Midea VCS38A13L Administrator Guide

Jiangsu Midea Cleaning Appliances Co.,Ltd
No.39 Caohu Avenue, Xiangcheng Economic
Development Zone, Suzhou , Jiangsu Province, 215131, P.R.C
http://www.midea.com/global
VACUUM CLEANER
OPERATION INSTRUCTIONS MANUAL
VCS38A13L
Please read this Instruction Manual carefully before operating, and keep it properly.
Contents Safety Introduction
Product Introduction
Product Operation
Product Maintenance
Trouble Shooting
2
4
32
6
8
11
Safety Introduction
1. Do not place the vacuum cleaner close to heat
sources, radiation, or burning cigarette, Do not use
the appliance to remove the following objects:
- All liquids such as water and solvents.
- Lime, cement, ash and other construction dust
and garbage.
- Hot objects, such as cigarette butts.
- Sharp objects, such as glass shards, etc.
- Inflammable and explosive articles, such as gaso
line or alcohol products.
2. Do not let children play with or operate the vacuum
cleaner to prevent accidents.
3. Your vacuum cleaner is an electric appliance: It
must be used appropriately.
4. Do not leave the operating vacuum cleaner
unattended.
5. The power must be turned off during cleaning,
maintenance or when in storage.
6. Do not pull the power plug to turn off the vacuum
cleaner. Hold the plastic part of the plug to remove
it from the power socket.
7. The power supply voltage must correspond to that
of the vacuum cleaner charging voltage.
8. Keep the power cord away from sharp objects to
prevent it from being damaged.
9. To prevent fires do not immerse the vacuum
cleaner in water, do not expose it to any heating
appliances.
10. Do not drag the power cord when moving the
charging station.
11. In the case of below situations do not use the
vacuum cleaner and send it immediately to the
nearest approved maintenance facility if:
- The vacuum cleaner fell and consequently
damaged.
- The power cord is damaged.
12. Stop operating the vacuum cleaner if the suction
inlet is blocked to prevent damages (such as
overheating) to the motor or deformations to the
vacuum plastic parts occasioned by overheating
motor.
13. Do not press the dust cup button during handling
to prevent the machine from falling off.
45
Product Introduction
Main Body
Dust Cup
1
2
3Hose
Extension Tube
Combination Tool
4
5
6
Main Brush
4
5
1
3
2
6
Note: all parts are assembled in the direction of the arrow, and the combination of the suction
brush and the small can be used directly in the pipe or metal tube.
67
Product Operation
Product use
1
Press the ON/OFF button:
Control the start and stop of the vacuum cleaner.
02.
03. Press the receiving button:
the power line is automatically rolled back into the fuselage.
Caution
Please slowly take up the cord, to avoid the power cord or power plug bruising human body
or furniture in the process of taking up.
Pull
04. Machine dismantlement:
Dust cup, main body, air sea and air cover can be disassembled, convenient to clean and
replace with loss accessories.
23
Dust cup
Main body
Air sea Air cover
Pull out the power cord to connect the power supply:
When you see the red mark on the power cord, do not pull out the cord outward.
01.
Brush use:
Press the pedal button and the bristles will stick out.
05.
Composite brush use:
According to the direction of arrow, 45 ° rotating brush out.
06.
Attachment:
The attachment can be used as follows.
07.
Bristles stick out
Press
89
Product Maintenance
Dust cup maintenance
Open the dust cup:
Lift the lid on the release button to open the lid, then take out the internal parts.
01.
Remove the filter cotton cleaning:
After opening the dust cup, the filter cotton shall be cleaned.
02.
Product Maintenance
Dust cup cleaning
01.
Remove the
dust cup
Dump garbage: Gently push the dust button and dump the garbage.
02.
Push
Push
Remove the dust cup: Press the dust bucket release button, gently pull the dust bucket
handle, then remove the dust bucket.
Clean the filter cotton
Remove and clean the filter core:
Put the filter up and wash the filter under the tap.
03.
10
In case of malfunction, please refer to the following table
TROUBLESHOOTING
If the problem still can’t be solved, please contact local service center.
Solution
- Reinsert the plug
- Check the circuit breaker
- Press the machine's power switch
- Unplug the plug and wait for the thermal protector
to recover
- Clean up the stemming
- Timely clean up garbage
- Clean the filter cotton
The vacuum
cleaner does not
work
Possible reason
- The main brush or accessories are clogged
- Dust in the dust barrel is too full
- Dust in the dust cup filter cotton is too much
Suction becomes
weaker
Problem
- The power plug is not properly plugged into
the socket
- No electricity on the power socket
- The vacuum cleaner switch is not turned on
- Motor thermal protector acts
11
Install the filter core:
After cleaning, put the filter into the dust cup and notice the direction of the arrow.
04.
Caution
1. The filter parts can be put back for use only after being cleaned and dried. It is recommended
to have sun exposure for 24 hours to ensure it is thoroughly dried.
2. All parts must be ensured to be properly installed, otherwise it will cause product failure.
3. Water is not allowed to penetrate into the vacuum cleaner electrical components, or otherwise
may cause product failure.
Load the filter cotton.
05.
Note the arrow direction
