BeneVision N22/N19/N17/N15/
N12
Quick Reference Guide

Note: The BeneVision N22/N19/N17/N15/N12 Quick
Reference Guide is not intended as a replacement to the
Operating Instructions. This document is a guideline only
to be used as an aid to comprehensive Inservice Training.

QUICK KEYS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
GESTURES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
PATIENT SETUP. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Admit Patient And Enter Demographics (Manual Entry) . . . . . . . . . . . . . . . . . . . .4
Enter Demographics from the CMS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Enter Demographics from the ADT Database. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Discharge a Patient . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
STANDBY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Enter Standby. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Resume Monitoring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Realtime Waveforms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Adjust Recorder’s Waveforms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
PRINT. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Realtime Waveforms (Laser printer connection required) . . . . . . . . . . . . . . . . . . .8
Adjust Printed Waveforms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
End Case Report . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
ECG. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Adjust ECG Lead . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Enable Pacemaker Detection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Initiate ECG Relearn . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Initiate ST Analysis . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Initiate QT Analysis . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Selecting Leads for QT Calculation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Initiate and Print a 12-lead ECG Report. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
NIBP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Initiate A Non-Invasive Blood Pressure Measurement (NIBP) . . . . . . . . . . . . . . .11
Table of Contents

Stop Non-Invasive Blood Pressure Measurement (NIBP) . . . . . . . . . . . . . . . . . . .11
Set A Non-Invasive Blood Pressure Measurement Interval . . . . . . . . . . . . . . . . .12
Configure A Custom Sequence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Factors that Affect Blood Pressure Measurement Accuracy. . . . . . . . . . . . . . . . .13
INVASIVE BLOOD PRESSURES (OPTIONAL) . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Adjust Invasive Blood Pressure Label. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Zero Invasive Blood Pressure. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
15
CONTINUOUS CARDIAC OUTPUT (OPTIONAL) . . . . . . . . . . . . . . . . . . . . . . . 16
Adjust the Displayed Parameters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
CENTRAL VENOUS OXYGEN SATURATION (OPTIONAL) . . . . . . . . . . . . . . . 16
Print Oxygenation Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
BISPECTRAL INDEX (OPTIONAL) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Adjust BIS Waveform Area . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
BIS Expand View (Bilateral Sensor Required). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Adjust Parameters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
ALARMS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Setting Parameter Alarm Properties . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Changing Arrhythmia Alarm Settings(Arrhythmia Option Required) . . . . . . .18
Disable Non-Lethal Arrhythmia Alarms (Arrhythmia Option Required). . . . . .19
Accessing Help When Technical Alarms Occur . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
RESET ALARMS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
PAUSE ALARMS/PAUSE ALARM TONES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
HEMODYNAMIC MONITORING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Initiate A Cardiac Output Measurement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Initiate Pulmonary Artery Wedge Pressure (PAWP) . . . . . . . . . . . . . . . . . . . . . . . . .22
Table of Contents (cont'd)

Initiate Hemodynamic Calculations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
SCREEN DISPLAY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
REVIEW . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Tabular Trends . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Arrhythmia and Alarm Events. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Full Disclosure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
OxyCRG. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
VIEWING OTHER BEDS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Entering the Remote View Screen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Adding a Bed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Resetting Alarms for Remote Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Removing a Bed. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Saving a Manual Event . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Displaying the Alarm Watch Tile on the Main Screen. . . . . . . . . . . . . . . . . . . . . . .28
VOLUMES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Alarm Volume. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Key Volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
Beat Tone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
DATE AND TIME . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
PARAMETER COLORS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
LOAD DEFAULT (PRESET) SETTINGS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
LOCK/UNLOCK TOUCHSCREEN DISPLAY . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
PAIR THE TM80 TELEMETRY MONITOR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Pair the TM80 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
Unpair the TM80 Telemetry Monitor from the N Series Bedside Monitor . . . .32
Unpair the N Series Bedside Monitor from the TM80 Telemetry Monitor . . . .32
Table of Contents (cont'd)

PAIR BP10 NIBP MODULE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Pair the BP10 Module with the N Series Bedside Monitor . . . . . . . . . . . . . . . . . .33
Unpair BP10 Module from the N Series Bedside Monitor . . . . . . . . . . . . . . . . . . .33
CLEANING/DISINFECTING. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Cleaning the Main Unit/Module/SMR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
Disinfecting the Main Unit/Module/SMR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
Cleaning and Disinfecting the Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
STERILIZATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Changes made from the N Series bedside monitor effecting the BeneVision Central
Monitoring System and changes made from the BeneVision Central Monitoring
System effecting N Series bedside monitor are indicated with the symbol.
Table of Contents (cont'd)

1
BeneVision N22/N19/N17/N15/N12 Quick Reference Guide
QUICK KEYS
Main Menu
Opens the main menu.
More
Shows more quick keys.
Alarm Setup
Opens the Alarm dialog.
Alarm Reset
Acknowledges alarms.
Audio Pause
Pauses alarm tone.
Alarm Pause
Pauses the current
and future alarms for a
preconfigured time.
Review
Opens Review dialog for the
patient’s historical data.
Standby
Opens Standby mode.
Patient Management
Opens the Patient
Management dialog.
Screen Setup
Opens the Screen Setup
dialog.
NIBP Start/Stop
Starts an NIBP measurement
or stops the current NIBP
measurement.
Stop All
Stops all NIBP
measurements.
NIBP
Starts NIBP STAT
measurement.
NIBP Measure
Opens the NIBP Measure
dialog.
Zero IBP
Zeros all IBPs.
C.O. Measure
Starts cardiac output
procedure.
PAWP
Opens the PAWP screen.
Loops
Opens the respiratory
Loops screen.

2
BeneVision N22/N19/N17/N15/N12 Quick Reference Guide
Venipuncture
Opens the Venipuncture
dialog.
Start TOF
Starts/stops TOF
measurement.
Parameters Setup
Opens the Parameters Setup
dialog.
Remote View
Opens the split-screen
view of another patient(s).
Manual Event
Triggers a manual event.
Minitrends
Opens the Minitrends
screen.
OxyCRG
Opens the OxyCRG screen.
ECG Full- Screen
Opens the 12-lead ECG full
screen.
Privacy Mode
Enters the privacy mode.
Night Mode
Enters the night mode.
CPB Mode
Enters the CPB mode.
Intubation Mode
Enters the intubation
mode.
Volume
Opens the Volume dialog.
Freeze
Freezes waveforms.
Calculations
Opens the Calculations
dialog.
Load Config
Opens the Load
Config dialog to load
preconfigured settings.
Print
Initiates a real-time report.
Record
Starts/Stops a recording.

3
BeneVision N22/N19/N17/N15/N12 Quick Reference Guide
Unit
Opens the Unit dialog.
Rotate Screen (for N22/
N19)
Changes the screen
orientation (between
portrait and landscape).
ECG Lead/Gain
Opens the ECG Lead/Gain
dialog.
Call Help
Calls for help.
HemoSight
Opens the HemoSight
dialog.
EWS
Opens the EWS screen.
GCS
Opens the GCS dialog.
SepsisSight
Opens the SepsisSight
dialog.
Enters the Discharged
Patients dialog.
ECG 24h Sum
Views the 24-hour ECG
summary.
Discharge Patient
Opens the Discharge Patient dialog to discharge the patient and
restore default settings.

4
BeneVision N22/N19/N17/N15/N12 Quick Reference Guide
GESTURES
The following gestures on the touchscreen are enabled:
Swipe down the touchscreen with two fingers to access the
Discharge Patient dialog box.
Swipe from left to right on the touchscreen with two fingers to
change the screen from normal screen, to minitrends screen, to
big numerics screen, to normal screen.
Swipe from right to left on the touchscreen with two fingers to
change the screen from normal screen, to big numerics screen, to
mini trends screen, to normal screen.
PATIENT SETUP
Admit Patient And Enter Demographics (Manual Entry)
The Patient Management dialog allows the clinician to admit a patient and enter
patient demographics. Admitting also restores default (preconfigured) settings
and clears the previous patient’s information.
After a patient is manually discharged, the monitor automatically admit a new
patient. To manually admit a patient on the N Series bedside monitor:
a. The monitor prompts to admit a new patient in the following situations:
• After being switched o for the selected time period*, the monitor
automatically discharge the previous patient and admit a new patient at
startup.
• If the monitor has not detected certain patient vital signs (ECG, SpO2, PR,
RR, NIBP) for 30 minutes, the clinician will be prompted to admit a new
patient once continuous monitoring is detected.
*Time period configurable.
b. To open the Patient Management dialog:
• Select the patient information area at the top left corner of the screen.
• Select the Patient Management quick key.

5
BeneVision N22/N19/N17/N15/N12 Quick Reference Guide
• Select the Main Menu quick key, and select Patient Management
from the Patient Management column.
• Select Patient Management from the discharge screen.
c. Select Patient Category and select OK to confirm.
d. Select patient field(s) and enter patient information as required using the
onscreen keyboard.
e. Select button to accept the information.
f. Select OK to confirm and return to the main screen.
Note: If the patient’s barcode is scanned, the medical number and associated
information is entered into the monitor.
Enter Demographics from the Central Monitoring System (CMS)
If the N Series bedside monitor is connected to the CMS, entering patient
information at the CMS will enter the patient information into the N Series
bedside monitor. In addition, entering demographic information into the N
Series monitor will automatically enter information into the CMS.
Enter Demographics from the ADT Database
If the N Series bedside monitor is connected to a hospital’s ADT server the patient
demographic information can be imported into the N Series bedside monitor. To
import patient information from the Hospital’s ADT server:
a. Enter the Find Patient dialog in either of the following ways:
• Select the Main Menu quick key, and select Find Patient from the
Patient Management column.
• Select Find Patient from the Patient Management dialog.
b. Verify the ADT tab is selected.
c. Enter search field such as patient ID.
d. Select Search to display a list of the search results.
e. Select a patient from the patient list.
f. Select adjacent to the patient information N Series bedside monitor to
import that patient’s information and return to patient management.

6
BeneVision N22/N19/N17/N15/N12 Quick Reference Guide
g. Select OK to confirm and return to the main screen.
Note: Find patient from the ADT server is only enabled if ADT Query is
supported.
Note: Loading patient information from the ADT server updates only patient
information in the N Series bedside monitor. The patient’s monitoring data is
unaffected.
Discharge a Patient
The Discharge function clears all patient information and restores default
(preconfigured) settings.
• Swipe down the touchscreen with two ngers, and select Discharge to
conrm.
• Select the Discharge Patient quick key, and select Discharge to
conrm.
• Select the Patient Management quick key, and select Discharge
Patient.
• Select the Main Menu quick key, and select Discharge from the
Patient Management column.
• Select Discharge patient from the standby screen.
And select Discharge to confirm.
STANDBY
Enter Standby
The Standby function allows the clinician to suspend monitoring on a patient.
While in standby, the patient is not being monitored; however, all data and
settings are preserved.
To place a patient into Standby on the N Series bedside monitor:
a. Select the Standby quick key.
Or
a. Select the Main Menu quick key, and select Standby from the Patient
Management column.
b. Set Location from the drop down list to define where the patient is when
the monitor enters the standby mode.

7
BeneVision N22/N19/N17/N15/N12 Quick Reference Guide
c. Select OK to confirm.
Resume Monitoring
To remove a patient from Standby and resume monitoring on the N Series
bedside monitor, select Resume Monitor.
Once a patient is discharged the monitor automatically enters the Standby
mode. To resume monitoring select Resume Monitor.
RECORD
Realtime Waveforms
To record a waveform on a patient with the recorder:
• Press the hardkey on front of the recorder.
• Select at the top left corner of a currently opened dialog if available.
• Select Record quick key.
Adjust Recorder’s Waveforms
To adjust recorded waveforms on a patient with the recorder:
a. Select Main Menu quick key.
b. Select Record Setup from the Report column.
c. Select Waveform 1.
d. Select the desired waveforms from drop down list or select off to turn off
the waveform recording.
e. Repeat steps c and step d for remaining waveforms as necessary.
f. Select the Main Menu quick key or to return to the main display.
PRINT
Realtime Waveforms (Laser printer connection required)
To print a real time report for a patient on the N Series bedside monitor:
a. Select quick key.
Or
a. Select Report Setup from Main Menu quick key.
b. Select Realtime Reports tab.

8
BeneVision N22/N19/N17/N15/N12 Quick Reference Guide
c. Select Print.
Adjust Printed Waveforms
To adjust the waveforms printed for a patient on the N Series bedside monitor:
a. Select the Main Menu quick key, and select Report Setup from the
Report column.
b. Select Realtime Reports tab.
c. Select Current Waveforms.
d. Select Print.
To print selected waveforms for a patient on the N Series bedside monitor:
a. Select the Main Menu quick key, and select Report Setup from the
Report column.
b. Select Realtime Reports tab.
c. Select Selected Waveforms.
d. Select the desired waveforms to add/delete from the selected list.
e. Select to return to the previous page
f. Select Print.
End Case Report
The following reports can be set as end case reports:
• ECG Report
• Realtime Report
• Tabular Trends Report
• Graphic Trend Report
If Print End Case Report are enabled, the N Series bedside monitor will
automatically print the selected reports when a patient is discharged.
To set reports to print as an End Case Report:
a. Select the Main Menu quick key, and select End Case Report from the
Report column.
b. Select the desired report tab.
c. Enable Set As End Case Report.

9
BeneVision N22/N19/N17/N15/N12 Quick Reference Guide
d. Select the Main Menu quick key or to return to the main display.
ECG
Adjust ECG Lead
The N Series bedside monitor allows the clinician to adjust the leads being
viewed on the main display. To adjust the ECG Lead:
a. Select the ECG numeric area or waveform area to enter the ECG dialog.
b. Select the Setup tab.
c. Set Lead Set according to the lead type you will be used.
d. Select ECG1 to adjust first lead.
e. Repeat step d or remaining displayed leads.
f. Select the Main Menu quick key or to return to the main display.
Enable Pacemaker Detection
The N Series bedside monitor allows the clinician to enable pacemaker detection.
The symbol is displayed when the pacemaker detection is enabled.
To enable the pacemaker detection on the N Series bedside monitor:
a. Select the ECG numeric area or waveform area to enter the ECG dialog.
b. Select the Pacer tab.
c. Set Paced to Yes.
d. Select the Main Menu quick key or to return to the main display.
Initiate ECG Relearn
To initiate ECG relearning manually on the N Series bedside monitor:
a. Select the ECG numeric area or waveform area to enter the ECG dialog.
b. Select Relearn at the bottom left corner of the dialog.
c. Select the Main Menu quick key or to return to the main display.
Initiate ST Analysis
To initiate ST analysis on the N Series bedside monitor:
a. Select the ECG numeric area or waveform area to enter the ECG dialog.
b. Select the ST tab.

10
BeneVision N22/N19/N17/N15/N12 Quick Reference Guide
c. Select the Setup tab.
d. Enable ST Analysis.
e. Select the Main Menu quick key or to return to the main display.
Initiate QT Analysis
To enable the QT monitoring on the N Series bedside monitor:
a. Select the ECG numeric area or waveform area to enter the ECG dialog.
b. Select the QT tab.
c. Select the Setup tab.
d. Enable QT Analysis.
e. Select the Main Menu quick key or to return to the main display.
Selecting Leads for QT Calculation
To select one lead or all leads for QT calculation:
a. Select the QT numerics area, ECG numeric area, or ECG waveform area to
enter the ECG dialog.
b. Select the QT tab.
c. Select the Setup tab.
d. Set QT Leads.
e. Select the Main Menu quick key or to return to the main display.
Initiate and Print a 12-lead ECG Report
To perform a Resting 12-lead ECG Analysis on the N Series bedside monitor:
a. Select the ECG Full-Screen quick key.
b. Select Setup to enter patient information or adjust Report options.
c. Select Analyze.
d. Select Print to print out the 12-lead ECG report.
Or
a. Select the ECG numeric area or waveform area to enter the ECG dialog.
b. Select the Setup tab.
c. Verify Lead Set to 12-Lead.

11
BeneVision N22/N19/N17/N15/N12 Quick Reference Guide
d. Select 12-Lead button.
e. Select Setup to enter patient information or adjust Report options.
f. Select Analyze.
g. Select Print to print out the 12-lead ECG report.
NIBP
Initiate A Non-Invasive Blood Pressure Measurement (NIBP)
To initiate a NIBP measurement:
a. Press the NIBP Start/Stop quick key.
Or
a. Select NIBP tile on the main screen to access the NIBP dialog.
b. Select Start NIBP.
c. Select the Main Menu quick key or to return to the main display.
Stop Non-Invasive Blood Pressure Measurement (NIBP)
To stop the current NIBP measurements,
a. Press the NIBP Start/Stop quick key during the NIBP measurement.
Or
a. Select NIBP tile on the main screen to access the NIBP dialog.
b. Select Stop NIBP.
c. Select the Main Menu quick key or to return to the main display.
To stop all NIBP measurements on a patient on the N Series bedside monitor:
a. Press the Stop All quick key.
Or
a. Select NIBP parameter area to access the NIBP dialog.
b. Select Stop All.
c. Select the Main Menu quick key or to return to the main display.
Select NIBP Start Mode
Start mode defines how NIBP auto mode works. To set the start mode,
a. Select the NIBP tile on the main screen to enter the NIBP dialog.

12
BeneVision N22/N19/N17/N15/N12 Quick Reference Guide
b. Set Start Mode.
• Clock: after the first measurement, the monitor automatically
synchronizes NIBP automatic measurements with the real time clock.
• Interval: after the first measurement, the monitor automatically repeats
measurements at set interval.
c. Select the Main Menu quick key or to return to the main display.
Set A Non-Invasive Blood Pressure Measurement Interval
The N Series bedside monitor allows the clinician to set a pre-configured interval
for a NIBP measurement to be obtained automatically. To set an automatic
interval on the N Series bedside monitor:
a. Select the NIBP Measure quick key.
b. Select the desired interval.
Or
a. Select NIBP tile on the main screen to access the NIBP dialog.
b. Select Interval to select the desired interval from the dropdown list.
• Intervals include: 1 min, 2 min, 2.5 min, 3 min, 5 min, 10 min, 15 min,
20 min, 30 min, 1 h, 1.5 h, 2h, 3h, 4h, 8h: The monitor automatically
measures NIBP based on the specified time interval.
• Select Sequence to automatically measure NIBP based on the sequence
customized by the user in the Sequence tab.
c. Select the Main Menu quick key or to return to the main display.
Configure A Custom Sequence
To configure a custom sequence:
a. Select NIBP tile on the main screen to access the NIBP dialog.
b. Set Interval to Sequence.
c. Select Sequence tab.
d. Set Duration and Interval for each phase in the measurement cycle.
e. Select the Main Menu quick key or to return to the main display.
Factors that Affect Blood Pressure Measurement Accuracy
The accuracy of non-invasive blood pressure (BP) measurement has been shown

13
BeneVision N22/N19/N17/N15/N12 Quick Reference Guide
to be affected by numerous factors. Some of the more important aspects (based
on published literature) to consider while measuring BP are:
• The cuff should fit snugly, but with enough room for two fingers to be
placed between the cuff and the patient’s arm (on adults), and loosely on
neonates with little or no air present within the cuff.
• Use the Guidance Table provided to select the proper size cuff. Too small
a cuff has been shown to result in the overestimation of BP (systolic and
diastolic) while too large a cuff results in the underestimation of BP.
Ensure that the cuff is wrapped directly over the patient’s skin. BP measurement
could be 10 to 40 mmHg higher or lower than actual when the cuff is applied
over clothing.
• The cuff should be applied so that the center of the bladder in the cuff is
over the brachial artery. Use the reference marker for ver.
• For best results, the cuff should be placed on the arm at heart level and
the lower arm supported passively. Published data indicates that BP can
increase about 2 mmHg for every inch that the cuff is below heart level and
decrease by the same amount if above heart level.
• Avoid compression or restriction of the pressure hose. Do not place the NIBP
cuff on a limb that is being utilized for any other medical procedure, for
example, an I.V. catheter.
• Have the patient sit quietly for several minutes before BP measurement and
remain still during measurement to avoid unnecessary motion artifact. If the
patient has not rested before measurement, BP could be elevated by 10 to
20 mmHg.
• Do not talk to the patient during BP measurement as talking has been
shown to result in a 10 to 15 mmHg overestimation of BP.
• The patient’s back and feet should be properly supported with the legs
kept uncrossed. Unsupported back and feet could increase BP by up to 15
mmHg, while crossed legs could result in a 4 to 12 mmHg increase.
• Other factors that have been shown to result in an overestimation of BP are
labored breathing (5 to 8 mmHg), full bladder (10 to 15 mmHg), pain (10 to
30 mmHg).
Guidance Table

14
BeneVision N22/N19/N17/N15/N12 Quick Reference Guide
Cuff Description Limb Circumference
Child 10 - 19 cm
Small Adult 18 - 26 cm
Adult 25 - 35 cm
Large Adult 33 - 47 cm
Thigh 46 - 66 cm
Adult Long 25 - 35 cm
Large Adult Long 33 - 47 cm
References:
1. American Association on Critical-Care Nurses (AACN): Practice Alert,
Non-Invasive Blood Pressure Monitoring (April 2010)- http://www.
aacn.org/wd/practice/docs/practicealerts/non-invasive-bp-monitoring.
pdf?menu=aboutus
2. Pickering Thomas G, Hall John E, Appel Lawrence J, Falkner Bonita E, Graves
John, Hill Martha N, Jones Daniel W, Kurtz Theodore, Sheps Sheldon G,
Roccella Edward J. Recommendations for blood pressure measurement in
humans and experimental animals: Part 1: Blood pressure measurement
in humans: A statement for professionals from the Subcommittee of
Professional and Public Education of the American Heart Association
Council on High Blood Pressure Research. J Hypertens 2005; 45: 142-161.
3. O’Brien Eoin, Asmar Roland, Beilin Lawrie, Imai Yutaka, Mallion Jean-Michel,
Mancia Giuseppe, Mengden Thomas, Myers Martin, Padfield Paul, Palatini
Paolo, Parati Gianfranco, Pickering Thomas, Redon Josep, Staessen Jan,
Stergiou George, Verdecchia Paolo. European Society of Hypertension
recommendations for conventional, ambulatory and home blood
pressure measurement. J Hypertens 2003; 21: 821-848.
INVASIVE BLOOD PRESSURES (OPTIONAL)
The N Series bedside monitor allows a clinician to monitor up to 8 invasive blood
pressures (IBP) simultaneously.
Adjust Invasive Blood Pressure Label
To adjust the label on an invasive blood pressure:
a. Insert IBP Module as needed.
