Service Manual
Vacuum Cleaner
VCS35B15KC
Midea LOGO

Contents
1Specifications…………………………………………………………1-2
2 Electrical Diagram…………..…………………………….…………..3
3 Schematic Diagram……………………………..…………………….4
4 Repair of Main Parts…………………………………….……………5
5 Trouble Shooting Chart……………………………………..…….10
6 Replacement Parts List…………………………………………….11
7 Packing Instruction……………………………………………….…12
(备注：黄色部分根据实际机型调整)

Follow caution information wherever you see this symbol.
1．Spcifications
Model
VCS35B15KC
Power Source
AC220V~240V,50/60Hz
Motor Power Max.
700W
Air Power
≥120W
Dust Capacity
1.2L
Cord Length
5M
Weight(Main Body)
6Kg
Mimension(WxLxH)
360*247*305
Attachments
Multi Surface Floor Nozzle,
Hose,Extension Wand
2.Electrical Diagram

3．Schematic Diagram
见爆炸图
4 Repair of Main Parts
4.1 Upper、Lower Body、Motorcover、Protector、
Rewinder、Hose
Removing
1
3. 4.
2
5．
Remove the 7 screws from the
body. Then take the middle
cover away.
Remove the screws（pointing
out）from the motorcover. Then
take the motor cover and
rewinder away.
Remove the screw from the
middlecover. Then take the
airinlet cover away.
Rewinder
frame
Plug
Remove the 3 screws inside of
the motorcover. Then take the
motor away.

5 Trouble Shooting Chart
Trouble
Possible Causes
Countermeasure
The vacuum cleaner can
not start operation
1.The plug is not plugged in
2.The power switch didn't open.
3.Internal wiring of loose
4.The motor burned out
1.Re plug
2.Press the power switch
3.Re connect the internal
wiring
4.Repair or replacement of the
new machine
The suction become
smaller
1.The channel blocked suction
head
2. Poor ventilation dust bag
3. Air inlet and
outlet filter blocked
4. Motor problems
1.Clean the suction
head channel
2.Clean up the dust bag
3.Cleaning filter
4. Repair replacement of
the motor
Full dust indicator of
adverse action
1. The dust suction channel block
2. The buoy stuck
3. Spring is broken
1.Clean up the dust absorption
channel
2. Repair full dust indicator
3. Repair full dust indicator
6 Replacement Parts List
No.
Part Name
Part Code
Specs.
QTY
1
AIRINLET HEPA
1
2
CORD REWIND
ASSEMBLY
According to the
power cord
1
3
AIROUT HEPA
-
1
4
AIROUTLET PLATE
Color！
1
5
SWITCH
According to the
1
Pull the entire plug out smoothly
and press the rewinder frame to
take all the cord in to test whether it
works well.

required Specification
6
Hose
Color！
1
7
Main Brush
Color！
1
8
Plastic Tube
-
1
9
Wires
-
1
10
Protector
According to the
required Specification
1
7 Packing Instruction
