METHVEN SATINJET ESCAPE MKII User manual

METHVEN
SATINJET ESCAPE MKII
WALL SHOWER ON UPSWEPT ARM
CLEANING RECOMMENDATIONS
This bathroom product should not be cleaned with abrasive materials eg.
steel wool/scourers. Do not use any corrosive or abrasive cleaning agents
containing acids or scouring agents. Bleaches can also discolour products
and therefore should not be used. Damage caused by any improper
treatment is not covered by the product warranty- refer to Warranty
Conditions on the last page.
To see the full METHVEN range at Reece go to
www.reece.com.au/bathrooms
SPECIFICATIONS
Recommended Use Domestic, hotel and commercial
Colour Chrome with satin chrome face
Chrome with white face
Pressure Rating Suitable for high pressure applications and has
been WELS certified to the following:
Minimum operating pressure 150kPa
Maximum operating pressure 500kPa
Temperature Rating Maximum continous working temperature 70˚C
(recommended 38˚C - 42˚C)
Minimum 1˚C
Suitable Hot Water
Units
Storage Tank: Yes
Continous Flow: Yes
Gravity Feed: Not recommended
WELS Stars: 3
Flow rate: 9L/min
Standards AS/NZS 3662
Spray Patterns Standard Satinjet; Massage
Disclaimer: Products in this specification manual must by regulation be installed by licensed and registered
trade people. The manufacturer/distributor reserves the right to vary specifications or delete models from
their range without prior notification. Dimensions are nominal measurements only. Dimensions and set-outs
listed are correct at time of publication however the manufacturer/distributor takes no responsibility for
printing errors.
Tech Page Version 1
AS3662
WMKT21090
153
1/2" BSP Femal e
53
218
141
page 1 of 3

METHVEN
SATINJET ESCAPE MKII
WALL SHOWER ON UPSWEPT ARM
INSTALLATION INSTRUCTIONS
Plumbers, please ensure a copy of the installation
instructions is left with the end user for future reference
Apply plumbing tape to pipe. Screw arm onto pipe
ensuring that the arm ends in the correct position. Remove cap from shower head if �tted. Screw shower head onto arm
1. 2. 3.
NOTE FOR SHOWER HEAD ONLY INSTALLATIONS - use step 2 onwards.
Water contains lime which remains on the surface
after the water has evaporated. These lime
deposits can be prevented from forming by wiping
immediately after use.
To clean the chrome-plated surfaces use a soft
cloth, soap and warm water. Never use cleaning
agents that contain a corrosive acid or a scouring
additive.
CLEANING
Do not use any
sharp objects to
clean nozzles.
Clean �lter washer
periodically.
Straighten shower head so it is in the correct
orientation.
4.
page 2 of 3

METHVEN
SATINJET ESCAPE MKII
WALL SHOWER ON UPSWEPT ARM
Don’t risk it, use a licensed plumber.™
REECE PRODUCT QUALITY GUARANTEE
You have purchased a quality product from Reece Pty Ltd
ABN 84 004 097 090 (“Reece”). This product is covered by a
Lifetime replacement product warranty, including spare parts,
and a 12 month warranty covering labour.
LIFETIME YEAR WARRANTY – DOMESTIC USE
This warranty covers faults in the product construction, material
and assembly. Products which are, found upon inspection
by an authorised Reece representative, to be defective
in construction, material or assembly, will be repaired or
exchanged with an equivalent product free of charge. Replaced
items become Reece’s property.
All replacement products will be available for collection without
charge to the customer at the nearest Reece branch to the
customer’s location, or elsewhere as agreed between the
customer and Reece.
Labour and Spare Parts
The labour for the replacement of products and spare parts
to which this warranty applies will be supplied by Reece or
relevant supplier using licensed plumbers engaged by Reece or
relevant supplier within 1 year from the date of purchase.
Spare parts found upon inspection by an authorised Reece
representative to be defective in construction, material
or assembly, will be replaced free of charge for the life of
the product.
Warranty Conditions
This warranty will apply only under all of the
following conditions:
• The item has been installed by a licensed plumber
• The item has been installed for and subjected to domestic
residential use only
• Failure is due to a fault in the manufacture of the product
• Proof of purchase (including the date of purchase)
is provided
• The installation of the product is in accordance with the
instructions provided
This warranty does not cover products purchased as an
ex-display without being fully checked and tested for sale by
the manufacturer.
This warranty does not include faults caused by:
• Unsuitable or improper use
• Incorrect installation or installation not in accordance with
the instructions provided
• Installation or part installation by the purchaser or any person
other than a LICENSED PLUMBER
• Normal wear and tear
• Inadequate or complete lack of maintenance
• Chemical, electrochemical or electrical influences
• Harsh detergents or abrasive cleaners used on
product finishes
1 YEAR WARRANTY – COMMERCIAL USE
‘Commercial’ use is all use other than for normal domestic
residential purposes, including use in non-business places as in
public buildings, schools, sports centres and in establishments
that contain private bathrooms with high frequency of use by
many individuals, such as hotels, motels, retirement villages
and hospitals.
The Commercial warranty covers this product against
manufacturing faults in the construction, material and assembly
of both the finished products and any spare parts for a period
of 1 year from the date of purchase. Products and spare
parts which are found upon inspection by an authorised
Reece representative to be defective in construction, material
or assembly will be repaired or exchanged free of charge.
Replaced items become Reece’s property. The labour for the
replacement of products and spare parts to which this warranty
applies will be supplied by Reece or relevant supplier using
licensed plumbers engaged by Reece or relevant supplier.
The Warranty Conditions and exclusions which apply to the
domestic use warranty also apply to this commercial warranty.
EXCLUSIONS
To the fullest extent permitted by law, Reece excludes all liability
for damage or injury to any person, damage to any property,
and any indirect consequential or other loss or damage.
CLAIM PROCEDURE
For all warranty queries customers are to contact the branch
where the product was purchased. These details can be found
on your purchase invoice.
Our goods come with guarantees that cannot be excluded
under the Australian Consumer Law. You are entitled
to a replacement or refund for a major failure and for
compensation for any other reasonably foreseeable loss or
damage. You are also entitled to have the goods repaired or
replaced if the goods fail to be of acceptable quality and the
failure does not amount to a major failure.
SHOWER.METH.T2.LIFE
Don’t risk it, use a licensed plumber.™
LIFE
TIME
Q
U
A
L
I
T
Y
G
U
A
R
A
N
T
E
E
page 3 of 3
