Mitsubishi Electric GOT 1000 Series Instruction manual

GOT 1000
Graphic Operation Terminal
Connection Manual
(Ethernet connection with FXCPU)
MITSUBISHI ELECTRIC
MITSUBISHI ELECTRIC
Art. no:
SH(NA)-080719ENG
01102008
Version B
INDUSTRIAL AUTOMATION

A - 1
SAFETY PRECAUTIONS
(Always read these precautions before using this equipment.)
Before using this product, please read this manual and the relevant manuals introduced in this manual
carefully and pay full attention to safety to handle the product correctly.
The precautions given in this manual are concerned with this product.
In this manual, the safety precautions are ranked as "DANGER" and "CAUTION".
Note that the caution level may lead to a serious accident according to the circumstances.
Always follow the instructions of both levels because they are important to personal safety.
Please save this manual to make it accessible when required and always forward it to the end user.
[DESIGN PRECAUTIONS]
DANGER
Some failures of the GOT, communication unit or cable may keep the outputs on or off.
An external monitoring circuit should be provided to check for output signals which may lead to a
serious accident.
Not doing so can cause an accident due to false output or malfunction.
If a communication fault (including cable disconnection) occurs during monitoring on the GOT,
communication between the GOT and programmable controller CPU is suspended and the GOT
becomes inoperative.
For bus connection : The CPU becomes faulty and the GOT becomes inoperative.
For other than bus connection : The GOT becomes inoperative.
A system where the GOT is used should be configured to perform any significant operation to the
system by using the switches of a device other than the GOT on the assumption that a GOT
communication fault will occur.
Not doing so can cause an accident due to false output or malfunction.
Do not use the GOT as the warning device that may cause a serious accident.
An independent and redundant hardware or mechanical interlock is required to configure the device
that displays and outputs serious warning.
Failure to observe this instruction may result in an accident due to incorrect output or malfunction.
DANGER Indicates that incorrect handling may cause hazardous conditions,
resulting in death or severe injury.
CAUTION Indicates that incorrect handling may cause hazardous conditions,
resulting in medium or slight personal injury or physical damage.

A - 2
[DESIGN PRECAUTIONS]
[MOUNTING PRECAUTIONS]
DANGER
Incorrect operation of the touch switch(s) may lead to a serious accident if the GOT backlight is gone
out.
When the GOT backlight goes out, the POWER LED flickers (green/orange) and the display section
turns black and causes the monitor screen to appear blank, while the input of the touch switch(s)
remains active.
This may confuse an operator in thinking that the GOT is in "screensaver" mode, who then tries to
release the GOT from this mode by touching the display section, which may cause a touch switch to
operate.
Note that the following occurs on the GOT when the backlight goes out.
The POWER LED flickers (green/orange) and the monitor screen appears blank.
CAUTION
Do not bundle the control and communication cables with main-circuit, power or other wiring.
Run the above cables separately from such wiring and keep them a minimum of 100mm apart.
Not doing so noise can cause a malfunction.
DANGER
Be sure to shut off all phases of the external power supply used by the system before mounting or
removing the GOT to/from the panel.
Not doing so can cause the GOT to fail or malfunction.
Be sure to shut off all phases of the external power supply used by the system before mounting or
removing the communication unit, option function board or multi-color display board onto/from the GOT.
Not doing so can cause the unit to fail or malfunction.
Before mounting an optional function board or Multi-color display board, wear a static discharge wrist
strap to prevent the board from being damaged by static electricity.
CAUTION
Use the GOT in the environment that satisfies the general specifications described in this manual.
Not doing so can cause an electric shock, fire, malfunction or product damage or deterioration.
When mounting the GOT to the control panel, tighten the mounting screws in the specified torque
range.
Undertightening can cause the GOT to drop, short circuit or malfunction.
Overtightening can cause a drop, short circuit or malfunction due to the damage of the screws or the
GOT.

A - 3
[MOUNTING PRECAUTIONS]
[WIRING PRECAUTIONS]
CAUTION
When loading the communication unit to the GOT, fit it to the connection interface of the GOT and
tighten the mounting screws in the specified torque range.
Overtightening can cause a drop, failure or malfunction due to the damage of the screws or unit.
When mounting the multi-color display board onto the GOT, tighten the mounting screws within the
specified torque range.
Loose tightening may cause the unit and/or GOT to malfunction due to poor contact.
Overtightening may damage the screws, unit and/or GOT; they might malfunction.
When mounting an optional function board onto the GT15 , fully connect it to the connector until
you hear a click.
When mounting an optional function board onto the GT11 , fully connect it to the connector.
Push the multi-color display board onto the corresponding connector so that it will be secured firmly.
When inserting a CF card into the GOT, push it into the insertion slot until the CF card eject button
will pop out.
Failure to do so may cause a malfunction due to poor contact.
When inserting/removing a CF card into/from the GOT, turn the CF card access switch off in
advance.
Failure to do so may corrupt data within the CF card.
When removing a CF card from the GOT, make sure to support the CF card by hand, as it may pop
out.
Failure to do so may cause the CF card to drop from the GOT and break.
DANGER
Be sure to shut off all phases of the external power supply used by the system before wiring.
Failure to do so may result in an electric shock, product damage or malfunctions.

A - 4
[WIRING PRECAUTIONS]
CAUTION
Always ground the FG terminal, LG terminal, and protective ground terminal of the GOT power to the
protective ground conductors dedicated to the GOT.
Not doing so may cause an electric shock or malfunction.
Be sure to tighten any unused terminal screws with a torque of 0.5 to 0.8N•m.
Failure to do so may cause a short circuit due to contact with a solderless terminal.
Use applicable solderless terminals and tighten them with the specified torque.
If any solderless spade terminal is used, it may be disconnected when the terminal screw comes
loose, resulting in failure.
Correctly wire the GOT power supply section after confirming the rated voltage and terminal
arrangement of the product.
Not doing so can cause a fire or failure.
Tighten the terminal screws of the GOT power supply section in the specified torque range.
Undertightening can cause a short circuit or malfunction.
Overtightening can cause a short circuit or malfunction due to the damage of the screws or the GOT.
Exercise care to avoid foreign matter such as chips and wire offcuts entering the GOT. Not doing so
can cause a fire, failure or malfunction.
Plug the bus connection cable by inserting it into the connector of the connected unit until it "clicks".
After plugging, check that it has been inserted snugly.
Not doing so can cause a malfunction due to a contact fault.
Plug the communication cable into the connector of the connected unit and tighten the mounting and
terminal screws in the specified torque range.
Undertightening can cause a short circuit or malfunction.
Overtightening can cause a short circuit or malfunction due to the damage of the screws or unit.

A - 5
[TEST OPERATION PRECAUTIONS]
[STARTUP/MAINTENANCE PRECAUTIONS]
DANGER
Before performing the test operations of the user creation monitor screen (such as turning ON or
OFF bit device, changing the word device current value, changing the settings or current values of
the timer or counter, and changing the buffer memory current value), read through the manual
carefully and make yourself familiar with the operation method.
During test operation, never change the data of the devices which are used to perform significant
operation for the system.
False output or malfunction can cause an accident.
DANGER
When power is on, do not touch the terminals.
Doing so can cause an electric shock or malfunction.
Connect the battery correctly.
Do not discharge, disassemble, heat, short, solder or throw the battery into the fire.
Incorrect handling may cause the battery to generate heat, burst or take fire, resulting in injuries or
fires
Before starting cleaning or terminal screw retightening, always switch off the power externally in all
phases.
Not switching the power off in all phases can cause a unit failure or malfunction.
Undertightening can cause a short circuit or malfunction.
Overtightening can cause a short circuit or malfunction due to the damage of the screws or unit.

A - 6
[STARTUP/MAINTENANCE PRECAUTIONS]
[BACKLIGHT REPLACEMENT PRECAUTIONS]
CAUTION
Do not disassemble or modify the unit.
Doing so can cause a failure, malfunction, injury or fire.
Do not touch the conductive and electronic parts of the unit directly.
Doing so can cause a unit malfunction or failure.
The cables connected to the unit must be run in ducts or clamped.
Not doing so can cause the unit or cable to be damaged due to the dangling, motion or accidental
pulling of the cables or can cause a malfunction due to a cable connection fault.
When unplugging the cable connected to the unit, do not hold and pull the cable portion.
Doing so can cause the unit or cable to be damaged or can cause a malfunction due to a cable
connection fault.
Do not drop or apply strong impact to the unit.
Doing so may damage the unit.
Do not drop or give an impact to the battery mounted to the unit.
Doing so may damage the battery, causing the battery fluid to leak inside the battery.
If the battery is dropped or given an impact, dispose of it without using.
Before touching the unit, always touch grounded metal, etc. to discharge static electricity from
human body, etc.
Not doing so can cause the unit to fail or malfunction.
DANGER
Be sure to shut off all phases of the external power supply of the GOT (and the programmable
controller CPU in the case of a bus topology) and remove the GOT from the control panel before
replacing the backlight (when using the GOT with the backlight replaceable by the user).
Not doing so can cause an electric shock.
Replacing a backlight without removing the GOT from the control panel can cause the backlight or
control panel to drop, resulting in an injury.
CAUTION
Wear gloves for the backlight replacement when using the GOT with the backlight replaceable by the
user.
Not doing so can cause an injury.
Before replacing a backlight, allow 5 minutes or more after turning off the GOT when using the GOT
with the backlight replaceable by the user.
Not doing so can cause a burn from heat of the backlight.

A - 7
[DISPOSAL PRECAUTIONS]
[TRANSPORTATION PRECAUTIONS]
CAUTION
When disposing of the product, handle it as industrial waste.
CAUTION
When transporting lithium batteries, make sure to treat them based on the transport regulations.
(For details on models subject to restrictions, refer to the User's Manual for the GOT you are using.)
Make sure to transport the GOT main unit and/or relevant unit(s) in the manner they will not be
exposed to the impact exceeding the impact resistance described in the general specifications of the
User's Manual, as they are precision devices.
Failure to do so may cause the unit to fail.
Check if the unit operates correctly after transportation.

A - 8
REVISIONS
* The manual number is given on the bottom left of the back cover.
© 2007 MITSUBISHI ELECTRIC CORPORATION
Print Date * Manual Number Revision
Jun., 2007 SH(NA)-080719ENG-A First edition
Oct., 2008 SH(NA)-080719ENG-B Compatible with GT Designer2 Version2.90U
Section 1.1, 2.1.1, 2.2.3, 2.2.5, 2.2.6
Section 2.2.1, 2.2.2, 2.2.4, 2.2.7
This manual confers no industrial property rights or any rights of any other kind, nor does it confer any patent licenses.
Mitsubishi Electric Corporation cannot be held responsible for any problems involving industrial property rights which may
occur as a result of using the contents noted in this manual.
Partial addition
Partial correction

A - 9
SAFETY PRECAUTIONS .................................................................................................................................A - 1
REVISIONS.......................................................................................................................................................A - 8
INTRODUCTION...............................................................................................................................................A - 9
CONTENTS ......................................................................................................................................................A - 9
ABOUT MANUALS .........................................................................................................................................A - 10
ABBREVIATIONS AND GENERIC TERMS.................................................................................................... A - 11
1. OVERVIEW 1 - 1 to 1 - 4
1.1 Ethernet Connection with FXCPU 1 - 4
2. ETHERNET CONNECTION WITH FXCPU 2 - 1 to 2 - 30
2.1 System Configuration 2 - 2
2.1.1 Connecting to FXCPU (FX3U).............................................................................................. 2 - 2
2.2 Preparatory Procedures for Monitoring 2 - 4
2.2.1 Installing OS on GOT ........................................................................................................... 2 - 5
2.2.2 Checking OS installation on GOT......................................................................................... 2 - 6
2.2.3 Setting communication interface (Communication settings)................................................. 2 - 7
2.2.4 Downloading project data ...................................................................................................2-14
2.2.5 Mounting communication unit and connecting cable.......................................................... 2 - 15
2.2.6 Checking if GOT recognizes controllers ............................................................................. 2 - 16
2.2.7 Checking if GOT correctly monitors controllers .................................................................. 2 - 19
2.3 Programmable Controller Settings 2 - 23
2.4 Precautions 2 - 29
2.5 List of Functions Added by Version Upgrade 2 - 30
INTRODUCTION
Thank you for choosing Mitsubishi Graphic Operation Terminal (Mitsubishi GOT).
Read this manual and make sure you understand the functions and performance of the GOT thoroughly
in advance to ensure correct use.
CONTENTS

A - 10
ABOUT MANUALS
The following manuals are also related to this product.
In necessary, order them by quoting the details in the tables below.
The manual in PDF-format is included in the GT Works2 and GT Designer2 products.
Related Manuals
Manual Name Manual Number
(Model Code)
GT16 User's Manual
- Describes the GT16 hardware-relevant contents, including the specifications, part names, mounting, power
supply wiring, external dimensions, and option devices.
- Describes the GT16 functions, including the utility.
(Sold separately)
SH-080778ENG
(1D7M88)
GT15 User's Manual
- Describes the GT15 hardware-relevant contents, including the specifications, part names, mounting, power
supply wiring, external dimensions, and option devices.
- Describes the GT15 functions, including the utility.
(Sold separately)
SH-080528ENG
(1D7M23)
GT11 User's Manual
- Describes the GT11 hardware-relevant contents, including the specifications, part names, mounting, power
supply wiring, external dimensions, and option devices.
- Describes the GT11 functions, including the utility.
(Sold separately)
JY997D17501
(09R815)
GT10 User's Manual
- Describes the GT10 hardware-relevant contents, including the specifications, part names, mounting, power
supply wiring, external dimensions, and option devices.
- Describes the GT10 functions, including the utility.
(Sold separately)
JY997D24701
(09R819)
Handy GOT User's Manual
- Describes the Handy GOT hardware-relevant contents, including the system configurations, specifications, part
names, mounting, power supply wiring, external dimensions, and option devices.
- Describes the Handy GOT functions, including the utility, and how to make cables.
(Sold separately)
JY997D20101
(09R817)
GT SoftGOT1000 Version2 Operating Manual
Describes the screen configuration, functions and using method of GT SoftGOT1000.
(Sold separately)
SH-080602ENG
(1D7M48)
GT Designer2 Version2 Basic Operation/Data Transfer Manual (For GOT1000 Series)
Describes methods of the GT Designer2 installation operation, basic operation for drawing and transmitting data
to GOT1000 series
(Sold separately)
SH-080529ENG
(1D7M24)
GT Designer2 Version2 Screen Design Manual (For GOT1000 Series) (1/3, 2/3, 3/3)
Describes specifications and settings of each object function applicable to GOT1000 series.
(Sold separately)
SH-080530ENG
(1D7M25)
GOT1000 Series Gateway Functions Manual
Describes specifications, system comfigurations and setting method of the gateway function.
(Sold separately)
SH-080545ENG
(1D7M33)
GOT1000 Series MES Interface Function Manual
Describes the specifications, system configurations, and setting method of GT MES interface function.
(Sold separately)
SH-080654ENG
(1D7M63)

A - 11
ABBREVIATIONS AND GENERIC TERMS
Abbreviations and generic terms used in this manual are as follows:
GOT
Abbreviations and generic terms Description
GOT1000 Series
GT SoftGOT1000 Abbreviation of GT SoftGOT1000
GT1695 GT1695M-X Abbreviation of GT1695M-XTBA, GT1695M-XTBD
GT1685 GT1685M-S Abbreviation of GT1685M-STBA, GT1685M-STBD
GT16 , GT16 Abbreviation of GT1695, GT1685
GT1595 GT1595-X Abbreviation of GT1595-XTBA, GT1595-XTBD
GT1585
GT1585V-S Abbreviation of GT1585V-STBA, GT1585V-STBD
GT1585-S Abbreviation of GT1585-STBA, GT1585-STBD
GT157
GT1575V-S Abbreviation of GT1575V-STBA, GT1575V-STBD
GT1575-S Abbreviation of GT1575-STBA, GT1575-STBD
GT1575-V Abbreviation of GT1575-VTBA, GT1575-VTBD
GT1575-VN Abbreviation of GT1575-VNBA, GT1575-VNBD
GT1572-VN Abbreviation of GT1572-VNBA, GT1572-VNBD
GT156
GT1565-V Abbreviation of GT1565-VTBA, GT1565-VTBD
GT1562-VN Abbreviation of GT1562-VNBA, GT1562-VNBD
GT155
GT1555-V Abbreviation of GT1555-VTBD
GT1555-Q Abbreviation of GT1555-QTBD, GT1555-QSBD
GT1550-Q Abbreviation of GT1550-QLBD
GT15 , GT15 Abbreviation of GT1595, GT1585, GT157 , GT156 , GT155
GT115
GT1155-Q Abbreviation of GT1155-QTBDQ, GT1155-QSBDQ, GT1155-QTBDA, GT1155-QSBDA,
GT1155-QTBD, GT1155-QSBD
GT1150-Q Abbreviation of GT1150-QLBDQ, GT1150-QLBDA, GT1150-QLBD
Handy
GOT
GT1155HS-Q Abbreviation of GT1155HS-QSBD
GT1150HS-Q Abbreviation of GT1150HS-QLBD
GT11 , GT11 Abbreviation of GT115 , GT11 Handy GOT
GT105
GT1055-Q Abbreviation of GT1055-QSBD
GT1050-Q Abbreviation of GT1050-QBBD
GT1030 Abbreviation of GT1030-LBD, GT1030-LBD2, GT1030-LBDW, GT1030-LBDW2
GT1020 Abbreviation of GT1020-LBD, GT1020-LBD2, GT1020-LBL, GT1020-LBDW,
GT1020-LBDW2, GT1020-LBLW
GT10 , GT10 Abbreviation of GT105 , GT1030, GT1020
GOT900 Series Abbreviation of GOT-A900 series, GOT-F900 series
GOT800 Series Abbreviation of GOT-800 series

A - 12
Communication unit
*1 A9GT-QJ71LP23 + GT15-75IF900 set
*2 A9GT-QJ71BR13 + GT15-75IF900 set
*3 A8GT-J61BT13 + GT15-75IF900 set
Option unit
*1 GT15-CFEX + GT15-CFEXIF + GT15-C08CF set.
Abbreviations and generic terms Description
Bus connection unit GT15-QBUS, GT15-QBUS2, GT15-ABUS, GT15-ABUS2,
GT15-75QBUSL, GT15-75QBUS2L, GT15-75ABUSL, GT15-75ABUS2L
Serial communication unit GT15-RS2-9P, GT15-RS4-9S, GT15-RS4-TE
RS-422 conversion unit GT15-RS2T4-9P, GT15-RS2T4-25P
Ethernet communication unit GT15-J71E71-100
MELSECNET/H communication unit GT15-J71LP23-25, GT15-J71BR13
MELSECNET/10 communication unit GT15-75J71LP23-Z*1, GT15-75J71BR13-Z*2
CC-Link IE controller network communication
unit GT15-J71GP23-SX
CC-Link communication unit GT15-J61BT13, GT15-75J61BT13-Z*3
Interface converter unit GT15-75IF900
Abbreviations and generic terms Description
Printer unit GT15-PRN
Video/RGB unit
Video input unit GT16M-V4, GT15V-75V4
RGB input unit GT16M-R2, GT15V-75R1
Video/RGB input unit GT16M-V4R1, GT15V-75V4R1
RGB output unit GT16M-ROUT, GT15V-75ROUT
Multimedia unit GT16M-MMR
CF card unit GT15-CFCD
CF card extension unit*1 GT15-CFEX-C08SET
External I/O unit GT15-DIO, GT15-DIOR
Sound output unit GT15-SOUT

A - 13
Option
Software
Abbreviations and generic terms Description
Memory card CF card GT05-MEM-16MC, GT05-MEM-32MC, GT05-MEM-64MC, GT05-MEM-128MC,
GT05-MEM-256MC
Memory card adaptor GT05-MEM-ADPC
Option function board GT16-MESB, GT15-FNB, GT15-QFNB, GT15-QFNB16M,
GT15-QFNB32M, GT15-QFNB48M, GT15-MESB48M, GT11-50FNB
Battery GT15-BAT, GT11-50BAT
Protective Sheet
GT16-90PSCB, GT16-90PSGB, GT16-90PSCW, GT16-90PSGW,
GT16-80PSCB, GT16-80PSGB, GT16-80PSCW, GT16-80PSGW,
GT15-90PSCB, GT15-90PSGB, GT15-90PSCW, GT15-90PSGW,
GT15-80PSCB, GT15-80PSGB, GT15-80PSCW, GT15-80PSGW,
GT15-70PSCB, GT15-70PSGB, GT15-70PSCW, GT15-70PSGW,
GT15-60PSCB, GT15-60PSGB, GT15-60PSCW, GT15-60PSGW,
GT15-50PSCB, GT15-50PSGB, GT15-50PSCW, GT15-50PSGW,
GT11-50PSCB, GT11-50PSGB, GT11-50PSCW, GT11-50PSGW,
GT11H-50PSC,
GT10-50PSCB, GT10-50PSGB, GT10-50PSCW, GT10-50PSGW,
GT10-30PSCB, GT10-30PSGB, GT10-30PSCW, GT10-30PSGW,
GT10-20PSCB, GT10-20PSGB, GT10-20PSCW, GT10-20PSGW
Protective cover for oil GT05-90PCO, GT05-80PCO, GT05-70PCO, GT05-60PCO,
GT05-50PCO
USB environmental protection cover GT16-UCOV, GT15-UCOV, GT11-50UCOV
Stand GT15-90STAND, GT15-80STAND, GT15-70STAND, A9GT-50STAND,
GT05-50STAND
Attachment GT15-70ATT-98, GT15-70ATT-87, GT15-60ATT-97, GT15-60ATT-96,
GT15-60ATT-87, GT15-60ATT-77, GT15-50ATT-95W, GT15-50ATT-85
Backlight
GT16-90XLTT, GT16-80SLTT, GT15-90XLTT, GT15-80SLTT,
GT15-70SLTT, GT15-70VLTT, GT15-70VLTN, GT15-60VLTT,
GT15-60VLTN
Multi-color display board GT15-XHNB, GT15-VHNB
Connector conversion box GT11H-CNB-37S
Emergency stop sw guard cover GT11H-50ESCOV
Memory loader GT10-LDR
Memory board GT10-50FMB
Abbreviations and generic terms Description
GT Works2 Version SW D5C-GTWK2-E, SW D5C-GTWK2-EV
GT Designer2 Version SW D5C-GTD2-E, SW D5C-GTD2-EV
GT Designer2 Abbreviation of screen drawing software GT Designer2 for GOT1000/GOT900 series
GT Converter2 Abbreviation of data conversion software GT Converter2 for GOT1000/GOT900 series
GT Simulator2 Abbreviation of screen simulator GT Simulator 2 for GOT1000 / GOT900 series
GT SoftGOT1000 Abbreviation of monitoring software GT SoftGOT1000
GT SoftGOT2 Abbreviation of monitoring software GT SoftGOT2
GX Developer Abbreviation of SW D5C-GPPW-E(-EV)/SW D5F-GPPW-E type software package
GX Simulator Abbreviation of SW D5C-LLT-E(-EV) type ladder logic test tool function software packages
(SW5D5C-LLT (-EV) or later versions)
Document Converter Abbreviation of document data conversion software Document Converter for GOT1000 series
PX Developer Abbreviation of SW D5C-FBDQ-E type FBD software package for process control

A - 14
License key (for GT SoftGOT1000)
License key (for GT SoftGOT2)
Others
Abbreviations and generic terms Description
License GT15-SGTKEY-U, GT15-SGTKEY-P
Abbreviations and generic terms Description
License key A9GTSOFT-LKEY-P (For DOS/V PC)
License key FD SW5D5F-SGLKEY-J (For PC CPU module)
Abbreviations and generic terms Description
OMRON PLC Abbreviation of PLC manufactured by OMRON Corporation
KEYENCE PLC Abbreviation of PLC manufactured by KEYENCE CORPORATION
KOYO EI PLC Abbreviation of PLC manufactured by KOYO ELECTRONICS INDUSTRIES CO., LTD.
SHARP PLC Abbreviation of PLC manufactured by Sharp Corporation
JTEKT PLC Abbreviation of PLC manufactured by JTEKT Corporation
TOSHIBA PLC Abbreviation of PLC manufactured by TOSHIBA CORPORATION
TOSHIBA MACHINE PLC Abbreviation of PLC manufactured by TOSHIBA MACHINE CO., LTD.
HITACHI IES PLC Abbreviation of PLC manufactured by Hitachi Industrial Equipment Systems Co., Ltd.
HITACHI PLC Abbreviation of PLC manufactured by Hitachi, Ltd.
FUJI FA PLC Abbreviation of PLC manufactured by Fuji Electric FA Components & Systems Co., Ltd.
MATSUSHITA PLC Abbreviation of PLC manufactured by Matsushita Electric Works, Ltd.
YASKAWA PLC Abbreviation of PLC manufactured by YASKAWA Electric Corporation
YOKOGAWA PLC Abbreviation of PLC manufactured by Yokogawa Electric Corporation
ALLEN-BRADLEY PLC Abbreviation of Allen-Bradley PLC manufactured by Rockwell Automation, Inc.
GE FANUC PLC Abbreviation of PLC manufactured by GE Fanuc Automation Corporation
LS IS PLC Abbreviation of PLC manufactured by LS Industrial Systems Co., Ltd.
SCHNEIDER PLC Abbreviation of PLC manufactured by Schneider Electric SA
SIEMENS PLC Abbreviation of PLC manufactured by Siemens AG
Temperature
controller
OMRON temperature
controller Abbreviation of temperature controller manufactured by OMRON Corporation
SHINKO indicating
controller Abbreviation of temperature controller manufactured by Shinko Technos Co., Ltd.
CHINO controller Abbreviation of temperature controller manufactured by CHINO CORPORATION
FUJI SYS temperature
controller Abbreviation of temperature controller manufactured by Fuji Electric Systems Co., Ltd.
YAMATAKE temperature
controller Abbreviation of temperature controller manufactured by Yamatake Corporation
YOKOGAWA temperature
controller Abbreviation of temperature controller manufactured by Yokogawa Electric Corporation
RKC temperature
controller Abbreviation of temperature controller manufactured by RKC INSTRUMENT INC.
PC CPU module Abbreviation of PC CPU Unit manufactured by CONTEC CO., LTD
GOT (server) Abbreviation of GOTs that use the server function
GOT (client) Abbreviation of GOTs that use the client function
Windows font Abbreviation of TrueType font and OpenType font available for Windows
(Differs from the True Type fonts settable with GT Designer2)
Intelligent function module Indicates the modules other than the PLC CPU, power supply module and I/O module that are
mounted to the base unit.
MODBUS /TCP Generic term for the protocol designed to use MODBUS protocol messages on a TCP/IP
network.

A - 15
HOW TO READ THIS MANUAL
1About each of functions
This manual includes information of GT Designer2 Version2.90U.
For additional functions of upgraded version, refer to the List of functions added by version upgrade.
2Symbols
Following symbols are used in this manual.
*Since the above page was created for explanation purpose, it differs from the actual page
Refers to a button displayed on the
computer screen or the GOT screen,
or a key of thecomputer keyboard.
Refers to an item displayed on the
computer screen or the GOT screen.
Refers to the information
required.
Refers to information useful
for operation.
Refers to the supplementary
explanations for reference.
Indicates the items in which the detailed
explanation is described (manual, chapter,
section, item of the manual).
Menu and items are differentiated with
parentheses.
:
:
Indicates the operation steps.
. . . .
Remark
Applicable model name
Connectable model name
Not connectable model name
Shows GT15.
Shows GT11 (BUS).
Shows GT11 (SERIAL).
Shows GT11.
Shows GT10(input power supply : 24V).
Shows GT10(input power supply : 5V).
Shows GT10.
Shows GT16.
Shows GT105 .

A - 16
MEMO

1 - 1
1
1
OVERVIEW
2
ETHERNET CONNECTION WITH FXCPU
OVERVIEW
This manual describes the specifications, system
configuration, setting method, connection cables, and
others for connecting the GOT to the FXCPU via the
Ethernet connection.
For applying the setting examples in this manual to the
actual system, make sure that the target system has no
troubles on the control.
1.1 Ethernet Connection with FXCPU . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . page 1-4
This section describes the connections and functions
supported by GOT1000 series.
Check the overview and others of the connection type in
this section.
Devices and access range applicable to FXCPU
For details on devices and access range applicable to the FXCPU, refer to the
following manual.
GT Designer2 Version Screen Design Manual
(2.9.2 Device range available for GOT1000 series)

1 - 2
1Relevant Manuals
The following manuals are available for GOT1000 series.
Refer to each manual suitable for the intended purpose.
The following manuals describe that the GOT cannot connect to the FXCPU (FX3U) via the Ethernet
connection because the manuals are written for commercially available products.
For referring to each manual, read the manuals so that the GOT can connect to the FXCPU (FX3U) via
the Ethernet connection.
(1) Installing software Drawing Data transfer
For operations from creating project data to transferring data to GOT, refer to the following
manuals.
*1 GT Works2 and GT Designer2 include the manual in PDF format.
Purpose
GT Designer2 Version
Basic Operation/
Data Transfer Manual*1
GT Designer2 Version
Screen Design Manual*1
Installing product on personal computer
Creating projects
Creating screens
Drawing figures
Making common settings
Placing/setting objects
Transferring data to GOT
Detailed
Detailed
Detailed
Detailed
Overview
Detailed
Overview
Detailed
Detailed
