Midea MF-CN35C2 User manual

IMPORTANT NOTE: Please read the manual carefully before operating
your product. Retain it for future reference.
AIR FRYER
MF-CN35C2
INSTRUCTION MANUAL

IMPORTANT SAFEGUARDS
1
1. This appliance is for household use only. Do not use out-
doors.
2. This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the haz-
ards involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by chil-
dren without supervision.
3. Children should be supervised to ensure that they do not play
with the appliance .
4. This appliance is intended to be used in household and simi-
lar applications such as:
-Staff kitchen areas in shops, of ce and other working envi-
ron-ments;
-Farm houses;
-By clients in hotels, motels and other residential type envi-
ron-ments;
-In bed and breakfast type environments;
5. If the supply cord is damaged, it must be replaced by the
manu-facturer, its service agentor similarly qualified persons
in order to avoid a hazard.
6. Please turn off and unplug the appliance before cleaning,
main-tenance or relocation and whenever it is not in use.
7. The surfaces are liable to get hot during use.
8. After being used for a long time, the corresponding heating
zone of the induction hotplate is till hot. Never touch the
ceramic surface to avoid burning.
9. Do not immerse any part of the appliance in water or other
liquid.
10. Never immerse the housing, which contains electrical com

IMPORTANT SAFEGUARDS
2
-
The appliance must not be disposed of with regular
household waste. At the end of its service life, the
appliance must be properly delivered to a collection
point for the recycling of electrical and electronic
equipment. By Collection and recycling of old appli-
ances, you are making an important contribution to
the conservation of our natural resources and pro-
vide for environmentally sound and healthy disposal.
11.Do not let any water or other liquid enter the appliance to
prevent electric shock.
12.Always put the ingredients to be fried in the basket, to pre-
vent it from coming into contact with the heating elements.
13.Do not cover the air inlet and the air outlet openings while the
appliance is operating.
14.Do not fill the pan with oil as this may cause a fire hazard.
15.Never touch the inside of the appliance while it is operating.
16.Keep the mains cord away from hot surfaces.
17.Never connect this appliance to an external timer switch or
separate remote-control system in order to avoid a hazard-
ous situation.
18.During hot air frying, hot steam is released through the air
outlet openings. Keep your hands and face at a safe distance
from the steam and from the air outlet openings.Also becare-
ful of hot steam and air when you remove the pan from the
appliance.
19.Immediately unplug the appliance if you see dark smoke
coming out of the appliance. Wait for the smoke emission to
stop before you remove the pan from the appliance.
20. Please pay attention to scald where there is a high tem-
perature symbol.
po-nents and the heating elements, in water nor rinse under
the tap. decreased suf ciently.

3
Product components
The product is subject to the actual product and configuration.
Air inlet
Control panel
Fried
basket
Handle
Fried
barrel
Heating
assembly
Base
Reel
Air
outlet
window

4
Electrical parameters
Precautions before use
Model Voltage Power
MF-CN35C2 220-240V~ 1500W
Frequency
50/60Hz
1. When the appliance is working and
when the barrel is withdrawn, hot
gases will be emitted from the air
outlet window and the upper part of
the barrel, so be careful to avoid
being burned by the high tempera-
ture gases.
2. During use the fried basket and
barrel is at a high temperature, so
be careful not to come into direct
contact with it.
3. The button for the fried basket can
only be pressed when the bucket is
placed on a horizontal table.
Pressing the button of the fried
basket when the basket is
suspended will cause the barrel to
fall down.

5
Instructions for use
2. Clean the fried basket and barrel
before use and set the product to
the highest temperature for the
first time and dry fry for 10 min.
4. Preheat the appliance for 3-5min
after put the barrel in the main unit
and before putting the ingredient in
for better cooking results.
Note: The silicone on the fried basket is
made of high temperature resistant
food-grade material and is mainly
applied to prevent the coating of the
basket and barrel from being scratched,
so be sure not to remove it when
baking food.
3. Install the fried barrel assemblies.
1. The product should be stably placed on a flat
table, so that the power cord has a sufficient
length to be plugged into the socket, and the
air power cord has a sufficient length to be
plugged into the socket, and the air around the
product should be kept in circulation, and
should not be close to flammable items.

6
Instructions for use
Operation panel: Default menus
Operation panel: Operating functions
French fries Chicken wings
Temp/time rise
Temp/time drop
Menu bar, the selected
menu light flashing,
while the rest of the
menu lights are always
ON
Start/Stop button, press
and hold it to enter
energy-saving mode
Time/temperature
toggle keys
Steak
Air drying
Cake
Thawing
Shrimp
Fish

7
Panel operating instructions:
1. Turn on the power, then touch
button to select the corresponding
function, and the digital screen shows
the preset temperature, (French fries
are selected for this picture).
2. Touch button to let the appliance
run for preheating, and the display
shows ON.
3. After the preheating is completed,
the appliance will beep and display
shows "ADD".
4. Pull out the barrel and place it on a
stable table, the display shows
OPEN.
5. Put the ingredients on the basket.
6. Push the barrel into the appliance,
after the appliance is powered on, it
will continue to work and the
interface shows the set time.

8
Instructions for use
7. Users may press to enter DIY to
set the required temperature and
time by touch keys, and
touch button to start. Then the
appliance enters the heating work
state, cooks and heats the food.
8. When heated to half of the set
time, the appliance will beep 3
times, at which point the barrel can
be removed and the food can be
turned over with an auxiliary tool
(chopsticks, clips, etc.), and the
display will show OPEN.
9. The appliance has a 10-minute
power-off memory function and the
next stage of heating will take place
when the barrel is pushed back into
the appliance. The display then
shows the remaining heating time.
10. The appliance beeps after cooked,
and you need to pull the barrel out
and place it on a flat table. To avoid
burns, use an aid to remove the
cooked food.
Please be careful with the hot
steam inside the barrel when pulling
it out, as it is at a high temperature,
an do not touch it with your hands
Please be careful with the hot
steam inside the barrel when pulling
it out, as it is at a high temperature,
an do not touch it with your hands

The default menu pre-sets the
heating temperature and time:
9
Menu function Symbol Temperature(℃) Time（min）Shake reminder
Defrost 80 6 /
French fries 180 15 Shake
Chicken wings 180 15 Shake
Steak 200 9 Shake
Shrimp 180 10 Shake
Fish 180 13 Shake
Cupcake 170 9 /
Dehydrate 70 4h /
Warm reminder
Cleaning and maintenance
• The first use requires 10 minutes of dry burning. A small amount of white
smoke or odor may appear during the dry burning process, which is normal.
Do not panic.
• Before the product works, please check whether the fried basket is in place to
avoid malfunction.
• If you find that the product is malfunctioning, please stop using it and contact
our service department immediately.
• Please use the fried basket and fried barrel together in the whole machine, and
avoid using them separately.
• After using, unplug the power plug and allow the air fryer to cool completely
before moving.
• Please clean up the remaining food in the frying basket before baking to
prevent the food from being burned by repeated baking.
• After using, please clean the fried basket and fried barrel in time to avoid the
damage of the coating due to the erosion of food residue oil.
• Do not use strong abrasive cleaners to prevent damage to the machine and
your health.
• Use a soft, clean cloth to wipe the air fryer. Please do not use an over-wet
cloth to clean the air fryer, to prevent water from entering the air fryer, which
may cause short circuit and fire.

10
Midea 0333 900 1101 [e-mail] www.midea.com/uk
• Please do not use other cleaning equipment such as a dishwasher to clean
the air fryer, otherwise it may cause damage and affect the use.
• Use neutral detergent or clean water to clean the frying pans and drums.
• Please do not use hard and sharp items (such as wire balls, blades, etc.) to
clean the fried basket and fried barrel to prevent scratching.
After sales service & your product warranty
We would like to thank you for choosing a Midea appliance.
We are confident that you will be happy with your purchase, and that your new
appliance will provide a long & reliable service.
We are here to help!
If you have any questions about setting up your appliance, it ’ s functions, or if you
are experiencing any problems, then please contact our Midea Aftersales Team.
Appliance Fault
If you suspect that your appliance may have a fault, then please check the User
Manual to ensure that the correct setup steps have been followed and your
appliance is being used in line with our guidelines.
If you are still experiencing problems, then please contact our Aftersales Team.
To help the team support you, please make sure that you have the following
information available when you contact them:
Your proof of purchase
The serial number of your appliance
A description of the fault
Your Midea appliance has been manufactured and tested to the highest
standards. It is supported with a 12- month manufacturer’s warranty from the
date it was purchased. The warranty covers any material or component defects
that were present in the manufacturing process.
The appliance is not suitable for commercial use.The claim under warranty
lapses in the event of intervention by the Buyer or by a third party. Damage
caused as a result of improper handling or operation, incorrect installation or
storage, improper connection or installation as well as an act [...] of God or
other external factors shall not be covered by this warranty

11
ANALYSIS OF COMMON PROBLEMS
When claims are submitted, the manufacturer reserves the right to make
improvements to defective parts or to replace or exchange the device. Only if it is
not possible to achieve the intended use of the device by repairing or replacing
the device, the buyer can demand a reduction of the purchase price or the
cancellation of the purchase contract within 6 months from the date of purchase.
Claims for damages, including consequential damag- es, are excluded unless
they are based on intent or gross negligence. The guarantee claim exists only
with submission of the product and the purchase receipt.This warranty is valid
within the United Kingdom only.
Remark: after the above phenomenon analysis still can not eliminate the fault,
please contact with the company's maintenance site or dealers, non-professional
personnel are strictly prohibited Disas-semble the machine by itself.
