READ AND FOLLOW ALL SAFETY INSTRUCTIONS.
Any other use is considered as improper use. The manufacturer accepts no liability for any damage resulting from such
use. The risk for such use is borne solely by the user. Proper use also includes proper operation, servicing and repairs as
specified by the manufacturer.
For Dust Class L machines the following applies:
The appliance is suitable for picking up dry, non-flammable dust and liquids, hazardous dust with OEL (Occupational
Exposure Limit) values > 1 mg/m3.
Warning label for dust class L machines
Dust Class L (IEC 60335-2-69). Dust in this class has OEL values > 1 mg/m3. For machines intended for Dust Class L, the
filter material has been tested. The maximum degree of permeability is 1% and there is no special requirement for disposal.
For dust extractors, ensure adequate air change rate L, when the exhaust air is returned to the room. Observe national
regulations before use.
Technical data
AUEUMirka® Dust Extractor 1125 L
220 240 VAC220 240 VACMains Voltage
1200 W1200 WPower
1100 W2400 WConnected load for appliance socket
2300 W3600 WTotal connected load
5060Hz5060HzMains frequency
1016Fuse
IPX4IPX4Protection grade (moist, dust)
IIProtection class (electrical)
62 l/s62 l/sMax. airflow (l/s)*
222 m3/h222 m3/hMax. airflow (m3/h)*
131 CFM131 CFMMax. airflow (CFM)*
24.5 kPa24.5 kPaMax. vacuum (kPa)
240 hPa245 hPaMax. vacuum (hPa)
98 inH2O
98 inH2O
Max. vacuum (inH2O)
69 ±2 dB(A)69 ±2 dB(A)Sound pressure level LPA (IEC 60335-2-69)
61 ±2 dB(A)61 ±2 dB(A)Working sound level
2.5 m/s2
2.5 m/s2
Vibration ISO 5349 ah
10 kg (22.1 lbs)10 kg (22.1 lbs)Weight
LLDust class
2525Container capacity
* Measured at container. Observe applicable country-specific regulations regarding air change rate.
WARNINGS
•Do not use to pick up flammable or combustible liquids such as gasoline, or use in areas where they may be present.
•Operators shall be adequately instructed on the use of these machines
•The machine shall be disconnected from its power source during cleaning or maintenance and when replacing parts
or converting the machine to another function by removing the plug from the socket-outlet.
•Only use the socket outlet on the machine for purposes specified in the instructions.
10 Mirka® Dust Extractor 1125 L PC
en (original)
