Mi-Light fullwat LENNY-MD-092 User manual

remote control - 4 ZONES control
LENNY-MD-092
Owners manual
by
Smart LED control system
New smart LED color control system with 2.4GHz remote control.
Auto synchronisation and auto transmission functions.
The device adopts low power consumption technologies
and one controller can manage several receivers at the same time.
The system does not produce interference as it uses a very low level transmission signal.
Suitable for simple installations in both domestic and professional environments.

LENNY-MD-092 4ZONES control
Smart LED control system
by
2
Technical specifications ...................................................................................3
Single color.......................................................................................................5
Touch panel functions
Mobile control
Tunable white....................................................................................................6
Touch panel functions
Mobile control
RGB ...................................................................................................................7
Touch panel functions
Mobile control
RGBW ................................................................................................................9
Touch panel functions
Mobile control
RGBWW ...........................................................................................................11
Touch panel functions
Mobile control
Led Strip-controller connection ......................................................................13
List of LENNY-DRV-LS2 modes and functions for RGB / RGBW / RGBWW ............15
List of LENNY-DRV-WL5 modes and functions for RGB / RGBW / RGBWW...........15
System linking and unlinking ..........................................................................16
Device auto-sync............................................................................................17
Auto-transmitting function ..............................................................................17
Installation diagram .......................................................................................18
Mobile phone pairing.....................................................................................19
ALEXA linking...................................................................................................23
Google Home linking......................................................................................24
Google Assistant linking..................................................................................25
Compatibility table.........................................................................................26
Table of controls by zones ............................................................................. 27

LENNY-MD-092 4ZONES control
Smart LED control system
by
3
Technical specifications
Remote control
Model LENNY-MD-092
Voltage 3V (2 AAA batteries)*
Emitting power 6dBm
Standby current 20uA
Working temperature -20~60°C
Working frequency 2400-2483.5MHz
Modulation type GFSK
Aprox. operational distance 30m
* Not included.
DIRECT CURRENT DRIVERS
LENNY-DRV-LS2 LENNY-DRV-WL5 LENNY-DRV-WL2P
Description 5 in 1 receiver WiFi 5 in 1 receiver WiFi 2 in 1 receiver
Voltage DC12V~24V (terminal block & jack plug inputs)
Output max. current 6A per channel 12A per channel
Total current 15A 12A
Working temperatue -20~60°C -10~40°C
Working frequency 2.4GHz
Aprox. operational distance 30m
Connection mode Common anode
WIFI Requires gateway
LENNY-WIFOX1 Included
23
124
38
SwitchIndicator light
Made in PRC
INPUT
V+RGBCW
V+RGBW
V+RGB
V+CWCW
OUTPUT
WWWW
WW
V+WWWWW
Model No.: LENNY-DRV-LS2 Working Temperature: -20~60°C Input Voltage: DC12V~24V Output: 6A/Channel Total Output: Max 15A RF: 2.4GHz Control Distance: 30m
5 IN 1 Smart LED Controller
RGB+CCT Mode RGBW Mode RGB Mode
Indicating lamp
show output mode
Dual White Mode
Green Blue Red Yellow
Single Color ModeWhite
23
124
38 17
74.5
36
LENNY-DRV-LS2 LENNY-DRV-WL5 LENNY-DRV-WL2P
20
138
56

LENNY-MD-092 4ZONES control
Smart LED control system
by
4
Technical specifications
ALTERNATE CURRENT DRIVER TRIAC controller
Model LENNY-TRIAC1
Input voltage AC 100-240V 50/60Hz
Output voltage AC 100-240V
Ouput current MAX 1.36A
Output power 150W@100VAC;
300W@240VAC
Regulation method Wireless RF, push button, APP
RF range 30m
Working temperature -10-40ºC
WIFI Requires gateway
LENNY-WIFOX1
49
25 49
WIFI GATEWAY
Model LENNY-WIFOX1
Working voltage DC5V/500mA (Micro USB)
Working temperature -20~60°C
Communication WiFi-IEEE 802.11b/g/n 2.4GHz
Working frequency 2.4GHz
Transmission power 6dBm
* Suggested AC/DC adaptors (not included): MWMU10GS
FU-ADPY10-5-USB
90,5 15
66
2.4GHz Gateway Model No.: LENNY-WIFOX1
INPUT
DC5V / 500mASET
Input Voltage: DC5V/500mA (Micro USB)
Working Temperature: -20~60°C
Communication Mode: WiFi-IEEE 802.11b/g/n 2.4GHz
RF: 2.4GHz
2.4GHz RF Transmitting Power 6dBm
2.4GHz RF Control Distance: 30m
Link
SYS
Support amazon alexa and
google assistant control
Scan to Install APP
Made in PRC
by

LENNY-MD-092 4ZONES control
Smart LED control system
by
5
by
SINGLE COLOR
Remote control functions: LENNY-MD-092
To regulate LED strip, we must use “brightness regulation” bar. Use “ON” and “OFF” keys to switch LED strips on and off.
Note: We need one driver at least per each zone we want to control.
Mobile control
For control via mobile phone, Alexa, Google Home or Google Assistant, a WIFI gateway is required, either built into the
receiver or using the LENNY-WIFOX1 gateway.
ON /OFF
Brightness level regulation
Exit preload mode
and night mode
Timer Link / Unlink
Preloaded modes
Increase the speed
of the preloaded modes
Decrease the speed
of preloaded modes
Define LED type:
Single color
Tunable white
RGB
RGB+white
RGB+tunable white
Night mode: 1% brightness
WIFI RECEIVER WIFI GATEWAY
Brightness control.
Saturation control
4 zones ON..
4 zones OFF.
Selected zone ON. Also used to link and
unlink driver from this zone.
Selected zone OFF.
Pre-loaded modes.
Brightness level regulation
Master ON
Saturation
control
Zone OFF
Zone ON
Master OFF
by
Decrease speed
preloaded mode
Increase speed
preloaded mode
Zone

LENNY-MD-092 4ZONES control
Smart LED control system
by
6
by
TUNABLE WHITE
Remote control functions: LENNY-MD-092
On the remote control, use slide bar “dynamic white” to switch between different white tones.
To regulate LED strip, we must use “brightness regulation” bar. Use “ON” and “OFF” keys to switch LED strips on and off.
Note: We need one driver at least per each zone we want to control.
Mobile control
For control via mobile phone, Alexa, Google Home or Google Assistant, a WIFI gateway is required, either built into the
receiver or using the LENNY-WIFOX1 gateway.
ON /OFF
Brightness level regulation
Exit preload mode
and night mode
Link / Unlink
Programmed modes
Increase the speed
of the programmed modes
Change color temperature
if our system is ready
to support such function
Decrease the speed
of programmed modes
Define LED type:
Single color
Tunable white
RGB
RGB+white
RGB+tunable white
Night mode: 1% brightness
WIFI RECEIVER WIFI GATEWAY
Brightness control.
Color saturation level.
Dynamic white regulation.
4 zones ON.
4 zones OFF.
Zone ON: Selected zone ON. Also used to link
and unlink driver from this zone.
Zone OFF: Selected zone OFF
Programmed modes.
Tunable white
Brightness level regulation
Master ON
Color
saturation
Zone OFF
Zone ON
Master OFF
by
Decrease speed
programmed mode
Increase speed
programmed mode
Timer
Zone

LENNY-MD-092 4ZONES control
Smart LED control system
by
7
RGB
Remote control functions: LENNY-MD-092
Note: One driver per each zone is necessary unless.
Slide your finger over the coloured ring to
change colors.
Colors and White Brightness regulation.
White color offered mixing R+G+B and it is
regulated with CCT slide control.
Color saturation level.
4 zones ON at once.
4 zones OFF at once.
Dynamic programmed modes.
Under dynamic mode running, you can get light
running faster with this switch.
Under dynamic mode running, you can get slow
speed with this switch.
Selected zone ON. Also it is used to link and unlink
every drive from this zone.
Selected zone OFF.
by
Zone OFF
Brightness level regulation
Programmed modes
Zone ON
Master ON
Color ring
Color
saturation
Speed +
Speed –
Master OFF
White color
Working mode:
• Select color: Touch color wheel on desired color (e.g.blue).
• “Color saturation” bar: Adjust color saturation (0% chosen color, 100% very saturated color).
• Brightness level: Adjust brightness level.
• White: With any color selected from color wheel, click on “white colour bar” to set full white with R+G+B mixing.
– If we slide on the bar, we will get a “dynamic white” tone mixing R+G+B (from the left is warmer and to the right is
cooler).
– Brightness bar: allows you “white level” brightness regulation.

LENNY-MD-092 4ZONES control
Smart LED control system
by
8
RGB
Control con móvil
For control via mobile phone, Alexa, Google Home or Google Assistant, a WIFI gateway is required, either built into the
receiver or using the LENNY-WIFOX1 gateway.
Working mode
• Select color: Touch color wheel on desired color (e.g. blue).
• Saturation: Adjust color saturation (0% chosen color, 100% very saturated color).
• Brightness level: Adjust brightness level.
• White color: Bring out white color using R+G+B mixing combination (If maximum level is required, set saturation bar at
highest level).
• Tunable white: System allows to simulate dynamic white levels using RGB leds.
Color ring
White with RGB
ON / OFF
Saturation
Tunable white
Timer
Modes
0%
0%
100%
100%
Increase the speedDecrease the speed
Brightness level regulation
Define LED type:
Single color
Tunable white
RGB
RGB+white
RGB+tunable white

LENNY-MD-092 4ZONES control
Smart LED control system
by
9
RGBW
Remote control functions: LENNY-MD-088
by
Note: One driver is necessary per every zone.
Slide your finger over the coloured ring to
change colors.
Color brightness level and white changing.
Turns on white channel (from 4th channel) at
full brightness. To regulate white, slide bar for
“white channel regulation” must be used. It
is not possible to achieve white with R+G+B
combination.
Increasing or decreasing white brightness
channel only (from 4th channel). If there is a
previously selected RGB colour, adds white to
the RGB colour.
4 zones ON.
4 zones OFF.
Dinamic modes.
Under dynamic mode running, you can get light
running faster with this switch.
Under dynamic mode running, you can get slow
speed with this switch.
Selected zone ON. Also used to link and unlink
driver from this zone.
Selected zone OFF.
Brightness regulation
Pre-loaded modes
Zone ON
Master ON
Color ring
White color
regulation
Speed +
Zone OFF
Speed –
Master OFF
ON of the white color
Working mode
• Select color: Touch color wheel on desired color (e.g.blue).
• Brightness bar: Adjust brightness level.
• Activate only white: Click on the bar “ON white colour”. It will be activated at 100%. To regulate brightness we will use
slide bar “brightness regulation”.
• Activate Colour + White: Choose colour with slide colour wheel and adjust white with slide saturation bar (0%
-downwards - white channel off, 100% - upwards - white channel on at maximum).
• Colour + White and colour removing: Press slide bar “ON white colour”.
• Colour + white and white removing: slide bar “white channel regulation” up to 0% (downwards).

LENNY-MD-092 4ZONES control
Smart LED control system
by
10
RGBW
Mobile control
For control via mobile phone, Alexa, Google Home or Google Assistant, a WIFI gateway is required, either built into the
receiver or using the LENNY-WIFOX1 gateway.
Color ring
White
ON / OFF
Saturation
Timer
Modes
0%
0%
100%
100%
Increase the speedDecrease the speed
Brightness
Define LED type:
Single color
Tunable white
RGB
RGB+white
RGB+tunable white
Working mode
• Select color: Touch color wheel on desired color (e.g. blue).
• “Saturation” bar: Adjust color saturation (0% chosen color, 100% very saturated color).
• Brightness level: Adjust brightness level.
• White light: Only white channel activation set.
– The “Brightness slide bar” is used to set desired brightness level.
• Color + White activation: Choose color with “color slide wheel” and set white level with saturation bar (0% white
channel off, 100% white channel set at max level).
• Color + tunable white and turn off white: We lower the saturation to 0%.
• Remove Color + white and Color levels: Press “White light”.

LENNY-MD-092 4ZONES control
Smart LED control system
by
11
RGBWW
Remote control functions: LENNY-MD-092
by
Slide your finger over the coloured ring to
change colors.
Color and white brightness control.
Dynamic white regulation.
Only white channel increasing or decreasing
previously defined with slide “white dynamic”
bar. If there is a previous selected color, you can
add white to RGB color level.
4 zones ON.
4 zones OFF.
Dynamic modes.
Under dynamic mode running, you can get light
running faster with this switch.
Under dynamic mode running, you can get slow
speed with this switch.
Selected zone ON. Also used to link and unlink
driver from this zone.
Selected zone OFF.
Brightness level regulation
Preloaded modes
Zone ON
Master ON
Color ring
Saturation
Speed +
Zone OFF
Speed –
Master OFF
Dynamic white
Note: We need one driver at least per each zone we
want to control.
Working mode
• Select color: Touch color wheel on desired color (e.g. blue).
• Brightness level: Adjust brightness level.
• Dynamic White Control: Use “Dynamic White” slide bar to achieve desired tone.
• Colour + White activation: Allows you to choose “white” tone, read “dynamic white control”. Once we have chosen
desired white tone, we choose colour using the colour slide wheel.
– Colour + Dynamic white and white removing: Use slide “colour saturation”bar. Upwards is 100% (selected white tone
will be turned on to the maximum) and downwards is 0% (white will be turned off and only selected colour will remain).
– Colour + Dynamic white and colour removing: Use slide “dynamic white” bar to choose desired white tone (when
pressed, it will be set to 100%).

LENNY-MD-092 4ZONES control
Smart LED control system
by
12
RGBWW
Mobile control
For control via mobile phone, Alexa, Google Home or Google Assistant, a WIFI gateway is required, either built into the
receiver or using the LENNY-WIFOX1 gateway.
Working mode
• Select color: Touch color wheel on desired color (e.g.blue)
• Brightness level: Adjust brightness level.
• Tunable white: Slide your finger over “tunable white bar” to get desired white tone.
– Note: If there is a previous selected level from color slide wheel, it will switch off.
• Color + Dynamic White: Choose desired color with slide wheel and adjust white tone desired with saturation bar
(0% white channel off, 100% white channel at highest level).
– Note: If dynamic white color is desired, please firstly set dynamic white mode.
• Color + dynamic white and turn white off: Set saturation bar at lowest level 0%.
• Color + dynamic white and color off: Select dynamic white tone with “Kelvin grade” bar and color will be switched off.
Color ring
White
ON/ OFF
Saturation
Tunable white
Timer
Modes
0%
0%
100%
100%
Increase the speedDecrease the speed
Brightness
Define LED type:
Single color
Tunable white
RGB
RGB+white
RGB+tunable white

LENNY-MD-092 4ZONES control
Smart LED control system
by
13
5 in 1 driver LENNY-DRV-LS2 / LENNY-DRV-WL5
“Switch” button can be used to indicate which type of product is being managed. To do so, press the “Switch” or “SET”
button with a short touch until color from “indicator light” is required one.
Single color Tunable white RGB RGBW RGBWW
Indicator light
Led Strip-controller connection
Connection drawing
Valid for models:
FU-BLF-2835-2165-(W)X
Valid for models:
CCTX-3535-RGB-XX FU-BLF-020L-RGB-XX
CCTX-5060-RGB-XX FU-BLF-2835-RGB-XX
DOMOX-5060-RGB-XX
12V 12V
G G
R R
B B
12V
G
R
B
AC DC12V/24V
AC TO DC
+
SwitchIndicator light
Made in PRC
INPUT
V+RGBCW V+RGBW V+RGB V+CWCW
OUTPUT
WWWW
WW
V+WWWWW
Model No.: LENNY-DRV-LS2
Working Temperature: -20~60°C
Input Voltage: DC12V~24V
Output: 6A/Channel
Total Output: Max 15A
RF: 2.4GHz
Control Distance: 30m
5 IN 1 Smart LED Controller
RGB+CCT Mode
RGBW Mode
RGB Mode
Indicating lamp
show output mode
Dual White Mode
Green
Blue
Red
Yellow
Single Color ModeWhite
Valid for model:
CVIC-5060-RGBX-ESP(W)X
X: Ámbar, 3000 / 4000 / 6000k
AC
AC TO DC
+
SwitchIndicator light
Made in PRC
INPUT
V+RGBCW V+RGBW V+RGB V+CWCW
OUTPUT
WWWW
WW
V+WWWWW
Model No.: LENNY-DRV-LS2
Working Temperature: -20~60°C
Input Voltage: DC12V~24V
Output: 6A/Channel
Total Output: Max 15A
RF: 2.4GHz
Control Distance: 30m
5 IN 1 Smart LED Controller
RGB+CCT Mode
RGBW Mode
RGB Mode
Indicating lamp
show output mode
Dual White Mode
Green
Blue
Red
Yellow
Single Color ModeWhite
12V
R
G
B
W
DC24V
Valid for model:
CVIC-5060-RGBFC-ESP(W)X
AC
AC TO DC
+
SwitchIndicator light
Made in PRC
INPUT
V+RGBCW V+RGBW V+RGB V+CWCW
OUTPUT
WWWW
WW
V+WWWWW
Model No.: LENNY-DRV-LS2
Working Temperature: -20~60°C
Input Voltage: DC12V~24V
Output: 6A/Channel
Total Output: Max 15A
RF: 2.4GHz
Control Distance: 30m
5 IN 1 Smart LED Controller
RGB+CCT Mode
RGBW Mode
RGB Mode
Indicating lamp
show output mode
Dual White Mode
Green
Blue
Red
Yellow
Single Color ModeWhite
12V 12V
G G
R R
B
WW
W
B
W
WW
DC24V
Valid for models:
DOMOX-2835-XX FU-BLF-XX CCTX-2835-XX
XX: 2100 / 2300 / 2700 / 3000 /40000 / 6000K
AC DC12V/24V
AC TO DC
+
SwitchIndicator light
Made in PRC
INPUT
V+RGBCW V+RGBW V+RGB V+CWCW
OUTPUT
WWWW
WW
V+WWWWW
Model No.: LENNY-DRV-LS2
Working Temperature: -20~60°C
Input Voltage: DC12V~24V
Output: 6A/Channel
Total Output: Max 15A
RF: 2.4GHz
Control Distance: 30m
5 IN 1 Smart LED Controller
RGB+CCT Mode
RGBW Mode
RGB Mode
Indicating lamp
show output mode
Dual White Mode
Green
Blue
Red
Yellow
Single Color ModeWhite
SINGLE COLOR
AC
AC TO DC
+
SwitchIndicator light
Made in PRC
INPUT
V+RGBCW V+RGBW V+RGB V+CWCW
OUTPUT
WWWW
WW
V+WWWWW
Model No.: LENNY-DRV-LS2
Working Temperature: -20~60°C
Input Voltage: DC12V~24V
Output: 6A/Channel
Total Output: Max 15A
RF: 2.4GHz
Control Distance: 30m
5 IN 1 Smart LED Controller
RGB+CCT Mode
RGBW Mode
RGB Mode
Indicating lamp
show output mode
Dual White Mode
Green
Blue
Red
Yellow
Single Color ModeWhite
24V
W
WW
DC24V TUNABLE WHITE
RGB
RGBW
RGBWW

LENNY-MD-092 4ZONES control
Smart LED control system
by
14
2 in 1 driver LENNY-DRV-WL2P
Valid for models:
DOMOX-2835-XX FU-BLF-XX CCTX-2835-XX
XX: 2100 / 2300 / 2700 / 3000 /40000 / 6000K
Valid for models:
FU-BLF-2835-2165-(W)X
Push button TOUCH
Short press: ON/OFF.
Long press: Brightness variation.
Push button TOUCH
Short press: ON/OFF.
Long press: Brightness variation.
AC
AC
DC12V/24V
DC12V/24V
AC TO D
AC TO D
C
C
+
+
Press “SET” continuously to switch between single color and tunable white mode.
Led Strip-controller connection
Connection drawing
SINGLE COLOR
TUNABLE WHITE
Functioning
Short press: Switches the connected device ON/OFF.
Long press (press and hold): increases or decreases the intensity of the light.
Connection
The maximum number of TRIACs is 25 pieces and maximum wiring distance from the push button is 20m.
To control everything with a single push button, LENNY-TRIACs must be connected in cascade according to the
connection diagram.
LENNY-TRIAC1 Push button control
Input: AC100~240V
L
N
NC NLL1
NL
INPUT
OUTPUT
Input: AC100~240V
L
N
NC NLL1
NL
INPUT
OUTPUT
Input: AC100~240V
L
N
NC NLL1
NL
INPUT
OUTPUT
Push button
Input: AC100~240V
L
N
NC NLL1
NL
INPUT
OUTPUT
Triac dimmable LED lighting.
Traditional filament lamp.
Halogen lamp
or AC led strip (ACCX series)
Triac dimmable LED lighting.
Traditional filament lamp.
Halogen lamp
or AC led strip (ACCX series)
Triac dimmable LED lighting.
Traditional filament lamp.
Halogen lamp
or AC led strip (ACCX series)
Triac dimmable LED lighting.
Traditional filament lamp.
Halogen lamp
or AC led strip (ACCX series)

LENNY-MD-092 4ZONES control
Smart LED control system
by
15
List of LENNY-DRV-LS2 modes and functions for RGB / RGBW / RGBWW
Number Dynamic mode Brightness / Saturation / Speed
1Mardi Gras
Adjustable
2Automatic colors changing
3Sam
4Gemma
5Twlight
6American
7Super super Tuesday
8Party
9Splash colors
List of LENNY-DRV-WL5 modes and functions for RGB / RGBW / RGBWW
Icon Dynamic mode Icon Dynamic mode Brightness / Saturation / Speed
Rainbow Starlit night
Adjustable
Swam dancing Food
Carnival Working
Musical show Relaxing
Disco Reading
First love Sunset
Green forest Good night
Trippingly dancing Night light

LENNY-MD-092 4ZONES control
Smart LED control system
by
16
System linking and unlinking
Note: The light only works after the controller is paired with one or more receivers.
Linking. Place Remote controller close to the desired driver to be paired.
Before starting linking process, configure receiver according to the type of LED strip. Refer to “wiring diagram” section
(previous point) from the manual.
Unlinking
If light does not flash quickly,
the bonding is not done.
Repeat the process until this occurs.
1.Switch off power supply and
after 10 seconds, switch it on
again.
Note: For LENNY-DRV-WL2P or
LENNY-TRIAC1, press the SET
button once to enter pairing
mode.
2.Press ON button on the
remote control 5 times within
a maximum period of 3 sec.
3.The light will flash 10 times
quickly to indicate that unlinking
is successful.
B
+
G
R
power supply
receiver
B
+
G
R
receiver
power supply
If light does not flash slowly,
the bonding is not done.
Repeat the process until this occurs.
1.Switch off power supply and
after 10 seconds, switch it on
again.
Note: For LENNY-DRV-WL2P or
LENNY-TRIAC1, press the SET
button once to enter pairing
mode.
2.Press ON button on the
remote control 3 times within
a maximum period of 3 sec.
3.The light will flash 3 times
slowly to indicate successful
pairing.
B
+
G
R
receiver
B
+
G
R
receiver
power supply power supply
Attention
1. Please check if input voltage is compatible with voltage supported by the driver. Pay special attention not to cross
positive and negative poles.
Reversed connection will damage the controller.
2. Do not connect the cables while the power supply is on. Turn it on when you are sure of connections are correct and
there is no short circuit is possible.
3. Avoid placing driver controller in areas influenced by electromagnetic fields or close to devices that produce
electromagnetic fields. Also, do not place driver controller in areas shielded by metal surfaces or where metal
surfaces come between the control and the controller.
This would affect operating distance effectiveness.
by
by
link/unliknk
button
link/unliknk
button

LENNY-MD-092 4ZONES control
Smart LED control system
by
17
Device auto-sync
Different receiver drivers can be connected to operate with the same remote controller and operate in the same
modes.
Notes:
1. : Self emitting indication.
2. Remote driver controllers can be paired
with the same remote controller within a
maximum range of 30 meters.
(possible where as free or semi-free
spaces and without too many obstacles
or walls).
Auto-transmitting function
A single remote controller may transmit control signals in succession to other driver controllers provided if maximum
coverage distance of 30m is respected between them.
Receiver
Auto-transmitting Auto-transmittingAuto-transmitting Auto-transmitting
ReceiverReceiver Receiver Receiver
Receiver
Receiver
ReceiverReceiver
ReceiverReceiver
by
by

LENNY-MD-092 4ZONES control
Smart LED control system
by
18
Installation diagram - LENNY-TRIAC1
Push button

LENNY-MD-092 4ZONES control
Smart LED control system
by
19
Mobile phone pairing
Download and install the application on your mobile phone:
a. Via QRl code
b. Searching the Play Store for “MiBoxer”.
To link our installation with our mobile phone, we will need one of these drivers:
– LENNY-DRV-WL5
– LENNY-DRV-WL2P
– LENNY-DRV-LS2 + LENNY-WIFOX1
– LENNY-TRIAC1 + LENNY-WIFOX1
Register in MiBoxer:
We will receive an e-mail with a registration verification code, which we will have to enter in the application to finish
registering account.
In order to use the application, we must activate GPS on our mobile phone (either Android or Apple).
Once on the main screen and our session started, we must add the device. To do this:
Insert your email
adress
Insert your country Choose password Accept conditions
and terms
Push “+” to
add device
Push
“add sharing”.
Note:
Also compatible with the
application: SMART LIFE

LENNY-MD-092 4ZONES control
Smart LED control system
by
20
Mobile phone pairing
Select device model:
For model LENNY-DRV-WL5:
Click on “Smart Strip Controller (WL5)”.
For model LENNY-DRV-WL2P:
Click on “LED controller (FUT035W-FUT039W)”.
For model LENNY-DRV-LS2 or model LENNY-TRIAC1:
Click on “2.4GHz Gateway (WL-Box1)”.
For model LENNY-DRV-WL5:
Disconnect power supply from LENNY-DRV-WL5 for 10 sec.
After 10 seconds, power the controller and within the first three seconds, press and
hold “SET” button on the receiver until LED on the receiver flashes.
For models LENNY-DRV-WL2P / LENNY-DRV-LS2 / LENNY-TRIAC1:
Press SET button on device or on WIFI gateway for 3 seconds to activate WIFI signal.
In both cases, on the phone screen, click on “Ensure pilot lamp blinking”.
Enter network name and
password.
Attention: only 2.4GHz network is
supported (no 5G) and click on
“Start configuration”.
A countdown will appear and once paired, it will
indicate that pairing has been successful.
Our device will appear in the list of paired devices.
