METHVEN 01-8222 User manual

Methven Australia Pty Ltd
ABN 15 104 813 390
Melbourne, Australia
www.methven.com
WMKA21005
IMPORTANT
Please read all of the instructions before installation
MA018222
Waipori Swivel Sink Mixer
01-8222
Use of this product is recommended for domestic and commercial applications.
Domestic and commercial warranty terms and conditions vary. Please refer to the Methven website
for full warranty terms and conditions - www.methven.com
All pipework must be thoroughly flushed prior to the installation of the mixer.
Inline filter washers must be installed on both hot and cold supplies to prevent foreign particles
damaging the ceramic cartridge.
Do not remove the ceramic cartridge from the mixer when installing.
Damage caused by hydrostatic testing is not covered by Methven’s warranty.
Methven recommends a licensed plumber carry out all installations in compliance with
the requirements of AS/NZS 3500. This product complies with AS/NZS 3718 regulations.
AUG 2016
Installation Guide
www.methven.com
Customer Care Hotline: 1300 METHVEN (638 483)
Email: [e-mail]
Cold
Max 40mm (without
plastic support flange)
Ø32mm min
Ø42mm max
Hot
Installation
Tip: Install product on bench before
connecting second hose to mixer.
1. Cut a single 35mm diameter hole into the
mounting surface. The mounting surface
can be a maximum of 40mm thick.
2. Insert o-ring into the groove in the
bottom of the base ring and fit the base
ring to the bottom of the mixer.
3. Feed the mixer’s threaded fastening
tube through the hole cut in the
mounting surface.
4. Position the mixer where required and
fit the rubber washer and triangular
spacer over the threaded fastening
tube. Tighten in place using the tube
spanner (from under the mounting
surface).
5. Insert the flexible hoses through the
hole in the mounting surface (from the
underside) and screw them into the
base of the mixer.
6. Connect the flexible hoses to the hot
and cold supplies (hot on the left, cold
on the right).
Note: It is a condition of Methven’s
warranty that the inline filter washers
supplied are fitted during this
connection.

R35mm Min
20mm
DO NOT CRUSH
HOSE OR SWAGED ENDS
CORRECT
INCORRECT
DO NOT STRETCH OR TWIST HOSES
3
6
7
2
5
4
1
8
Tap body
Stream shaper (ASDA)
Threaded
fastening tube
Base ring
O-ring
Aerator key
2.5mm hex key
Triangular spacer
(for use when mounting
to standless steel sink)
Rubber washer
Mounting nut
Flexible inlet hoses:
cold
hot
Product Components
Please check every component in accordance
with the table below
No. Item description Qty supplied
1 Tap body 1
2 Threaded fastening tube 1
3 Base ring 1
4 O-ring 1
5 Triangular spacer 1
6 Rubber washer 1
7 Mounting nut 1
8 Flexible inlet hoses 2
9 Aerator key 1
10 2.5mm hex key 1
11 Tube spanner 1
THE METHVEN GUARANTEE
The warranty statement shall apply to all tapware & showers supplied by Methven
For more information visit www.methven.com
THIS WARRANTY ISSUED BY: Methven Australia Pty Ltd, Melbourne Australia
Technical Specification
Inlet Connections: All 1/2" BSP
Operating Pressure: 150kPa - 500kPa
For optimum performance hot and cold water pressures should be equal.
AS/NZS 3500 stipulates a 500kPa maximum operating pressure at any outlet
within a building. Where normal pressure exceeds 500kPa, a pressure limiting
valve must be installed.
This sink mixer is rated at 7.5l/m. If limited water flow is experienced, locate
stream shaper flow restricting device and filter washers and clean away foreign
material as required.
Operating Temperature: Recommended hot water supply 50°C, maximum 70°C. AS/NZS 3500 requires all
hot water supplies to any sanitary fitting to be tempered to 50°C.
Ceramic cartridges: Warranty claims will be void where the ceramic cartridge has malfunctioned due
to the presence of the following within the water supply:
Copper tube pieces
Plastic pieces
Sand, dirt or stones
Thread tape
Other objects not normally present in the potable water supplies
Hose Requirement for Mixers
Do not hydrostatic test* the installation with this mixer installed. Damage to the ceramic cartridge may
occur, voiding warranty.
*Hydrostatic testing refers to placing the system under pressure, above the recommended operating pressure, to determine water
tightness and to uncover leaks or weak joints within the system.
Care and Cleaning
Never use abrasives to clean this product. Clean regularly with contamination free warm soapy water
and a damp soft cloth. Damage caused by using unsuitable cleaning agents is not covered by warranty.
