Metro DataVac TB93000 TOTE BOX Series User manual

INSTRUCTIONS FOR USE
One-Piece Undershelf Slide for
Super Erecta Shelf®Wire Shelves
INSTRUCTIONS
FOR USE
One-Piece Undershelf Slide
InterMetro Industries Corporation
North Washington Street, Wilkes-Barre, PA USA 18705
For Product Information Call: 1-800-992-1776
Visit Our Web Site: www.metro.com
NOTE: This instruction sheet covers the following models
For TB93000 SERIES TOTE BOX
BSD2218NA
BSD2221NA
BSD2224NA

2
FRONT
REAR
Undershelf
Slide
A
Slide
Bracket (x4)
NOTE: Do Not Tighten the Screws (x4) and
Slide Brackets (x4). Keep Loose to Install on
Wire Shelves.
L01-075 Rev.A
04/15


* Save this document for future application, load rating and/or safety reference.
InterMetro Industries Corporation
North Washington Street, Wilkes-Barre, PA USA 18705
For Product Information Call: 1-800-992-1776
Visit Our Web Site: www.metro.com
One·Piece Undershelf Slide for
Super Erecta Shelf®Wire Shelves
Flat Washer
(x4)
External Star
Lock Washer (x4)
Screw (x4)
BSES Shelf
SIDE VIEW
Undershelf
Slide
C
DNOTE: Tighten the Screws (x4) Completely
E
Tote Box
