Microlife IR 1DE1 User manual

Microlife IR 1DE1
1 sec. Measurement (Scan-Peak-method)
Mesure en 1 sec. / Medición en 1 seg. / 1 Sek. Messung /
Medição em 1 seg.
Multiple Use (Wide Range 0 °C - 100 °C)
• Body temperature / Température du corps / Temperatura
corporal / Körpertemperatur / Temperatura corporal
• Milk surface temperature / Température de surface du lait /
Temperatura superficial de la leche / Milch-Oberflächen-
temperatur / Temperatura da superficie do leite
• Surface temperature of Baby’s bath / Température de sur-
face du bain de bébé / Temperatura superficial del agua
del baño del bebé / Badewasser-Oberflächentemperatur /
Temperatura superficial del agua del baño
• Ambient temperature / Température ambiante / Tempera-
tura ambiente / Raumtemperatur / Temperatura ambiente
Fever alarm / Silent GlowTM Technology
Alarme de fièvre / Silent GlowTM technologie
Señal de alarma en caso de fiebre / Tecnología Silent GlowTM
Fieberalarm / Silent GlowTM Technologie
Alarme de febre / Tecnologia Silent GlowTM
Illuminated Display
Ecran rétro-éclairé / Pantalla con iluminación / Beleuchtetes
Display / Visor iluminado
12 Memories
12Mémoires / 12Memorias / 12Speicherplätze / 12Memórias
Signal Tone
Signal sonore / Señal acústica / Signalton / Sinal sonor
Probe Cover Free
Sans embout / Sin funda protectora / Schutzhüllenfreies / Sem
cobertura protectora do sensor
Celsius - Fahrenheit switchable
Microlife AG
Espenstrasse 139
9443 Widnau / Switzerland
Tel. +41 / 71 727 70 30
Fax +41 / 71 727 70 39
Email [email protected]
www.microlife.com
1 sec.
IB IR IDE1-1S VarA5 1008

Microlife IR 1DE1
Probe Cover Free Ear Thermometer
Instruction Manual (1-12)
Thermomètre auriculaire sans embout
Mode d’emploi (13-24)
Termómetro de oído sin funda protectora
Manual de Instrucciones (25-38)
Schutzhüllenfreies Ohrthermometer
Gebrauchsanleitung (39-50)
Termómetro de ouvido sem
cobertura protectora do sensor
Manual de Instruções (51-62)
EN
FR
ES
DE
PT

Probe Cover Free Ear Thermometer
Instruction Manual
Please read these instructions carefully before using the
instrument and keep them in a safe place.
The Microlife Probe Cover Free Ear Thermometer IR 1DE1 is a high
quality product incorporating the latest technology and tested in
accordance with international standards. With its unique technology,
the IR 1DE1 can provide a stable, heat-interference-free reading with
each measurement. The instrument performs a self-test every time it
is switched on to always guarantee the specified accuracy of measu-
rements.
The Microlife Probe Cover Free Ear Thermometer IR 1DE1 is intended
for the periodic measurement and monitoring of human body tempe-
rature in the home. It is intended for use on people of all ages.
Batteries and electronic instruments must be disposed of in
accordance with the locally applicable regulations, not with
domestic waste.
1

Table of Contents
1. The Advantages of this Thermometer
2. Important Safety Instructions
3. Product Description
4. How this Thermometer Measures Ear Temperature
5. Control Displays and Symbols
6. Directions for Use
7. Changing from Fahrenheit to Celsius and vice-versa
8. How to recall 12 readings in Memory Mode
9. Error Messages
10. Cleaning and Storage
11. Replacing the Battery
12. Guarantee
13. Technical Specifications
14. www.microlife.com
2

3
1. The Advantages of this Thermometer
Multiple Use (Wide Range Measurement)
The IR 1DE1 offers a wide measurement range feature from 0 - 100.0 °C
(32.0 - 212.0 °F); meaning the unit can be used as an ear thermometer to
measure body temperature, but it can also be used to measure surface
temperature of following objects:
• Milk surface temperature in baby's bottle.
• Surface temperature of baby's bath.
• Ambient temperature.
Probe Cover Free
Since a probe cover is not required with this thermometer it makes
using the IR 1DE1 more user-friendly and more cost-effective.
Measurement in 1 second
The innovative infrared technology allows measurement of ear
temperature in only 1 second.
Accurate and reliable
The unique probe assembly construction, incorporating an advanced
infrared sensor ensure that each measurement is accurate and reliable.
Gentle and Easy to Use
• The ergonomic design enables simple and easy use of the ther-
mometer.
• This thermometer can be used even on a sleeping child, thereby
causing no interruption.
• This thermometer is fast and therefore pleasant to use for children.
Auto-Display Memory
The last reading is automatically displayed for 2 seconds when the
unit is switched ON.
Multiple Reading Recalls
Users will be able to recall the last 12 readings when entering the
recall mode, enabling efficient tracking of temperature variations.
Safe and Hygienic
• No risk of broken glass or mercury ingestion.
• Completely safe for use on children.
• Cleaning of the probe tip can be done with an alcohol-moistened
cotton tissue, making the IR 1DE1 completely hygienic for use by
the whole family.

High Temperature Indication
10 short beeps and a red LCD backlight alert the patient that he/she
may have a temperature above 37.5 °C.
2. Important Safety Instructions
• Never use the thermometer for purposes other than those it has
been intened for. Please follow the general safety precautions
when using on children.
•Never immerse this thermometer into water or other
liquids (not waterproof). For cleaning please follow the
instructions in the «Cleaning and Storage» section.
• Keep the instrument away from direct exposure to the sun and
keep it in a dust-free, dry area at a temperature between
5 - 40 °C (41 - 104 °F).
• Do not use the thermometer if there are signs of damage to the
measuring tip or to the instrument itself. If damaged, do not
attempt to repair the instrument! Please contact your nearest
Microlife customer service department.
• Earwax in the ear canal may cause a lower temperature reading.
Therefore it is important to ensure the subject's ear canal is clean.
• This thermometer consists of high-quality precision parts. Do not
drop the instrument! Protect it from severe impact and shock. Do
not twist the instrument and the measuring probe!
WARNING:
•Use of this thermometer is not intended as a substitute for
consultation with your physician.
•Thermometer is not waterproof! Please NEVER immerse
into liquids without a probe cover.
3. Product Description
(1) Probe
(2) START button
(3) LCD Display
(4) O/I button
(5) Battery Cover
4
(2)
(3)
(4)
(5)
(1)

5
4. How this Thermometer Measures Ear Temperature
This thermometer measures infrared energy radiated from the eardrum
and the surrounding tissue. This energy is collected through the lens
and converted to a temperature value. The measured reading obtained
directly from the eardrum (Tympanic Membrane) can ensure the most
accurate ear temperature.
Measurements taken from the surrounding tissue of the ear canal
generate lower readings and may result in misdiagnosis of a fever.
To avoid an inaccurate measurement:
• Switch on the thermometer by pressing the O/I button.
• After one beep is heard (and the temperature scale icon is flas-
hing), straighten the ear canal by gently pulling the middle of the
ear back and up.
• Place the probe firmly into the ear canal, press the START button
and keep the probe in the ear until the thermometer beeps to
identify the completion of the measurement.
This thermometer has been clinically tested and proven to be
safe and accurate when used in accordance with its operating
instruction manual.

6
5. Control Displays and Symbols
LCD Display Display
Meaning
All segments
displayed
Memory
Ready
Measurement
complete
Out-of-ear
temperature
indication
Low battery
indication
Description
Press the O/I button to
turn on the unit, all seg-
ments will be shown
for 2 seconds.
The last reading will be
shown on the display
automatically for
2 seconds.
The unit is ready for
measurement, the °C or
°F icon will keep
flashing.
The reading will be shown
on the LCD display with
the °C or °F icon flashing,
the unit is ready again for
the next measurement.
A crossed-ear-icon
shown on the LCD if the
reading falls outside the
range 32.0 ~ 42.2 °C
(89.6 ~ 108.0 °F)
When the unit is turned
on, the battery icon will
keep flashing to remind
the user to replace the
battery.

7
6. Directions for Use
1. Press the O/I button. The LCD is activated
to show all segments for 2 seconds.
2. The last measurement reading will be
shown on the display automatically for
2 seconds with the «M» icon.
3. When the °C or °F icon is flashing, a beep
sound is heard and the thermometer is
ready for measurement.
4. Straighten the ear canal by pulling the ear
up and back to give a clear view of the
eardrum.
• For children under 1 year:
Pull the ear straight back.
• Children above 1 year and adults:
Pull the ear up and back.
5. While gently pulling the ear, insert the probe
snugly into the ear canal and press the
START button. Release the button and wait
for the beep sound. This is the indication that
confirms the end of measurement.
6. Remove the thermometer from the ear canal.
The LCD displays the measured temperature.
NOTE:
• 10 short beeps will sound and a red LCD backlight will illuminate
when the temperature is higher than 37.5 °C (99.5 °F) in order to
alert the patient that he/she may have a temperature above 37.5 °C.
•In order to assure the accurate readings, plase wait at least
30 seconds after 3-5 continuous measurements.
• Accumulation of ear wax on the probe tip can result in less accurate
temperature readings or cross infection between users. Therefore,
it is essential that a clean probe tip is used before each
measurement. Please follow the instructions in the «Cleaning and
Storage» section for cleaning.
•After cleaning the probe tip with alcohol, it is necessary to
wait 5 minutes before taking the next measurement, in order to
allow the thermometer to reach its operating reference temperature.

8
• For an infant, it is best to have the child laying flat with his head
sideways so the ear is facing upwards. For an older child or adult,
it is best to stand behind and slightly to the side of the patient.
• Always take the temperature in the same ear, since the tempera-
ture readings may be different from the right ear and left ear.
• Wait for a few minutes to take the ear temperature after sleeping.
• In the following situations it is recommended that 3 measurements
are done in the same ear and the highest one is taken as the reading:
1) New born infants in the first 100 days.
2) Children under three years of age with a compromised immune
system and for whom the presence or absence of fever is critical.
3) When the user is learning how to use the IR thermometer for the
first time until he/she has familiarized himself/herself with the
instrument and obtains consistent readings.
7. Changing from Fahrenheit to Celsius and vice-versa
The thermometer can display temperature measurements in either Fah-
renheit or Celsius. To switch the display between °C and °F, simply turn
OFF the unit, press and hold the START button for 5 seconds until «-- -»
and the flashing °C or °F icon is shown on the LCD. Switch the measure-
ment scale between °C and °F by pressing the START button again. When
the measurement scale has been chosen, wait for 5 seconds and the unit
will enter the ready for measuring mode automatically.

8. How to recall 12 readings in Memory Mode
This thermometer can recall the last 12 readings. To recall please fol-
low sequence.
Display
Pressing and releasing the START button after the last 12 readings
have been recalled will resume the above sequence from reading 1.
9
Display Meaning
Recall Mode
Reading 1
(the last reading)
Reading 2
(the second latest
reading)
Reading 12
(the last reading)
Description
Press the START button to
enter Recall Mode when
power is off.The memory
icon «M» flashes.
Press and release the START
button to recall the last rea-
ding. Display 1 alone with
memory icon.
Press and release the START
button to recall the second
latest reading
Press and release the START
button consecutively to recall
readings in succession, up to
the last 12 readings.

9. Error messages
Display / Problem Display
Meaning
Measured
Temperature
too high
Measured
temperature
too low
Ambient tem-
perature too
high
Ambient tem-
perature too
low
Error function
display
Blank display
Dead battery
indication
Possible cause and
fault remedy
Displays «H» when
measured temperature
higher than 100.0 °C or
212.0 °F.
Displays «L» when mea-
sured temperature
lower than 0 °C or
32.0 °F.
Displays «H» in
conjunction with the
«▲» when ambient tem-
perature is higher than
40.0 °C or 104.0 °F.
Displays «L» in conjunc-
tion with the «▼» when
ambient temperature is
lower than 5.0 °C or
41.0 °F.
When system has mal-
function.
Please check if the bat-
tery has been loaded
correctly. Also check
polarity (<+> and <->) of
batteries.
If the steady battery
icon is the only symbol
shown on the display,
the batteries should be
replaced immediately.
10

10. Cleaning and Storage
Use an alcohol swab or cotton tissue
moistened with alcohol (70% Isopropyl)
to clean the thermometer casing and
the measuring probe. Ensure that no
liquid enters the interior of the thermo-
meter. Never use abrasive cleaning
agents, thinners or benzene for cleaning
and never immerse the instrument in water or other cleaning liquids.
Take care not to scratch the surface of the probe lens and the LCD.
Remove the battery from the instrument if it is not required for exten-
ded periods of time in order to avoid damage to the thermometer
resulting from a leaking battery.
11. Replacing the battery
The thermometer is supplied with one lithium battery, type CR2032.
Replace with a new CR2032 battery when the flashing battery symbol
appears on the LCD display.
Remove the battery cover by sliding it in the direction shown. Take
out the battery and put in a new one.
12. Guarantee
Subject to the following conditions this high-quality measuring instru-
ment is covered by a 2 year guarantee from the date of purchase.
Warranty claims must be lodged within the guarantee period.
This product was manufactured with the utmost of care according to
international quality standards. Should you have reason for com-
plaints despite this, please send the instrument, accompanied by the
completed Guarantee Card with dealer's stamp as well as original
proof of purchase directly or through your medical supplier to your
closest Microlife Distributor.
Damage resulting from incorrect use is not covered by the guarantee.
Battery and packaging are excluded from the guarantee. Claims
beyond this, including claims for damages, are excluded.
Name and adress of responsible dealer:
11

12
13. Technical Specifications
Type:
Measuring Range:
Accuracy:
Display:
Accoustic:
Memory:
Backlight:
Operating
temperature:
Storage/transport
temperature:
Automatic
Switch-off:
Battery:
Dimensions:
Weight:
Standards:
According to the Medical Product User Act a biennial technical ins-
pection is recommenden for professional users. Please observe the
applicable disposal regulations.
14. www.microlife.com
Detailed user information about our thermometers and blood pressure
monitors as well as services can be found at www.microlife.com.
Probe Cover Free Ear Thermometer IR 1DE1
0 °C to 100.0 °C (32.0 °F to 212.0 °F)
Laboratory: ±0.2 °C, 32.0 ~ 42.2 °C
(±0.4 °F, 89.6 ~ 108.0 °F)
Liquid Cristal Display with indicating unit 0.1 °C/°F
a. The unit is turned ON and ready for the measu-
rement:1 short «bi» sound.
b.
Complete the measurement: 1 long beep (1sec.),
if the reading is less than 37.5 °C (99.4 °F),
10short «beep» sounds, if the reading is equal
to or greater than 37.5 °C (99.4 °F).
c. System error or malfunction: 3 short «bi» sounds.
a. Auto-Display the last measured temperature
when switched on.
b. 12 readings recall in the Memory Mode.
a. The display will be lighted GREEN for 4 sec.,
when the unit is turned ON.
b. The display will be lighted GREEN for 5 sec.,
when a measurement has been completed
with a reading less than 37.5 °C (99.4 °F).
c. The display will be lighted RED for 5 sec.,
when a measurement is completed with a rea-
ding equal to or higher than 37.5 °C (99.4 °F).
5 °C to 40 °C (41.0 °F to 104 °F)
-25 °C to + 55 °C (-13 °F to 131 °F)
Approx. 1 minute after last measurement.
Foolproof Switch-off: Auto-off if START button is
pressed and held for 15 seconds.
CR2032 Battery (X1) - at least 1000 measurements
153 mm (L) x 31 mm (W) x 40 mm (H)
53 g (w/ battery), 50 g (w/o battery)
Complies with ASTM E-1965 requirements

Thermomètre auriculaire sans embout
Mode d’emploi
Veuillez lire attentivement ces instructions avantl'utilisation
de l'instrument et conservez-les dans un endroit sûr.
Le thermomètre auriculaire sans embout Microlife IR 1DE1 est un pro-
duit de haute qualité utilisant la technologie la plus récente et testé
selon les normes internationales. Grâce à sa technologie unique, le
IR 1DE1 assure pour chaque mesure une lecture stable, sans interfé-
rence de la chaleur environnante. L’appareil effectue un autocontrôle
à chaque mise en marche pour toujours garantir des mesures confor-
mes à la précision annoncée.
Le thermomètre auriculaire sans embout Microlife est destiné à des
mesures ponctuelles et à la surveillance de la température corporelle
à domicile. Il est conçu pour les personnes de tous les âges.
Les piles et instruments électroniques doivent être éliminés
en conformité avec les prescriptions locales, séparément des
ordures ménagères.
13

Sommaire
1. Les avantages du thermomètre
2. Consignes de sécurité importantes
3. Description de l’appareil
4. Comment le thermomètre mesure la température auriculaire
5. Affichage de contrôle et symboles
6. Instructions d’utilisation
7. Passage de Fahrenheit en Celsius et inversement
8. Comment appeler 12 mesures en mode mémoire
9. Messages d’erreurs
10. Nettoyage et rangement
11. Remplacement de la pile
12. Garantie
13. Spécifications techniques
14. www.microlife.com
14

15
1. Les avantages du thermomètre
Utilisation multiple (large étendue de mesure)
IR 1DE1 a la particularité d’offrir une large étendue de mesure de
0 - 100 °C (32,0 - 212.0 °F). L’appareil peut donc être utilisé comme
thermomètre auriculaire pour mesurer la température corporelle, mais
aussi pour mesurer la température de surface des éléments suivants:
• Température de surface du lait.
• Température de surface du bain de bébé.
• Température ambiante.
Sans embout
Ne nécessitant pas la mise en place d’un embout avant une mesure,
le thermomètre s’avère plus convivial et économique.
Mesure rapide
La technologie innovatrice de la mesure de la température par le
rayonnement infrarouge permet de prendre la température de l’oreille
en seulement 1 seconde.
Précis et fiable
Grâce au mode d’assemblage de la sonde, à son capteur à rayons infra-
rouges perfectionné et à son processus de calibrage complet, ce produit
offre une mesure aussi précise que sûre de la température auriculaire.
Agréable et facile d’utilisation
• Forme ergonomique qui rend l’utilisation du thermomètre simple et
facile.
• Ce thermomètre peut être utilisé sans perturber la vie quotidienne. Une
prise de température pendant le sommeil d’un enfant est possible.
• Ce thermomètre est agréable d’utilisation pour les enfants.
Affichage automatique de la mémoire
Le thermomètre affiche automatiquement la dernière mesure pendant
2 secondes lorsqu’il est mis en route.
Appel multiple de mesures
Les utilisateurs ont la possibilité d’appeler les 12 dernières mesures
enregistrées quand l’appareil est en mode mémoire, ce qui permet de
mieux suivre les variations de température.
Sûr et hygiénique
• Pas de risques de verre cassé et d’ingestion de mercure.
• Totalement sûr pour la prise de température des enfants.
• Un nettoyage de l'extrémité de la sonde avec un chiffon de coton
imbibé d’alcool rend l’emploi du IR 1DE1 complètement hygiénique.

Indication d'une température élevée
10 bips courts et un rétroéclairage rouge de l'écran LCD signalent que
la température peut être supérieure à 37,5 °C. Signal de fièvre
10 bips brefs signalent au patient un éventuel état fébrile.
2. Consignes de sécurité importantes
• N’utilisez jamais ce thermomètre à d’autres fins que celles pour
lesquelles il a été conçu. Suivez bien les consignes générales de
sécurité lors des prises de température sur l’enfant.
•Ne plongez jamais ce thermomètre dans l’eau ou un autre
liquide (il n’est pas étanche). Pour son nettoyage et sa
désinfection suivez les indications du paragraphe 10:
«Nettoyage et rangement»
• Placez l’appareil à l’abri de toute exposition directe au soleil.
Rangez-les dans un endroit sans poussière, sans humidité et à
une température comprise entre 5 - 40 °C (41 - 104 °F).
• N’utilisez plus le thermomètre si la sonde ou le corps de l’ap-
pareil lui-même présentent des traces de dommages. S’il est
abîmé ne tentez pas de le réparer vous-même. Prenez contact
avec le service après-vente Microlife le plus proche.
• La présence de cérumen dans le canal auditif peut abaisser arti-
ficiellement la température lue. Le canal auditif doit donc être
bien propre pour obtenir une mesure précise.
• Ce thermomètre est constitué de pièces de précision de haute
qualité. Ne le faites pas tomber. Protégez-le des chocs brutaux et
des coups. Ne tordez ni l’appareil ni la sonde.
AVERTISSEMENT:
•L’utilisation de ce thermomètre auriculaire ne peut vous
dispenser de consulter votre médecin.
• Le thermomètre n’est pas étanche. Ne le plongez JAMAIS
dans un liquide.
3. Description de l’appareil
(1) Sonde
(2) Bouton START
(3) Ecran d’affichage à cristaux liquides
(4) Bouton «O/I»
(5) Compartiment de la pile
16
(2)
(3)
(4)
(5)
(1)

17
4. Comment ce thermomètre mesure la température auriculaire
Ce thermomètre mesure l’énergie infrarouge émise par la membrane
du tympan et les tissus avoisinants. Cette énergie est recueillie par la
lentille puis convertie en une indication de température. La mesure
affichée obtenue directement du tympan (membrane tympanique)
donne la température auriculaire la plus juste.
Les mesures prises sur le tissu environnant du canal de l’oreille
génèrent une lecture de la température plus basse, ce qui peut ent-
raîner un mauvais diagnostic de la fièvre.
Pour éviter une mesure inexacte:
• Activer le thermomètre en appuyant sur le bouton 0/I.
• Après le premier bip (le symbole de l’échelle de température clig-
notant), redresser le canal auriculaire en tirant doucement le
milieu de l’oreille vers l’arrière et vers le haut.
• Bien introduire la sonde dans le canal de l’oreille, appuyer sur le
bouton START et garder la sonde dans l’oreille jusqu’au bip qui
signale la fin de la mesure.
Ce thermomètre, qui a été testé cliniquement, s’est avéré par-
ticulièrement précis et sûr lorsque les consignes du mode
d’emploi sont bien respectées.

18
5. Affichage de contrôle et symboles
Affichage de l’écran Signification
de l’affichage
Tous les seg-
ments sont
affichés
Mémoire
Prêt
Mesure effec-
tuée
Température
auriculaire hors
plage
Signal d’usure
de la pile
Description
Appuyer sur le bouton O/I
pour allumer l’appareil,
tous les segments sont
affichés pendant
2 secondes.
La dernière mesure sera
affichée automatique-
ment pendant 2 secondes.
L’appareil est prêt pour la
mesure, le symbole °C ou
°F clignote.
La température est
affichée avec le symbole
°C ou °F clignotant, l’ap-
pareil est prêt pour la
prochaine mesure.
Le symbole oreille barrée
signale que le résultat
est en dehors de la plage
32.0 - 42.2 °C
(89.6 - 108.0 °F)
Quand l’appareil est
allumé, le symbole pile
continue de clignoter
pour rappeler à l’usager
de la changer
.
