INSTALLATION INSTRUCTIONS FOR PART 99-7320
1-800-221-0932 www.metraonline.com
© COPYRIGHT 2004-2009 METRA ELECTRONICS CORPORATION
KIT FEATURES
• DIN head unit provision
A) Radio Housing
KIT COMPONENTS
TOOLS REQUIRED:
99-7320
A
APPLICATIONS
Hyundai Sonata
2006-2008
Phillips Screwdriver • Small Flat Blade Screwdriver
WIRING AND ANTENNA CONNECTIONS
(Sold Separately)
Harness:
• 70-5520 - Ford harness 2003-up
Antenna Adapter:
• Not required

Dash Disassembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Kit Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Final Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
TABLE OF CONTENTS
99-7320
K NOWLEDGE IS P OWER
Enhance your installation and fabrication skills
by enrolling in the most recognized and respected
mobile electronics school in our industry.
Log onto www.installerinstitute.com
or call 800-354-6782 for more information
and take steps toward a better tomorrow.

99-7320
1
Disconnect the negative battery
terminal to prevent an accidental
short circuit.
1
Open glove box and remove (2)
Phillips screws from top edge of
glove box opening and bottom edge
of wood trim below radio.
(Figure A)
2
HYUNDAI SONATA 2006-2008
Unclip and remove wood trim from
below radio and above glove box.
(Figure B)
3
Remove (1) Phillips screw per side
panel next to radio then unclip and
remove panels. (Figure C)
4
Remove (6) Phillips screws from
radio to extract from sub dash.
(Figure D)
5
DASH DISASSEMBLY
A
OFF
AUTO
B
FM1 95.7
2 14
Lo
93
D
FM1 95.7
2 14
Lo
93
C

99-7320
KIT ASSEMBLY
2
Slide the DIN cage into the Radio
Housing and secure by bending the
metal locking tabs down. (Figure A)
1
A
Slide the aftermarket head unit into
the cage and secure. (
Figure B)
2
B
DIN HEAD UNIT PROVISION

3
FINAL ASSEMBLY
1
Locate the factory wiring harness in the dash and make the connection as shown.
Metra recomends using the proper mating adapter and making the connections as
shown. (Isolate and individually tape off the ends of any unused wires to prevent
electrical short circuit.)
2
Re-connect the negative battery terminal and test the unit for proper operation.
3
Reassemble radio and dash assemblies in reverse order of disassembly.
A
A) Strip wire ends back 1/2"
B) Twist ends together
C) Solder
D) Tape
B
C
D
Make wiring connections using the EIA color code chart shown below and the instructions included with the head
unit. Metra recommends making connections as shown below; Strip, Splice, Solder, Tape. Isolate and individually
tape off ends of any unused wires to prevent electrical short circuit.
12V Ignition / Acc . . . Red
12V Batt / Memory . . Yellow
Ground . . . . . . . . . . . Black*
Power Antenna . . . . . Blue
Amp Turn-On . . . . . . Blue / White
Amp Ground . . . . . . . Black / White
Illumination. . . . . . . . Orange
Dimmer . . . . . . . . . . Orange / White
Right Front (+) . . . . . Gray
Right Front (-) . . . . . . Gray / Black
Left Front (+) . . . . . . White
Left Front (-) . . . . . . . White / Black
Right Rear (+). . . . . . Violet
Right Rear (-) . . . . . . Violet / Black
Left Rear (+). . . . . . . Green
Left Rear (-) . . . . . . . Green / Black
*NOTE: When Black a wire is not present, ground radio to vehicle chassis.
All colors may not be present on all leads due to manufacturer’s specifications.
METRA / EIA WIRING CODE
FINAL WIRING CONNECTIONS
