MGI ZIP series User manual

User Manual
VERSION 3.0

Thank you for purchasing the Game
Changing MGI Zip X5. To get the most out of
your Zip X5 please follow these quick steps
before use.
• Register your Zip X5 online [section 1.0]
• Assembling the Zip X5 [section 3.0]
• Charge the battery [section 4.0]
For Customer Support, please contact MGI directly
for immediate and professional advice.
www.mgigolf.com
MGI AUSTRALIA
Service Email: [email protected]
Live Chat: visit www.mgigolf.com
Toll Free within Australia: 1300 644 523 (excludes mobiles)
Western Australia/ Internal phone [phone]
Local Service Centres: visit www.mgigolf.com
to locate you local service centre.
MGI USA
Service Email: [email protected]
Live Chat: visit www.mgigolf.com
Telephone: [phone]
Servicing Enquiries Telephone: [phone]
MGI GLOBAL
Sales Email: [email protected]
Service Email: [email protected]
Live Chat: visit www.mgigolf.com
NOTE: This user manual was correct at time of printing. The online
version is the most up-to-date and must be referred to as the
correct version. To download the most current user manual
please visit www.mgigolf.com. Images shown throughout this
manual may not be of the particular model you have purchased,
however the instruction they refer to is for the model in the
user manual.
Contents
MGI Zip X5 User Manual 03
1.0 Registration 04
2.0 What Is Included 04
3.0 Assembling the Zip X5 05
3.1 Attaching the Rear Wheels 05
3.2 Rear Wheel Positions 06
3.3 Unfolding 07
3.4 Folding 08
3.5 Fourth Foldable Rear Wheel 09
3.6 GPS Holder and Top Handle
Compartment 09
3.7 Inverting Rear Wheels 09
4.0 Battery Charging & Connection 10
4.1 Initial Charge 10
4.2 Connecting the Battery onto the Zip X5 10
4.3 Charging the Battery after Use 11
5.0 Fitting the Golf Bag 11
6.0 Front Wheel 12
7.0 Operating the Digital Top Box 12
7.1 Top Box Display 12
7.2 Start / Stop the Zip X5 13
7.3 Turn the Zip X5 Off 13
7.4 Battery Level Indicator 14
7.5 Unit Measurements 14
7.6 Distances Modes 14
7.7 Electronic Park Brake 14
7.8 Control Distance Function 15
7.9 Downhill Speed Control 16
7.10 Competition Mode 16
8.0 Adjusting and Aligning the Front Wheel 17
9.0 Warranty 18
9.1 Warranty Policy 18
9.2 Warranty Exclusions 18
9.3 Parts Installed During Warranty 18
10.0 Preventative Maintenance Program 19
10.1 Cleaning Your Zip X5 19
10.2 Rear Wheel Axles Maintenance 19
10.3 Upper and Lower Bag Strap 19
10.4 MGI Service Schedule 20
10.5 Service Record 21
11.0 Service and Repair Centres 22
12.0 Purchasing Parts and Accessories 22
13.0 Contacting MGI 22
14.0 Contacting Local Agent 22
15.0 Frequently Asked Questions 23

1.0 Registration
It is most important you register your MGI Zip X5 online
immediately as registration:
• Records your Zip X5 for warranty purposes
• Speeds up any servicing required on your Zip X5
• Assist us to contact you with any updates to your Zip X5
To register your Zip X5, visit www.mgigolf.com
You will need to record your MGI serial number. This is found on
the Zip X5 battery base or in the top box compartment.
Please keep this user manual on file for your own reference
and a copy of your serial number;
My MGI Zip X5 Serial Number is
[example AZX5V1173401234]
Purchased Date
/ /
You may be required to show proof of purchase so we
recommend you keep your receipt with this manual.
2.0 What’s Included
• MGI Zip X5
• 24v Lithium Battery
• Battery Charger
• GPS Holder
• MGI Pouch with:
– User Manual
– Accessory Guide
3.0 Assembling Your Zip X5
3.1 Attaching the Rear Wheels
On the wheel, press the grey release button on the wheel hub.
Place the wheel onto the axle. You will notice you need to match
up the inner female groove on the axle and the male
of the wheel. When placed in position simply release the button.
You will notice you hear a “click” when the wheel is properly
secured. To check that the wheel is properly in position pull
on the wheel. If it is properly in position it will not slide off.
Repeat for the other wheel.
MGI Zip X5 User Manual 0504

3.2 Rear Wheels Positions
The MGI Zip X5 is designed to allow the rear wheels to be in two
positions. The position is determined by where the wheel is locked
on the axle in either of the two grooves [see picture]. The drive
position is used during the normal operation of the Zip X5. The
free wheel position is used to freely push the Zip X5 should you
experience battery or Zip X5 issues on the course.
i. Drive position – Lock the wheel onto the groove closest to the
battery base. To do this, press the grey release button on the
wheel hub, push the wheel on to the axle as far as possible. To
test for drive position try rolling the wheel backwards. If you feel
resistance then the wheel is now in drive position and ready to
use. Repeat for both wheels.
ii. Free wheel – Lock the wheel into the groove closest to the
end of the axle. To do this, press the grey release button on
the wheel hub, push the wheel on to the axle and release the
release button onto the groove. To test for free wheel position try
rolling the wheel backwards. The wheel should spin freely with no
resistance. Repeat for both wheels.
3.3 Unfolding
Please see below
the steps to unfold
a Zip X5 Handle.
Step 7: Push the top bag support down to move it into position.
MGI Zip X5 User Manual 0706
Free wheel position
Drive position Step 1: Ensure both rear
wheels are attached.
Step 2: Release Fold Lever.
Step 4: The handle is now free to pull
upwards. The handle will naturally
unfold as you continue to pull until the
handle is completely open.
Step 3: Move Top Bag
Support away from front
wheel assembly until you
hear it click.
Step 6: Close the fold lever to lock
the handle into place in one
of three positions.
Step 5: Ensure that
the latch at the bottom
of the handle clicks into
place.

3.5 Fourth Foldable Rear Wheel
The MGI Zip X5 comes standard with a fourth foldable rear wheel.
This wheel MUST be unfolded into position at all times when the
Zip X5 is in use. This will reduce damaging the Zip X5, and provide
the ultimate in stability across all terrains. This fourth wheel should
be cleaned regularly with a cloth to ensure it can be folded as
required for storage.
3.6 GPS Holder and Top Handle Compartment
In the top handle compartment there is a position for a GPS/
mobile device holder. Open the compartment and connect the
holder into position. To open the holder always press the button
at the top of the holder. Place the GPS into the cradle, then close
the holder by squeezing the two sides closer together.
3.7 Inverting Rear wheels
The rear wheels can be inverted on the axle to reduce the size of
the Zip X5 when folded. To invert the rear wheels, press the grey
release button on the wheels hub and remove from the axle. Invert
the rear wheels so that the wheels hub protrudes away from the
axles. Press the grey release button on the wheels hub and release
once the wheel is fitted onto the axle.
MGI Zip X5 User Manual 0908
3.4 Folding
Step 1: Disconnect the battery by
lifting the battery handle. It can be
left on or removed from the Zip X5.
Step 2: Open the fold lever
to release the handle.
Step 3: Pull up the latch at the
bottom of the handle.
Step 4: Lower the handle down flat.
Step 6: Close the fold lever to lock
the handle into place.
Step 5: Push the
toggle down on the
top bag support and
then move the Top
Bag Support down so
that it locks over the
front wheel assembly.
Toggle
