Miele DA 6798 W User manual

Operating and Installation Instructions
Ventilation Hood
To prevent accidents and damage to the appliance, you must read
these instructions before installing the appliance and using it for the first
time.
en-US M.-Nr. 10 931 390

Contents
2
IMPORTANT SAFETY INSTRUCTIONS ................................................................ 4
Caring for the environment ................................................................................ 13
Guide to the appliance........................................................................................ 14
Description of functions ..................................................................................... 16
Before using for the first time ............................................................................ 17
Selecting extraction mode or recirculation mode.................................................. 17
Setting up Miele@home ........................................................................................ 17
Connecting via the app .................................................................................... 18
Connecting via WPS ........................................................................................19
Signing out of WiFi (reset to factory settings) ..................................................20
Setting up Con@ctivity .......................................................................................... 21
Con@ctivity via the home WiFi network (Con@ctivity 3.0) ...............................22
Con@ctivity via a direct WiFi connection (Con@ctivity 3.0) .............................22
Con@ctivity with direct wireless connection (Con@ctivity 2.0) ........................23
Operation (Automatic mode).............................................................................. 27
Cooking with Con@ctivity (Automatic mode) ........................................................ 27
Temporarily exiting Automatic mode..................................................................... 29
Resuming Automatic mode..............................................................................29
Operation (Manual mode) ................................................................................... 30
Cooking without Con@ctivity (Manual mode) ....................................................... 30
Turning on the blower............................................................................................ 30
Selecting the power level ...................................................................................... 30
Selecting the delayed shutdown time ................................................................... 30
Turning off the blower............................................................................................ 30
Dimming/switching the overhead lighting on/off................................................... 31
Power management .............................................................................................. 31
Safety shut-off....................................................................................................... 32
Operation (Automatic and Manual modes) ....................................................... 33
Filter saturation indicator....................................................................................... 33
Adjusting the filter saturation indicator for the grease filters............................ 33
Adjusting or deactivating the filter saturation indicator for the charcoal filter.. 34
Checking the filter saturation indicator.............................................................34
Energy-saving tips............................................................................................... 35
Cleaning and care ............................................................................................... 36
Stainless steel housing.......................................................................................... 36
Grease filter ........................................................................................................... 37

Contents
3
OdorFree Charcoal Filter ....................................................................................... 39
Resetting the filter saturation indicator for the charcoal filters......................... 40
Disposing of charcoal filters ............................................................................. 40
Installation............................................................................................................ 41
Before installation.................................................................................................. 41
Removing the protective film................................................................................. 41
Installation Instructions ......................................................................................... 41
Installation parts .................................................................................................... 42
Appliance dimensions ........................................................................................... 44
Distance between cooktop and ventilation hood (S)............................................. 45
Installation recommendations ............................................................................... 46
Drilling diagram for wall mounting......................................................................... 46
Plywood backing................................................................................................... 47
To install a plywood backing ................................................................................ 47
Air venting ............................................................................................................ 48
Condensate trap.................................................................................................... 49
Electrical connection .......................................................................................... 50
Service and warranty .......................................................................................... 51
Location of the data plate ..................................................................................... 51
MieleCare .............................................................................................................. 51
Technical data..................................................................................................... 52
Optional accessories for recirculation mode......................................................... 52

IMPORTANT SAFETY INSTRUCTIONS
4
READ AND SAVE THESE INSTRUCTIONS
This appliance complies with current safety requirements.
Improper use of the appliance can lead to personal injury and
material damage.
Read all instructions before installing or using the appliance for the
first time. Only use the appliance for its intended purpose.
Keep these operating instructions in a safe place and pass them
on to any future user.
Appropriate use
 CAUTION: For General Ventilating Use Only. Do Not Use To
Exhaust Hazardous Or Explosive Materials And Vapors.
 This appliance is intended for residential use only. Use only as
described in these operating instructions.
 This ventilation hood is not intended for outdoor use.
 It must only be used to extract and clean vapors produced during
cooking. Any other use occurs at the owner's own risk.
 Where a recirculation ventilation hood is installed above a gas
cooktop, please ensure that there is an adequate supply of fresh air
into the room in which it is installed. Please seek the advice of a
qualified gas fitter if necessary.
 This appliance is suitable for installation above gas or electric
cooking surfaces.
 Persons who lack physical, sensory or mental abilities, or
experience with the appliance should not use it without supervision
or instruction by a responsible person.

IMPORTANT SAFETY INSTRUCTIONS
5
Safety with children
 As with any appliance, close supervision is necessary when used
by children.
 Please supervise children in the vicinity of the hood and do not let
them play with it.
 The LED ClearView lighting is very intense.
Ensure that especially babies/small children don't look into the light.
 Danger of suffocation! Ensure that any plastic wrappings, bags,
etc. are disposed of safely and kept out of the reach of children.
Technical safety
 WARNING: TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK,
OR INJURY TO PERSONS, OBSERVE THE FOLLOWING:
– Use this appliance only in the manner intended by the
manufacturer. If you have questions, contact Miele.
– Before servicing or cleaning the appliance, switch power off at the
service panel and lock the service disconnecting means to
prevent power from being switched on accidentally. If the service
disconnecting means cannot be locked, securely fasten a
prominent warning device, such as a tag, to the service panel.
 Unauthorized installation, maintenance, and repairs can cause
considerable danger for the user. Installation, maintenance, and
repairs must only be carried out by a Miele authorized technician.
 A damaged ventilation hood can be dangerous. Always check for
visible signs of damage. Never use a damaged ventilation hood.
 Be certain your appliance is properly installed and grounded by a
qualified technician. To guarantee the electrical safety of this
appliance, continuity must exist between the appliance and an
effective grounding system. It is imperative that this basic safety
requirement be met. If there is any doubt, have the electrical system
of the house checked by a qualified electrician.

IMPORTANT SAFETY INSTRUCTIONS
6
 Reliable and safe operation of this hood can only be guaranteed if
it has been connected to the electrical supply.
 To avoid damaging the ventilation hood, make sure that the
connection data (voltage and frequency) on the data plate
correspond to the building's power supply before connecting the
appliance.
If in doubt, consult a qualified electrician.
 Do not use a power bar or extension cord to connect the
ventilation hood to electricity. These are a fire hazard and do not
guarantee the required level of appliance safety.
 To ensure safe operation, only use the ventilation hood after it has
been properly installed.
 This ventilation hood may not be used in non-stationary locations
(e.g. on a ship).
 Adequate ventilation must be provided when the hood is operated
simultaneously with devices that burn gas or other fuels.
 Only open the housing as described in the enclosed “Installation
diagram” and in the “Cleaning and care” section of this manual.
Under no circumstances should any other parts of the housing be
opened.
Tampering with electrical connections or components and
mechanical parts is highly dangerous to the user and can cause
operation faults.
 Defective components should be replaced by Miele original parts
only. Only with these parts can the manufacturer guarantee the
safety of the appliance.
 If the power cord is damaged, it must only be replaced by a
qualified service technician.

IMPORTANT SAFETY INSTRUCTIONS
7
 During installation, maintenance, and repair work, the ventilation
hood must be disconnected from the electrical supply. It is only
completely isolated from the electricity supply if one of the following
applies:
– The circuit breakers on the electrical service panel are tripped.
– The screw-type fuses on the electrical service panel have been
removed.
– The power cord (if present) has been unplugged from the socket
(pull the plug not the cord).
Correct use
 WARNING: TO REDUCE THE RISK OF A COOKTOP GREASE
FIRE:
– a) Never leave surface units unattended at high settings. Boilovers
cause smoking and greasy spillovers may ignite. Heat oils slowly
on low or medium settings.
– b) Always turn the hood on when cooking at a high heat.
– c) Clean the ventilation hood frequently. Grease should not be
allowed to accumulate on the fan or filter.
– d) Use the proper pan size. Always use cookware appropriate for
the size of the cooking area.
 Never use an open flame beneath the ventilation hood.
To avoid the risk of fire, do not flambé or grill over an open flame.
When turned on, the ventilation hood will draw any flames into the
filter. Fat deposits may ignite.
 WARNING: TO REDUCE THE RISK OF INJURY TO PERSONS IN
THE EVENT OF A COOKTOP GREASE FIRE, OBSERVE THE
FOLLOWING*:
– a) SMOTHER FLAMES with a close fitting lid, cookie sheet, or
metal tray then turn off the burner. BE CAREFUL TO PREVENT
BURNS. If the flames do not go out immediately, EVACUATE AND
CALL THE FIRE DEPARTMENT.

IMPORTANT SAFETY INSTRUCTIONS
8
– b) NEVER PICK UP A FLAMING PAN - You may be burned.
– c) DO NOT USE WATER, including wet dishcloths or towels - a
violent steam explosion will result.
– d) Use a fire extinguisher ONLY if:
– 1) You have a class ABC extinguisher, and you know how to operate it.
– 2) The fire is small and contained in the area where it started.
– 3) The fire department is being called.
– 4) You can fight the fire with your back to an exit.
*Based on “Kitchen Fire Safety Tips” published by NFPA.
 The ventilation hood may become damaged if exposed to
excessive heat from a gas cooktop.
– When using the ventilation hood over a gas cooktop, ensure that
any burners in use are always covered by cookware. Turn burners
off when removing the cookware, even if doing so for just a short
time.
– Select cookware that is suitable for the size of the burner.
– Adjust the flame so that it never extends up the sides of the
cookware.
– Avoid overheating the cookware (e.g., when cooking with a wok).
 Always turn the ventilation hood on whenever a burner is in use to
prevent damage from condensation.
 Overheated oil and fat can ignite, causing fire damage to the
ventilation system.
Do not leave cookware, pans, and deep fryers unattended when
cooking with oil or fat. Similarly, never leave an open grill unattended
when grilling.
 Fat and debris deposits impair the proper functioning of the
ventilation hood.
To ensure that cooking vapors are properly cleaned, never use the
ventilation hood without the grease filters in place.

IMPORTANT SAFETY INSTRUCTIONS
9
 Please note that the heat rising from the stovetop during cooking
can cause the ventilation hood to become very hot.
Do not touch the housing or the grease filters until the ventilation
hood has cooled down.

IMPORTANT SAFETY INSTRUCTIONS
10
Proper installation
 WARNING: TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK,
OR INJURY TO PERSONS, OBSERVE THE FOLLOWING:
– a) Installation work and electrical wiring must be done by qualified
person(s) in accordance with all applicable codes and standards,
including fire-rated construction.
– b) Sufficient air is needed for combustion and exhausting of gases
through the flue (chimney of fuel burning equipment to prevent
back drafting. Follow the heating equipment manufacturer’s
guideline and safety standards such as those published by the
National Fire Protection Association (NFPA) and the American
Society for Heating, Refrigeration and Air Conditioning Engineers
(ASHRAE), and the local code authorities.
– c) When cutting or drilling into the wall or ceiling, do not damage
electrical wiring and other hidden utilities.
– d) Ducted hoods must always be vented to the outdoors.
– e) Do not use this hood with any solid-state speed control device.
 To determine whether a ventilation hood may be operated above
your cooking appliance, please refer to the information provided by
the appliance's manufacturer.
 Safety regulations prohibit the installation of a ventilation hood
over solid fuel stoves.
 An insufficient safety distance between the cooktop and the
ventilation hood can result in damage to the ventilation hood.
The minimum safety distances between the top of the cooktop and
the bottom of the ventilation hood given in the “Installation” section
of this booklet must be observed, unless the cooktop manufacturer
states that a greater safety distance is required.
If more than one cooking appliance is installed beneath the
ventilation hood, and they have different minimum safety distances
to the ventilation hood, select the greater distance.

IMPORTANT SAFETY INSTRUCTIONS
11
 Be sure to observe the information contained in the “Installation”
section when mounting the ventilation hood.
 Metal parts can have sharp edges which may cause injury.
Wear gloves to protect your hands from being cut.
 When installing the exhaust duct, only use pipes or tubes made of
non-flammable material. These can be obtained from your Miele
dealer or from Miele Technical Service.
 Exhaust air should not be vented into a chimney or vent flue which
is otherwise in use and should not be channeled into ducting which
ventilates rooms with fuel-burning installations.
 If exhaust air is to be extracted into a chimney or ventilation duct
no longer used for other purposes, seek professional advice.
 WARNING: TO REDUCE THE RISK OF FIRE USE ONLY METAL
DUCTWORK.

IMPORTANT SAFETY INSTRUCTIONS
12
Cleaning and maintenance
 There is a risk of fire if cleaning is not completed according to the
instructions in this manual.
 Never use a steam cleaner to clean the ventilation hood.
The steam can reach the electrical components and cause a short
circuit.
Accessories
 Use only genuine original Miele parts. If parts or accessories from
other manufacturers are used, the warranty will become void.
FCC Declaration of Conformity
 These devices comply with FCC Rules Part 15. This equipment
has been tested and found to be in compliance with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules of
Operation and is subject to the following conditions:
These devices may not cause harmful interference.
These devices must accept any interference received, including
interference that may cause undesired operation.
FCC Radiation Exposure Statement
 This equipment complies with FCC radiation exposure limits set
forth for an uncontrolled environment. This equipment should be
installed and operated with minimum distance 8" (20 cm) between
the radiator and your body.
Industry Canada Statement
 This digital apparatus does not exceed the Class B limits for
Radio Noise Emissions from digital apparatus set out in the Radio
Interference Regulations of the Canadian Department of
Communications.
Complies with Canadian ICES-003 Class B specifications.

Caring for the environment
13
Disposal of the packing
material
The cardboard box and packing
materials protect the appliance during
shipping. They have been designed to
be biodegradable and recyclable.
Ensure that any plastic wrappings,
bags, etc. are disposed of safely and
kept out of the reach of children.
Danger of suffocation!
Disposal of your old appliance
Electrical and electronic appliances
contain valuable materials. They also
contain certain substances, compounds
and components which were essential
for the proper functioning and safe use
of the equipment. Handling these
materials improperly by disposing of
them in your household waste can be
harmful to your health and the
environment. Therefore, please do not
dispose of your old appliance with
regular household waste and follow
local regulations on proper disposal.
Consult with local authorities, dealers or
Miele in order to dispose of and recycle
electrical and electronic appliances.
Miele assumes no responsibility for
deleting any personal data left on the
appliance being disposed. Please
ensure that your old appliance is kept
away from children until removal.
Observe safety requirements for
appliances that may tip over or pose an
entrapment hazard.

Guide to the appliance
14

Guide to the appliance
15
aFold-down canopy
bDADC 6000 canopy
Available as an optional accessory for concealing ducting to the ceiling.
cCharcoal filter
Optional accessory for recirculation mode
dOverhead cooktop lighting
eControl panel
The symbols act as sensor buttons. You select the functions by pressing these
buttons. You will hear a brief beep as confirmation.
fGrease filter
gExhaust air connection
Extraction ducting can be directed through the back of the ventilation hood or
upwards to the ceiling.
hSensor button for turning the blower on and off
iSensor button for the overhead lighting
jSensor buttons for blower power selection
kSensor button for delayed shutdown function
lFilter saturation indicator for the grease filter
mFilter saturation indicator for the charcoal filter

Description of functions
16
The following functions are available on
your ventilation hood, depending on the
model:
Vented mode
Air entering through the intake is
cleaned by the grease filters and
conducted out of the building.
Non-return flap
A non-return flap in the ducting
prevents the exchange of inside and
outside air from occurring when the
ventilation hood is not in use.
The flap is closed when the ventilation
hood is turned off.
When the ventilation hood is turned on,
the non-return flap opens so that the
exhaust air can be transported outside
without any obstruction.
A non-return flap has been provided
with the hood in case your ducting does
not have one. It is inserted into the
outlet duct collar of the fan.
Recirculation mode
(Recirculation mode ventilation hoods
require charcoal filters. These are
available as optional accessories: see
“Technical Data”)
Air entering through the intake is first
cleaned by the grease filters and then
by a charcoal filter. The cleaned air is
then recirculated back into the kitchen.

Before using for the first time
17
Selecting extraction mode or
recirculation mode
The ventilation hood can be operated
with either extraction mode or
recirculation mode. The power of the
blower is adapted to suit the selected
mode of operation. The ventilation
hood is set up at the factory for
recirculation mode. It has to be reset
for extraction mode.
To reset it for extraction mode, the filter
saturation indicator for the charcoal
filter(s) has to be deactivated.
Switch off the blower and the lighting.
Touch the delayed shutdown
control and the charcoal filter
control at the same time.
The charcoal filter symbol and one of
the blower power level indicators will
flash.
Touch the B control.
Confirm your choice by touching the
charcoal filter control.
All the indicator lights will go out.
Extraction mode has now been set.
If the new setting is not confirmed
within 4minutes, the ventilation hood
will revert to the previous setting.
Setting up Miele@home
Prerequisite:
– Home WiFi network
Your ventilation hood is equipped with
an integrated WiFi module. The
ventilation hood can be connected to
the household WiFi network.
You will then be able to operate the
ventilation hood via the Miele@mobile
app.
If your Miele cooktop is connected to a
home WiFi network, you can control the
ventilation hood automatically via the
Con@ctivity function.
Before installing the ventilation hood
in its final location, ensure that the
signal of your WiFi network is strong
enough.
Please note that you cannot set up a
WiFi connection at the same time as
the wireless Con@activity 2.0 system.

Before using for the first time
18
Miele@mobile App
The Miele@mobile App is available to
download free of charge from the Apple
App Store® or from the Google Play
Store™.
Connecting via the app
The Miele@mobile app can be used to
connect to your network.
Install the Miele@mobile app on your
mobile device.
To log in you will need:
1. Your WiFi network password
2. Your ventilation hood password
The password for your ventilation hood
consists of the last nine digits of the
serial number. This can be found on the
appliance's data plate.
The data plate is visible once you have
removed the grease filter.
Start signing the appliance on in the
app. Follow the signing in
instructions.
If requested to activate WiFi on the
ventilation hood, proceed as follows:

Before using for the first time
19
Switch the ventilation hood off.
Press and hold the B control.
Touch the lighting control at the
same time.
2 will light up constantly, 3 will flash on
and off.
The ventilation hood is ready for
connection in the next two minutes.
Follow the instructions in the app.
When successfully connected, 2 and 3
will light up constantly.
Quit connection mode on the
ventilation hood by touching the
delayed shutdown control.
The ventilation hood can now be
operated via the app.
Connecting via WPS
Your WiFi router must support WPS
(WiFi Protected Setup).
Switch the ventilation hood off.
Press and hold the B control.
Touch the lighting control at the
same time.
2 will light up constantly, 3 will flash on
and off.
The WiFi connection must be started on
the ventilation hood at the same time as
on the WiFi router.
Press the B control on the ventilation
hood after a few seconds.
After a short while, 2 will light up
constantly, and 3 and B will flash on
and off.
The ventilation hood is ready for
connection in the next two minutes.

Before using for the first time
20
Start the WiFi connection on your
WiFi router.
When successfully connected, 2 and 3
will light up constantly.
Quit connection mode on the
ventilation hood by touching the
delayed shutdown control.
The ventilation hood can now be
operated via the app.
If the connection fails, you have
probably not connected WPS to your
router quickly enough. Repeat the steps
above.
Tip: If your WiFi router does not support
WPS, please connect via the
Miele@mobile app.
Signing out of WiFi (reset to factory
settings)
To set up a new WiFi connection, the
existing WiFi connection must be
disconnected.
Switch the ventilation hood off.
Press and hold the 1 control.
Touch the lighting control at the
same time.
With an existing WiFi connection, 2 and
3 will light up constantly.
The ventilation hood is ready for
disconnection during the next two
minutes.
