Metrohm OMNIS Titrator User manual

OMNIS Titrator
2.1001.0X20
Product manual
8.1001.8002EN / 2020-11-13

Metrohm AG
Ionenstrasse
CH-9100 Herisau
Switzerland
Phone [phone]
Fax [phone]
[email protected]
www.metrohm.com
OMNIS Titrator
2.1001.0X20
Product manual
8.1001.8002EN /
2020-11-13

Technical Communication
Metrohm AG
CH-9100 Herisau
[email protected]
This documentation is protected by copyright. All rights reserved.
This documentation has been prepared with great care. However, errors
can never be entirely ruled out. Please send comments regarding possible
errors to the address above.

￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭ Table of contents
OMNIS Titrator
￭￭￭￭￭￭￭￭ III
Table of contents
1 Overview 1
1.1 OMNIS Titrator – Product description ................................ 1
1.2 OMNIS Titrator – Product versions ..................................... 1
1.3 About the documentation ................................................... 2
1.4 Additional information ......................................................... 3
1.4.1 Accessories .............................................................................. 3
2 Safety 4
2.1 Product safety ....................................................................... 4
2.2 Hazard levels ......................................................................... 4
2.3 Warning symbols .................................................................. 5
2.4 Intended use ......................................................................... 6
2.5 Residual risks ........................................................................ 6
2.5.1 General dangers at the workplace ........................................... 6
2.5.2 Danger from electrical potential ............................................... 7
2.5.3 Danger from biological substances .......................................... 8
2.5.4 Danger from highly flammable substances ............................... 8
2.5.5 Danger from careless transport ................................................ 9
2.5.6 Danger from leakage ............................................................... 9
2.6 Responsibility of the operator ............................................. 9
2.7 Personnel requirement ....................................................... 10
3 Functional description 11
3.1 OMNIS Titrator – Single-workplace titration system –
Overview ............................................................................. 11
3.2 OMNIS Titrator – Single-workplace KF titration system
volumetric – Overview ....................................................... 13
3.2.1 System – Signals .................................................................... 14
3.2.2 System – Interfaces ................................................................ 14
3.3 OMNIS Titrator – Overview ............................................... 15
3.3.1 Magnetic stirrer – Overview ................................................... 17
3.3.2 Magnetic stirrer with accessories – Overview ......................... 18
3.3.3 Dosing unit – Overview .......................................................... 19
3.3.4 Bottle unit – Overview ........................................................... 23
3.3.5 Measuring Module Analog – Overview .................................. 26
3.3.6 Measuring Module Digital – Overview ................................... 27
3.3.7 OMNIS product with a volumetric KF titration cell – Over-
view ...................................................................................... 28

Table of contents ￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
IV ￭￭￭￭￭￭￭￭
OMNIS Titrator
3.4 OMNIS Titrator – Function ................................................. 29
3.4.1 Magnetic stirrer – Function .................................................... 29
3.4.2 Dosing unit – Function ........................................................... 29
3.4.3 Bottle unit – Function ............................................................ 30
3.4.4 Measuring Module Analog – Functional description ............... 31
3.4.5 Measuring Module Digital – Functional description ................ 31
3.4.6 Volumetric Karl Fischer titration cell – Function ...................... 31
3.4.7 Magnetic stirrer – Indicators and controls .............................. 32
3.5 OMNIS main instrument – Indicators and controls ......... 33
3.6 Magnetic stirrer – Indicators and controls ....................... 34
3.7 OMNIS Titrator – Interfaces ............................................... 36
3.8 Measuring Module Analog – Interfaces ........................... 37
3.9 Measuring Module Digital – Interfaces ............................ 38
4 Transport and storage 39
4.1 Checking the delivery ......................................................... 39
4.2 Storing the packaging ........................................................ 39
5 Installation 40
5.1 Installation by Metrohm .................................................... 40
5.2 Setting up the product ....................................................... 40
5.3 Attaching the cylinder unit OMNIS ................................... 41
5.4 Magnetic stirrer – Installing the accessories .................... 43
5.5 OMNIS Karl Fischer products – Replacing the adsorber
material ............................................................................... 46
5.6 OMNIS system – Mounting the measuring module ......... 48
5.7 Measuring module – Plugging in the electrode cable ..... 51
5.8 OMNIS Titrator – Mounting the volumetric Karl Fischer
titration cell ......................................................................... 52
5.9 OMNIS system – Mounting the electrode ........................ 63
5.10 OMNIS system – Mounting the electrode parking sta-
tion ....................................................................................... 66
5.11 OMNIS titration system – Mounting the bottle unit ....... 68
5.12 Connecting/Disconnecting the power cord ...................... 69
6 Start-up 71
6.1 Initial start-up by Metrohm ............................................... 71
7 Operation and control 72
7.1 Operation ............................................................................ 72

￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭ Table of contents
OMNIS Titrator
￭￭￭￭￭￭￭￭ V
7.2 Switching the OMNIS main instrument on and off ......... 72
7.3 Refitting the cylinder unit OMNIS ..................................... 73
7.3.1 Removing the cylinder unit OMNIS ........................................ 73
7.3.2 Attaching the cylinder unit OMNIS ......................................... 75
7.4 Magnetic stirrer – Operation ............................................. 78
7.4.1 Switching the stirrer on and off .............................................. 78
7.4.2 Setting the stirring rate .......................................................... 79
8 Maintenance 80
8.1 General maintenance ......................................................... 80
8.2 Maintenance agreement .................................................... 81
8.3 Cleaning the product .......................................................... 82
8.3.1 Cleaning the OMNIS Liquid Adapter ...................................... 83
8.4 Checking and replacing product parts .............................. 85
9 Malfunctions and troubleshooting 87
9.1 Troubleshooting .................................................................. 87
10 Disposal 88
11 Technical specifications 89
11.1 Ambient conditions ............................................................ 89
11.2 OMNIS Titrator – Energy supply ........................................ 89
11.3 OMNIS Magnetic Stirrer – Energy supply ......................... 89
11.4 OMNIS Measuring Module – Energy supply ..................... 90
11.5 OMNIS Titrator – Dimensions ............................................ 90
11.6 OMNIS Measuring Module – Dimensions ......................... 90
11.7 OMNIS Magnetic Stirrer – Dimensions ............................. 91
11.8 OMNIS Titrator – Housing ................................................. 91
11.9 OMNIS Measuring Module – Housing .............................. 91
11.10 OMNIS Magnetic Stirrer – Housing ................................... 92
11.11 OMNIS Titrator – Connectors specifications .................... 92
11.12 OMNIS Measuring Module Analog – Connectors specifi-
cations ................................................................................. 93
11.13 OMNIS Measuring Module Digital – Connectors specifi-
cations ................................................................................. 94
11.14 OMNIS Titrator – Display specifications ........................... 94
11.15 OMNIS Measuring Module Digital – Display specifica-
tions ..................................................................................... 94

Table of contents ￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
VI ￭￭￭￭￭￭￭￭
OMNIS Titrator
11.16 OMNIS Measuring Module Analog – Measuring specifi-
cations ................................................................................. 95
11.17 OMNIS Titrator – Liquid Handling specifications ............ 96
11.18 Magnetic stirrer – Stirrer specifications ............................ 96

￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭ Overview
￭￭￭￭￭￭￭￭ 1
1 Overview
1.1 OMNIS Titrator – Product description
The OMNIS Titrator is the central instrument of an OMNIS titration system.
It contains the logic necessary for controlling the titration system. The
OMNIS Titrator is connected to the Ethernet network and to the power
grid. It assumes responsibility for the energy supply to all of the modules
in the titration system and for communications between the titration sys-
tem and the OMNIS Software. All of the other modules of the titration
system are connected with the OMNIS Titrator.
The OMNIS Titrator with magnetic stirrer can also be used as a stand-
alone instrument with manual sample change.
The OMNIS Titrator can be operated with the OMNIS Software if it is con-
nected to the Ethernet network.
The scope of the functions of the OMNIS Titrator is defined in the selected
function license.
1.2 OMNIS Titrator – Product versions
The product is available in the following versions:
Table 1 Product versions
Art. no. Designation Version feature: Magnetic
stirrer
Version feature: Function
license
2.1001.0010 OMNIS Titrator without individual
2.1001.0020 OMNIS Titrator with individual
2.1001.0110 OMNIS Basic Titrator without Basic
2.1001.0120 OMNIS Basic Titrator with Basic
2.1001.0210 OMNIS Advanced Titrator without Advanced
2.1001.0220 OMNIS Advanced Titrator with Advanced
2.1001.0310 OMNIS Professional Titrator without Professional
2.1001.0320 OMNIS Professional Titrator with Professional

About the documentation ￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
2￭￭￭￭￭￭￭￭
NOTICE
Information on the available function licenses is available on the Met-
rohm website or from the regional Metrohm representative.
The article number and serial number for identifying the product version
can be found on the type plate:
1(01) = External article number 2(21) = Serial number
3(240) = Metrohm article number
1.3 About the documentation
NOTICE
Please read through this documentation carefully before putting the
product into operation.
The documentation contains important information and warnings
that must be followed for safe operation of the product.
Symbols and conventions
The following icons and formatting may appear in this documentation:
Cross-reference to figure legend
The first number refers to the figure number, the sec-
ond to the product part in the figure.
Instruction step
Carry out these steps in the sequence shown.
Method Designations for names of parameters, menu items,
tabs and dialog windows in the software.
File ▶ New Menu or menu item

￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭ Overview
￭￭￭￭￭￭￭￭ 3
Work area /
Properties
Menu paths in order to arrive at a particular position
in the software.
[Continue] Button or key
1.4 Additional information
Additional information concerning the topic can be found:
￭in the software help
￭in the Metrohm information portal on the Internet https://
guide.metrohm.com
1.4.1 Accessories
Up-to-date information on the scope of delivery and optional accessories
for your product can be found on the Internet. You can download this
information using the article number as follows:
Downloading the accessories list
1Enter https://www.metrohm.com/ into your Internet browser.
2Enter the article number of the product (e.g. 2.1001.0010) into the
search field.
The search result is displayed.
3Click on the product.
Detailed information regarding the product is shown on various tabs.
4On the Included parts tab, click Download the PDF.
The PDF file with the accessories data is created.
NOTICE
When you receive your new product, we recommend downloading
the accessories list from the Internet, printing it out and keeping it for
reference purposes.

Product safety ￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
4￭￭￭￭￭￭￭￭
2 Safety
2.1 Product safety
This product exhibited no flaws in terms of technical safety at the time it
left the factory. To preserve this status and ensure non-hazardous opera-
tion of the product, the following instructions must be observed carefully.
2.2 Hazard levels
The following warning messages indicate the severity of the danger and
its possible effects.
DANGER
Immediate danger of life
Irreversible injuries that will result in death.
Warns of dangerous situations or unsafe actions that will most cer-
tainly cause severe injuries or death.
Lists measures to avoid hazard.
WARNING
Severe health hazards
Serious injuries that could result in death.
Warns of dangerous situations or unsafe actions that could result in
serious injuries or death.
Lists measures to avoid hazard.

￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭ Safety
￭￭￭￭￭￭￭￭ 5
CAUTION
Health hazards or severe property damage
Warns of dangerous situations or unsafe actions that could result in
moderate injuries or considerable property damage.
Lists measures to avoid hazard.
2.3 Warning symbols
Make sure that any additional hazard symbols are marked on the product
for your operation of the product.
The following warning symbols in the documentation and at hazard areas
of the product point out hazard potentials:
– Warning of a hazard area
NOTICE
Warning symbol on the product
If this warning symbol is on the product, read the respective docu-
mentation prior to installation and initial start-up.
– Warning of electric shock from electrical potential
– Warning of danger of fire and explosion from highly flammable
substances and gases
– Warning of danger of poisoning and chemical burns from chemi-
cal hazardous substances
– Warning of danger of infection and poisoning from biological
hazardous substances
– Warning of risk of injury from high temperatures

Intended use ￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
6￭￭￭￭￭￭￭￭
– Warning of cut injuries from pieces of broken glass and/or sharp
edges
– Warning of risk of injury by laser radiation
– Warning of dangerous optical radiation
2.4 Intended use
Metrohm products are used for the analysis and handling of chemicals.
Usage therefore requires the user to have basic knowledge and experience
in handling chemicals. Knowledge regarding the application of fire preven-
tion measures prescribed for laboratories is also mandatory.
Adherence to this technical documentation and compliance with the
maintenance specifications make up an important part of intended use.
Any utilization in excess of or deviating from the intended use is regarded
as misuse.
Specifications regarding the operating values and limit values of individual
products are contained in the "Technical specifications" section, if relevant.
Exceeding and/or not observing the mentioned limit values during opera-
tion puts people and components at risk. The manufacturer assumes no
liability for damage due to non-observance of these limit values.
The EU declaration of conformity loses its validity as soon as modifications
are carried out on the products and/or the components.
2.5 Residual risks
2.5.1 General dangers at the workplace
Generally, the regulations and provisions of the regulatory institutions and
authorities in the field of work apply.
The instructions regarding the following areas have to be followed when
using the products:
￭Work safety
￭Handling mechanical installations
￭Handling electricity
￭Handling hazardous and environmentally damaging substances
￭Handling hazardous and environmentally damaging liquids
￭Disposing hazardous and environmentally damaging substances
If they are not followed, this may result in:

￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭ Safety
￭￭￭￭￭￭￭￭ 7
￭Disturbing, injuring and/or killing of people
￭Malfunction and/or damage to instruments and infrastructure
￭Damage and/or contamination of the environment
WARNING
General dangers at workplace
If the safety measures are not followed, working in a laboratory bears
a high risk of injury, which can endanger life and health.
￭Only professionally trained and qualified specialist personnel may
operate the products.
￭Follow the applicable provisions concerning work safety and all
regulations on wearing protective clothing.
￭Use suitable tools to perform your work.
￭Check the fill level of waste bottles or waste canisters and analysis
vessels, and make sure they do not overflow.
￭Use protective grounding when working with highly flammable
substances and gases.
2.5.2 Danger from electrical potential
WARNING
Electric shock from electrical potential
Risk of injury by touching live components or through moisture on
live parts.
￭Never open the housing of the product.
￭Protect live parts (e.g. power supply unit, power cord, connection
sockets) against moisture.
￭If you suspect that moisture has gotten into the product, discon-
nect the product from the energy supply. Then notify Metrohm
Service.
￭Only personnel who have been issued Metrohm qualification may
perform service and repair work on electrical and electronic com-
ponents.

Residual risks ￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
8￭￭￭￭￭￭￭￭
2.5.3 Danger from biological substances
If the product is used for biological hazardous substances, it must be
marked in accordance with regulations.
In case of a return shipment to Metrohm or a Metrohm Service partner,
the product or product component has to be decontaminated and the
hazard symbol for biological hazardous substances must be removed. A
declaration of decontamination must be enclosed.
WARNING
Danger of infection and poisoning from biological hazardous
substances
Poisoning from toxins and/or infections from samples contaminated
with microorganisms.
￭Clean and disinfect contaminated surfaces.
￭Wear protective equipment.
￭Use exhaust equipment when working with vaporizing hazardous
substances.
￭Dispose of biologically contaminated substances properly.
2.5.4 Danger from highly flammable substances
WARNING
Danger of fire and explosion from highly flammable substances
and gases
Burns from fire and/or injuries from explosions.
￭Avoid ignition sources.
￭Use protective grounding.
￭Use exhaust equipment.

￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭ Safety
￭￭￭￭￭￭￭￭ 9
2.5.5 Danger from careless transport
WARNING
Risk of injury from careless transport
Injuries from spilled chemical and/or biological substances, falling
parts and pieces of broken glass.
￭Remove loose parts (e.g. sample racks, sample vessels, bottles)
before transport.
￭Remove liquids.
￭Lift and transport the instrument with both hands on the base
plate.
￭Lift and transport heavy instruments only according to instruc-
tions.
2.5.6 Danger from leakage
WARNING
Risk of injury by leakage
A risk of injury exists in connection with escaping liquids of leaking
parts and/or connection elements.
￭Replace leaking parts and connection elements without delay.
￭Tighten loose connecting elements.
￭Use environmentally-friendly methods to dispose of escaping liq-
uids.
2.6 Responsibility of the operator
￭Eliminate defects or damage which impair operating safety without
delay.
￭Eliminate malfunctions which could impair safety without delay.
￭The rules, regulations and instructions listed in the present document
are not the only valid ones. Comply with the applicable statutory rules,
government agency directives and regulations.
￭Unauthorized modification of the products excludes any and all liability
on the part of the manufacturer for any damage resulting from this as
well as for any consequential damage. No modifications, attachments
or conversions which could impair safety may be carried out on the
products without the approval of the manufacturer.

Personnel requirement ￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
10 ￭￭￭￭￭￭￭￭
￭Spare parts must meet the technical requirements established by the
manufacturer. Original spare parts always meet these requirements.
￭Personnel must be familiar with this safety-relevant information and it
must be available for consultation at all times.
2.7 Personnel requirement
Only qualified personnel may operate the present product.
Qualified personnel are people authorized by the safety responsible to
carry out the necessary operations. They are capable of recognizing and
avoiding possible dangers. These people are qualified due to their profes-
sional training, experience and/or instruction. They know the relevant
standards, laws, provisions, accident prevention regulations and the com-
pany conditions.

￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭ Functional description
￭￭￭￭￭￭￭￭ 11
3 Functional description
3.1 OMNIS Titrator – Single-workplace titration system
– Overview
Figure 1 Single-workplace titration system – Front
1FEP tubing 2Cylinder unit
3Measuring module 4Electrode cable
5Electrode 6Antidiffusion tip
7Support rod 8Electrode holder
9Clamping ring 10 Stirring bar
11 Sample beaker

OMNIS Titrator – Single-workplace titration system – Overview ￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
12 ￭￭￭￭￭￭￭￭
Figure 2 Single-workplace titration system – Rear
1OMNIS Liquid Adapter 2Bottle cap multi-use
3Chemical bottle 4Bottle holder
