Midea MF-TN35D User manual

MIDEA-MF-TN35D2（MF-TN35D）-0502 MIDEA-MF-TN35D2（MF-TN35D）-0502
MF-TN35D
Rated voltage: 220-240V~
Rated power: 1500W
Frequency: 50/60Hz
AIR FRYER
en

IMPORTANT SAFEGUARDS
1
1.This appliance is for household use only. Do not use outdoors.
2.This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervi-
sion.
3. Children should be supervised to ensure that they do not play
with the appliance
4.This appliance is intended to be used in household and similar
applications such as:
-
ments;
-Farm houses;
-By clients in hotels, motels and other residential type environ-
ments;
-In bed and breakfast type environments;
5. If the supply cord is damaged, it must be replaced by the
manufacturer, its service agentor similarly qualified persons
in order to avoid a hazard.
6. Please turn off and unplug the appliance before cleaning,
maintenance or relocation and whenever it is not in use.
7.The surfaces are liable to get hot during use.
8. Do not immerse any part of the appliance in water or other
liquid.
9. Never immerse the housing, which contains electrical com-
ponents and the heating elements, in water nor rinse under
the tap.

IMPORTANT SAFEGUARDS
2
10.Do not let any water or other liquid enter the appliance to
prevent electric shock.
11.Always put the ingredients to be fried in the basket, to
prevent it from coming into contact with the heating
elements.
12.Do not cover the air inlet and the air outlet openings while
the appliance is operating.
13.Do not fill the pan with oil as this may cause a fire hazard.
14.Never touch the inside of the appliance while it is operat-
ing.
15.Keep the mains cord away from hot surfaces.
16.Never connect this appliance to an external timer switch or
separate remote-control system in order to avoid a hazard-
ous situation.
17.During hot air frying, hot steam is released through the air
outlet openings. Keep your hands and face at a safe
distance from the steam and from the air outlet open-
ings.Also becareful of hot steam and air when you remove
the pan from the appliance.
18.Immediately unplug the appliance if you see dark smoke
coming out of the appliance. Wait for the smoke emission
to stop before you remove the pan from the appliance.
The appliance must not be disposed of with regular
household waste. At the end of its service life, the
appliance must be properly delivered to a collection
point for the recycling of electrical and electronic
equipment. By Collection and recycling of old appli-
ances, you are making an important contribution to
the conservation of our natural resources and pro-
vide for environmentally sound and healthy disposal.
19. Please pay attention to scald where there is a high tem-
perature symbol.

3
Product components
The product is subject to the actual product and configuration.
Fried basket

Preparation
4
Electrical parameters
Instructions for use
Model Voltage Power
Frequency
1.The product should be stably placed on a flat table (Figure 1), so that the
power cord has a sufficient length to be plugged into the socket, and the air
around the product should be kept in circulation, and should not be close to
flammable items.
2.According to different configurations install the barrel assembly (Figure 2),
then push it into the Main unit (Figure 3).
Figure 1
Figure 2
MF-TN35D 220-240V~ 1500W50/60Hz

Instructions for use
Instructions
5
3.Before placing ingredients, preheat the machine for 3-5 minutes, the cooking
effect will be better.
1.position and the time knob to 3-5 minutes to complete the warm-up operation
of the machine.
2.After the preheating is completed,
hold the top of the machine with
one hand, and pull the barrel out
by holding the handle of the
barrel with the other hand.The
barrel must be placed on a
stable table.
3.Put the ingredients on the
bakware in the fried barrel.
4.Push the fryer into the machine, select the corresponding cooking
temperature and time by the knob, and cook and heat the ingredients.
Note: When the drum is not fully advanced, the micro-switch is not triggered, the
machine is in the state of power off the barrel, and it will not work. At this time,
you only need to fully push the drum.
Tips For Fried basket
When assembling Fried basket and fried barrel,the sound of metal duckles proves
that the assembly is in place.
Figure 3

6
Handle with care and remember to lay it flat on the table to avoid being
burned by steam or dumping the fryer, or burned by oil or hot food. In
the process of removing food, it is recommended to use auxiliary tools
(such as chopsticks) to assist.
Tips For Timer
If you set the scale within 30 degrees(about 10
mins）from the OFF position,roll to more than
30 degrees and then adjust to the required scale.
Settings
This table below helps you to select the basic settings for the ingredients you
want to prepare.
Note: Keep in mind that these settings are indications. As ingredients differ
in origin, size, shape as well as brand, we cannot guarantee the best setting
for your ingredients.
Instructions for use
This button is only used to pull out or insert the inner barrel when
it is cold. When cooking, the button and its surrounding are very
hot , please don't touch !
Menus Temperature Time(min.)
Defrost 80 5-10
Frozen fries 180 15-17
Chicken wing 180 15-19
Chicken legs 180 20-24
Meat 200 10-14
Shrimp 180 8-12
Fish 180 13-17
Cake 180 8-10
5.After the timer “ding”, the heating is completed. When
the food is ready, unplug it.Take out the fryer
carefully, lay it flat on the table, and then use the
auxiliary tools (such as chopsticks) to remove the
cooked food.

7
smoke or odor may appear during the dry burning process, which is normal.
Do not panic.
in place to avoid malfunction.
our service department immediately.
machine, and avoid using them separately.
before moving.
avoid the damage of the coating due to the erosion of food residue oil.
your health.
to clean the air fryer, to prevent water from entering the air fryer, which may
cause short circuit and fire.
air fryer, otherwise it may cause damage and affect the use.
clean the bakeware or fried basket and fried barrel to prevent scratching t
Warm reminder
Cleaning and maintenance
fried basket is
fried basket

fire
