Metasys META TOUCH User manual

META TOUCH
Gebrauchsanweisung | Instructions for use

2
Inhaltsverzeichnis | Table of contents
Inhaltsverzeichnis | Table of contents
EN - Instructions for use............................................................ 4
1. Information......................................................................................................4
1.1. General information ..............................................................................................................................................4
1.2. Explanation of the symbols ...................................................................................................................................4
1.3. Copyright notice....................................................................................................................................................4
2. Intended use ...................................................................................................4
3. Safety-related information............................................................................. 4
3.1. General safety-related information........................................................................................................................4
3.2. Warning notices ....................................................................................................................................................5
3.3. Combination with other products / materials.........................................................................................................5
4. Product description ....................................................................................... 5
4.1. Technical data / performance data........................................................................................................................5
5. Preparation for use ........................................................................................ 6
5.1. Installation requirements.......................................................................................................................................6
5.2. Assembly ..............................................................................................................................................................6
5.3. Commissioning .....................................................................................................................................................7
5.3.1. Placement / exchange of the bottle ........................................................................................................7
5.3.2. Flexible sealing cap................................................................................................................................8
6. Use...................................................................................................................8
6.1. Application ...........................................................................................................................................................8
6.2. Pump removal / pump replacement ......................................................................................................................8
6.3. Setting the dosage................................................................................................................................................9
7. Care and maintenance................................................................................... 9
7.1. General care instructions ......................................................................................................................................9
7.1.1. Manual cleaning ...................................................................................................................................10
7.1.2. Processing in thermal disinfector..........................................................................................................10
7.1.3. Processing in autoclave (steam sterilizer)............................................................................................10
8. Disposal ........................................................................................................10
9. Annex ............................................................................................................10
9.1. REF numbers and scope of delivery...................................................................................................................10
9.1.1. Consumables and accessories.............................................................................................................10
9.2. Guarantee terms.................................................................................................................................................11
9.3. Change history....................................................................................................................................................11

3
Inhaltsverzeichnis | Table of contents

4
EN | Information
EN - Instructions for use
1. Information
1.1. General information
METASYS can only guarantee the safety, reliability and performance of this product if the following instructions are ob-
served:
> The product is only to be used in accordance with the instructions for use.
>METASYS assumes no responsibility for damage caused by external in uences (wrong installation), use of incorrect
information, improper use of the device or unauthorized technical intervention.
>The user must familiarize himself with the operation of the product and ensure that the product is in good working
order before each use.
Important: Read the instructions for use carefully before installation, commissioning and use and keep them for the entire
service life of the product!
1.2. Explanation of the symbols
REF / order number Attention / Caution
Manufacturer
1.3. Copyright notice
All names and content are protected by copyright. Distribution, duplication or other use of this document is only permitted
with the written consent of METASYS Medizintechnik GmbH.
2. Intended use
This device is suitable for hand disinfectants and liquid soaps. It is not intended for use with highly viscous, abrasive or
aggressive products. Use the dispenser only indoors. The device is intended for hand disinfection and cleaning under
normal conditions of use.
3. Safety-related information
3.1. General safety-related information
All serious incidents that have occurred in connection with the device must be reported to the manufacturer and the com-
petent authority of the Member State in which the user and / or patient is established.
Before using new products, the compatibility of the product and the dispenser must always be checked in order to be
able to guarantee fault-free functionality. METASYS assumes no liability for any damage or costs that may arise due to

5
Product description | EN
incompatibilities dispenser and products used.
The device is not suitable for transporting the product being used. The device is only suitable for hand disinfectants and
liquid soaps.
3.2. Warning notices
ATTENTION Warning of a danger that can lead to minor injuries
CAUTION Notice of a danger that can lead to extensive property damage
3.3. Combination with other products / materials
This device is suitable for hand disinfectants and liquid soaps. It is not intended for use with highly viscous, abrasive or
aggressive products. Tests are required before using new lling goods!
4. Product description
4.1. Technical data / performance data
230 mm
321 mm
94 mm
203 mm
321 mm
90 mm
51 mm
40 mm
ca. 170 mm
Housing aluminum, matt silver anodized
Bottle plastic, removable; 1000 ml
Pump recyclable DHP disposable plastic pump
Operating lever stainless steel
Wall bracket plastic
Wall mounting wall mounting with 3 screws and dowels
Quantity dispensed 1.5 ml / stroke (depending on the viscosity of the product)
Cleaning dispenser dishwasher safe and autoclavable up to 134 ° C, 2 bar

6
EN | Preparation for use
5. Preparation for use
5.1. Installation requirements
> When using the device as a soap dispenser, install the dispenser above or as close as possible to the sink to prevent
liquid dripping from your hands onto the oor.
> Required space above the dispenser: 50-70 mm for the lever as well as for attaching and removing the dispenser, and
an additional 100 mm for operation.
> Required space below the dispenser for bottle removal: approx. 170 mm
> Ergonomically optimal installation height: 130–135 cm, measured from the oor to the top edge of the dispenser
housing.
5.2. Assembly
1First remove the bottle: Tilt the bottom of the inserted bottle slightly for-
wards and remove the bottle from the dispenser.
2Remove the dispenser from the wall plate: Press the latch on the wallpla-
te and slide the dispenser up and out.

7
Preparation for use | EN
3Fasten the wall plate to the wall with the enclosed or other suitable fas-
tening material.
4Slide the dispenser onto the wallplate from the top until the latch clicks
into place.
5.3. Commissioning
When using for the rst time and after replacing the pump or the bottle, press the lever a few times as far as it will go until
the dispenser doses. Hold your hand under the spout.
5.3.1. Placement / exchange of the bottle
Insert the lled bottle into the dispenser from below until it clicks into place.

8
EN | Use
5.3.2. Flexible sealing cap
The exible sealing cap included in the scope of delivery ensures optimum
pressure for different bottle sizes and prevents the loss of alcohol from the
disinfectant.
Use only for liquid soap and disinfectant pumps.
6. Use
6.1. Application
The product is dosed by pressing the lever. The dispenser is preset to a maximum dosage of approx. 1.5 ml / stroke. To
change the dosage, see „6.3. Setting the dosage“.
6.2. Pump removal / pump replacement
1 First pull the outlet cover slightly forward and then rotate it upwards.
2Hold down the pump lock with your nger and pull the pump out towards
you.

9
Care and maintenance | EN
6.3. Setting the dosage
1To change the dosage,  rst remove the pump from the dispenser (see
„6.2. Pump removal / pump replacement“).
2
The dosage can be changed to 1.5 m (MAX) / 1.0 ml / 0.75 ml (MIN)
(dosage dependent on the viscosity of the  lling solution) by turning the
adjustable wheel.
With  rst use, the wheel may be hard to turn; if necessary use a pair of
 at-nose pliers.
CAUTION:
Do not dismantle the housing! Use only original spare parts. The dispenser is only suitable for
dispensing compatible products such as liquid soap (without abrasives), low viscosity lotions or
disinfectants.
ATTENTION:
The use of incompatible products can impair the function of the dispenser and may cause liquid
to spray into eyes!
7. Care and maintenance
7.1. General care instructions
The Robert Koch-Institute recommends: “For both dispenser types (note: hand disinfectant and soap dispenser), the  xed
outer and inner parts must be able to be reprocessed. This is also possible by machine. (...) Visible contamination of the
outer housing and all accessible parts without further manipulation as well as soilings at the outlet must be removed by
wipe disinfection. Daily wipe disinfection is recommended for operating levers. The scope and frequency of checks and
the reprocessing of dispensers should be speci ed in the internal hygiene plan, e.g. every six months.” (Source: Robert
Koch Institute, recommendations for hand hygiene, 2016)
In order to guarantee proper functioning of the dispenser regular manual cleaning is necessary.

10
EN | Disposal
7.1.1. Manual cleaning
Regularly remove adhering product residues. Clean the dispenser housing and the pump regularly with hot water. Rinse
the pump with hot water. Disinfection of the housing is also possible with suitable surface disinfectants.
7.1.2. Processing in thermal disinfector
Choose program „Dispenser cleaning” and use pH-neutral cleaning solutions. Important: Cleaning of plastic pumps up to
max. 65 °C!
7.1.3. Processing in autoclave (steam sterilizer)
The dispenser is autoclavable with superheated steam (134 °C, 2 bar, max. 20 min dwell time).
CAUTION:
Wall plate, bottle and plastic pumps (K pumps) are not autoclavable!
After autoclaving, let the dispenser cool for at least one hour prior to next use!
8. Disposal
The packaging material can be recycled.
The device can be disposed of at a local collection point. Further information may be obtained from your local authority,
waste disposal service or the company from where you purchased this product.
9. Annex
9.1. REF numbers and scope of delivery
Description
40200105 META TOUCH
Soap and disinfectant dispenser, bottle 1000 ml (empty), wall bracket, mounting kit (screws and do-
wels), instructions for use
9.1.1. Consumables and accessories
Description
GREEN&CLEAN HD - Hand disinfection
60030161 GREEN&CLEAN HD 1000 ml 1000 ml Euro bottle
60030162 GREEN&CLEAN HD 500 ml 500 ml Euro bottle
60030069 GREEN&CLEAN HD Re ll kit 3 6 x 1000 ml Euro bottle
60030070 GREEN&CLEAN HD Re ll kit 4 6 x 500 ml Euro bottle
GREEN&CLEAN HL - Hygienic hand cleaning

11
Annex | EN
Description
60030151 GREEN&CLEAN HL 1000 ml 1000 ml Euro bottle
RD-60.132 GREEN&CLEAN HL 750 ml 750 ml
60030051 GREEN&CLEAN HL Intro kit 5 x 750 ml + dispensing bottle
60030052 GREEN&CLEAN HL Re ll kit 1 6 x 750 ml
60030053 GREEN&CLEAN HL Re ll kit 2 1 x canister 5 l
Accessories
40200004 Water tap 5 l canister for GREEN&CLEAN HL
9.2. Guarantee terms
2-year manufacturer‘s guarantee from the date of delivery.
9.3. Change history
Version Date Description
ZK-58.100/00 06.10.2020 New

METASYS Medizintechnik GmbH
Florianistraße 3, 6063 Rum bei Innsbruck, Austria
Tel.: [phone] | Fax: [phone]
www.metasys.com | [email protected]
EN | 2020-10 | ZK-58.100/00 | Subject to printing and setting errors!
