number and firmware version
5.1.1. View Sample History
Press the Select dial to navigate to the Settings Menu. Rotate the Select dial to the
History selection. Follow the steps below to view sample history. To return to the
Settings Menu, press Start/Stop or wait 7 seconds.

GT-324 Manual Page 13 GT-324-9800 Rev B
Press to View
HISTORY
Press Select to view history.
30/MAR/2018 L001
10:30:45 #2252
GT-324 will display the last record (Date, Time, Location, and
Record Number). Rotate dial to scroll through records. Press to
view record.
0.3u 2,889 CF
0.5u 997 60
5.0u 15 60
10u 5 60
Location 001
DATE 30/MAR/2018
TIME 10:30:45
Low Battery!
Rotate dial to scroll through record data (counts, date, time,
alarms). Press Start/Stop to return to previous screen.
5.2. Edit Settings
Press the Select dial to navigate to the Settings Menu. Rotate the Select dial to scroll to
the desired setting then press the Select dial to edit the Setting. A blinking cursor will
indicate edit mode. To cancel edit mode and return to the Settings Menu, press
Start/Stop.
Edit mode is disabled when the GT-324 is sampling (see below).
Sampling…
Press Stop Key
Screen displayed for 3 seconds then return to Settings Menu
5.2.1. Password Feature
The following screen is displayed if you attempt to edit a setting when the password
feature is enabled. The unit will remain unlocked for a period of 5 minutes after a
successful password unlock code is entered.
Press to Enter
UNLOCK ####
Press Select to enter Edit mode. Return to Sample screen if no
Select key in 3 seconds
Rotate and Press
UNLOCK 0###
Blinking cursor indicates Edit mode. Rotate dial to scroll value.
Press dial to select next value. Repeat action until last digit.
Rotate and Press
UNLOCK 0001
Rotate dial to scroll value. Press dial to exit Edit Mode.
Incorrect
Password!
Screen displayed for 3 seconds if the password is incorrect.
5.2.2. Edit Location Number
Press to Change
LOCATION 001
View screen. Press Select to enter Edit mode.
Rotate and Press
LOCATION 001
Blinking cursor indicates Edit mode. Rotate dial to scroll value.
Press dial to select next value. Repeat action until last digit.
Rotate and Press
LOCATION 001
Rotate dial to scroll value. Press dial to exit Edit Mode and
return to view screen.

GT-324 Manual Page 14 GT-324-9800 Rev B
5.2.3. Edit Sizes
Press to View
CHANNEL SIZES
Press Select to view Sizes.
Press to Change
SIZE 1 of 4 0.3
Sizes view screen. Rotate dial to view channel sizes. Press dial
to change setting.
Rotate and Press
SIZE 1 of 4 0.5
Blinking cursor indicates Edit mode. Rotate dial to scroll values.
Press dial to exit Edit mode and return to view screen.
5.2.4. Edit Sample Mode
Press to Change
MODE CONTINUOUS
View screen. Press Select to enter edit mode.
Rotate and Press
MODE CONTINUOUS
Blinking cursor indicates Edit mode. Rotate dial to toggle value.
Press dial to exit Edit mode and return to view screen.
5.2.5. Edit Count Units
Press to Change
COUNT UNITS CF
View screen. Press Select to enter edit mode.
Rotate and Press
COUNT UNITS CF
Blinking cursor indicates Edit mode. Rotate dial to toggle value.
Press dial to exit Edit mode and return to view screen.
5.2.6. Edit Temp Units
Press to Change
TEMP UNITS C
View screen. Press Select to enter edit mode.
Rotate and Press
TEMP UNITS C
Blinking cursor indicates Edit mode. Rotate dial to toggle value.
Press dial to exit Edit mode and return to view screen.
5.2.7. Edit Sample Time
Press to Change
SAMPLE TIME 60
View screen. Press Select to enter Edit mode.
Rotate and Press
SAMPLE TIME 60
Blinking cursor indicates Edit mode. Rotate dial to scroll value.
Press dial to select next value.
Rotate and Press
SAMPLE TIME 10
Rotate dial to scroll value. Press dial to exit Edit Mode and
return to view screen.
5.2.8. Edit Time
Press to Change
TIME 10:30:45
View screen. Time is real time. Press Select to enter edit mode.
Rotate and Press
TIME 10:30:45
Blinking cursor indicates Edit mode. Rotate dial to scroll values.
Press dial to select next value. Repeat action until last digit.
Rotate and Press
TIME 10:30:45
Last digit. Rotate dial to scroll values. Press dial to exit Edit
mode and return to view screen.

GT-324 Manual Page 15 GT-324-9800 Rev B
5.2.9. Edit Date
Press to Change
DATE 30/MAR/2018
View screen. Date is real time. Press Select to enter edit mode.
Rotate and Press
DATE 30/MAR/2018
Blinking cursor indicates Edit mode. Rotate dial to scroll values.
Press dial to select next value. Repeat action until last digit.
Rotate and Press
DATE 30/MAR/2018
Rotate dial to scroll values. Press dial to exit Edit mode and
return to view screen.
5.2.10. Clear Memory
Press to Change
FREE MEMORY 80%
View screen. Available memory. Press Select to enter edit
mode.
Press and Hold
to Clear Memory
Hold Select dial for 3 seconds to clear memory and return to
view screen. Return to view screen if no action for 3 seconds or
key hold time is less than 3 seconds.
5.2.11. Edit Password
Press to Change
PASSWORD NONE
View screen. #### = Hidden password. Press Select to enter
Edit mode. Enter 0000 to disable password (0000 = NONE).
Rotate and Press
PASSWORD 0000
Blinking cursor indicates Edit mode. Rotate dial to scroll value.
Press dial to select next value. Repeat action until last digit.
Rotate and Press
PASSWORD 0001
Rotate dial to scroll value. Press dial to exit Edit Mode and
return to view screen.
6. Serial Communications
Serial communications, firmware field upgrades and real time output are provided via
the USB port located on the side of the unit.
6.1. Connection
ATTENTION:
The included USB driver CD must be installed before connecting the GT-324 USB port
to your computer. If the supplied drivers are not installed first, Windows may install
generic drivers that are not compatible with this product.
To install USB drivers:
Insert the USB Drivers CD. The install program should run automatically and display the
screen below. If an AutoPlay pop-up window appears, select “Run AutoRun.exe”.
Finally, select “USB Drivers” to start the install process.
Note:
For proper communication, set the
virtual COM port baud rate to 38400

GT-324 Manual Page 16 GT-324-9800 Rev B
6.2. Commands
The GT-324 provides serial commands for accessing stored data and settings. The
protocol is compatible with terminal programs such as Comet, Putty or Windows
HyperTerminal.
The unit returns a prompt (‘*’) when it receives a carriage return to indicate a good
connection. The following table lists the available commands and descriptions.
SERIAL COMMANDS
Protocol Summary:
38,400 Baud, 8 Data bits, No Parity, 1 Stop Bit
Commands (CMD) are UPPER or lower case
Commands are terminated with a carriage return <CR>
To view setting = CMD <CR>
To change setting = CMD <SPACE> <Value> <CR>
CMD
Type
DESCRIPTION
?,H
Help
View the help menu
1
Settings
View the settings
2
All data
Returns all available records.
3
New data
Returns all records since last ‘2’ or ‘3’ command.
4
Last data
Returns the last record or last n records (n = <Value>)
D
Date
Change date. Date is format is MM/DD/YY
T
Time
Change time. Time format is HH:MM:SS
C
Clear data
Displays a prompt for clearing the stored unit data.
S
Start
Start a sample
E
End
Ends a sample (abort the sample, no data record)
ST
Sample time
View / change the sample time. Range 3-60 seconds.
ID
Location
View / change the location number. Range 1-999.
CS w x y z
Channel
Sizes
View / change channel sizes where w=Size1, x=Size2,
y=Size3 and z=Size4. Values (w x y z) are
1=0.3, 2=0.5, 3=0.7, 4=1.0, 5=2.5, 6=5.0, 7=10
SM
Sample
mode
View / change sample mode. (0=Manual, 1=
Continuous)
CU
Count units
View / change count units. Values are 0=CF, 1=/L,
2=TC
OP
Op Status
Replies OP x, where x is “S” Stopped or “R” Running
RV
Revision
View Software Revision
DT
Date Time
View / change date and time.
Format = DD-MM-YY HH:MM:SS

GT-324 Manual Page 17 GT-324-9800 Rev B
6.3. Real Time Output
The GT-324 outputs real time data at the end of each sample. The output format is a
comma separated values (CSV). The following sections show the format.
6.4. Comma Separated Value (CSV)
A CSV header is included for multiple record transfers like Display All Data (2) or
Display New Data (3).
CSV Header:
Time, Location, Sample Time, Size1, Count1 (units), Size2, Count2 (units), Size3,
Count3 (units), Size4, Count4 (units), Ambient Temperature, RH, Status
CSV Example Record:
31/AUG/2010 14:12:21, 001,060,0.3,12345,0.5,12345,5.0,12345,10,12345,22.3,
58,000<CR><LF>
Note: Status bits: 000 = Normal, 016 = Low Battery, 032 = Sensor Error, 048 = Low
battery and Sensor Error.
7. Maintenance
WARNING: There are no user serviceable components inside this instrument. The
covers on this instrument should not be removed or opened for servicing, calibration or
any other purpose except by a factory-authorized person. To do so may result in
exposure to invisible laser radiation that can cause eye injury.
7.1. Charging the Battery
Caution:
The provided battery charger is designed to work safely with this device. Do not
attempt to connect any other charger or adapter to this device. Doing so may
result in equipment damage.
To charge the battery, connect the battery charger module AC power cord to an AC
power outlet and the battery charger DC plug to the socket on the side of the GT-324.
The universal battery charger will work with power line voltages of 100 to 240 volts, at
50/60 Hz. The battery charger LED indicator will be Red when charging and Green
when fully charged. A discharged battery pack will take approximately 2.5 hours to fully
charge.
There is no need to disconnect the charger between charging cycles because the
charger enters a maintenance mode (trickle charge) when the battery is fully charged.

GT-324 Manual Page 18 GT-324-9800 Rev B
7.2. Service Schedule
Although there are no customer serviceable components, there are service items which
ensure the proper operation of the instrument. Table 1 shows the recommended
service schedule for the GT-324.
Item To Service
Frequency
Done By
Flow rate test
Monthly
Customer or Factory Service
Zero test
Optional
Customer or Factory Service
Inspect pump
Yearly
Factory service only
Test battery pack
Yearly
Factory service only
Calibrate Sensor
Yearly
Factory service only
Table 1 Service Schedule
7.2.1. Flow Rate Test
The sample flow rate is factory set to 0.1cfm (2.83 lpm). Continued use can cause
minor changes in flow which can reduce measurement accuracy. A flow calibration kit is
available separately that includes everything needed to test and adjust the flow rate.
To test the flow rate: remove the Isokinetic inlet. Attach the tubing connected to the
flow meter (MOI# 9801) to the instrument inlet. Start a sample, and note the flow meter
reading. The flow rate should be 0.10 CFM (2.83 LPM) 5%.
If the flow is not within this tolerance, it can be adjusted by a trim pot located in an
access hole in the side of the unit. Turn the adjustment pot clockwise to increase the
flow and counter-clockwise to decrease the flow.
7.2.1. Zero Count Test
Air leaks or debris in the particle sensor can cause false counts which may result in
significant count errors when sampling in clean environments. Perform the following
zero count test weekly to ensure proper operation:
1. Attach zero count filter to the inlet nozzle (PN G3111).
2. Configure the unit as follows: Samples = MANUAL, Sample Time = 60 seconds,
Volume = Total Count (TC)
3. Start and complete a sample.
4. The smallest particle size should have a count <= 1.
desired.
7.2.2. Annual Calibration
The GT-324 should be sent back to Met One Instruments yearly for calibration and
inspection. Particle counter calibration requires specialized equipment and training.
The Met One Instruments calibration facility uses industry accepted methods such as
ISO.

GT-324 Manual Page 19 GT-324-9800 Rev B
In addition to calibration, the annual calibration includes the following preventative
maintenance items to reduce unexpected failures:
Inspect filter
Inspect / clean optical sensor
Inspect pump and tubing
Cycle and test the battery
Verify RH and Temperature measurements
7.3. Flash Upgrade
Firmware can be field upgraded via the USB port. Binary files and the flash program
must be provided by Met One Instruments.
8. Troubleshooting
WARNING: There are no user serviceable components inside this instrument. The
covers on this instrument should not be removed or opened for servicing, calibration or
any other purpose except by a factory-authorized person. To do so may result in
exposure to invisible laser radiation that can eye injury.
The following table covers some common failure symptoms, causes and solutions.
Symptom
Possible Cause
Correction
Low battery message
Low battery
Charge battery 2.5 hrs
System noise message
Contamination
1. Blow clean air into nozzle
(low pressure, do not
connect via tubing)
2. Send to service center
Sensor error message
Sensor failure
Send to service center
Does not turn on, no
display
1. Dead battery
2. Defective Battery
1. Charge battery 2.5 hrs
2. Send to service center
Display turns on but
pump does not
1. Low Battery
2. Defective pump
1. Charge battery 2.5 hrs
2. Send to service center
No counts
1. Pump stopped
2. Laser diode bad
1. Send to service center
2. Send to service center
Low counts
1. Incorrect flow rate
2. Calibration drift
1. Check flow rate
2. Send to service center
High counts
1. Incorrect flow rate
2. Calibration drift
1. Check flow rate
2. Send to service center
Battery pack does not
hold a charge
1. Defective battery pack
2. Defective charger module
1. Send to service center
2. Replace charger

GT-324 Manual Page 20 GT-324-9800 Rev B
9. Specifications
Features:
Size Range:
Count Channels:
Size Selections:
Accuracy:
Concentration Limit:
Temperature
Relative Humidity
Flow Rate:
Sampling Mode:
Sampling Time:
Data Storage:
Display:
Keyboard:
Status Indicators:
Calibration
Measurement:
Method:
Light Source:
Electrical:
AC Adapter/Charger:
Battery Type:
Battery Operating Time:
Battery Recharge Time:
Communication:
Physical:
Height:
Width:
Thickness:
Weight
Environmental:
Operating Temperature:
Humidity
Storage Temperature:
0.3 to 10.0 microns
4 channels preset to 0.3, 0.5, 5.0 and 10.0 m
0.3, 0.5, 0.7, 1.0, 2.5, 5.0 and 10.0 m
± 10% to traceable standard
3,000,000 particles/ft3
± 2 °C
± 3%
0.1 CFM (2.83 L/min)
Single or Continuous
3 –60 seconds
2200 records
2 line by 16-character LCD
2 button with rotary dial
Low Battery
NIST, ISO
Light scatter
Laser Diode, 35 mW, 780 nm
AC to DC module, 100 –240 VAC to 8.4 VDC
Li-ion rechargeable Battery
8 hours continuous use
2.5 hours typical
USB Mini B Type
6.25” (15.9 cm)
3.65” (9.3 cm)
2.00” (5.1 cm)
1.6 lbs –(0.73 kg)
0º C to +50º C
10 –90%, noncondensing
-20º C to +60º C

GT-324 Manual Page 21 GT-324-9800 Rev B
Warranty / Service Information
