Metra Electronics 99-5812 User manual

INSTALLATION INSTRUCTIONS FOR PART 99-5812
Cutting Tool • Phillips Screwdriver • Socket Wrench
1-800-221-0932 www.metraonline.com
KIT FEATURES
© COPYRIGHT 2004-2010 METRA ELECTRONICS CORPORATION
APPLICATIONS
FORD
Edge 2007-2010 / Expedition 2007-2010
Explorer 2006-2010 / Explorer Sport Trac 2006-2010
F-150 2004-2008 / E Series 2009-10 / F Series 2005-2009
Five-Hundred 2005-2007 / Focus 2005-2007 / FreeStar 2004-2007
Freestyle 2005-2007 / Fusion 2006-2011
Mustang 2005-2009 / Super Duty 2008-2011
Taurus 2008 / Taurus X 2008-2009
MERCURY
Monterey 2004-2007 / Milan 2006-2008
Montego 2005-2007 / Mountaineer 2006-2010
Sable 2008-2009
LINCOLN
Mark LT 2005-2008
Factory Navigation Only: MKX 2007-2011 / Navigator 2007-2010
• DIN Head Unit Provision with Pocket
• ISO DIN Head Unit Provision with Pocket
A) Radio Housing • B) ISO Brackets • C) Trim Plate • D) Side brackets • E) Spacers • F) (4) Screws
KIT COMPONENTS
TOOLS REQUIRED:
99-5812
A
p
BC
E
F
D
WIRING AND ANTENNA CONNECTIONS (Sold Separately)
Harness:
• 70-5520 - Ford Harness 2003-up
• 70-5521 - Ford Amplified Harness 2003-up
• 70-5522 - Ford Sub Harness 2003-up
• XSVI-5520 NAV - Ford Interface 2006-up
Antenna Adapter:
• 40-CR10 - Chrysler/GM Antenna Adapter 2002-up

Dash Disassembly
Ford Edge 2007-2010.........................................................................................................................1
Ford F-150 2004-2008 / Expedition 2007-2010.................................................................................1
Lincoln Mark LT 2005-2008 ............................................................................................................. 1
Ford Mustang 2005-2009.................................................................................................................. 2
Ford Five Hundred 2005-2007 .......................................................................................................... 3
Mercury Sable 2008-2009................................................................................................................. 3
Ford Taurus 2008-2009 ..................................................................................................................... 3
Mercury Montego 2005-2007............................................................................................................ 3
Ford Fusion 2006-2011..................................................................................................................... 4
Mercury Milan 2006-2008................................................................................................................. 4
Ford Freestyle 2005-2007................................................................................................................. 5
Ford Taurus X 2008 -2009 ................................................................................................................5
Ford Freestar 2004-2007 .................................................................................................................. 6
Mercury Monterey 2004-2007 .......................................................................................................... 6
Ford Focus 2005-2007 ...................................................................................................................... 7
Ford Explorer 2006-2010 .................................................................................................................. 8
Ford Explorer Sport Trac 2006-2010 ................................................................................................. 8
Mercury Montaineer 2006-2010 ....................................................................................................... 8
Ford E Series 2009-2010 .................................................................................................................. 9
Ford F Series Super Duty 2005-2008................................................................................................ 9
Ford Super Duty 2008-2011............................................................................................................ 10
Lincoln MKX 2007-2011 ..................................................................................................................11
Lincoln Navigator 2007-2010...........................................................................................................12
Kit Assembly
DIN Head Unit Provision.....................................................................................................................13
ISO DIN Head Unit Provision............................................................................................................ 14
Final Assembly ................................................................................................................................15
TABLE OF CONTENTS
99-5812
*Note: Refer also to the instructions included with the aftermarket radio.
KNOWLEDGE IS POWER
Enhance your installation and fabrication skills by
enrolling in the most recognized and respected
mobile electronics school in our industry.
Log onto www.installerinstitute.com or call
800-354-6782 for more information and take steps
toward a better tomorrow.

1
Disconnect the negative battery terminal
to prevent an accidental short circuit.
Unsnap and remove entire panel
surrounding the radio and climate
controls.
(Figure A)
1
2
Remove (4) 9/32" screws to remove the
factory radio.
(Figure B)
3
A
FORD F-150 2004-2008
LINCOLN MARK LT 2005-2008
FORD EXPEDITION 2007-2010
FORD EDGE 2007-2010
B
99-5812 DASH DISASSEMBLY
Continue to kit assembly

2
FORD MUSTANG 2005-2009
Disconnect the negative battery terminal
to prevent an accidental short circuit.
Remove (2) Phillips screws from under
the center armrest at the back of the
shifter trim panel (including cup
holders).
(Figure B)
1
3
Unclip and remove panel. (Figure B)
4
A
B
Unclip and remove the (2) center stack
trim panels from the left and right side
of the radio and climate controls.
(Figure C)
5
Remove (6) 9/32” screws from center
trim panel surrounding the radio and
climate controls then unclip and remove
panel.
(Figure D)
6
Remove (4) 9/32” screws from the radio
to remove.
(Figure E)
7
C
DE
Remove the small rectangular shifter
lever trim panel if equipped. (Figure A)
2
99-5812 DASH DISASSEMBLY
Continue to kit assembly

Disconnect the negative battery terminal
to prevent an accidental short circuit.
Unclip and remove the small rectan-
gular trim around shift lever.
(Figure A)
1
2
Unclip and remove the entire panel
(including cup holders) surrounding the
shift lever.
(Figure B)
3
A
FORD FIVE-HUNDRED 2005-2007, FORD TAURUS 2008-09
MERCURY MONTEGO 2005-2007, MERCURY SABLE 2008-09
B
Remove (2) 9/32” screws at the bottom
of the center radio/ climate control
panel.
(Figure C)
4
Unclip and remove the center panel.
(Figure D)
5
Remove (4) 9/32” screws from the radio
to remove.
(Figure E)
6
C
D
E
3
99-5812 DASH DISASSEMBLY
Continue to kit assembly

4
FORD FUSION 2006-2011
MERCURY MILAN 2006-2008
Disconnect the negative battery terminal
to prevent an accidental short circuit.
1
3
A
B
Remove (4) 9/32” screws to remove the
factory radio.
(Figure B)
Unsnap and remove entire panel sur-
rounding the radio and climate controls.
(Figure A)
2
99-5812 DASH DISASSEMBLY
Continue to kit assembly

5
FORD FREESTYLE 2005-2007
FORD TAURUS X 2008-09
99-5812
Disconnect the negative battery terminal
to prevent an accidental short circuit.
1
3
A
B
Remove (4) 9/32” screws from radio to
remove. (Figure B)
Unclip and remove entire panel sur-
rounding the radio and a/c controls.
(Figure A)
2
DASH DISASSEMBLY
Continue to kit assembly

6
FORD FREESTAR 2005-2007
MERCURY MONTEREY 2004-2007
Disconnect the negative battery terminal
to prevent an accidental short circuit.
Remove (4) 9/32” screws to remove the
factory radio.
(Figure B)
1
3
A
B
Unsnap and remove entire panel sur-
rounding the radio and climate controls.
(Figure A)
2
99-5812 DASH DISASSEMBLY
Continue to kit assembly

7
Disconnect the negative battery terminal
to prevent an accidental short circuit.
Unsnap and remove entire panel
surrounding the radio and climate
controls.
(Figure A)
1
2
Remove (4) 9/32” screws to remove the
factory radio.
(Figure B)
3
A
FORD FOCUS 2005-2007
B
99-5812 DASH DISASSEMBLY
Continue to kit assembly

8
Disconnect the negative battery terminal
to prevent an accidental short circuit.
Open center console and remove (2)
Phillips screws then unclip and remove
entire panel surrounding shifter.
(Figure A)
1
2
Remove dash panel surrounding radio to
access the factory radio screws.
(Figure B)
3
Remove (4) 9/32” screws to remove the
factory radio. (Figure C)
4
A
C
FORD EXPLORER 2006-2010
FORD SPORT TRAC 2006-2010
MERCURY MOUNTAINEER 2006-2010
B
99-5812 DASH DISASSEMBLY
Continue to kit assembly

9
Disconnect the negative battery terminal
to prevent an accidental short circuit.
Unsnap and remove entire panel
surrounding the radio and climate
controls.
(Figure A)
1
2
Remove (4) 9/32” screws to remove the
factory radio. (Figure B)
3
A
FORD E SERIES 2009-2010
FORD F SERIES SUPER DUTY 2005-2009
B
99-5812 DASH DISASSEMBLY
Continue to kit assembly

10
Disconnect the negative battery terminal
to prevent an accidental short circuit.
Unclip and remove the power outlet
panel and the blank panel on the left
and right side of the radio trim panel.
(Figure A)
1
2
Remove the (2) 9/32” screws exposed
behind the two panels remove in step 2.
3
Remove (4) 9/32” screws securing the
radio.
5
Unclip and remove the entire radio trim
panel including the a/c control and
vents.
4
FORD SUPER DUTY 2008-2011
99-5812 DASH DISASSEMBLY
Continue to kit assembly
A

11
Disconnect the negative battery terminal
to prevent an accidental short circuit.
Open center console lid and unclip and
remove the center console trim panel
surrounding the shifter.
(Figure A)
1
2
Remove (2) Phillips screws from the
storage bin then unclip and remove the
bin.
(Figure B)
3
Remove (4) 9/32” screws securing the
radio. Unplug and remove the Radio.
5
Unclip and remove the upper and lower
center trim panel as one assembly.
(Figure C)
4
LINCOLN MKX 2007-2011
99-5812 DASH DISASSEMBLY
Continue to kit assembly
A
B
C

12
Disconnect the negative battery terminal
to prevent an accidental short circuit.
Unclip and remove the panel surround-
ing the shifter.
(Figure A)
1
2
Remove (2) 9/32” screws from the bot-
tom of the radio/climate control trim
panel.
(Figure B)
3
Unclip and remove the entire panel sur-
rounding the radio and including the cli-
mate controls. (Figure B)
4
Remove (4) 9/32” screws securing the
radio. Unplug and remove the Radio.
5
LINCOLN NAVIGATOR 2007-2010
99-5812 DASH DISASSEMBLY
Continue to kit assembly
A
B

13
DIN HEAD UNIT PROVISION
99-5812
KIT ASSEMBLY
NOTE: Refer also to the instructions included with the aftermarket radio.
2
Slide the DIN cage into the Radio
Housing and secure by bending the
metal locking tabs outward.
(Figure A)
1
(a) For the Ford Edge/Expedition
2007, Explorer 2006-07, Fusion
2006-07, Mustang 2007 and the
Super Duty 2008 attach the included
spacers to the back of the radio hous-
ing mounting tabs.
(Figure 1A)
NOTE: Use the screws supplied with this kit
to mount the radio housing in the vehicles
that require the spacers.
(b) For the Ford Freestar 2004-07,
Monterey 2004-07, Focus 2005-07,
and the F Series Super Duty 2005-07,
slide the included brackets onto the
sides of the radio housings pocket from
the back of the housing forward.
(Figure 1B)
If your vehicle is not listed above
move to step 2.
3
Slide the aftermarket radio into the
cage until it snaps in place.
(Figure B)
A
B
1A
1B
Continue to final assembly

14
ISO DIN HEAD UNIT PROVISION
99-5812
KIT ASSEMBLY
2
Mount the ISO Brackets to the head
unit with the screws supplied with the
unit.
(Figure A)
3
Slide the head unit into the radio open-
ing until the side clips engage
(Figure B)
4
Snap the Trim plate into the Radio
Housing.
(Figure B)
1B
A
B
1
(a) For the Ford/Edge Expedition
2007, Explorer 2006-07, Fusion
2006-07, Mustang 2007 and the
Super Duty 2008 attach the included
spacers to the back of the radio hous-
ing mounting tabs.
(Figure 1A)
NOTE: Use the screws supplied with this kit
to mount the radio housing in the vehicles
that require the spacers.
(b) For the Ford Freestar 2004-07,
Monterey 2004-07, Focus 2005-07,
and the F Series Super Duty 2005-
07, slide the included brackets onto
the sides of the radio housings pocket
from the back of the housing forward.
(Figure 1B)
If your vehicle is not listed above
move to step 2.
NOTE: Refer also to the instructions included with the aftermarket radio.
1A

15
FINAL ASSEMBLY
1
Locate the factory wiring harness in the dash and make the connection as shown.
Metra recomends using the proper mating adapter and making the connections as
shown. (Isolate and individually tape off the ends of any unused wires to prevent
electrical short circuit.)
2
Re-connect the negative battery terminal and test the unit for proper operation.
3
Reassemble radio and dash assemblies in reverse order of disassembly.
A
A) Strip wire ends back 1/2"
B) Twist ends together
C) Solder
D) Tape
B
C
D
Make wiring connections using the EIA color code chart shown below and the instructions included with the head
unit. Metra recommends making connections as shown below; Strip, Splice, Solder, Tape. Isolate and individually
tape off ends of any unused wires to prevent electrical short circuit.
12V Ignition / Acc . . . Red
12V Batt / Memory . . Yellow
Ground . . . . . . . . . . . Black*
Power Antenna . . . . . Blue
Amp Turn-On . . . . . . Blue / White
Amp Ground . . . . . . . Black / White
Illumination. . . . . . . . Orange
Dimmer . . . . . . . . . . Orange / White
Right Front (+) . . . . . Gray
Right Front (-) . . . . . . Gray / Black
Left Front (+) . . . . . . White
Left Front (-) . . . . . . . White / Black
Right Rear (+). . . . . . Violet
Right Rear (-) . . . . . . Violet / Black
Left Rear (+). . . . . . . Green
Left Rear (-) . . . . . . . Green / Black
*NOTE: When Black a wire is not present, ground radio to vehicle chassis.
All colors may not be present on all leads due to manufacturer’s specifications.
METRA / EIA WIRING CODE
FINAL WIRING CONNECTIONS
99-5812
KIT ASSEMBLY
NOTE: Use the screws supplied with this kit to mount the radio housing in the vehicles that require the
spacers.

16
99-5812
NOTES

INSTRUCCIONES DE INSTALACIÓN PARA LA PIEZA 99-5812
Herramienta de corte • Destornillador Phillips • Llave de tubo
1-800-221-0932 www.metraonline.com
CARACTERÍSTICAS DEL KIT
© COPYRIGHT 2004-2010 METRA ELECTRONICS CORPORATION
APLICACIONES
FORD
Edge 2007-2010 / Expedition 2007-2010
Explorer 2006-2010 / Explorer Sport Trac 2006-2010
F-150 2004-2008 / E Series 2009-10 / F Series 2005-2009
Five-Hundred 2005-2007 / Focus 2005-2007 / FreeStar 2004-2007
Freestyle 2005-2007 / Fusion 2006-2011
Mustang 2005-2009 / Super Duty 2008-2011
Taurus 2008 / Taurus X 2008-2009
MERCURY
Monterey 2004-2007 / Milan 2006-2008
Montego 2005-2007 / Mountaineer 2006-2010
Sable 2008-2009
LINCOLN
Mark LT 2005-2008
Factory Navigation Only: MKX 2007-2011 / Navigator 2007-2010
• Accesorio para unidades centrales DIN con bolsillo
• Accesorio para unidades centrales DIN ISO con bolsillo
A) Alojamiento del radio • B) Soportes ISO • C) Placa de terminación • D) Soportes laterales • E) Espaciadores
• F) (4) Tornillos
COMPONENTES DEL KIT
HERRAMIENTAS REQUERIDAS:
99-5812
A
BC
E
F
D
CONEXIONES DE CABLEADO Y ANTENA (se venden por separado)
Arnés:
• Arnés de Ford 70·5520 2003 y modelos posteriores
• Arnés amplificado de Ford 70-5521 2003 y modelos posteriores
• Subarnés de Ford 70-5522 2003 y modelos posteriores
• Interfaz de Ford XSVI-5520 NAV 2006 y modelos posteriores
Adaptador de antena:
• Adaptador de antena Chrysler/GM 40-CR10 2002 y modelos posteriores

Desmontaje del tablero
Ford Edge 2007-2010.........................................................................................................................1
Ford F-150 2004-2008 / Expedition 2007-2010.................................................................................1
Lincoln Mark LT 2005-2008 ............................................................................................................. 1
Ford Mustang 2005-2009.................................................................................................................. 2
Ford Five Hundred 2005-2007 .......................................................................................................... 3
Mercury Sable 2008-2009................................................................................................................. 3
Ford Taurus 2008-2009 ..................................................................................................................... 3
Mercury Montego 2005-2007............................................................................................................ 3
Ford Fusion 2006-2011..................................................................................................................... 4
Mercury Milan 2006-2008................................................................................................................. 4
Ford Freestyle 2005-2007................................................................................................................. 5
Ford Taurus X 2008 -2009 ................................................................................................................5
Ford Freestar 2004-2007 .................................................................................................................. 6
Mercury Monterey 2004-2007 .......................................................................................................... 6
Ford Focus 2005-2007 ...................................................................................................................... 7
Ford Explorer 2006-2010 .................................................................................................................. 8
Ford Explorer Sport Trac 2006-2010 ................................................................................................. 8
Mercury Montaineer 2006-2010 ....................................................................................................... 8
Ford E Series 2009-2010 .................................................................................................................. 9
Ford F Series Super Duty 2005-2008................................................................................................ 9
Ford Super Duty 2008-2011............................................................................................................ 10
Lincoln MKX 2007-2011 ..................................................................................................................11
Lincoln Navigator 2007-2010...........................................................................................................12
Montaje del kit
Accesorio para unidades centrales DIN............................................................................................13
Accesorio para unidades centrales DIN ISO.................................................................................... 14
Montaje final ...................................................................................................................................15
INDICE
99-5812
*Nota: Asimismo, remítase a las instrucciones incluidas con el radio de posventa.
KNOWLEDGE IS POWER
Enhance your installation and fabrication skills by
enrolling in the most recognized and respected
mobile electronics school in our industry.
Log onto www.installerinstitute.com or call
800-354-6782 for more information and take steps
toward a better tomorrow.
