Metro DataVac qwikSIGHT User manual

INSTRUCTIONS FOR USE
qwikSIGHTTM BASKET SUPPLY SYSTEM
© 2016 InterMetro Industries Corporation, Wilkes-Barre, PA 18705
L01-602 Rev.A 09/2016
DESCRIPTION / DESCRIPTION / DESCRIPCIÓN
Metro qwikSIGHTTM
!"#!"$"
%&$$'$(
Part No. Description Part No. Description
QB74L 74" Height L-Frame, Single Side QB03D 3" Long Divider (hook)
QB74T 74" Height T-Frame, Double Side QB06D 6" Long Divider (hook)
QB18F 18" Long Frame Bar with Hardware QB18D 18" Long Divider (snap)
QB36F 36" Long Frame Bar with Hardware QB36LHC 36" Long Label Holder, Clear
QB48F 48" Long Frame Bar with Hardware QB03LHBL 3" Long Label Holder, Blue
QB1818C 18" Bottom Cover QB03LHCL 3" Long Label Holder, Clear
QB1836C 36" Bottom Cover QB03LHGR 3" Long Label Holder, Green
QB1848C 48" Bottom Cover QB03LHOR 3" Long Label Holder, Orange
QB4B 4" Diameter Brake Caster QB03LHPK 3" Long Label Holder, Pink
C05-1198 Metro qwikSIGHT Branding Label QB03LHRD 3" Long Label Holder, Red
QB1236B 12" Depth x 36" Long Basket with Brackets QB03LHYL 3" Long Label Holder, Yellow
QB1836B 18" Depth x 36" Long Basket with Brackets
MODE D’EMPLOI
INSTRUCCIONES DE USO

2 )*+',*-
qwikSIGHTTM
Levelling Foot (x4)
B
4" Caster (x4)
CD
SINGLE STARTER CONFIGURATION - STATIONARY TO MOBILE FRAME
L-Frame
(x2)
Frame Bar
(x3)
CAUTION: WEIGHT CAPACITY
Maximum capacities are based on evenly distributed load.
Shelf can hold up to 100 lbs. (45kg) evenly distributed.
NEVER exceed 500 lbs. (227kg) of evenly distributed load on
any stationary unit.
NEVER exceed 375 lbs. (170kg) of evenly distributed load on
any mobile unit.
MAINTENANCE
Regularly inspect this product. Tighten loose fasteners and
replace worn or damaged parts with new InterMetro approved
parts. For mobile units, regularly inspect casters and replace
worn or damaged casters immediately; lubricate casters
regularly (if equipped with grease fittings).
NOTE: Lay the Unit on Ground.
A
MISE EN GARDE : CAPACITÉ DE POIDS
MAINTENANCE
Inspecter régulièrement ce produit. Resserrer les attaches mal
fixées et remplacer les pièces usées ou endommagées par des
pièces neuves approuvées par InterMetro. Inspecter régulière-
ment les roulettes des unités mobiles et remplacer immédiatement
les roulettes usées ou endommagées; lubrifier régulièrement les
roulettes (si elles sont équipées de graisseurs).
MISE EN GARDE : CAPACITÉ DE POIDS
MAINTENANCE
Inspeccione regularmente este producto. Apriete los afianza-
dores flojos y cambie las piezas desgastadas o dañadas por
piezas InterMetro homologadas. En el caso de las unidades
móviles, inspeccione las ruedas con regularidad y reemplace
las ruedas desgastadas o dañadas inmediatamente; lubrique
las ruedas con regularidad (si llevan engrasadores).
Tool Required:
14mm or 9/16" Wrench to
Install the Casters
E
Optional
Extension
Bar (x2)

3)*+',*-
qwikSIGHTTM
PREPARING BASKET ASSEMBLY (12" and 18" Depth)
Horizontal Basket - Position 1
NOTE: Adjust square bracket to
properly seat its four flanges on wires.
RIGHT SIDE VIEW
LEFT SIDE VIEW
Square
Bracket (x4)
Lock Nut
(x4)
Wire
Basket
Right
Hanging
Plate
Left Hanging
Plate
Hole Position 1
on Both Ends
Location on Basket to
Mount Right and Left
Hanging Plates
Slanted Basket - Position 2
RIGHT SIDE VIEW LEFT SIDE VIEW
10°
10°
Slanted Basket - Position 3
RIGHT SIDE VIEW LEFT SIDE VIEW
13°13°
Location on Basket to
Mount Right and Left
Hanging Plates
Location on Basket to
Mount Right and Left
Hanging Plates
Top screw mounting
location on basket:
2nd grid from rear and
3rd grid from top.
Bottom screw mounting
location on basket (Same
for Positions 2 and 3):
2nd grid from rear and
2nd grid from bottom.
Top screw mounting
location on basket:
3rd grid from rear and
3rd grid from top.
Top screw mounting
location on basket:
2nd grid from rear and
3rd grid from top.

4 )*+',*-
qwikSIGHTTM
D
E
12" x 36" Basket
Assembly
18" x 36" Basket
Assembly
NOTE: Configurations shown in Step-E is
for reference only. Various combinations can
be attained with 12"x36" and 18"x36" basket
assemblies.
12" x 36" Basket
Assembly (x4)
CSIDE VIEW
INSTALLATION OF BASKET ASSEMBLY ON FRAME
A
1
2
3
4
5
6
7
B
Dust
Cover
Groove #6
Groove #5
Groove #1
E
NOTE: Refer to Page-5, Step-F for position 2 and 3 hole locations.

5)*+',*-
qwikSIGHTTM
INSTALLATION OF SLANTED BASKET ASSEMBLY FROM HORIZONTAL POSITION
A B C
D
1
2
3
4
5
6
7
8
9
10
F
HG SIDE VIEW
NOTE: For position 2 - locate grooves 9, 8, 4 to install 18"
baskets on frame AND - locate grooves 8, 7, 3 to install 12"
baskets on frame.
NOTE: For position 3 - locate grooves 10, 9, 5 to install 18"
baskets on frame AND - locate grooves 9, 8, 4 to install 12"
baskets on frame.
E
Position-2
CAUTION:
Empty basket before changing the position.

, )*+',*-
qwikSIGHTTM
I
12" x 36" Basket
Assembly
18" x 36" Basket
Assembly
NOTE: Configurations shown below are for reference only.
Various combinations can be attained with 12"x36" and
18"x36" basket assemblies.
DOUBLE STARTER CONFIGURATION
ADD-ON CONFIGURATION
Add-On Frame
A B
18" x 36" Basket
Assembly

7)*+',*-
qwikSIGHTTM
ACCESSORIES
12"/18" Long Divider
A
A
B
BSIDE SECTIONAL VIEW
Push on Top
Divider
C
3"/6" Long Divider
B
18" Long
Divider
ASIDE SECTIONAL VIEW

8
qwikSIGHTTM
)*+',*-
C D
3"/6" Long Label Holder (Clear)
A B
3" Long Label Holder
ASIDE VIEW B
SIDE SECTIONAL VIEW
* Save this document for future application, load rating and/or safety reference.
* Conserver ce document pour une utilisation ultérieure, pour vérifier la capacité de charge et pour consulter la référence de sécurité.
* Conserve este documento en caso de que lo necesite en aplicaciones futuras, especificaciones de carga y/o por consultas de seguridad.
