Midea PD User manual

Technical Support Department
PAC Installation
March 20

Product Line
PD PF PQ PH PHA

Series Adaptor
connecting to unit
Pipe size
Adaptor connecting to
window slider Window sealing board
PD/PF/PB Round
150mm
150mm
pipe
to window slider
Window sealing
board
PH Square
150mm
150mm
pipe
to
window slider
Window sealing
board
PHA Square
130mm
130mm pipe
to
window slider
Window sealing board
PQ Round
180mm
180mm pipe
to
window slider
Window sealing
board
Window Kit Overview

Note: Just pick out one set of accessories to show the differences, this set isn’t suitable for all of the PAC models.
Window end adaptor Unit end adaptor Exhaust hose
Accessories

You will need

Sash Window Installation
Step 1:
• Cut the adhesive seal foams (J) and (K) to the required lengths.
• Remove the strips from adhesive seal foams (J) and (K).
• Attach the adhesive seal foams (J) and (K) to the window sash and
frame.

Sash Window Installation
Step 2:
• Slide the window slider part (G) into part (F).
• Adjust the window slider to the width of the window assembly and secure with plastic bolt
(E).

Sash Window Installation
Step 3:
Before securing the window sash, mark and then drill the pilot holes in the window sill to prevent it
from splitting.
• Insert the window slider into the window opening. Close the window sash to secure the window slider in
place.
• Measure the width of the window sash.
• Cut the sash seal (L) so it fits the space between the lower and upper window sash.
• Place the sash seal (L) between the window sashes.
• Secure the position of the lower window sash using the bracket (M) and 2 screws (N).

Sliding Window Installation
Step 1:
• Cut the adhesive seal foams (J) and (K) to the required lengths.
• Remove the strips from adhesive seal foams (J) and (K).
• Attach the adhesive seal foams (J) and (K) to the window sash and frame.

Sliding Window Installation
Step 2:
• Slide the window slider part (G) into part (F).
• Adjust the window slider to the width of the window assembly and secure with plastic bolt
(E).

Sliding Window Installation
Step 2:
• Before securing the window sash, mark and then drill the pilot holes in the window sill to prevent it
from splitting.
• Insert the window slider into the window opening. Close the window sash to secure the window slider
in place.
• Measure the height of the window sash.
• Cut the sash seal (L) so it fits the space between the window sashes.
• Place the sash seal (L) between the window sashes.
• Secure the position of the window sash using the bracket (M) and 2 screws (N).

Exhaust Hose Connection
Step 1:
• Connect the exhaust hose (C) with the hose adaptors (B) and (D).

Exhaust Hose Connection
Step 2:
• Slide the hose adaptor (B) onto the air outlet (VB).
• Connect the other end to the window slider.

Exhaust Hose Connection
Step 2:
To ensure proper operation, do not overextend or abnormally bend the hose (C).
Place the product at a suitable distance from walls, furnitures and curtains to prevent it from
overheating due to poor ventilation.

Water Drainage
• Risk of electric shock! To prevent electric shock, unplug before cleaning.
The product features a bottom tray which collects excess water when in the DRY (dehumidifying) mode.
When the
bottom tray is full, the product beeps 8 times and the main unit display (UF) shows P1. To drain the
excess water:
• Carefully move the product to a location where the water can be drained. Use the side handles.
• Unscrew the bottom tray drain outlet’s (VE) cap and remove the drain plug.
• Drain the water.
• Reinstall the drain plug and the cap.

Continuous Water Drainage
• Remove the exhaust hose (C).
• Unscrew the drain outlet’s (VC) cap and remove the drain plug.
• Attach the hose (O) to the drain outlet (VC).
• Place the other end of the hose over the drain receptacle, for example, a basement floor drain, a sink
or similar.
Ensure that there are no kinks or bends on the drain hose (O) as this can stop water from draining.

Location
• Place the product at a distance of 12 in (30 cm) from walls, furnitures and curtains on all sides to
prevent it from
overheating due to poor ventilation.
• The product additionally requires at least 20 in (50 cm) of clearance on the back.
• Place the product on a smooth and level floor.
• Place the product near an easily accessible grounded wall outlet.

Installing/replacing the batteries
• Remove the battery compartment cover.
• Insert 2 x AAA batteries (H) with the correct polarities (+) and (-) as marked on the battery and inside
the battery
compartment.
• Slide the battery compartment cover back into place.

PD Series
Control panel
Auto swing Timer button
Mode select button
Mode:
Cooling;
Fan;
Auto Defrost Follow me indicator light
Timer/Temp. setting Fan button
Speed: Hi / Mi /Lo
Timer indicator light
Sleep indicator light
Sleep button
Power on/off button

PF Series
Control panel
Auto swing
Sleep button
Timer setting Mode select
button
Temp. setting
Power on/off button
Fan button
