mikroElektronika Flip&Click PIC32MZ User manual

click boards™ meet Arduino

I want to express my thanks to you for being interested in our products and for
having confidence in MikroElektronika.
The primary aim of our company is to design and produce high quality electronic
products and to constantly improve the performance thereof in order to better
suit your needs.
To our valued customers
Nebojsa Matic
General Manager

Page 3
Table of Contents
Introduction to Flip&Click 4
1. What’s on board? 5
2. Programming Flip&Click 6
Using Flip&Click with Arduino IDE
Using Flip&Click with mikroC, mikroBasic
and mikroPascal
4. Red side 9
5. USB ports 10
6. White side 11
7. click boards™12
8. Schematic 13

Page 4
Flip&Click PIC32MZ is a two-sided development board with a split personality. It can be
used whit chipKIT core (Arduino-style development environment), but it can also be used
with mikroC, mikroBasic and mikroPascal.
With more than 300 bite-sized click boards™ to pick from (and more coming out every
week), anything goes. All sorts of sensors, transceivers, encoders, displays, connection
ports are at your disposal. Separate communication lines allow for thousands of click board
combinations, with no need for unsightly stacking or wire jumping. Flip&Click PIC32MZ is a
perfect sidekick for your adventures in Maker land.
A maker’s sidekick

Page 5
1. What’s on board?
System specification
1mikroBUS™socket (one of 4)
2Reset button
3LED (one of 4)
1USB/UART port
2host/device USB port
3Signal LEDs
4PIC32MZ2048EFH100 MCU
5Arduino pinout
624 MHz Crystal oscilator
7PICkit 3 connector
8mikroProg connector
power supply
via USB cable
(5V DC)
board dimensions
73 x 73 mm
(2.87 x 2.87 inch)
weight
30 g (0.066 lbs)
mikroBUS™
4 sockets
1
3
4
6
5
5
5
5
2
13
2
7
8

Page 6
Using Flip&Click with Arduino IDE (chipKIT core)
1) Plug in Flip&Click PIC32MZ (use the USB-UART port between C and D socket).
2) Launch Arduino IDE
3) From within the Arduino IDE, go to File->Preferences dialog box. Look at the text entry field called
“Additional Boards Manager URLs:” .If that text entry field is blank, then you can just copy/paste the following
URL into that text field https://github.com/chipKIT32/chipKIT-core/raw/master/package_chipkit_index.json
.Then click OK to close the Preferences dialog box.
4) If that field is not blank, then click the little box icon to the right of the text field, and copy/paste the
URL https://github.com/chipKIT32/chipKIT-core/raw/master/package_chipkit_index.json onto the next line of
the text entry field. Arduino lets you have as many different cores as you want loaded into the IDE as long as
each URL is on a separate line. Click OK to close the Additional Boards Manager URLs dialog box and then click
OK again to close the Preferences dialog box.
2. Programing Flip&Click PIC32MZ

Page 7
5) Now select the Tools->Board->Board Manager menu from the Arduino IDE, and it will open up the
Boards Manager window. From there, scroll down until you see the chipKIT board. Click once on any of the text
in the chipKIT section, and you will see a button appear that says “Install”. It will take some time to download
all of the chipKIT components and install them, but when it’s done, you can click the Close button to close the
Board Manager window.
6) Now choose a Mikroelektronika Flip N Click MZ board from the Tools -> Board menu and program
your Flip&Click board!
7) Start writing Arduino sketches.

Page 8
We made several examples to show off the
potentials of Flip & click and click board™
combinations. All the code is available on
MikroElektronika’s GitHub channel. Keep visiting the
link, as more code will be added in the future:
www.github.com/mikroe/Flip_n_Click_Examples
Using Flip&Click with mikroC
1) Plug in Flip&Click PIC32MZ (use the USB port between A and B socket).
2) Start mikroC PRO for PIC32
3) Write your code
4) Start mikroElektronika USB HID bootlader
(see our bootloader Learn article: https://learn.mikroe.com/mikrobootloader/)
5) Download your code on MCU.

Page 9
DIGITAL
(~PWM)
PINS
POWER
PINS
ANALOG
PINS
4. Red side
On the red side, Flip&Click
PIC32MZ features a standard
Arduino pinout, which makes
it compatible with a range of
Arduino shields. All the pins
operate on 3.3V logic, just like
with Arduino Due.
The four LEDs are the same as
on Arduino Due. From left to
right: indicating power supply
(PWR), signaling programming
is in progress (TX, RX), and one
connected to MCU pin 43 (L).
Arduino
pinout

Page 10
host/device USB port
The USB/UART is for programming
the board, in case you use the
chipKIT bootloader. And the
host/device USB port is for
programming in case you use
mikroE bootloader. So, depending
on what project you are working
on, you can set the board to be a
USB device or a host.
USB/UART
port
5. USB ports

Page 11
6. White side
On the white side, Flip&Click
PIC32MZ has four mikroBUSTM
sockets along with four LEDs and
a reset button. The silkscreen
markings clearly denote which
microcontroller pins are used on
each socket. The pinout provides
both 3.3V and 5V power supplies.

Page 12
7. click boards™
click boards™
Buzzer, Relays, WiFi, RFid, GSM,
GPS, OLED, Speech recognition
— you name it, we got it! There
are more than 300 click boards™
available. Many of the chips on
clicks already have their own
Arduino libraries you can reuse.
More and more will be coming
out in the future. See them all,
on: shop.mikroe.com/click

Page 13
8. Schematic
1
2
3
4
5
ID
D+
D-
VBUS
GND
CN1
USB MICRO
FB3
C11
10nF
DZ1 DZ2
USBD_N
USBD_P
C12
10µF
R14
10k
SW 6
VIN 5
EN 4 FB
3GND
2BOOST
1
U4
LM2734YMK
C2
10µF
R1
10k
VIN
C3
10µF
D2
PMGER3010ER
C1
10nF
L1
3.3µH
C4
10µF
VCC-5V
R3
10k
D1
CD1206-S01575
R2
52.3k
VCC-5V
AN
RST
CS
SCK
MISO
MOSI
3.3V
GND
PWM
INT
RX
TX
SCL
SDA
5V
GND
VCC-3.3V VCC-5V
A
AN
RST
CS
SCK
MISO
MOSI
3.3V
GND
PWM
INT
RX
TX
SCL
SDA
5V
GND
VCC-3.3V VCC-5V
B
AN
RST
CS
SCK
MISO
MOSI
3.3V
GND
PWM
INT
RX
TX
SCL
SDA
5V
GND
VCC-3.3V VCC-5V
D
AN
RST
CS
SCK
MISO
MOSI
3.3V
GND
PWM
INT
RX
TX
SCL
SDA
5V
GND
VCC-3.3V VCC-5V
C
VO 3
GND
2
VIN 1
U3
LD29080DT33R
C5
10µF
VCC-5V
FB1
C6
10µF
VCC-3.3V
VCC-3.3VVCC-3.3V
VDDANA
VDDANAVCC-3.3V
FB2
C8
10µF
C9
0.1µF
C23
0.1µF
C24
0.1µF
C25
0.1µF
C26
0.1µF
C27
0.1µF
C28
0.1µF
C29
0.1µF
VCC-3.3VVCC-3.3VVCC-3.3VVCC-3.3VVCC-3.3VVCC-3.3VVCC-3.3V
USBD_N
USBD_P
C22
0.1µF
VCC-3.3V
VBUS
UART1_RX
UART1_TX
UART2_TX
UART2_RX
UART3_TX UART3_RX
UART4_TX
UART4_RX
UART5_TX UART5_RX
SPI1_SCK
SPI1_SS0
SPI1_MISO SPI1_MOSI
SPI2_SCK
SPI2_SS0
SPI2_MISO
SPI2_MOSI
SPI3_SCK SPI3_SS SPI3_MISO SPI3_MOSI
I2C1_SCL
I2C1_SDA
I2C5_SCL
I2C5_SDA
I2C2_SCL
I2C2_SDA
OC4
OC3
OC6
OC8
AN1
AN2
AN3
AN4
AN5
AN6
AN7
AN8
AN9
AN10
INT0
INT1 INT2 INT3
INT4
FM1 FM2 FM3 FM4
1
2
3
4
5
6
7
8
9
10
11
12
13
14 15
16
17
18
19
20
21
22
23
24
25
26
27
28
TXD
DTR#
RTS#
VCCIO
RXD
RI#
GND
NC
DSR#
DCD#
CTS#
CBUS4
CBUS2
CBUS3
CBUS0
CBUS1
OSCO
OSCI
TEST
AGND
NC
GND
GND
VCC
RESET#
3V3OUT
USBDM
USBDP
FT232RL
U2
FT232RL
C13
0.1µF
VCC-3.3VVCC-3.3V
C14
0.1µF
C15
0.1µF
VCC-3.3VVCC-3.3V
VCC-3.3V
USB_TX
USB_RX
R4
2.2k
R5
2.2k
VCC-3.3VVCC-3.3V
UART5_TX
UART5_RX
U2_USBD_N
U2_USBD_P
FT232_RST
R6
4.7k
R11
10k
FT232_RST
1
2
3
4
5
ID
D+
D-
VBUS
GND
CN2
USB MICRO
FB4
C17
10nF
VCC-5V
DZ3 DZ4
U2_USBD_N
U2_USBD_P
U2_VCC-USB
U2_VCC-USB
1
2
3
4
5
6
7
8
J3
HF 1x8
1
2
3
4
5
6
7
8
J2
HF 1x8
1
2
3
4
5
6
7
8
9
10
J1
F1X10
1
2
3
4
5
6
J4
HF 1x6
RST
VIN
VCC-3.3VVCC-5V
RST
I2C5_SCL
I2C5_SDA
LD3
R10
470
VCC-3.3V
C10
10µF
C18
10µF
R16 27
R17 27
R27 27
R33 27
R34 27 R35 27
R9
27 R8
27 R7
27
RESET
RST
R15
10k
VCC-3.3V
PGC PGD
C7 0.1µF
RST
T2
T1
UART3_TX
UART3_RX
UART4_TX
UART4_RX UART1_RX
UART1_TX UART2_TX
UART2_RX
I2C1_SCL
I2C1_SDA
I2C2_SCL
I2C2_SDA
I2C1_SCL
I2C1_SDA
I2C2_SCL
I2C2_SDA
INT1 INT2INT3INT4
SPI1_SCK
SPI1_MISO
SPI1_MOSI
SPI1_SCK
SPI1_MISO
SPI1_MOSI
SPI2_SCK
SPI2_MISO
SPI2_MOSI
SPI2_SCK
SPI2_MISO
SPI2_MOSI
AN1
AN2
AN3
AN4
AN5
AN6
SPI3_SCK
SPI3_MISO
SPI3_MOSI
UART5_TX
UART5_RX
AN7 AN8AN9AN10
R18 1k
OC4 OC3OC7OC6
OC1
OC5
OC8
OC2
OC9
OC2
OC9
INT0
RST1 RST2RST3RST4
RST1 RST2 RST3 RST4
SPI2_SS0 SPI1_SS0SPI2_SS1 SPI1_SS1
SPI2_SS1
SPI1_SS1
SPI3_SS
R30
10k
R31
10k
VCC-3.3V
R37
10k
R39
10k
VCC-3.3V
BTN1
BTN2
BTN2
BTN1
GPIO1
GPIO2
GPIO1
GPIO2
R12 27
R13 27
R19 27
R20 27
LEDA LEDB LEDC LEDD
LEDA
LEDB
LEDC
LEDD
R29
1k
R32
1k
R36
1k
R38
1k
LEDA
LEDB
LEDC
LEDD
L
R28
1k
SPI3_SCK
VCC-3.3V
RST
PGD
PGC
OC1 OC5
STANDBY
1
GND
2OUT3
VCC 4
Y1
24MHz
C19
0.1µF
VCC-3.3V
4
5
6
1
2
3
J5
ICSP
30
29
28
27 34
33
58
57
56
55
54
53
52
46
36
35
42
43
44
45
37
50
9
48
49
11
12
32
72
69
68
67
66
65
64
63
4
3
78
77
24
23
18
17
16
15
14
13
5
6
7
8
10
79
80
1
2
22
21
20
19
62
61
60
59
38
39
40
41 47
71
31
51
70
26
25
76
75
74
73
100pin LQFP
81
82
83
84
85
86 87
88
89 90
91 92
93 94
95 96
97
98
99 100
RB13 RB12
RE7
RC1
RC2
RC3
RD10
RD9
RA15
RF3
RB15 RB14
VUSB3V3
VSS
D-
D+
VSS VDD
RE0
RA7 RA6
VDD
RG0
RG1
RE6
RE5
RE2
RG13
RG12
RG14
RE1
VSS
RG8
RB2
RB3
RB4
RB5
RE9
RE8
RD0
RD11
VBUS
RF5
VDD
RG7
RG6
RA1
RE3
RE4
RG15
RA5
RB0
RB1
RC12/OSC1 RC15/OSC2
RA14
RA3
RD14 RD15
RF2
RF13 VDD
RF8
RA4
RF1
RA0
RG9
MCLR
VSS RF12
RA2
RF4
VSS
RC4
VDD
VSS
RC13
RD3
RD1
RC14
VDD
VSS
RD2
RD12
RD13
RD4
AVSS AVDD RB9 RB8 RB10 RB11 RB7 RA9 RB6 RA10
RD5
VDD
VSS
RF0
PIC32MZ
U1
PIC32MZ2048EFH100-I/PF
1
2
3
OUT
GND
IN
5
4
OCEN
U5
TPS2041B
VCC-5V
USB_VBUS
USB_PSW#
R44
10k
VBUS
D3
R40
10k
USB_ID
C21
10µF
VCC-5V
USB_VBUS
R47 1k
VCC-5V
C20
10µF
USB_PSW# USB_ID
R41
10k
VCC-3.3V
USB_OC1
USB_OC1
32
1
Q1
DMP2160UW-7
D4
4
5
1
2
3
J6
M1X5
RST
PGD
PGC
VCC-3.3V
OC7

Page 14
DISCLAIMER
All the products owned by MikroElektronika are protected by copyright law and international copyright treaty. Therefore, this manual is to be treated as any
other copyright material. No part of this manual, including product and software described herein, may be reproduced, stored in a retrieval system, translated or
transmitted in any form or by any means, without the prior written permission of MikroElektronika. The manual PDF edition can be printed for private or local use,
but not for distribution. Any modification of this manual is prohibited. MikroElektronika provides this manual ‘as is’ without warranty of any kind, either expressed or
implied, including, but not limited to, the implied warranties or conditions of merchantability or fitness for a particular purpose. MikroElektronika shall assume no
responsibility or liability for any errors, omissions and inaccuracies that may appear in this manual. In no event shall MikroElektronika, its directors, officers, employees
or distributors be liable for any indirect, specific, incidental or consequential damages (including damages for loss of business profits and business information,
business interruption or any other pecuniary loss) arising out of the use of this manual or product, even if MikroElektronika has been advised of the possibility of such
damages. MikroElektronika reserves the right to change information contained in this manual at any time without prior notice, if necessary.
HIGH RISK ACTIVITIES
The products of MikroElektronika are not fault – tolerant nor designed, manufactured or intended for use or resale as on – line control equipment in hazardous
environments requiring fail – safe performance, such as in the operation of nuclear facilities, aircraft navigation or communication systems, air traffic control,
direct life support machines or weapons systems in which the failure of Software could lead directly to death, personal injury or severe physical or environmental
damage (‘High Risk Activities’). MikroElektronika and its suppliers specifically disclaim any expressed or implied warranty of fitness for High Risk Activities.
TRADEMARKS
The MikroElektronika name and logo, mikroC™, mikroBasic™, mikroPascal™, Visual TFT™, Visual GLCD™, mikroProg™, Ready™, MINI™, mikroBUS™, EasyPIC™, EasyAVR™,
Easy8051™, click™boards and mikromedia™are trademarks of MikroElektronika. All other trademarks mentioned herein are property of their respective companies.
All other product and corporate names appearing in this manual may or may not be registered trademarks or copyrights of their respective companies, and are only
used for identification or explanation and to the owners’ benefit, with no intent to infringe.
Copyright © 2017 MikroElektronika. All Rights Reserved.

If you want to learn more about our products, please
visit our web site at www.mikroe.com. If you are
experiencing some problems with any of our products
or just need additional information, please place your
ticket at helpdesk.mikroe.com. If you have any questions,
comments or business proposals, do not hesitate to
contact us at offi[email protected]

Mouser Electronics
Authorized Distributor
Click to View Pricing, Inventory, Delivery & Lifecycle Information:
Mikroe:
MIKROE-2340
