Microsoft Surface Go 2 Parts list manual

SG
Surface Go 2
Surface Go 3
Kickstand Replacement Guide

2M1196211
Disclaimer of Warranties and Limitation of Damages
All information, content, materials, and products made available in or in conjunction with this Manual are provided
by Microsoft on “as-is” and “as available” basis, unless otherwise specied by Microsoft in writing. Microsoft makes no
representations or warranties of any kind, express or implied, as to the information, content, materials and products
included or otherwise made available to you or accompanying this Manual unless specied in writing. You expressly
agree that your use of the information, content, materials, and product in or accompanying this Manual is at your
sole risk.
To the fullest extent permissible by law, Microsoft disclaims all warranties, express or implied, including but not
limited to implied warranties of merchantability and tness for a particular purpose. To the fullest extent permissible
by law, Microsoft shall not be liable for damages of any kind arising from the use of information, content, materials, or
product made available in or in conjunction with this Manual, including but not limited to direct, indirect, incidental,
consequential, and/or punitive damages unless otherwise specied in writing.
Notice
Microsoft and its suppliers may have patents, patent applications, trademarks, copyrights, trade secrets and/or other
intellectual property rights covering subject matter in this document. Microsoft’s furnishing of this document to
recipient does not grant or imply any license to any patents, trademarks, copyrights, trade secrets or other intellectual
property rights, and recipient’s permitted use of any such intellectual property rights, if any, is solely governed by the
Agreements.
This document and the information it contains are subject to change without notice. You can nd the latest
information on Surface device servicing and repair at https://aka.ms/surfaceservicing. Always consult the most up-to-
date information available before performing device servicing or repair.
© 2021 Microsoft Corporation. All rights reserved.
Document Part Number: M1196211

3M1196211
Table of Contents
DEVICE IDENTITY INFORMATION........................................................................................................................... 4
· SURFACE GO 2 & 3 MODELS ....................................................................................................................... 4
· GLOSSARY OF TERMS ................................................................................................................................. 4
GENERAL INFORMATION, PRECAUTIONS, WARNINGS ........................................................................................5
· SERVICE TOOLS AND JIGS ...........................................................................................................................5
· STANDARD SERVICE TOOLS: .......................................................................................................................5
· GENERAL SAFETY PRECAUTIONS ...............................................................................................................6
· REPAIR-SPECIFIC PRECAUTIONS AND WARNINGS ..................................................................................6
· SAFETY POLICIES/PROCEDURES .................................................................................................................7
ILLUSTRATED SERVICE PARTS LIST ..........................................................................................................................8
SERVICE DIAGNOSTICS/TROUBLESHOOTING OVERVIEW ....................................................................................9
· SOFTWARE TOOLS: ......................................................................................................................................9
· TROUBLESHOOTING APPROACH ...............................................................................................................9
COMPONENT REMOVAL AND REPLACEMENT PROCEDURES...............................................................................9
· PRIOR TO DEVICE DISASSEMBLY: ...............................................................................................................9
KICKSTAND REPLACEMENT PROCESS ..................................................................................................................10
· PROCEDURE – REMOVAL (KICKSTAND) .................................................................................................. 10
· PROCEDURE – INSTALLATION (KICKSTAND)...........................................................................................13
ENVIRONMENTAL COMPLIANCE REQUIREMENTS..............................................................................................16

4M1196211
Device Identity Information
Surface Go 2 & 3 Models
1901 – Surface Go 2 Consumer Wi-Fi (Platinum and Black)
1926 – Surface Go 2 Commercial Wi-Fi (Platinum and Black)
1927 – Surface Go 2 Consumer/Commercial LTE (Platinum)
2022 – Surface Go 3 Consumer/Commercial LTE (Platinum and Black)
The serial number and model for Surface Go 2 are located under the kickstand. The model number is also noted on
the kickstand’s underside.
Glossary of Terms
The following terms are used throughout this manual:
• SDT – Surface Diagnostic Toolkit
• ESD – Electro-Static Discharge
• IBC – Tablet Back Cover
• TDM – Touch Display Module is the complete screen with all layers.
• FRU – Field Replaceable Units are sub-system components such as the SIM/rSSD door, Kickstand, and rSSD.
FRU are available only to ASPs. Some replaceable units will only be available as FRUs and therefore are only
supported at an ASP.
• Commercial Spares/CRU – Customer Replaceable Units available to commercial customers for repair by a
skilled-technician.

5M1196211
General Information, Precautions, Warnings
This symbol identies important safety and health information in this manual.
Service Tools and Jigs
Standard Service Tools:
• Anti-static wrist strap (1 MOhm resistance)
• Soft Electro-Static Discharge (ESD) safe mat
• 3IP (Torx-Plus) driver
• Microber cloth
The tools identied on this list can be purchased from many different commercial sources, including but not limited
to Amazon.com; iFixit; Chemdex, and other vendors.

6M1196211
General Safety Precautions
Always observe the following, general safety precautions:
• Opening and/or repairing any device can present electric shock, device damage, re, and/or personal injury
risks and other hazards. Exercise caution when undertaking these activities as described in this manual. Only
skilled IT technicians to whom Microsoft has provided this manual should attempt CRU repair activities. Only
Microsoft-authorized service providers should undertake FRU repair activities.
• Always select and use the appropriate AC power supply for a device. We recommend you use genuine
Microsoft power supply units and AC power cords. A genuine Microsoft power supply unit is provided with
every device.
• Use only AC power provided by a standard (mains) wall outlet. Do not use non-standard power sources, such
as generators or inverters, even if the voltage and frequency appear acceptable.
• Improper use of device batteries may result in re or explosion. Only open the enclosure on a device as
outlined in this manual. Do not heat, puncture, mutilate, or dispose of devices or their batteries in re. Do not
leave or charge devices in direct sunlight or exposed to other extreme sources of heat for an extended period
of time. Doing so may cause damage or melt the batteries.
For additional product safety information, including information about
• Hearing conservation
• Heat related concerns
• Choking hazard/small parts
• Interference with medical devices
• Broken glass
• Photosensitive seizures
• Musculoskeletal disorders
See aka.ms/surface-safety or the Surface app. To open the Surface app, select the Start button, enter Surface into the
search box, then select the Surface app.
Repair-Specic Precautions and Warnings
• Prior to opening device, ensure device is powered off and disconnected from a power supply.
• We recommend wearing protective eyewear as a safety precaution when disassembling/re-assembling
a device.
• Before opening device, always check that an anti-static wrist strap is worn and work area is properly
grounded to ensure electrostatic discharge (ESD) safe environment
• Check to make sure that general guidelines and ESD compliance steps are followed prior to starting
activities. Refer to Prior to Device Disassembly section for details.
• As you remove each subassembly from the device, place the subassembly (and all accompanying screws)
away from the work area to prevent damage to the device and to the subassembly.

7M1196211
Safety Policies/Procedures
Microsoft’s eld product safety program team is referred to as the Rapid Response Team (RRT). All device issues
that may be safety related should be managed per the following instructions.
As a quick guide, any Microsoft Surface device that visually exhibits any of the following symptoms shall be
immediately removed from the replacement process and delivered to your Variance Manager or IT Support
Professional for notication to Microsoft RRT:
• Any burned or melted components, traces or plastic parts on the outside of the device, or which otherwise
exhibits heat damage, including charring seen in charging and other ports;
• Any burned or melted components, traces or plastic parts on the inside of the device, or which otherwise
exhibits heat damage.
• Any accessories exhibiting melting or heat damage that are included with the Microsoft device, such as power
supplies, keyboards, mice, cables, charging connectors, etc.
• Any devices that exhibit a case that has separated apart or opened for reasons other than customer abuse
(e.g., impact damage from dropping, evidence of tampering, separation caused by a malfunctioning battery).
• Any other nding that may constitute a safety hazard to the user, such as sharp edges on plastics.
The Variance Manager or IT Support Professional must send an email to Microsoft RRT with pictures showing the
damage within 24 hours of device receipt. Refer to the ASP Guidebook for the Microsoft RRT email address.
Non-ASP’s are to contact Microsoft Surface Support Services.
Your email should include:
• The model and serial number of the affected Microsoft Surface device and/or accessory(ies).
• The Service Request (SR) Number that the device was received under (Note as N/A if no SR exists).
• A brief description of the damage found.
• Clear photographs depicting the symptoms observed.
The Variance Manager or IT Support Specialist must await instructions from Microsoft Product Safety RRT for the
affected unit before continuing with activities or returning the device to the end user.

8M1196211
Illustrated Service Parts List
IMPORTANT: Device service part availability is segmented into two groups. FRUs are parts available
for repair activity through an Authorized Service Provider under specic contract with Microsoft. CRUs/
Spares are parts available for repair activity by a skilled technician.
Models
Item Component ASP / FRU
Part No.
CRU
Part No.
1901 1926 1927 2022
(1) Kickstand
Platinum Kickstand 1RD-00001 I64-00001 X
Platinum Kickstand 1RD-00002 I64-00002 X
Platinum Kickstand 1RD-00003 X
Platinum Kickstand 1RD-00009 I64-00003 X
Black Kickstand 1RD-00007 I64-00004 X
Black Kickstand 1RD-00008 I64-00005 X
Black Kickstand 1RD-00010 I64-00006 X
1

9M1196211
Service Diagnostics/Troubleshooting Overview
• For general Surface support, visit www.support.microsoft.com
• To troubleshoot device feature/function problems or learn more about Surface Go visit
www.aka.ms/SurfaceGoHelp
• If you’d like to learn more about Windows, visit www.aka.ms/WindowsHelp
• To learn more about the accessibility features of the Surface Go, visit the online user guide at
www.aka.ms/Windows-Accessibility
Software Tools:
• How To: Update Surface device rmware and OS
• How To: Surface Tools Video
• Download: Surface drivers and rmware
• Download: Surface Diagnostic Toolkit (SDT)
• Download: Surface Data Eraser
• Download: Surface Imaging Tools
Troubleshooting Approach
The following approach should be considered when troubleshooting Surface devices:
1. Update device to latest OS/FW versions using the SDT tool.
IMPORTANT: Device updates are required as a prerequisite to all hardware replacement.
2. Verify any suspected hardware failures by setting the device in a known OS/FW version state and running SDT
to verify fault:
a. Run SDT and verify if condition persists – Refer to Software Tools section for details on SDT
i. If problem is not resolved, then re-image SSD.
ii. If re-image fails replace device per established procedures.
Component Removal and Replacement Procedures
Prior to Device Disassembly:
• Before attempting any removal or replacement, always ensure device is powered off and disconnected from a
power supply.
• Always ensure that the work surface is covered with an ESD-safe, soft, non-marring material.
• Work surfaces should be cleaned regularly to ensure debris/abrasive particles are not present.
• Check to make sure that general guidelines and ESD compliance steps are followed prior to opening device.

10 M1196211
Kickstand Replacement Process
Preliminary Requirements
IMPORTANT: Be sure to follow all special (bolded) notes of caution within each process section.
Required Tools and Components
• Tools:
o 3IP (Torx-Plus) driver
o Soft ESD safe mat
o Microber cloth
• Components:
o New Kickstand FRU
(FRU includes new 3IP screws)
Prerequisite Steps:
• Power off device – Ensure device is powered off and disconnected from a power supply.
• General Safety – Check to make sure that general guidelines and ESD compliance steps are followed prior to
opening device. Refer to Prior to Device Disassembly section (page 10) for details.
• Verify device model number – Ensure the model number on the new kickstand FRU matches the model
number on the backside of the device.
Procedure – Removal (Kickstand)
1. Place device screen-down on soft ESD safe mat. Ensure mat is clear of any abrasive material that may
scratch the Touch Display Module (TDM) glass.
2. Extend the kickstand to approximately 90°.

11 M1196211
3. Remove hinge screws – Using the 3IP (Torx-Plus) driver, loosen all four hinge screws by 2-3 rotations. With
the screws loose, use your nger to hold the back of the kickstand behind each hinge while fully removing the
two hinge screws. Ensure screws do not fall into the hinge opening.
4. Lay Kickstand Down – Lay the kickstand at against the IBC. Be careful not to jostle the kickstand in this
position as it may cause abrasions on the IBC.
HOLD

12 M1196211
5. Angle hinges Down – Using your thumb or index nger, push both hinges down from 90° to approximately
30°. This will require a great deal of force. If necessary, place the microber cloth between your nger and
the hinge for comfort. Be careful not to push the hinge all the way into the bucket as it will be difcult to pull
back out.
6. Remove Kickstand – Using the palm of your hand, rmly hold the device down from the center of the IBC.
Simultaneously, grip the kickstand off-center between your thumb and index nger and rmly pull. Pull with
a moderate amount of force until the foam inserts slide out of the device. If the kickstand is stuck, ensure it is
not caught on the hinges.
H
O
L
D
PULL

13 M1196211
Procedure – Installation (Kickstand)
IMPORTANT: Use caution when handling new kickstand assembly to avoid cosmetic damage of the
kickstand and the device. The Surface Go 2 kickstands are not compatible with the original Surface Go.
1. Insert Foam Tabs – With the hinges still at ~30° start to slide the new kickstand’s foam tabs into the slots on
the back of the IBC. Foam should slide in with minimal force—do not crumple the foam by using excess force.
CAUTION: Do not use any tool or sharp object to assist inserting the tabs into the slots. Only the tabs
should be inserted. Doing so could damage internal components.

14 M1196211
2. Lay Kickstand Down – Lay the kickstand at against the IBC. Be careful not to jostle the kickstand in this
position as it may cause abrasions on the IBC.
3. Angle hinges Up – Using your thumb or index nger, push both hinges up from 30° to approximately 90°.
This will require a great deal of force. If necessary, place the microber cloth between your nger and the
hinge for comfort.

15 M1196211
4. Install hinge screws – Flip the kickstand up to approximately 90° such that the threaded holes of the
kickstand align with the mounting holes of the hinge. Install the hinge screws in the order shown below with
the 3IP (Torx-Plus) driver. Ensure screws do not fall into the hinge opening. Use your nger to hold the back
of the kickstand behind the hinge while installing the screws until they are fully seated. Verify the kickstand is
properly aligned and seated in the hinges, then tighten the screws an additional ~quarter turn (~90°).
.
5. Final inspection Kickstand installation – Fold the kickstand down and peel off protective plastic from the
kickstand and logo if present. Verify the side edges of the kickstand are aligned with the midframe walls
and that there are no obvious steps/gaps between the kickstand and the IBC. Wipe the device thoroughly
(including under the kickstand) with the microber cloth to remove all ngerprints.
2
4
1
3
HOLD

16 M1196211
Environmental Compliance Requirements
All waste electrical and electronic equipment (WEEE), waste electronic components, waste batteries, and electronic
waste residuals must be managed according to applicable laws and regulations and H09117,
“Conformance Standards for Environmentally Sound Management of Waste Electrical and Electronic Equipment
(WEEE),” which is available at this link: https://www.microsoft.com/en-pk/download/details.aspx?id=11691 In case of
questions, please contact [e-mail].
©2021 Microsoft.
