IMPORTANT
Please read all of the instructions before installation
MA433098
Minimalist Plate Mount Basin Mixer
Minimalist Plate Mount Bath Mixer
Basin: 01-2053
Bath: 01-2404
Use of this product is recommended for domestic and commercial applications.
All pipework must be thoroughly flushed prior to the installation of the mixer.
Inline filter washers must be installed on both hot and cold supplies to prevent foreign particles
damaging the ceramic cartridge.
Do not remove the ceramic cartridge from the mixer when installing.
Methven recommends a licensed plumber carry out all installations in compliance with
the requirements of AS/NZS 3500. This product complies with AS/NZS 3718 regulations.
JUNE 2014
Installation Guide
www.methven.com
Customer Care Hotline: 1300 METHVEN (638 483)
Email: [e-mail]
Installation
1. Leave protective cover in place.
2. Screw the body assembly (1) on to the
mounting stud positioned to observe the
installation depth, ID (to front of finished
wall lining e.g. tiles) range as follows:
Range of Install Depth, ID = 62 ± 12mm
3. Connect body assembly (1) into system.
4. Cut holes in lining as pictured.
5. Trim the brass nipple to 15 +/- 2mm
protruding from finished wall lining.
Lubricate the o-ring in the faceplate (2).
Place the faceplate (2) over the the body
assembly (1) until flat on the finished wall
surface. Remove protective cover prior to
next step.
6. Screw on half dome (3). Fit handle (5) and
fasten grub screw with hex key supplied.
Screw on lever (6) onto grub screw in handle
(5). Screw spout (4) on using Teflon tape or
similar to ensure a seal.
Applies to basin mixer only
1.
115
25
ø 60 ± 5mm
2.
3.
4.
5.
6.
ID

Technical Specification
Inlet Connections: All 1/2" BSP
Operating Pressure: 150kPa - 500kPa
For optimum performance hot and cold water pressures should be equal.
AS/NZS 3500 stipulates a 500kPa maximum operating pressure at any outlet
within a building. Where normal pressure exceeds 500kPa, a pressure limiting
valve must be installed.
The basin mixer is rated at 7.5l/m. If limited water flow is experienced, locate
stream shaper flow restricting device and filter washers and clean away
foreign material as required.
Operating Temperature: Recommended hot water supply 50°C, maximum 70°C. AS/NZS 3500 requires all
hot water supplies to any sanitary fitting to be tempered to 50°C.
Ceramic cartridges: Ceramic cartridge can be damaged due to the presence of the following within the
water supply:
Copper tube pieces
Plastic pieces
Sand, dirt or stones
Thread tape
Other objects not normally present in the potable water supplies
Piping Requirements for Mixers
Avoid restrictive piping, fitting or sharp angled bends when plumbing the mixer
Do not hydrostatic test* the installation with this mixer installed. Damage to the ceramic cartridge may occur.
Hydrostatic testing refers to placing the system under pressure, above the recommended operating pressure, to
determine water tightness and to uncover leaks or weak joints within the system.
Care and Cleaning
Never use abrasives to clean this product. Clean regularly with contamination free warm soapy water and a damp
soft cloth.
www.methven.com
Customer Care Hotline: 1300 METHVEN (638 483)
Email: [e-mail]
Ceramic Cartridge
Adjustment
Do not remove the ceramic cartridge
from the body while carrying out the
following adjustments.
Note: the cartridge is factory set for
maximum temperature.
+
+
-
Remove half-dome (if attached) Flow limiting
adjustment
Mix
temperature
limiting
adjustment
1
2
Body Assembly
Faceplate
4
Spout
3
Half Dome
5
Handle
6
Lever
