1. Overview of the IP Phone
IP-Phone is a full-featured IP-based telephone set via Ethernet base communication. Over
the office LAN connection, it provides IP-PBX solution such as station-to-station call, IP call
and local PSTN/PBX Extension call via PSTN Gateway.
IP-Phone provides two 10/100BaseT switch/hub RJ-45 ports allow connecting to office LAN
and PC simultaneously. It is compatible with ADSL or Cable Modem provided by ITSP, ISP
or Carrier Company to provide VoIP services to residential and SOHO application.
IP-Phone is also an integrated Analog Phone provides IP call or PSTN call selection. When
external power is down, it can be a Plain Old Telephone set (POTs).
It provides internal high-quality speakerphone, programmable keys and feature buttons.
IP-Phone also embedded with a dot matrix of two lines 24 characters LCD, which can
display date and time, calling party name, calling party number, and digits dialed and etc.
3

1.1.Hardware Overview
Front View and Keypad function
●LCD: 2 lines, 24 character Dot Matrix display.
●C: Jump out current LCD menu.
●Í: Move to previous selection or clear previous data.
●Î: Move to right or next selection.
●OK: Press OK to confirm the modification.
●Direct Line (DL) Button 1 – 10: User press DL button after off-hook to do speed dial
according to phone book data from 1-10 (please refer to LCD configuration-3.Phone
Book; Advanced Configurations via Telnet- 10.[pbook] command, or Web
Configuration-Phone Book chapter.
●Number 1 –10, * and #: The function is the same as the general phone set.
Corresponding list of keypad and symbol:
(1) Character mode:
1 “1”
2 “A” ; “ B” ; “C” ; “2”
4

3 “D” ; “E” ; “F” ; “3”
4 “G” ; “H” ; “I” ; “4”
5 “J” ; “K” ; “L” ; “5”
6 “M” ; “N” ; “O” ; “6”
7 “P” ; “Q” ; “R” ; “S” ; “7”
8 “T” ; “U” ; “V” ; “8”
9 “W” ; “X” ; “Y” ; “Z” ; “9”
* “.” ; “@” ; “_” ; ”-“ ; “,” ; “!” ; “?” ; “*” ; “’” ; “+” ; “$” ; “*”
0 “Space” ; “0”
# “#”
(2) Digit mode:
1 “1”
2 “2”
3 “3”
4 “4”
5 “5”
6 “6”
7 “7”
8 “8”
9 “9”
* “.”
0 “0”
#
●MUTE: Mute the voice of MIC and let others can’t hear from user in communication.
●PSTN: Press PSTN to switch IP-Phone as PSTN or IP Phone Mode. In PSTN mode,
“PSTN” characters will be displayed on LCD left bottom side, then users can dial out as
if standard telephone set in PSTN; in IP Phone mode, “PROXY ” characters will be
displayed on LCD left bottom side.
Note:
1. When IP-Phone is in PSTN mode, only PSTN and SPEAKER function key can work.
2. On LCD will display ”…Incoming Call... ” to inform user when IP-Phone has both IP
and PSTN side incoming calls.
3. If in communication with IP side, user can press HOLD to hold IP side, then press
PSTN to pick up PSTN side, after that can press HOLD again to retrieve IP side.
4. If in communication with PSTN side, user must hang up PSTN side before pick up IP
5

side.
●HOLD: To hold a call, after press HOLD button, both sides will hear hold tone.
●SPEED:
1. Press SPEED and number (Phone book index) after off-hook can do speed dial
according to phone book data (please refer to 3.LCD configuration-6. Phone Book
or Advanced Configurations via 4.Telnet- 10.[pbook] command).
2. Switch input mode between character mode or digit mode, e.g., when user wants to
input phone number can press SPEED to switch input mode as digit mode; when
user wants to input name can also press SPEED to switch input mode as character
mode.
●FORWARD: Forward an incoming call to another IP device. (Please refer to LCD
configuration-Forward Type) (**)
●MESSAGE and its indicated LED light: When having missed incoming calls, the
MESSAGE LED will be flashing. User can check the information of missed calls by
pressing the MESSAGE button. (**)
●TRANSFER:
1. Transfer a call to the third site. When A and B are in communication, A wants to
transfer this call to C, A can press TRANSFER button, now B will hear hold tone,
and A will hear dial tone, then A can press phone number of C, after C picks up, A
can talk with C, after A hangs up, B and C can be connected.
Note:
1. A cannot press phone number of C before hearing dial tone.
2. If A press TRANSFER and number, press TRANSFER again can cancel
transferring and retrieve call with B.
3. If A press TRANSFER and number of C, C is ringing, press TRANSFER again C
will return to standby mode and A can retrieve call with B.
2. Change characters to be capital or lowercase: when pressing TRANSFER before
press letters can switch input type of letters.
●REDIAL: Redial the last outgoing call.
●+And -: Adjust the voice volume heard of communication.
●SPEAKER: Hand free mode. User can talk without picking up handset.
6

Note:
All function keys mentioned above (except dialing keypad) are effective only in IP
Phone mode.
Back View
nDC 9V: DC 9V power input outlet
oLAN: RJ-45 connector, connected directly to the Hub through the straight CAT-5
cable.
pPC: RJ-45 connector, connected directly to the PC through the straight CAT-5
cable
qLine: RJ-11 connector, connected directly to the PSTN analog line.
Note:
There are two LED indicated lights: LINK/ACT and 10/100 for LAN port and PC port.
When network status is regular, LED of LINK/ACT will light on; when IP-Phone is
transmitting or receiving data, LED will be flashing; when transmit rate is in 10 mbps or
100mbps, LED of 10/100 will light off or light on.
Specification of connector
Ethernet Port：
Ethernet port is for connecting IP-Phone to network, transmit rate supports 10/100 Base-T.
7

Ethernet connector（LAN）
RJ-11connector：
RJ-11 connector is for connecting IP-Phone with PSTN.
RJ11connector
8

1.2.Software Features and Specification
Application:
●ISP/ITSP (Internet Telephony Service Provider)
●IP-PBX with office telephony services
●Multi-nation enterprise communication
●SOHO Telephony
Calling Features
●Call Hold
●Call Transfer
●Call Forward (**)
●10 sets last number Redial
●Ten configurable speed dials
Network Supported
●Fixed IP
●Dynamic Host Configuration Protocol (DHCP)
●PPPoE connection (When PPPoE disconnect, IP-Phone can automatically
re-connect)
●Behind NAT IP Sharing Device
●Support QOS by setting DSCP (Differentiated Service Code Point) parameters of
VoIP packet
●Support 802.1p1q (VLAN) (**)
Audio Features
●G.711 a/µ-Law, G.723.1, G.729, G.729a
●VAD, CNG
●G.165/G.168 compliant echo cancellation
●Programmable Dynamic Jitter Buffer
●Bad Frame Interpolation
●Gain/Attenuation Settings
