4Mirka® Dust Extractor • 1230 M • 230 V / 100–120 V • PC & AFC
Quick reference
Operating elements
1Handle
2Accessory positions
3Container clamp
4Wheel
5Container
6Inlet fitting
7Switch
8Speed control
9Appliance socket
10 Filter cleaning button (Push & Clean)
11 Hose hook
12 Hose diameter setting
13 LED indicator
14 Inlet cap
The pictorial quick reference guide
The pictorial quick reference guide is designed to help you
when starting up, operating and storing the unit. The guide is
subdivided into four sections, which are represented by symbols:
Before starting
DO READ OPERATING INSTRUCTIONS BEFORE USE!
Control/Operation
AFlow rate and filter warning
BPC – Push & Clean filter cleaning system
CAFC– Auto Filter Cleaning system
DCable and hose storage
EHose insert & operations
FCase fastening accessory
Connecting electrical appliances
GPower tool adaption
Maintenance
HFilter bag replacement
IFilter replacement
JMotor cooling filter cleaning
KGaskets and float cleaning
3
