Minuteman EN750LCD User manual

User's Manual
Para Systems, Inc.
1455 LeMay Dr.
Carrollton, TX 75007
Phone: [phone]
Fax: [phone]
Internet: minutemanups.com
UPS Sizing: sizemyups.com
PN - 34000496 R2
Enspire Series UPS
EN750LCD / EN900LCD

1
1. Introduction 2
2. Controls and Indicators 7
3. Installation 9
4. Operation 12
5. Obtaining Service 15
6. Troubleshooting 16
7. Replacing the Battery 17
8. Specifications 21
9. Limited Product Warranty 23
A1. Declaration of Conformity 24
Table Of Contents

3
2
Thankyouforpurchasingthispowerprotectionproduct. Ithasbeendesigned
and manufactured to provide many years of trouble free service. Please read
this manual before installing your Enspire Series UPS, models EN750LCD,
EN900LCDasitprovidesimportantinformationthatshouldbefollowedduring
the installation and the maintenance of the UPS system allowing you to cor-
rectly set up your system for the maximum safety and performance. Included
is information on customer support and factory service, if it is required. If you
experienceaproblemwiththeUPSsystem please refertotheTroubleshooting
guide in this manual to correct the problem or collect enough information so
that the Technical Support Department can assist you.
CAUTION! Themaximumambientoperatingtemperaturefor this UPS series
is 40°C (“0 ~ 40°C” for Ambient Operation).
ATTENTION! La température ambiante de fonctionnement maximale pour
cettesérie d'onduleursestde40° C("0~ 40° C"pour une opérationambiante).
Theexternalventsandopeningson the UPS are provided for ventilation.
To ensure reliable operation of the UPS and to protect the UPS from over-
heating,these vents and openingsmustnotbe blocked or covered.Donot
insert any object into any of the vents or openings that may hinder the ve-
ntilation.
Installthe UPS system in awellventilatedarea,away from excess moistu-
re,heat,dust,flammablegasorexplosives.
Leaveadequate space (at least 20cm) aroundallsidesofthe UPS system
forproperventilation.
Before usage, you must allow the UPS system to adjust to room temper-
ature (20°C~25°C or 68°F~77°F) for at least one hour to avoid moisture
condensing inside the UPS.
IMPORTANT SAFETYINSTRUCTIONS
SAVE THESE INSTRUCTIONS !
CONSIGNES DE SÉCURITÉ IMPORTANTES
SAUVEGARDEZ CES CONSIGNES!
Chapter 1: Introduction
CAUTION! Toreducetherisk ofelectricalshockin conditionswherethe load equip-
ment grounding cannot be verified, disconnect the UPS from the AC wall outlet
beforeinstalling a computer interface cable. Reconnect the power cord only after
allsignaling connections are made.
ATTENTION! Pour réduire le risque de choc électrique dans une situation où il
n'estpas possiblede vérifierla mise à la terredu matérielde charge,il faut d'abord
débrancher l'onduleur de la prise murale c.a. avant d'installer un câble d'interface
ordinateur. Rebranchezle cordon d'alimentationuniquement aprèsque toutes les
connexions de signalisation aient été établies.
CAUTION! Connectthe UPS toa two pole,three wire, grounded,utility powerAC
walloutlet. The receptacle mustbe connectedto theappropriate branch protection
(circuitbreaker orfuse). Connection toany other type of receptaclemay resultin a
shockhazardandviolatelocal electrical codes. Donotuseextensioncords, adapter
plugs,or surge strips.
ATTENTION! Branchez l'UPS sur une prise murale c.a. de terre bipolaire à trois
fils. La prise de courant doit être connectée au circuit de protection approprié
(disjoncteurou fusible). Uneconnexion à tout autretype de prisepeut entraîner le
risque d'électrocution et enfreindre les codes électriques locaux. N'utilisez jamais
derallonge, d'adaptateur oude limiteur de surtension.
CAUTION! To reduce the risk of electrical shock with the installation of this UPS
equipmentand theconnected equipment, the user mustensure thatthe combined
sum of theAC leakage current does not exceed 3.5mA.
ATTENTION! Pour réduire le risque de choc électrique pendant l'installation de
cet onduleur et du matériel connecté, l'utilisateur doit s'assurer que la quantité de
courant de fuite c.a. ne dépasse pas 3,5 mA.
CAUTION! Toreduce therisk offire, connectonly toa utility power circuit provided
with 20 amperes maximum branch circuit over-current protection in accordance
with the National Electric Code,ANSI/NFPA70.
ATTENTION! Pour réduire les risques d'incendie, faites le raccordement
uniquementsur uncircuit d'alimentation électriqueéquipé d'undispositif deprotec-
tiondesurintensitédecircuit dedérivationdemaximum20 ampères,conformément
au Code national de l'électricité,ANSI/NFPA70.
Veuillez lire ce manuel avant l'installation de l'onduleur modèles EN750LCD,
EN900LCD. Il contient de l'information importante qui doit être respectée au
cours de l'installation et de l'entretien de l'onduleur et des batteries. Cette
informationvous permettra de correctementinstallerlesystèmepour atteindre
sonrendementmaximum en toute sécurité.
CAUTION! This UPS series is ONLYintended to be installed in an indoor tem-
peraturecontrolled environmentthat isfree of conductive contaminants. This UPS
seriesis notintended for use in acomputer roomas defined in the Standardfor the
Protection of Electronic Computer/Data Processing EquipmentANSI/NFPA 75.
ATTENTION! Cette série d'onduleurs est uniquement destinée à être installée
dansunenvironnement intérieuràtempérature contrôlée,exemptde contaminants
conducteurs. La série d'onduleurs ne convient pas pour une utilisation en salle
d'ordinateur comme défini dans la norme pour la Protection des ordinateurs
électroniques/équipementsde traitementde données,ANSI/NFPA75.

5
4
NOTE: TheseUPSsareshippedwiththebatteriesdisconnected. Thebatter-
ies must be connected before putting these UPSs into service. Refer to Sec-
tion 3 "Installation" for connecting the batteries.
Thisequipment has been tested and found to complywiththelimitsfor a Class
B computing device in accordance with the specifications in Subpart J of Part
15 of FCC Rules and the Class B limits for radio noise emissions from digital
apparatus set out in the Radio Interference of the Canadian Department of
Communications. Theselimitsaredesignedtoprovidereasonableprotection
against such interference in a residential installation. This equipment gener-
atesandusesradio frequency and if not installed and used properly, that is, in
strict accordance with the manufacturer's instructions, this equipment may
cause interference to radio and television reception. If this equipment does
cause interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
Reorientthereceivingantenna.
Relocatethecomputerwithrespect to the receiver.
Movethe computer away fromthereceiver.
Plugthecomputerintoadifferent outlet so that the computer and receiver
areondifferentbranch circuits.
Shieldedcommunications interface cables must be usedwiththisproduct.
Changes or modifications to this unit not expressly approved by the party
responsiblefor compliance couldvoidthe user's authoritytooperatethe equip-
ment.
ON / OFF BUTTON: To turn the UPS on: press and hold the
On/Off button until the alarm sounds one beep and then re-
lease. Theninaproximately twenty seconds the UPS will per-
form a five second self-test. Once the UPS has passed its
self-test the UPS will be ready for normal operation. To turn
the UPS off: press and hold the On/Off button until the alarm
sounds one beep and then release.
The output of this device is not sinusoidal. It has a total harmonic distortion
andmaximumsingle harmonic as below:
Total harmonic
Model EN750LCD
15.9% EN900LCD
15.6%
Singleharmonic 19.4%15.2%
WARNING: ThisUninterruptible Power Supply containspotentially hazard-
ous voltages. Do not attempt to disassemble the UPS beyond the battery
replacement procedure. This UPS contains no user serviceable parts. Re-
pairs and battery replacement must be performed by QUALIFIED SERVICE
PERSONNELONLY.
AVERTISSEMENT! Cet onduleur contient des tensions potentiellement
dangereuses. N'essayez pas de le démonter au-delà de la procédure de
remplacement de la batterie. L'onduleur ne contient aucune pièce réparable
par l'utilisateur. SEUL UN TECHNICIEN QUALIFIÉ est autorisé à effectuer
lesréparationsetleremplacementd'unebatterie.
WARNING: Qualified Service Personnel ONLY must perform the Installa-
tion and Servicing of these UPS systems. MINUTEMAN accepts no liabilities
and is not limited to: injury to the Service Personnel, or damages to; the UPS,
or the connected equipment caused by the incorrect installation or servicing
of the UPS system.
AVERTISSEMENT! Seul un technicien qualifié peut installer et entretenir
cessystèmes UPS. MINUTEMAN n'accepte aucune responsabilité pour, sans
s'ylimiter:lesblessuressouffertesparlepersonneldeserviceoulesdommages
infligésà l'onduleur ouaumatérielconnecté, résultant d'unemauvaiseinstalla-
tion ou d'un entretien incorrect de l'onduleur.
WARNING: Risk of Electrical Shock. Hazardous live parts inside these
power supplies are energized from the battery even when the AC input is
disconnected.
AVERTISSEMENT! Risquedechocélectrique.Lespartiesactivesdangereuses
àl'intérieur de ces blocs d'alimentationsontsoustension à partir delabatterie,
mêmelorsquel'alimentationc.a.estcoupée.
To de-energize the outputs of the UPS:
1. If the UPS is on press and release the On/Off Button.
2. Disconnect the UPS from theAC wall outlet.
3. To completely de-energize the UPS, disconnect the battery.

7
6
Chapter 2: Controls and Indicators
OutputPower Receptacles
NEMA5-15PW/6ft cord
Model# Input PowerCord
5-NEMA 5-15R Battery Backup &Surge
5-NEMA5-15RSurgeOnly
1. ScrollButton: scroll throughthe UPSparameters thatare availableon theLCD
screen.
2. Battery Backup & Surge output receptacles: Mission critical equipment.
3. Inputcircuit breaker: Protectionagainst an excessiveoverload.
4. LCD: UPS parameters and warnings.
5. On/OffButton: Turns theUPS Onor Off.
6. Inputpower cord: Connectingto Utility Power.
7. Surge-onlyoutput receptacles: Noncriticalequipment.
8. Coaxialconnectors: fortransient voltage surge suppression for cable modem,
CATV converter or DSS receiver.
9. USB Communications Port: UPS monitoring and control.
10.AlarmSilencerButton: Silences the alarmduring the Battery mode.
11.RJ11/45Single line Phone/Network protectionport.
There will be one ECO Master outlet controlling four ECO Controlled outlets. The
ECO Controlled outlets will turn on when the connected load on the ECO Master
outletis greaterthan 12Watts(0.1Amps). Ifthe load onthe ECOMaster outletfalls
below 10Watts the ECO Controlled outlets will turn off. The default setting for the
ECO mode is Disabled. Enable the ECO function by using the power monitoring
software.
EN750LCD
EN900LCD
Life Support Policy
Asageneral policy,wedo not recommend the use of any of our productsin life
supportapplications where failure ormalfunctionofthe product can bereason-
ablyexpected to cause failure of the life supportdeviceortosignificantlyaffect
its safety or effectiveness. We do not recommend the use of any of our prod-
ucts in direct patient care. We will not knowingly sell our products for use in
suchapplicationsunlessPara Systems receives, in writing, assurances satis-
factory to us that (a) the risks of injury or damage have been minimized, (b)
the customer assumes all such risks, and (c) our liability is adequately pro-
tected under the circumstances.
After removing your UPS from its carton, it should be inspected for damage
that may have occurred in shipping. Immediately notify the carrier and place
of purchase if any damage is found. Warranty claims for damage caused by
the carrier will not be honored. The packing materials that your UPS was
shipped in are carefully designed to minimize any shipping damage. In the
unlikely case that the UPS needs to be returned to the manufacturer, please
use the original packing material. Since the manufacturer is not responsible
for shipping damage incurred when the system is returned, the original pack-
ingmaterial is inexpensive insurance. PLEASE SAVE THE PACKING MATE-
RIALS!
Receiving Inspection
© COPYRIGHT 2016 BY PARASYSTEMS, INC.
AllRightsReserved.All rightsof this User Manual(“Manual”),includingbut not
limitedtothe content, information, and figures are solely ownedand reserved
by Para Systems, Inc. (“Para Systems”). The Manual can only be applied to
the operation or the use of this product.Any disposition, duplication, dissemi-
nation, reproduction, modification, translation, extraction, or usage of this
Manual in whole or in part is prohibited without the prior written permission of
Para Systems. Given that Para Systems will continuously improve and de-
velop the product, changes may be made to the information in this Manual at
any time without obligation to notify any person of such revision or changes.
Para Systems will make all possible efforts to secure the accuracy and the
integrity of this Manual. Para Systems disclaims any kinds or forms of war-
ranty, guarantee, or undertaking, either expressly or implicitly, including but
not limited to the completeness, faultlessness, accuracy, non-infringement,
merchantability or fitness for a particular purpose of the Manual.

9
8
INSTALLATION
(QUALIFIEDSERVICE PERSONNELONLY)
Besure to readthe installation placementand all thecautions before installing the
UPS. Place the UPS in the final desired location and complete the rest of the
installationprocedure. These UPSsare shipped withthe internal batteriesdiscon-
nected. The batteries must be connected before putting these UPSs into service.
See Connecting the Battery. The primary installation is the Desktop / Office type.
These UPSs can be wallmounted. The wallmount configuration allows the user to
mountthe UPSon thewall. There isa wallmountkit thatcomes withthe UPS. The
kitincludes the wallmounttemplate andtwo wallmountscrews. See theWallmount
Template forthe wallmountinstallationinstructions.
INSTALLATION PLACEMENT
ThisUPS series isONLYintendedto be installin an indoortemperature controlled
environmentthat isfree ofconductive contaminants. DONOT operatethe UPS in:
extremelydusty and/orunclean areas,locations nearheating devices,water orex-
cessivehumidity,or wherethe UPSis exposedto directsunlight. Select alocation,
whichwill provide good aircirculation for the UPS at all times. Routepower cords
sothey cannot bewalked on ordamaged. Typicalbattery lifeis 3 to 5 years. Envi-
ronmentalfactors doaffect batterylife. High temperatures, poor utilitypower,and
frequent, short duration discharges have a negative impact on battery life. This
UPS series is not intended for use in a computer room as defined in the Standard
forthe Protectionof ElectronicComputer/DataProcessing EquipmentANSI/NFPA
75.
Operating Temperature (Maximum): 0 to 40°C (+32 to +104°F)
Operating Elevation: 0 to 3,000m (0 to +10,000 ft)
Operatingand Storage Relative Humidity: 95%,non-condensing
Storage Temperature: -15 to +50°C (+5 to +122°F)
Storage Elevation: 0 to 15,000m (0 to +50,000 ft)
Chapter 3: Installation
CONNECTING THE BATTERY
(QUALIFIED SERVICEPERSONNELONLY)
Please read all of the WARNINGS and CAUTIONS before attempting to connect
thebattery.
1. Use caution the UPS is heavy. Remove the UPS from the shipping box and
set upside down on a desk or a bench top.
NOTE: No tools are required for removing or installing the battery door.
2. Graspthebattery doorhandle, slidethe batterydooroutward, thenlift up-wards
and set aside. (FIG. 1)
The AC normal icon will be on when the UPS is operating in the
normalAC mode and will turn off when the UPS is operating in the
Batterymode.
The On-Battery icon will turn on when the UPS is operating in the
Battery mode and will turn off when the UPS is operating in theAC
normalmode.
The Warning/Fault icon will turn on when the UPS detects an inter-
nal fault, an Overload, or a Weak/Bad/Disconnected Battery. The
icon will be off when the UPS is operating normally.
TheAlarmSilence icon will bedisplayedwhentheaudible alarm has
been silenced by the Alarm Silencer Button or the monitoring soft-
ware.
UPSParameters:
Input-VoltageandFrequency.
Output-VoltageandFrequency.
EstimatedRuntime(minutes)-ACnormalandBatterymode.
GreenModeIcon-WhentheGreenModeIconison,theUPSisoperat-
ingatits optimumefficiencylevel(>90%).
DualfunctionBarGraph:
LoadCapacityBarGraph:IntheACmodedisplaysthe amountofload
connectedtothe UPS'sBattery Backup& Surgeoutletsas20%,40%;
60%,80%,100%.
BatteryCapacityBarGraph:IntheBatterymodedisplaystheamountof
batterycapacityremainingas20%, 40%;60%, 80%,100%.
TheOn/OffButtonfunctionsasfollows:
Whenthe UPSisin the Offposition,pressand holdtheOn/Off button
untilthealarmsoundsonebeepand thenreleasetoturntheUPSOn.
Whenthe UPSisin the Onposition,pressand holdtheOn/Off button
untilthealarmsoundsonebeepandthenreleaseto turntheUPS Off.
TheScrollButtonallowstheusertoscrollthroughthe UPSparameters
thatareavailableonthe LCDscreen.
WhentheunitisoperatinginBatterymode,pressingtheAlarmSilencer
Buttonwillsilencetheaudiblealarm. OncetheUPSreachestheLBW
(LowBatteryWarning)thresholdthealarmwillstartbeeping. Thealarm
cannotbesilencedduringtheLBWalarm. OncetheUPStransfersback
totheACnormalmode thealarmwill reset backtothe defaultsetting.
NOTE: WiththeexceptionoftheOn-Batteryalarmall theother Warn-
ing/Faultalarmscannotbe silenced.
NOTE: The LCD backlight remains on while the UPS is on.

11
10
CHARGING THE BATTERY
TheUPSwill chargethe internal batterieswhenever theUPSis connectedto anAC
source and there is an acceptableAC voltage present (95 - 140VAC). It is recom-
mendedthat the UPS'sbatteries be charged fora minimum of4 hours before use.
TheUPS maybe usedimmediately however, the“On Battery”runtime maybe less
thannormally expected. Typicalbatterylife is 3 to 5years. Environmentalfactors
doaffectbattery life. Hightemperatures,poor utilitypower,andfrequent shortdura-
tiondischarges have a negativeimpact on battery life. NOTE: Ifthe UPS is going
to be out of service or stored for a prolonged period of time, the batteries must be
rechargedfor atleast twenty-four hoursevery ninetydays.
CONNECTING THE UPS TO AN AC SOURCE
CAUTION! To reducethe riskoffire, connectonlyto autility powered circuitwith 20
amperes maximum branch circuit over-current protection in accordance with the
National Electric Code,ANSI/NFPA70. Plug the UPS into a two pole, three wire,
groundedreceptacleonly. DONOTPLUGTHE UPSINTOEXTENSION CORDS,
ADAPTER PLUGS, SURGE STRIPS OR POWER STRIPS. DO NOT CUT THE
INPUT PLUG OFFANDATTEMPT TO HARDWIRE THIS UPS, DOING SO WILL
VOIDTHEWARRANTY.
ATTENTION! Pour réduire les risques d'incendie, faites le raccordement
uniquementsur uncircuit d'alimentation électriqueéquipé d'undispositif deprotec-
tiondesurintensitédecircuit dedérivationdemaximum20 ampères,conformément
au Code national de l'électricité,ANSI/NFPA70. Branchez l'onduleur uniquement
suruneprisebipolaireàtrois fils miseàlaterre.NEBRANCHEZ PASL'ONDULEUR
SURUNE RALLONGE,UNADAPTATEUR, UNLIMITEUR DESURTENSIONOU
UNE BARRE MULTIPRISES. NE COUPEZ JAMAIS LE CONNECTEUR
D'ENTRÉE POUR TENTER DE CÂBLER CET ONDULEUR; CECI ANNULERA
LAGARANTIE.
PHONE/FAX/NETWORK PROTECTION CONNECTION (OPTIONAL)
Connect a 10/100 Base-T network, single line phone, or fax line to the RJ11/45
modular connectors on the side panel of the UPS. This connection will require
anotherlengthof telephone ornetworkcable. The cablecomingfrom thetelephone
serviceor network systemis connected to the portmarked “IN”. The equipmentto
be protected is connected to the port marked "OUT". NOTE: Connecting to the
Phone/Fax/Networkmodularconnectors isoptional. The UPSworksproperly with-
outthis connection.
3. Slightlypull thebatterymoduleupwardsby pullingthepull-tab.(FIG.2) DONOT
pull the battery module out by pulling on the battery wires.
4. Verifyproperpolarity. Connectthe battery negative (Black) wire to thebattery
negative(Black) terminal.(FIG 2)
NOTE: Some sparking may occur this is normal.
5. Reinstallthebattery module.
6. Reinstallthe batterydoor onto the UPS.
7. Continuewiththe restof theInstallation.
FIG. 1
FIG. 2
CONNECTING YOUR EQUIPMENT
Plugthe mission critical equipment into the BatteryBackup & Surge outputrecep-
tacles on the top panel of the UPS. Plug the noncritical equipment into the Surge
Only output receptacles on the top panel of the UPS. Ensure that the connected
equipment does not exceed the maximum output rating of the UPS (refer to the
information label on the UPS or the electrical specifications in this manual). DO
NOT PLUG EXTENSION CORDS, ADAPTER PLUGS, SURGE STRIPS OR
POWER STRIPS INTO THE OUTPUT RECEPTACLES OF THE UPS, there is a
riskof damaging the UPS and/or connected equipment. DO NOT connecta laser
printer, copier, vacuumcleaner orany otherlarge electrical deviceinto theoutput of
theUPS.
POWER MONITORING SOFTWARE
The EN750LCD and EN900LCD support Minuteman's SentryHD power monitor-
ingsoftware. Pleasego to ourweb site atwww.minutemanups.com/support,then
look under Downloads, and then Software Download Center. Please download
(Freeof Charge) thelatest version of the MinutemanSentryHD software.
COAXIAL PROTECTION CONNECTION (OPTIONAL)
Connecta cablemodem , CATV converter orDSS receiverto the coaxconnectors
onthe sideof theUPS. This connectionwill requireanother coaxcable. The cable
comingfrom thecoax serviceis connectedto theport marked“IN”. The equipment
tobe protected isconnected to theport marked "OUT". NOTE: Connectingto the
coaxialconnectors is optional. TheUPS works properlywithout this connection.

13
12
OVERLOAD
When the amount of load attached to the UPS exceeds its power rating, the Warning/
Fault icon will turn on, the Load capacity bar graph will flash on/off and the alarm will
soundonebeepeveryhalfasecond(AC and Battery modes). This alarm will remain on
untiltheexcessloadisremovedortheUPS’sselfprotectioncircuitshutstheUPSdown.
If the UPS has shutdown, remove part of the load and then press the On/Off button to
turnthe UPS on. The audiblealarm cannot be silencedduring the Overloadalarm.
TURNING THE UPS ON / OFF
To turn the UPS on: press and hold the On/Off button until the alarm sounds one beep
and then release. Then in aproximately twenty seconds the UPS will perform a five
second self-test. Once the UPS has passed its self-test the UPS will be ready for
normaloperation. To turn theUPS off: press andholdthe On/Offbuttonuntil the alarm
soundsonebeepandthenrelease. The UPS will continue to chargethebatterieswhen-
ever it is plugged into a wall outlet and there is an acceptableAC voltage present (95 -
140VAC).
ALARM SILENCER BUTTON
When the unit is operating in Battery mode, pressing the Alarm Silencer Button will
silence the audible alarm. Once the UPS reaches the LBW (Low Battery Warning)
threshold the alarm will start beeping. Once the UPS transfers to the AC mode the
alarm will reset to default. NOTE: With the exception of the On-Battery alarm all the
otherWarning/Fault alarmscannotbe silenced.
SCROLL BUTTON
The Scroll Button allows the user to scroll through the UPS parameters that are avail-
able on the LCD screen.
ALARMS
BATTERYMODE
WhentheUPSis operating in the Batterymode,theACnormaliconwillturnoff,theOn-
Batteryiconwillturnon,theBatteryCapacitybargraphwilldisplaythebattery'scapacity
and the alarm will sound one beep every five seconds. Once the UPS returns to the
normalACmode, thealarmwill stop, the On-Battery iconwillturn offandtheACnormal
iconwill turn on. The audiblealarm can be silencedduring the BatteryMode alarm.
LOW BATTERYWARNING
Whenthebatteriesreachthepredeterminedlevel,thealarmwillsoundtwobeeps every
fiveseconds and theBattery Capacity bargraph will flashoff/on. This information isto
informtheuser that there isapproximatelytwo minutes of runtime remainingbefore the
UPS shuts down. This condition will continue until eitherAC returns or the UPS’s self
protectioncircuitshuts the UPS downtoprotect the battery fromoverdischarging. The
audiblealarm cannot be silencedduring the LBWalarm.
ECO MODE
TheECO mode allowsthe UPS to save energy by automatically turning off designated
outlets when the connected equipment is turned off or in a standby mode. The default
setting for the ECO mode is Disabled. Enable the ECO function by using the power
monitoring software. There will be one ECO Master outlet controlling four ECO Con-
trolledoutlets. The ECO Controlled outletswillturn on whentheconnected load on the
ECO Master outlet is greater than 12Watts (0.1Amps). If the load on the ECO Master
outletfalls below 10Watts the ECOControlled outlets will turn off.
SYSTEM OVERVIEW
This Standby UPS protects computers, servers, telecom systems, VoIP systems,
securitysystems, anda variety of electronic equipmentfrom blackouts,brownouts,
overvoltages, and surges. During normal AC operation, the UPS will quietly and
confidentlyprotect yoursystem from poweranomalies.
The UPS will charge the batteries with the UPS in the on or off position as long as
theUPSispluggedinto thewalloutletandthere is anacceptableACvoltagepresent
(95 - 140VAC). When a blackout, brownout, or an overvoltage condition occurs;
theUPSwill transfertothe batterymode,the OnBattery indicator willilluminate and
theaudiblealarm willsound onceeveryfive secondsindicating that thecommercial
power is lost or unacceptable. When the commercial power returns or is at an
acceptable level, the UPS will automatically transfer back to theAC normal mode
and start recharging the batteries. During an extended outage when there is ap-
proximately two minutes of backup time remaining the audible alarm will sound
twiceevery fiveseconds. This Low BatteryWarningisinforming the userthat they
shouldsave all openfiles, turn off their computer and then turnoff the UPS. When
the batteries reach the predetermined level the UPS will automatically shutdown
protecting the batteries from over discharging. Once the commercial power re-
turns the UPS will automatically restart, providing safe usable power to the con-
nectedequipment and start recharging the batteries.
Chapter 4: Operation
Block Diagram of the Basic Wiring and Internal Circuit Configuration
USB COMMUNICATIONS PORT CONNECTION (OPTIONAL)
TheEN750LCD and EN900LCD support USBcommunications. The power moni-
toring software and interface cable can be used with the UPS. Use only the inter-
facecable that come with theseUPSs. The USB communicationsprotocol is HID.
TheHID USBdriver comesstandard inthe WindowsOS. Simply connect the USB
cableto the USB communicationsport on the side panel of the UPS. Connect the
otherend ofthe USBcable tothe devicethat willbe monitoring/controllingthe UPS
and then follow the prompts on the screen. NOTE: When using the UPS's USB
portwith WindowsXP,7, 8 or10 the Power Options inthe Control Panelmay need
to be configured. Connecting to the Communications Port is optional. The UPS
worksproperly withoutthis connection.

15
14
IF THE UPS REQUIRES SERVICE
Chapter 5: Obtaining Service
1. Use theTroubleshootingsection to eliminate obvious causes.
2. Verify there are no tripped circuit breakers and that the batteries are good.
A tripped circuit breaker and defective batteries are the most common iss-
ues.
3. Call your dealer for assistance. If you cannot reach your dealer, or if they
cannotresolve the issue callorfaxtheTechnicalSupportdepartmentatthe
following numbers; Voice phone [phone], FAX line [phone]
or visit our Web site at www.minutemanups.com the "Discussion Board".
Before calling the Technical Support Department have the following infor-
mationavailable:
a) Contact name and address.
b) Where and when the unit was purchased.
c) All of the model information about your unit.
d) The serial number of your unit.
e) Any information on the failure, including LEDs that may be illuminated
or error codes displayed.
f) A description of the protected equipment including model numbers, if
possible.
g) A technician will ask you for the above information and if possible,
helpsolvethe issue over the phone. In the event that theunitrequires
factoryservice,theTechnical Support Representative will issue you a
Return MaterialAuthorization Number (RMA#). NOTE: We must
have the model number and the serial number of the product to
issue an RMA #.
h) If the unit is under warranty, the repairs will be done at no charge. If
the unit is not under warranty there will be a charge for the repair.
4. Pack the unit in its original packaging. If the original packaging is no lon-
geravailable,asktheTechnicalSupportRepresentativeabout obtaining a
new set. It is important to pack the unit properly in order to avoid damage
in transit. Never use Styrofoam beads for a packing material.
a) Include a letter with your name, address, day time phone number,
RMAnumber, a copy of your original sales receipt, and a brief desc-
ription of the problem.
5. Mark the RMA #on the outside of all packages. The factory cannot accept
any package without the RMA # marked on the outside of the package.
6. Return the unit by insured, prepaid carrier to:
Para Systems Inc.
MINUTEMANUPS
1809 W. Frankford Road, Suite 150
Carrollton,TX75007
ATTN: RMA#_______
ACMode
AudibleAlarm
OFF
Description ACNormal
Icon On-Battery
Icon
OFF
Warning /Fault
Icon
OFF
ON
Battery Mode 1-Beep every
5-seconds
OFF
OFF
LowBattery
Warning 2-Beeps every 5-seconds
ON OFF(Battery
capacity bar graph
will flash off/on)
OFF
OverloadAC
Mode 1-Beep every 0.5-seconds
OFF ON (Load
capacity bar graph
will flash off/on)
ON
ON
Overload
BatteryMode 1-Beep every
0.5-seconds
ON ON
OFF
Weak / Bad /
Disconnected
Battery
3-Beepsevery
5-minutes
OFF(AC Mode) ON(AC Mode)
ON(AC Mode)
InternalFault Constant
Beeping
OFF ON
OFF
The unit is off,
pluggedinto
thewalloutlet
and charging
thebattery
OFF
OFF OFF
OFF
LCD ICONS andALARM FUNCTIONS
WEAK/BAD/DISCONNECTEDBATTERY
TheUPSautomatically tests thebattery’scondition. If the batteryisweak, bad ordis-
connected,theWarning/Faulticonwillturnon,thebargraphframewillflashoff/on,and
the alarm will sound three beeps every five minutes until the battery is either recon-
nected,replacedor passes aself-test. Itis recommended thattheUPS be allowedto
chargeovernightbeforeperforming abatterytesttoconfirmaWeak/BadBatterycondi-
tion. Theaudiblealarmcannot besilencedduringtheWeak/Bad/DisconnectedBattery
alarm.
OFF(Unitoff,
butplugged in) OFF(Unitoff, butplugged in) ON(Unit off, butplugged in)
UPSFAULT
WhentheUPSdetectsaninternalfault,theWarning/Faulticonwillturnonandthealarm
willsoundcontinuously and theoutputwillbe turned off. TheFaultcondition, in some
instances,maybe cleared byturningthe UPS offandthen back onagain. If the Fault
conditiondoesnotcleartheUPSmustbe sent in forservice. SeetheTroubleshooting
section. TheaudiblealarmcannotbesilencedduringtheFaultalarm.
GreenMode OFF
OFF OFF
ON
ECOMode OFF
OFF OFF
ON

17
16
REPLACING THE BATTERY
WARNING! This UPS contains potentially hazardous voltages. Do not at-
tempt to disassemble the UPS beyond the battery replacement procedure.
This UPS contains no user serviceable parts. Repairs and battery replace-
ment must be performed by QUALIFIED SERVICE PERSONNEL ONLY.
AVERTISSEMENT! Cet onduleur contient des tensions potentiellement
dangereuses. N'essayez pas de le démonter au-delà de la procédure de
remplacement d'une batterie. L'onduleur ne contient aucune pièce réparable
par l'utilisateur. SEUL UN TECHNICIEN QUALIFIÉ est autorisé à effectuer
lesréparationsetleremplacementd'unebatterie.
CAUTION: Donotopenormutilatebatteries. Releasedelectrolyteisharmful
to the skin and eyes and may be toxic.
ATTENTION! Évitez d'ouvrir ou d'abîmer les batteries. L'électrolyte qu'elles
contiennent nuit à la peau et aux yeux et peut être toxique.
(QUALIFIEDSERVICEPERSONNELONLY)
CAUTION: Do not dispose of batteries in a fire. The batteries may explode.
The batteries in this UPS are recyclable. Dispose of the batteries properly.
The batteries contain lead and pose a hazard to the environment and human
health if not disposed of properly. Refer to local codes for proper disposal
requirements or return the battery to the supplier.
ATTENTION! N'essayez jamais de vous débarrasser d'une batterie en la
brûlant. Ellerisque d'exploser. Les batteries de cet onduleur sont recyclables.
Éliminez-les de manière appropriée. Les batteries contiennent du plomb et
posentundangerpourl'environnementet lasanté siellesnesontpaséliminées
de façon appropriée. Consultez les codes locaux pour savoir comment
correctement éliminer une batterie ou renvoyez-la au fournisseur.
Please read all of the WARNINGS and CAUTIONS before attempting to ser-
vice the batteries. Typical battery life is 3 to 5 years. Environmental factors
do affect battery life. High temperatures, poor utility power, and frequent,
short duration discharges have a negative impact on battery life.
Chapter 7: Replacing the BatteryChapter 6: Troubleshooting
Symptom / Error Code Cause / What To Do
Pressthe On/Off button and release after onebeep.
UPS will not turn on.
Reset the input circuit breaker by pressing the
plunger back in. If the input circuit breaker trips af-
ter the UPS restarts, reduce the load on the UPS.
UPSoperatesinbattery
modeonly,eventhough
there isAC present.
The AC normal icon is
illuminated,but thereis
nooutput.
Disconnectthecomputercable from the UPS, press
the On/Off button. If UPS works normally, the soft-
ware had control of the UPS.
Charge the batteries for 8-hours and retest. If the
runtimeisstilllessthanexpected,thebatteriesmay
need to be replaced.
UPS does not provide
expectedruntime.
The UPS has an internal problem. Call for service.
The Warning / Fault
icon is illuminated and
the alarm is sounding
continuously.
The Warning / Fault
icon is illuminated, the
Load bar graph is
flashing and the alarm
issounding1-beep ev-
ery 0.5 seconds.
Checkthe specificationsandremove partofthe load.
If the UPS shuts down because of an Overload, re-
movepart of the loadand then press theOn/Off button
toturn theUPS on.
The Warning / Fault
icon is illuminated, the
bar graph frame is
flashing and the alarm
issounding3-beepsev-
ery 5 minutes.
Check the battery connections, charge the batteries
for 8-hours and retest, or replace the batteries.
Low Battery Warning. TheUPS's battery reserve is low. Thiscondition will
continueuntilAC returnsorthe UPSshutsdownfrom
batteryexhaustion.
Fourof the Surge-Only
output receptacles are
off.
The ECO function is controlling the output recep-
tacles. Turn on the equipment that is connected to
theMasterECOoutputreceptacleor DisabletheECO
function using the Power Monitoring Software.

19
18
7. Grasp the pull-tab and pull the battery module upwards. (FIG. 2) DO NOT
pull the battery module out by pulling on the battery wires.
8. Disconnect the battery negative (Black) wire. (FIG. 2)
9. Disconnect the battery positive (Red) wire and set the old battery module
aside.(FIG.2) Donotshortthebatterypositivewiretothebatterynegative
wire.
10.Verifyproper polarity. Connectthe battery positive (Red) wireto thebattery po-
sitive(Red) terminalon the newbattery module. (FIG 2)
BATTERYREPLACEMENT PROCEDURE
(QUALIFIEDSERVICEPERSONNELONLY)
PLEASE READ THE CAUTIONSAND WARNINGS BEFOREATTEMPTING
TO REPLACE THE BATTERYMODULE.
Hot-swappablebatteries meanthatthebattery modulecanbe replaced without
poweringdownthe whole UPS system.
NOTE: If there is a power interruption while replacing the hot-swappable
battery module, with the UPS on, the load will not be backed up. To hot-swap
thebatterymodule start with step number 6.
1. Turn off the equipment that is plugged into the output of the UPS.
2. Turn off the UPS.
3. Unplug the UPS'sAC power cord from theAC wall outlet.
4. Unplug the equipment from the output receptacles of theUPS.
5. Unplug all of the cables from the side panel of the UPS.
NOTE: No tools are required for removing or installing the battery door.
6. Grasp the battery door handle, slide the battery door outward, then lift up-
wards and set aside. (FIG. 1)
FIG. 1
CAUTION: The battery system can present a risk of electrical shock. These
batteries produce sufficient current to burn wire or tools very rapidly, produc-
ingmoltenmetal. Observetheseprecautions when replacing the batteries:
1. Remove watches, rings, or other metal objects.
2. Use handtoolswithinsulatedhandles.
3. Wear protective eye gear (goggles), rubber gloves and boots.
4. Do not lay tools or other metal parts on top of batteries.
5. Disconnect the charging source prior to connecting or disconnecting the
batteryterminals.
6. Determine if the battery is inadvertently grounded. If the battery is, remove
the source of the grounding. Contact with any part of a grounded battery
can result in an electrical shock. The likelihood of such shock will be redu-
ced, if such grounds are removed during installation and maintenance.
ATTENTION! Les batteries peuvent entraîner le risque de choc électrique.
Elles produisent suffisamment de courant pour brûler très rapidement des fils
ou outils, les causant à fondre. Prenez les précautions suivantes lors du
remplacementd'une batterie.
1. Retirez votremontre,baguesouautresobjets métalliques.
2. Utilisez des outils à main à poignées isolantes.
3. Portez des lunettes de protection, des gants en caoutchouc et des bottes.
4. Ne placez jamais des outilsou autresobjets en métalsur le dessusd'une
batterie.
5. Déconnectez lasourced'alimentationavantde brancher ou de débrancher
lesbornesd'une batterie.
6. Vérifiez si, par inadvertance, la batterie est toujours mise à la terre. Si
c'estlecas, supprimez la source de mise à terre. Lecontactavecn'importe
quelle partie d'une batterie mise à la terre peut causer un choc électrique.
La suppression de dispositifs de mise à terre pendant l'installation et
l'entretien réduit le risque de chocs électriques.
CAUTION: Replacethebatterieswiththesamenumberandtypeasoriginally
installed in the UPS. These batteries have pressure operated vents. These
UPSscontainsealednon-spillablemaintenance-freelead acid batteries.
ATTENTION! Remplacez les batteries par des batteries du même numéro et
typeque celles d'origine.Unebatteriede numéro ettypedifférentspeut causer
uneexplosion.Lesbatteries sontéquipéesdepurgeursactionnés parpression.
Lesonduleurs contiennent des batteries au plomb étanches etinversablesqui
ne requièrent aucun entretien.
BatteryModule
Part #
Model# EN750LCD
BM0068
EN900LCD

21
20
120VAC
Protection
WaveformType
Over-Current,Short-Circuit Protectedand LatchingShutdown
SimulatedSine Wave
Frequency 60Hz, +/-0.5Hz (unless synchronized to utility)
NominalVoltage
MaximumPower Capacity
6 ms Typical
>95%(Full Load)
ResettableCircuit Breaker
60 Hz, +/-6Hz
0- 150VAC
95- 140VAC
95- 140VAC
TransferTime
Efficiency(Line Mode)
InputProtection
FrequencyLimits
VoltageRange
AcceptableInput voltage
ModelNumber
SYSTEMSPECIFICATIONS
VoltageRange
Topology Standby, SimulatedSine Wave
OUTPUT NON-BATTERYOPERATION
INPUT
Numberof Phase Single (1∅2W +G)
NominalVoltage 120VAC
LowVoltageTransferPoint 95V resets to Utility Power at 99V or higher
HighVoltageTransferPoint 140V resets to Utility Power at 136V or lower
VoltageRegulation 120VAC: -20.8% - +16.7%
FrequencyRange 60Hz: 54 - 66Hz
OUTPUT BATTERYOPERATION
VoltageRegulation +/-5% (until Low Battery Warning)
OverloadCapacity AC Mode: 105% for 1-minute then shutdown, 115% Shutdown Immediately
EN900LCD
900VA
500W
REGULATORYCOMPLIANCE
SafetyandApprovals cTUVus (Conformsto UL17785thEdition& CSA22.2no. 107.3-
14 / R: 2014), FCC Class B, CE certified, RoHS2 (EU Directive
2011/65/EU &2015/863/EU)
EN750LCD
750VA
450W
DC Mode: 105% for 20-seconds then shutdown, 115% Shutdown Immediately
Chapter 8: Specifications
FIG. 2
11.Verify proper polarity. Connect the batterynegative (Black) wire to the battery
negative(Black) terminalon the newbattery module.
NOTE: Some sparking might occur this is normal.
12.Slide the new battery module into the UPS.
13.Reinstall thebattery door onthe UPS.
14.Properly dispose of the old battery module at an appropriate recycling fac-
ility or return them to the supplier in the packing material for the new batt-
ery module.
15.The UPS is now ready for the normal operation.
NOTE: If the UPS has a Weak/Bad BatteryAlarm after replacing the battery
module,a battery testmustbeperformed to cleartheWeak/BadBatteryAlarm.
A battery test can be performed by using the software or by disconnecting the
power cord from the wall outlet for 10-seconds and then reconnecting the
power cord back to the wall outlet.

23
22
BATTERYSYSTEM
TypicalRechargeTime
Typical BatteryLife 3 to 5 years. Environmental factors do affect battery life. High
temperatures, poor utility power, and frequent, short duration
discharges have a negative impact on battery life.
8-hours to 90% capacity from a full load discharge
BatteryType Sealed,Non-Spillable,MaintenanceFree,ValueRegulatedLeadAcid
Runtime:Half Load(minutes)
Runtime:Full Load (minutes)
SURGE PROTECTIONAND FILTERING
Audible Noise at 1 m (3 ft.)
NoiseFilter
Surgevoltage let-through(as a
percentageof anappliedANSI
C62.41 Cat.A +/-6 kV)
SurgeResponse Time
SurgeCurrent Capability
SurgeEnergy Rating 500J
0 ns (instantaneous) normal mode; <5 ns common mode
< 14%
>45dbnormal andcommon mode EMI/RFIsuppression
<45 dBA
10000Amps total(onetime8to 20uswaveform)
PHYSICAL
Weight - Net
Size - Net
L X W X H
Size - Shipping
L X W X H
Weight- Shipping
12.6 x 7.2 x 3.6"
320 x 183 x 92 mm
15.0 x 5.6 x 10.4"
382 x 143 x 263 mm
8.4 lbs
3.8 Kgs
9.0 lbs
4.1 Kgs
ENVIRONMENTAL
Operating/Storage Humidity 0- 95%Non-Condensing
Storage Elevation 0 to 15,000m (0 to +50,000 ft)
StorageTemperature -15 to +45°C (+5 to +113°F)
OperatingTemperature
7.7 lbs
3.5 Kgs
8.4 lbs
3.8 Kgs
3
11
3
11
Battery Module Part # BM0068
OperatingElevation 0 to 40°C (+32 to +104°F)
0 to 3000m (0 to +10,000 ft)
OutputReceptacles
NEMA 5-15P W/6 ft cord
PowerCord
5 - NEMA 5-15R Battery Backup & Surge
5- NEMA 5-15RSurge Only
ParaSystems,Inc.(ParaSystems)warrantsthisequipment,whenproperlyappliedand
operatedwithinspecifiedconditions,againstfaultymaterials(excludingthebatteries) or
workmanshipfor a period of three years from thedate of purchase. Para Systems Inc.
(Para Systems) warrants the batteries for a period of two years from the date of pur-
chase. Forequipment sites withinthe United Statesand Canada, thiswarranty covers
depot repair or replacement of defective equipment at the discretion of Para Systems.
Depotrepairwill be from the nearest authorized servicecenter. The customerpaysfor
shipping the product to Para Systems. Para Systems pays ground freight to ship the
product back to the customer. Replacement parts and warranty labor will be borne by
Para Systems. For equipment located outside of the United States and Canada, Para
Systems only covers faulty parts. Para Systems products that are depot repaired or
replaced pursuant to this warranty shall only be warranted for the unexpired portion of
the warranty applying to the original product. This warranty applies only to the original
purchaserwho must have properly registered the productwithin 10 daysof purchase.
Thewarranty shall bevoid if (a)the equipment isdamaged by thecustomer, isimprop-
erlyused, is subjected toan adverse operating environment,or is operatedoutside the
limitsofits electrical specifications; (b) theequipmentisrepaired or modified by anyone
otherthanPara Systems or Para Systemsapprovedpersonnel; or (c) hasbeenused in
amanner contrary to the product’s User's Manualor other writteninstructions.
Anytechnical advice furnished beforeor after deliveryin regard to useor application of
ParaSystems’equipmentisfurnishedwithoutchargeandonthebasisthat it represents
Para Systems’ best judgment under the circumstances, but it is used at the recipient’s
solerisk.
EXCEPTAS PROVIDED HEREIN, PARASYSTEMS MAKES NO WARRANTIES, EX-
PRESSEDORIMPLIED,INCLUDINGWARRANTIESOFMERCHANTABILITYANDFIT-
NESSFORAPARTICULARPURPOSE. Somestatesdo not permit limitationofimplied
warranties;therefore, the aforesaid limitation(s)may not applyto the purchaser.
EXCEPTAS PROVIDED ABOVE, IN NO EVENT WILL PARASYSTEMS BE LIABLE
FORDIRECT,INDIRECT, SPECIAL,INCIDENTAL,ORCONSEQUENTIALDAMAGES
ARISINGOUTOFTHEUSEOFTHISPRODUCT,EVEN IFADVISEDOFTHE POSSI-
BILITYOFSUCHDAMAGE. Specifically, Para Systems is not liable foranycosts,such
as; labor for on-site installation, on-site maintenance or on-site service, lost profits or
revenue,lossofequipment,lossof use of equipment, loss of software, lossofdata,cost
ofsubstitutes, claims by third parties, or otherwise. The soleand exclusive remedy for
breachof any warranty, expressed or implied, concerning ParaSystems’products and
theonly obligation ofPara Systems hereunder,shall be depot repair or replacement of
defective equipment, components, or parts; or, at Para Systems’ option, refund of the
purchase price or substitution with an equivalent replacement product. This warranty
givesyou specific legal rightsandyou may alsohaveother rights which varyfrom state
tostate.
No employee, salesman, or agent of Para Systems is authorized to add to or vary the
terms of this warranty.
Chapter 9: Limited Product Warranty

25
24
A1. DECLARATION OF CONFORMITY
Application of Council Directive(s): 2004/108/EC, 2006/95/EC, cTUVus (for
UL1778)
Standard(s) to which Conformity is declared: EN61000-3-2, EN61000-3-3,
EN62040-2, IEC61000-2-2 IEC61000-4-2, IEC61000-4-3, IEC61000-4-4,
IEC61000-4-5, IEC61000-4-6, IEC61000-4-8, IEEE C62.41 Category A1,
UL1778, CSA 22.2 no. 107.3-14 / R: 2014, FCC Class B
Manufacturer’s Name: Para Systems, Inc. (MINUTEMAN UPS)
Manufacturer’sAddress: 1455LeMayDrive
Carrollton,Texas 75007 USA
Type of Equipment: Uninterruptible Power Supplies (UPS)
Model No: EN750LCD, EN900LCD
I hereby declare that the equipment specified above conforms to the above
Directive(s).
Place:Carrollton,Texas, USA Date: September 1, 2016
RobertCalhoun
(Name) ManagerEngineering
(Position)
Year of Manufacture: Beginning September, 2016
Notes:
