Microsoft UUC-00001 - SideWinder X3 Mouse Parts list manual

Results stated herein are based on internal Microsoft testing. Individual results and performance may vary. Any device images shown are not actual size. This document is provided for informational purposes only and is subject to change
without notice. Microsoft makes no warranty, express or implied, with this document or the information contained herein. Review any public use or publications of any data herein with your local legal counsel.
©2011 Microsoft Corporation. The names of actual companies and products mentioned herein may be trademarks of their respective owners.
Rev. 1103A Microsoft®SideWinder™X3 Mouse Page 1 of 1
Version Information
Product Name
Microsoft®SideWinder™ X3 Mouse
Product Version
Microsoft SideWinder X3 Mouse
Mouse Version
Microsoft SideWinder X3 Mouse
Product Dimensions
Mouse Length
4.74 inches (120 millimeters)
Mouse Width
2.76 inches (70.2 millimeters)
Mouse Depth/Height
1.60 inches (40.8 millimeters)
Mouse Weight
4.80 ounces (136 grams)
Mouse Cable Length
83 +3/-0 inches (2114 +85/-0 millimeters)
Compatibility and Localization
Interface
USB Compatible
Operating Systems
Microsoft Windows®7, Windows Vista®, and Windows XP (excluding Windows XP 64-bit)
Top-line System Requirements
Requires a PC that meets the requirements for and has installed one of these operating systems:
• Microsoft Windows 7, Windows Vista, or Windows XP (excluding Windows XP 64-bit)
• 100 MB available hard drive
• Powered USB port
• CD Drive
• Internet access may be required for certain features. Local and/or long-distance telephone toll charges may apply
• Microsoft IntelliPoint 7.0 software
Compatibility Logos
• Compatible with Microsoft Windows 7
• Certified for Microsoft Windows Vista
• Certified USB logo
Tracking Technology
Mouse Tracking System
Avago-based laser technology
Imaging Rate
7080 frames per second
X-Y Resolution
Maximum 2000 points per inch (78.76 points per millimeter). Selectable range from 200 to 2000 points per inch.
Tracking Speed
Up to 45 inches (1140 millimeters) per second
Maximum Acceleration
20G
USB Reporting
500Hz
Product Feature Performance
Mouse Button Features
8 buttons including scroll wheel button, 3 buttons for quick dpi changes
Right & Left Main Button Life
10,000,000 actuations
Wheel Button Life
250,000 actuations
Side Button Life
1,000,000 actuations
DPI Switch Life
20,000 actuations
Mouse Scrolling Features
Rubberized scroll wheel with detent clicking action
Wheel Vertical Scrolling Life
• 85,000 revolutions (away from user) at no more than 60 rotations per minute
• 300,000 revolutions (toward user) at no more than 60 rotations per minute
Storage Temperature & Humidity
-40 °F (-40 °C) to 140 °F (60 °C) at <5% to 65% relative humidity (non-condensing)
Operating Temperature & Humidity
37 °F (0 °C) to 104 °F (40 °C) at <5% to 80% relative humidity (non-condensing)
Certification Information
Country of Manufacture
People's Republic of China (PRC)
ISO 9001 Qualified Manufacturer
Yes
ISO 14001 Qualified Manufacturer
Yes
Laser Compliance
This device complies with International standard IEC 60825-1:2001-08 for a Class 1 laser product. This device also complies with 21 CFR 1040.10and
1040.11, except for deviations pursuant to Laser Notice No. 50, dated June 24, 2007
Restriction on Hazardous Substances
This device complies with all applicable worldwide regulations and restrictions including, but not limited to: EU directive 2002/95/EC on the Restriction of
the Use of Certain Hazardous Substances in Electrical and Electronic Equipment and EU Registration Evaluation and Authorization of Chemicals
(REACH) regulation regarding Substances of Very High Concern.
FCC ID
This device complies with Part 15 of the FCC Rules and Industry Canada ICES-003. Operation is subject to the following two conditions: (1) This device
may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired
operation. Tested to comply with FCC standards. For home and office use. Model number: 1382, SideWinder X3 Mouse.
Agency and Regulatory Marks
• ACMA Declaration of Conformity (Australia)
• ICES-003 report on file (Canada)
• EIP Pollution Control Mark, EPUP (China)
• CE Declaration of Conformity, Safety and EMC (European Union)
• WEEE (European Union)
• VCCI Certificate (Japan)
• KCC Certificate (Korea)
• GOST Certificate (Russia)
• CITC Letter (Kingdom of Saudi Arabia)
• BSMI Certificate (Taiwan)
• FCC Declaration of Conformity (USA)
• UL and cUL Notice of Approval (USA and Canada)
• CB Scheme Certificate (International)
Windows Hardware Quality Labs (WHQL)
ID: 1411306 Microsoft Windows 7
