Service Manual
Vacuum Cleaner
VCB42A3670G

Contents
1Specifications……………………………………………………………1
2 Electrical Diagram…………..…………………………….…………..1
3 Schematic Diagram……………………………..…………………….2
4 Repair of Main Parts…………………………………….……………3
5 Trouble Shooting Chart………………………………………..…….4
6 Replacement Parts List……………………………….………….….4
7 Packing Instruction………………….……………………….…….…5

Follow caution information wherever you see this symbol.
1 Spcifications
Model
VCB42A3670G
Power Source
AC120V,60Hz
Motor Power Max.
1200W
Air Power
170W
Dust Capacity
2.65
Cord Length
6 meters
Weight(Main Body)
3.19kg
Mimension(WxLxH)
275*300*525mm
Attachments
Crevice Tool/2 in 1 brush
2 Electrical Diagram

3 Schematic Diagram

4 Repair of Main Parts
Removing
1
3
2
4
Open the front cover and take out
the dust bag .Put the unit on the
desk.
Remove all the screws on the
back of body.
Take the body away from the machine
gently.
Remove the power cord and wires.
Remove the motor adjust ring and
motor press plate .And then remove
the motor assembly.

5 Trouble Shooting Chart
6 Replacement Parts List
No.
Part Name
Part Code
Specs.
QTY
1
Hose Assembly
12175000064401
L:2000
1
2
Crevice Tool
12175000064388
L:201
1
3
Brush Assembly
12175000064400
L:70.2
W:35.8
H:92.8
1
4
Dust Bag
12475000004507
L:267
W:170
1
5
Nozzle Assembly
12175000064386
L:266.5
W:123.2
H:53.7
1
PROBLEM
POSSIBLE
PROBLEM
Countermeasure
The vacuum cleaner is
plugged in but does not
work
Power cord/ plug damage
Check the power cord and plug for
signs of damage.
The thermostat is open.
Wait the temperature goes down
and turn on the unit again.
The suction is decreasing
and the vacuum is not
picking up dirt
Dust bag.
Check if the dust bag is full, if so,
change another new one.
The hose is blocked.
Clean the hose.
Can’t push or pull on some
carpet
Air control.
Rotate the air control button and
try again.

7 Packing Instruction
Step1. Put nozzle,crevice tool,dust bag to the bottom of the carton
Step2. Put the inner cover into the carton
Step3. Put the unit into the carton
Step4. Put the tube and hose into the carton
Step5. Package the carton.
